Restart Your Sitecore Content Management (CM) and Content Delivery (CD) Instances using Custom Events

05/24/2020 18:52 / Leave a comment

Last Friday, I had worked on a PowerShell script which is executed by clicking a custom button in the Sitecore Content Editor ribbon using the Content Editor Ribbon integration point offered through Sitecore PowerShell Extensions (SPE) in a UAT environment. This UAT environment has separate Content Management (CM) and Content Delivery (CD) Sitecore instances on two different servers. The script updates some records in an external datasource (data not in Sitecore) but its data is cached in the Sitecore instances outside of the stand Sitecore caching framework. In order to see these updates on the sites which live on these Sitecore instances , I needed a programmatic way to restart all Sitecore instances in the UAT environment I had built this solution for, and the following solution reflects what I had worked on to accomplish this spanning Friday until today — this post defines two custom events in Sitecore — just so I could get this out as soon as possible as it may help you understand custom events, and maybe even help you do something similar to what I am doing here.

I do want to caution you on using code as follows in a production environment — this could cause disruption to your production CDs which are live to the public; be sure to take your CD servers out of a load-balancer before restarting the Sitecore instance on them as you don’t want people showing up to your door with pitchforks and torches asking why production had been down for a bit.

I’ve also incorporated the concept of Sitecore configuration-driven feature toggles which I had discussed in a previous blog post where I had altered the appearance of the Sitecore content tree using a pipeline-backed MasterDataView, and will be repurposing code from that post here — I strongly suggest reading that post to understand the approach being used for this post as I will not discuss much how this works on this post.

Moreover, I have used numerous Configuration Objects sourced from the Sitecore IoC container in this post which I had discuss in another previous post; you might also want to have a read of that post before proceeding in order to understand why I am decorating some classes on this post with the [ServiceConfigObject] attribute.

I first defined the following Configuration Object which will live in the Sitecore IoC container:

using Foundation.DependencyInjection;
using Foundation.DependencyInjection.Enums;
using Foundation.Kernel.Services.FeatureToggle;

namespace Foundation.Kernel.Models.RestartServer
{
	[ServiceConfigObject(ConfigPath = "moduleSettings/foundation/kernel/restartServerSettings", Lifetime = Lifetime.Singleton)]
	public class RestartServerSettings : IFeatureToggleable
	{
		public bool Enabled { get; set; }
	}
}

This Configuration Object will act is the main feature toggle to turn the entire feature on/off based on the Enabled property’s value from Sitecore configuration (see the Sitecore patch configuration file towards the bottom of this post).

I then created the following interface which will ascertain when the entire feature should be turned on/off at a global level, or at an individual piece of functionality’s level:

using Foundation.Kernel.Services.FeatureToggle;

namespace Foundation.Kernel.Services.RestartServer
{
	public interface IRestartServerFeatureToggleService
	{
		bool IsFeatureEnabled();

		bool IsEnabled(IFeatureToggleable toggleable);
	}
}

The following is the implementation of the interface above.

using Foundation.Kernel.Models.RestartServer;
using Foundation.Kernel.Services.FeatureToggle;

namespace Foundation.Kernel.Services.RestartServer
{
	public class RestartServerFeatureToggleService : IRestartServerFeatureToggleService
	{
		private readonly RestartServerSettings _settings;
		private readonly IFeatureToggleService _featureToggleService;

		public RestartServerFeatureToggleService(RestartServerSettings settings, IFeatureToggleService featureToggleService)
		{
			_settings = settings;
			_featureToggleService = featureToggleService;
		}

		public bool IsEnabled(IFeatureToggleable toggleable) => _featureToggleService.IsEnabled(_settings, toggleable);

		public bool IsFeatureEnabled() => _featureToggleService.IsEnabled(_settings);
	}
}

I won’t explain much here as I had talked about feature toggles on a previous configuration-driven post; I suggest reading that to understand this pattern.

Now that we have our feature toggle magic defined above, let’s dive into the code which defines and handles custom events which do the actual restarting of the Sitecore instances.

I created the following Config Object to hold log messaging formatted strings which we will use when writing to the Sitecore log when restarting Sitecore instances:

using Foundation.DependencyInjection;
using Foundation.DependencyInjection.Enums;

namespace Foundation.Kernel.Models.RestartServer.Events
{
	[ServiceConfigObject(ConfigPath = "moduleSettings/foundation/kernel/restartServerEventHandlerSettings", Lifetime = Lifetime.Singleton)]
	public class RestartServerEventHandlerSettings
	{
		public string RestartServerLogMessageFormat { get; set; }

		public string RestartServerRemoteLogMessageFormat { get; set; }
	}
}

We need a way to identify the Sitecore instance we are on in order to determine if the Sitecore instance needs to be restarted, and also when logging information that a restart is happening on that instance. The following Config Object will provide the name of a Sitecore setting which holds thie identifier for the Sitecore instance we are on:

using Foundation.DependencyInjection;
using Foundation.DependencyInjection.Enums;

namespace Foundation.Kernel.Models.Server
{
	[ServiceConfigObject(ConfigPath = "moduleSettings/foundation/kernel/serverServiceSettings", Lifetime = Lifetime.Singleton)]
	public class ServerServiceSettings
	{
		public string InstanceNameSetting { get; set; }
	}
}

The following interface/implementation class will provide the name of the Sitecore instance we are on:

namespace Foundation.Kernel.Services.Server
{
	public interface IServerService
	{
		string GetCurrentServerName();
	}
}

Here’s the implementation of the interface above:

using Sitecore.Abstractions;

using Foundation.Kernel.Models.Server;

namespace Foundation.Kernel.Services.Server
{
	public class ServerService : IServerService
	{
		private readonly ServerServiceSettings _settings;
		private readonly BaseSettings _settingsProvider;

		public ServerService(ServerServiceSettings settings, BaseSettings settingsProvider)
		{
			_settings = settings;
			_settingsProvider = settingsProvider;
		}

		public string GetCurrentServerName() => GetSetting(GetInstanceNameSetting());

		protected virtual string GetInstanceNameSetting() => _settings.InstanceNameSetting;

		protected virtual string GetSetting(string settingName) => _settingsProvider.GetSetting(settingName);
	}
}

The class above consumes the ServerServiceSettings config object then uses the BaseSettings service to get the name of the Sitecore instance based on the value in the setting, and returns it to the caller. There’s really nothing more to it.

Back in 2014, I had written a post on restarting your Sitecore instance using a custom FileWatcher, and in that post I had used the RestartServer() method on the Sitecore.Install.Installer class in Sitecore.Kernel. I will be using this same class but backed by a service class. Here is the interface of that service class:

namespace Foundation.Kernel.Services.Installer
{
	public interface IInstallerService
	{
		void RestartServer();
	}
}

The following implements the interface above:

namespace Foundation.Kernel.Services.Installer
{
	public class InstallerService : IInstallerService
	{
		public void RestartServer() => Sitecore.Install.Installer.RestartServer();
	}
}

The class above just calls the RestartServer() method on the Sitecore.Install.Installer class; ultimately this just does a “touch” on your Web.config to recycle your Sitecore instance.

Like all good Sitecore custom events, we need a custom EventArgs class — well, you don’t really need one if you aren’t passing any data beyond what lives on the System.EventArgs class but I’m sure you will seldom come across such a scenario 😉 — so I defined the following class to be just that class:

using System;
using System.Collections.Generic;

using Sitecore.Events;

namespace Foundation.Kernel.Models.RestartServer.Events
{
	[Serializable]
	public class RestartServerEventArgs : EventArgs, IPassNativeEventArgs
	{
		public List<string> ServerNames { get; protected set; }

		public RestartServerEventArgs(List<string> serverNames)
		{
			ServerNames = serverNames;
		}
	}
}

We will be passing a List of server names just in case there are multiple servers we would like to reboot simultaneously.

Now it’s time to create the event handlers. I created the following abstract class for my two event handler classes to have a centralized place for most of this logic:

using System;
using System.Linq;

using Sitecore.Abstractions;

using Foundation.Kernel.Models.RestartServer.Events;
using Foundation.Kernel.Services.Installer;
using Foundation.Kernel.Services.Server;
using Foundation.Kernel.Services.RestartServer;
using Foundation.Kernel.Services.FeatureToggle;

namespace Foundation.Kernel.Events.RestartServer
{
	public abstract class BaseRestartServerEventHandler : IFeatureToggleable
	{
		private readonly RestartServerEventHandlerSettings _settings;
		private readonly IRestartServerFeatureToggleService _restartServerFeatureToggleService;
		private readonly IServerService _serverService;
		private readonly IInstallerService _installerService;
		private readonly BaseLog _log;

		public bool Enabled { get; set; }

		public BaseRestartServerEventHandler(RestartServerEventHandlerSettings settings, IRestartServerFeatureToggleService restartServerFeatureToggleService, IServerService serverService,  IInstallerService installerService, BaseLog log)
		{
			_settings = settings;
			_restartServerFeatureToggleService = restartServerFeatureToggleService;
			_serverService = serverService;
			_installerService = installerService;
			_log = log;
		}

		protected void ExecuteRestart(object sender, EventArgs args)
		{
			if(!IsEnabled())
			{
				return;
			}

			RestartServerEventArgs restartServerArgs = GetArguments<RestartServerEventArgs>(args);
			if (!ShouldRestartServer(restartServerArgs))
			{
				return;
			}

			string restartLogMessageFormat = GetRestartLogMessageFormat();
			if (!string.IsNullOrWhiteSpace(restartLogMessageFormat))
			{
				LogInfo(GetRestartServerMessage(restartLogMessageFormat, GetCurrentServerName()));
			}

			RestartServer();
		}

		protected virtual bool IsEnabled() => _restartServerFeatureToggleService.IsEnabled(this);

		protected abstract string GetRestartLogMessageFormat();

		protected virtual TArgs GetArguments<TArgs>(EventArgs args) where TArgs : EventArgs => args as TArgs;

		protected virtual bool ShouldRestartServer(RestartServerEventArgs restartServerArgs)
		{
			if(restartServerArgs.ServerNames == null || !restartServerArgs.ServerNames.Any())
			{
				return false;
			}

			string currentServerName = GetCurrentServerName();
			if (string.IsNullOrWhiteSpace(currentServerName))
			{
				return false;
			}

			return restartServerArgs.ServerNames.Any(serverName => string.Equals(serverName, currentServerName, StringComparison.OrdinalIgnoreCase));
		}

		protected virtual string GetCurrentServerName() => _serverService.GetCurrentServerName();

		protected virtual string GetRestartServerMessage(string messageFormat, string serverName) => string.Format(messageFormat, serverName);

		protected virtual void RestartServer() => _installerService.RestartServer();

		protected virtual void LogInfo(string message) => _log.Info(message, this);
	}
}

Subclasses of the class above will have methods to handle their events which will delegate to the ExecuteRestart() method. This method will use the feature toggle service class to determine if it should execute or not; if not, it just gracefully exits.

If it does proceed forward, the passed System.EventArgs class is casted as RestartServerEventArgs instance, and the current Sitecore instance’s name is checked against the collection server names in the RestartServerEventArgs instance. If the current server’s name is in the list, the server is restarted though proceeded by a log message indicating that the server is being restarted.

Subclasses of thie abstract class above must provide the log message formatted string so the log message can be written to the Sitecore log.

I then created the following interface for an event handler class to handle a local server restart:

using System;

namespace Foundation.Kernel.Events.RestartServer
{
	public interface IRestartLocalServerEventHandler
	{
		void OnRestartTriggered(object sender, EventArgs args);
	}
}

Here’s the implementation of the interface above:

using System;

using Sitecore.Abstractions;

using Foundation.Kernel.Models.RestartServer.Events;
using Foundation.Kernel.Services.Installer;
using Foundation.Kernel.Services.Server;
using Foundation.Kernel.Services.RestartServer;

namespace Foundation.Kernel.Events.RestartServer
{
	public class RestartLocalServerEventHandler : BaseRestartServerEventHandler, IRestartLocalServerEventHandler
	{
		private readonly RestartServerEventHandlerSettings _settings;

		public RestartLocalServerEventHandler(RestartServerEventHandlerSettings settings, IRestartServerFeatureToggleService restartServerFeatureToggleService, IServerService serverService, IInstallerService installerService, BaseLog log)
			: base(settings, restartServerFeatureToggleService, serverService, installerService, log)
		{
			_settings = settings;
		}

		public void OnRestartTriggered(object sender, EventArgs args) => ExecuteRestart(sender, args);

		protected override string GetRestartLogMessageFormat() => _settings.RestartServerLogMessageFormat;
	}
}

This subclass of the abstract class defined above just supplies its own log formatted message, and the rest of the logic is handled by its parent class.

I then created the following interface of an event handler class to remote events (those that run on CD servers):

using System;

namespace Foundation.Kernel.Events.RestartServer
{
	public interface IRestartRemoteServerEventHandler
	{
		void OnRestartTriggeredRemote(object sender, EventArgs args);
	}
}

The following class implements the interface above:

using System;

using Sitecore.Abstractions;

using Foundation.Kernel.Models.RestartServer.Events;
using Foundation.Kernel.Services.Installer;
using Foundation.Kernel.Services.Server;
using Foundation.Kernel.Services.RestartServer;

namespace Foundation.Kernel.Events.RestartServer
{
	public class RestartRemoteServerEventHandler : BaseRestartServerEventHandler, IRestartRemoteServerEventHandler
	{
		private readonly RestartServerEventHandlerSettings _settings;

		public RestartRemoteServerEventHandler(RestartServerEventHandlerSettings settings, IRestartServerFeatureToggleService restartServerFeatureToggleService, IServerService serverService,  IInstallerService installerService, BaseLog log)
			: base(settings, restartServerFeatureToggleService, serverService, installerService, log)
		{
			_settings = settings;
		}

		public void OnRestartTriggeredRemote(object sender, EventArgs args) => ExecuteRestart(sender, args);

		protected override string GetRestartLogMessageFormat() => _settings.RestartServerRemoteLogMessageFormat;
	}
}

Just as the previous event handler class had done, this class inherits from the abstract class defined above but just defines the GetRestartLogMessageFormat() method to provide its own log message formatted string; we need to identify that this was executed on a CD server in the Sitecore log.

In order to get remote events to work on your CD instances, you need to subscribe to your remote event on your CD server — this is done by listening for an instance of your custom EventArgs, we are using RestartServerEventArgs here, being sent across via the EventQueue — and then raise your custom remote event on our CD instance so your handlers are executed. The following code will be wrappers around static classes in the Sitecore API so I can use Dependency Injection in a custom <initialize> pipeline processor which ties all of this together with these injected service classes.

I will need to call methods on Sitecore.Events.Event in Sitecore.Kernel. I created the following interface/implementation for it:

using System;

using Sitecore.Events;

namespace Foundation.Kernel.Services.Events
{
	public interface IEventService
	{
		TParameter ExtractParameter<TParameter>(EventArgs args, int index) where TParameter : class;

		object ExtractParameter(EventArgs args, int index);

		void RaiseEvent(string eventName, IPassNativeEventArgs args);

		EventResult RaiseEvent(string eventName, params object[] parameters);
	}
}

using System;

using Sitecore.Events;

namespace Foundation.Kernel.Services.Events
{
	public class EventService : IEventService
	{
		public TParameter ExtractParameter<TParameter>(EventArgs args, int index) where TParameter : class => Event.ExtractParameter<TParameter>(args, index);

		public object ExtractParameter(EventArgs args, int index) => Event.ExtractParameter(args, index);

		public void RaiseEvent(string eventName, IPassNativeEventArgs args) => Event.RaiseEvent(eventName, args);

		public EventResult RaiseEvent(string eventName, params object[] parameters) => Event.RaiseEvent(eventName, parameters);
	}
}

I then created the following Config Object to provide the names of the two custom events (check out the patch configuration file at the end of this post to see what these values are):

using Foundation.DependencyInjection;
using Foundation.DependencyInjection.Enums;

namespace Foundation.Kernel.Models.RestartServer.Events
{
	[ServiceConfigObject(ConfigPath = "moduleSettings/foundation/kernel/restartServerEventSettings", Lifetime = Lifetime.Singleton)]
	public class RestartServerEventSettings
	{
		public string RestartCurrentServerEventName { get; set; }

		public string RestartRemoteServerEventName { get; set; }
	}
}

Now, I need a way to raise events, both on a local Sitecore instance but also on a remote instance. I defined the following interface for such a service class:

namespace Foundation.Kernel.Services.Events
{
	public interface IEventTriggerer
	{
		void TriggerEvent(string eventName, params object[] parameters);

		void TriggerRemoteEvent<TEvent>(TEvent evt);

		void TriggerRemoteEvent<TEvent>(TEvent evt, bool triggerGlobally, bool triggerLocally);
	}
}

I then implemented the interface above:

using Sitecore.Abstractions;

namespace Foundation.Kernel.Services.Events
{
	public class EventTriggerer : IEventTriggerer
	{
		private readonly IEventService _eventService;
		private readonly BaseEventQueueProvider _eventQueueProvider;

		public EventTriggerer(IEventService eventService, BaseEventQueueProvider eventQueueProvider)
		{
			_eventService = eventService;
			_eventQueueProvider = eventQueueProvider;
		}

		public void TriggerEvent(string eventName, params object[] parameters) => _eventService.RaiseEvent(eventName, parameters);

		public void TriggerRemoteEvent<TEvent>(TEvent evt) => _eventQueueProvider.QueueEvent(evt);

		public void TriggerRemoteEvent<TEvent>(TEvent evt, bool triggerGlobally, bool triggerLocally) => _eventQueueProvider.QueueEvent(evt, triggerGlobally, triggerLocally);
	}
}

The class above consumes the IEventService service class we defined above so that we can “trigger”/raise local events on the current Sitecore instance, and it also consumes the BaseEventQueueProvider service which comes with stock Sitecore so we can “trigger”/raise events to run on remote servers via the EventQueue.

I also need to use methods on the Sitecore.Eventing.EventManager class in Sitecore.Kernel. The following interface/implementation do just that:

using System;

using Sitecore.Eventing;

namespace Foundation.Kernel.Services.Events
{
	public interface IEventManagerService
	{
		SubscriptionId Subscribe<TEvent>(Action<TEvent> eventHandler);
	}
}

using System;

using Sitecore.Eventing;

namespace Foundation.Kernel.Services.Events
{
	public class EventManagerService : IEventManagerService
	{
		public SubscriptionId Subscribe<TEvent>(Action<TEvent> eventHandler) => EventManager.Subscribe(eventHandler);
	}
}

I do want to call out that there is an underlying service behind the Sitecore.Eventing.EventManager class in Sitecore.Kernel but it’s brought into this static class through some service locator method I had never seen before, and was afraid of traversing too much down this rabbit hole out of fear of sticking my hands into a hornets nest, or even worse, a nest of those murderer hornets we keep hearing about on the news these days; I felt it was best not to go much further into this today. 😉

We can now dive into the <initialize> pipeline processor which binds the “subscribing and trigger remote event” functionality together.

I first created the following interface for the pipeline processor:

using Sitecore.Pipelines;

namespace Foundation.Kernel.Pipelines.Initialize.RestartServer
{
	public interface IRestartServerSubscriber
	{
		void Process(PipelineArgs args);
	}
}

I then implemented the interface above:

using System;

using Sitecore.Eventing;
using Sitecore.Pipelines;

using Foundation.Kernel.Services.Events;
using Foundation.Kernel.Services.FeatureToggle;
using Foundation.Kernel.Services.RestartServer;
using Foundation.Kernel.Models.RestartServer.Events;

namespace Foundation.Kernel.Pipelines.Initialize.RestartServer
{
	public class RestartServerSubscriber: IFeatureToggleable, IRestartServerSubscriber
	{
		private readonly RestartServerEventSettings _settings;
		private readonly IRestartServerFeatureToggleService _restartServerFeatureToggleService;
		private readonly IEventTriggerer _eventTriggerer;
		private readonly IEventManagerService _eventManagerService;

		public bool Enabled { get; set; }

		public RestartServerSubscriber(RestartServerEventSettings settings, IRestartServerFeatureToggleService restartServerFeatureToggleService, IEventTriggerer eventTriggerer, IEventManagerService eventManagerService)
		{
			_settings = settings;
			_restartServerFeatureToggleService = restartServerFeatureToggleService;
			_eventTriggerer = eventTriggerer;
			_eventManagerService = eventManagerService;
		}

		public void Process(PipelineArgs args)
		{
			if(!IsEnabled())
			{
				return;
			}

			Subscribe(GetRaiseRestartServerEventMethod());
		}

		protected virtual bool IsEnabled() => _restartServerFeatureToggleService.IsEnabled(this);

		protected virtual Action<RestartServerEventArgs> GetRaiseRestartServerEventMethod() => new Action<RestartServerEventArgs>(RaiseRestartServerEvent);

		protected virtual void RaiseRestartServerEvent(RestartServerEventArgs args) => RaiseEvent(GetRestartRemoteServerEventName(), args);

		protected virtual string GetRestartRemoteServerEventName() => _settings.RestartRemoteServerEventName;

		protected virtual void RaiseEvent(string eventName, params object[] parameters) => _eventTriggerer.TriggerEvent(eventName, parameters);

		protected virtual SubscriptionId Subscribe<TEvent>(Action<TEvent> eventHandler) => _eventManagerService.Subscribe(eventHandler);
	}
}

The Process() method of the pipeline processor class above uses the feature toggle service we had discuss earlier in this post to determine if it should execute or not.

If it can execute, it will subscribe to the remote event by listening for an RestartServerEventArgs instance being sent across by the EventQueue.

If it one is sent across, it will “trigger” (raise) the custom remote event on the CD server this pipeline processor lives on.

Are you still with me? 😉

Now we need a service class which glues all of the stuff above into a nice simple API which we can call. I defined the following Config Object which will be consumed by this service class; this Config Object determines if Remote events should also run on local servers — I had set this up so I can turn this on for testing/troubleshooting/debugging on my local development instance:

using Foundation.DependencyInjection;
using Foundation.DependencyInjection.Enums;

namespace Foundation.Kernel.Models.RestartServer.Events
{
	[ServiceConfigObject(ConfigPath = "moduleSettings/foundation/kernel/restartServerRemoteEventSettings", Lifetime = Lifetime.Singleton)]
	public class RestartServerRemoteEventSettings
	{
		public bool TriggerRemoteEventLocally { get; set; }

		public bool TriggerRemoteEventGlobally { get; set; }
	}
}

The following interface is for our “simple” API for restarting Sitecore instances:

using System.Collections.Generic;

namespace Foundation.Kernel.Services.RestartServer
{
	public interface IRestartServerService
	{
		void RestartCurrentServer();

		void RestartRemoteServer(string serverName);

		void RestartRemoteServers(List<string> serverNames);
	}
}

Here’s the implementation of the interface above:

using System.Collections.Generic;
using System.Linq;

using Foundation.Kernel.Models.RestartServer.Events;
using Foundation.Kernel.Services.Events;
using Foundation.Kernel.Services.Server;

namespace Foundation.Kernel.Services.RestartServer
{
	public class RestartServerService : IRestartServerService
	{
		private readonly RestartServerEventSettings _eventSettings;
		private readonly RestartServerRemoteEventSettings _remoteEventSettings;
		private readonly IRestartServerFeatureToggleService _restartServerFeatureToggleService;
		private readonly IServerService _serverService;
		private readonly IEventTriggerer _eventTriggerer;

		public RestartServerService(RestartServerEventSettings eventSettings, RestartServerRemoteEventSettings remoteEventSettings, IRestartServerFeatureToggleService restartServerFeatureToggleService, IServerService serverService, IEventTriggerer eventTriggerer)
		{
			_eventSettings = eventSettings;
			_remoteEventSettings = remoteEventSettings;
			_restartServerFeatureToggleService = restartServerFeatureToggleService;
			_serverService = serverService;
			_eventTriggerer = eventTriggerer;
		}

		public void RestartCurrentServer()
		{
			if(!IsFeatureEnabled())
			{
				return;
			}

			TriggerEvent(GetRestartCurrentServerEventName(), CreateRestartServerEventArgs(CreateList(GetCurrentServerName())));
		}

		protected virtual string GetRestartCurrentServerEventName() => _eventSettings.RestartCurrentServerEventName;

		protected virtual string GetCurrentServerName() => _serverService.GetCurrentServerName();

		public void RestartRemoteServer(string serverName) => RestartRemoteServers(CreateList(serverName));

		protected virtual List<string> CreateList(params string[] values) => values?.ToList();

		public void RestartRemoteServers(List<string> serverNames)
		{
			if (!IsFeatureEnabled())
			{
				return;
			}

			TriggerRemoteEvent(CreateRestartServerEventArgs(serverNames));
		}


		protected virtual bool IsFeatureEnabled() => _restartServerFeatureToggleService.IsFeatureEnabled();

		protected virtual RestartServerEventArgs CreateRestartServerEventArgs(List<string> serverNames) => new RestartServerEventArgs(serverNames);

		protected virtual void TriggerEvent(string eventName, params object[] parameters) => _eventTriggerer.TriggerEvent(eventName, parameters);

		protected virtual void TriggerRemoteEvent<TEvent>(TEvent evt) => _eventTriggerer.TriggerRemoteEvent(evt, GetTriggerRemoteEventGlobally(), GetTriggerRemoteEventGlobally());

		protected virtual bool GetTriggerRemoteEventGlobally() => _remoteEventSettings.TriggerRemoteEventGlobally;

		protected virtual bool GetTriggerRemoteEventLocally() => _remoteEventSettings.TriggerRemoteEventLocally;
	}
}

The class above implements methods for restarting the current server, one remote server, or multiple remote servers — ultimately, it just delegates to the IEventTriggerer service class we defined further above, and uses other services discussed earlier in this post; there’s really not much to it.

I then stitched everything above together in the following Sitecore patch configuration file:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/" xmlns:set="http://www.sitecore.net/xmlconfig/set/" xmlns:role="http://www.sitecore.net/xmlconfig/role/">
	<sitecore>
		<events>
			<event name="server:restart">
				<handler type="Foundation.Kernel.Events.RestartServer.IRestartLocalServerEventHandler, Foundation.Kernel" method="OnRestartTriggered" resolve="true">
					<Enabled>true</Enabled>
				</handler>
			</event>
			<event name="server:restart:remote">
				<handler type="Foundation.Kernel.Events.RestartServer.IRestartRemoteServerEventHandler, Foundation.Kernel" method="OnRestartTriggeredRemote" resolve="true">
					<Enabled>true</Enabled>
				</handler>
			</event>
		</events>
		<pipelines>
			<initialize>
				<processor type="Foundation.Kernel.Pipelines.Initialize.RestartServer.IRestartServerSubscriber, Foundation.Kernel" resolve="true">
					<Enabled>true</Enabled>
				</processor>
			</initialize>
		</pipelines>
		<moduleSettings>
			<foundation>
				<kernel>
					<serverServiceSettings type="Foundation.Kernel.Models.Server.ServerServiceSettings, Foundation.Kernel" singleInstance="true">
						<InstanceNameSetting>InstanceName</InstanceNameSetting>
					</serverServiceSettings>
					<restartServerSettings type="Foundation.Kernel.Models.RestartServer.RestartServerSettings, Foundation.Kernel" singleInstance="true">
						<Enabled>true</Enabled>
					</restartServerSettings>
					<restartServerEventHandlerSettings type="Foundation.Kernel.Models.RestartServer.Events.RestartServerEventHandlerSettings, Foundation.Kernel" singleInstance="true">
						<RestartServerLogMessageFormat>Restart Server Event Triggered: Shutting down server {0}</RestartServerLogMessageFormat>
						<RestartServerRemoteLogMessageFormat>Restart Server Remote Event Triggered: Shutting down server {0}</RestartServerRemoteLogMessageFormat>
					</restartServerEventHandlerSettings>
					<restartServerEventSettings type="Foundation.Kernel.Models.RestartServer.Events.RestartServerEventSettings, Foundation.Kernel" singleInstance="true">
						<RestartCurrentServerEventName>server:restart</RestartCurrentServerEventName>
						<RestartRemoteServerEventName>server:restart:remote</RestartRemoteServerEventName>
					</restartServerEventSettings>
					<restartServerRemoteEventSettings type="Foundation.Kernel.Models.RestartServer.Events.RestartServerRemoteEventSettings, Foundation.Kernel" singleInstance="true">
						<!-- setting this to "true" so I can test/debug locally -->
						<TriggerRemoteEventLocally>true</TriggerRemoteEventLocally>
						<TriggerRemoteEventGlobally>true</TriggerRemoteEventGlobally>
					</restartServerRemoteEventSettings>
			</kernel>
			</foundation>
		</moduleSettings>
		<services>

			<!-- General Services -->
			<register
				serviceType="Foundation.Kernel.Services.Installer.IInstallerService, Foundation.Kernel"
				implementationType="Foundation.Kernel.Services.Installer.InstallerService, Foundation.Kernel"
				lifetime="Singleton" />
			<register
				serviceType="Foundation.Kernel.Services.Server.IServerService, Foundation.Kernel"
				implementationType="Foundation.Kernel.Services.Server.ServerService, Foundation.Kernel"
				lifetime="Singleton" />
			<register
				serviceType="Foundation.Kernel.Services.RestartServer.IRestartServerFeatureToggleService, Foundation.Kernel"
				implementationType="Foundation.Kernel.Services.RestartServer.RestartServerFeatureToggleService, Foundation.Kernel"
				lifetime="Singleton" />
			<register
				serviceType="Foundation.Kernel.Services.RestartServer.IRestartServerService, Foundation.Kernel"
				implementationType="Foundation.Kernel.Services.RestartServer.RestartServerService, Foundation.Kernel"
				lifetime="Singleton" />

			<!-- Event Related Services -->
			<register
				serviceType="Foundation.Kernel.Services.Events.IEventService, Foundation.Kernel"
				implementationType="Foundation.Kernel.Services.Events.EventService, Foundation.Kernel"
				lifetime="Singleton" />
			<register
				serviceType="Foundation.Kernel.Services.Events.IEventManagerService, Foundation.Kernel"
				implementationType="Foundation.Kernel.Services.Events.EventManagerService, Foundation.Kernel"
				lifetime="Singleton" />
			<register
				serviceType="Foundation.Kernel.Services.Events.IEventTriggerer, Foundation.Kernel"
				implementationType="Foundation.Kernel.Services.Events.EventTriggerer, Foundation.Kernel"
				lifetime="Singleton" />

			<!-- Event Handler Services -->

			<register
				serviceType="Foundation.Kernel.Events.RestartServer.IRestartLocalServerEventHandler, Foundation.Kernel"
				implementationType="Foundation.Kernel.Events.RestartServer.RestartLocalServerEventHandler, Foundation.Kernel"
				lifetime="Singleton" />
			<register
				serviceType="Foundation.Kernel.Events.RestartServer.IRestartRemoteServerEventHandler, Foundation.Kernel"
				implementationType="Foundation.Kernel.Events.RestartServer.RestartRemoteServerEventHandler, Foundation.Kernel"
				lifetime="Singleton" />

			<!-- Pipeline Processor Services -->
			<register
				serviceType="Foundation.Kernel.Pipelines.Initialize.RestartServer.IRestartServerSubscriber, Foundation.Kernel"
				implementationType="Foundation.Kernel.Pipelines.Initialize.RestartServer.RestartServerSubscriber, Foundation.Kernel"
				lifetime="Singleton" />
		</services>
		<settings>

			<!-- This is set here for testing. Ideally, you would have this set for every Sitecore instance you have in your specific custom patch file where identify your server -->
			<setting name="InstanceName">
				<patch:attribute name="value">Sandbox</patch:attribute>
			</setting>
		</settings>
	</sitecore>
</configuration>

Considering I had built this to be executed from a PowerShell script hooked into a custom button through the Content Editor Ribbon integration point via Sitecore PowerShell Extensions (SPE), I will be testing this using two simple PowerShell scripts; both will be executed from the Sitecore PowerShell Extensions ISE (why yes, Sitecore MVP Michael West, I had tested this on SPE v6.1.1 😉 ):

Let’s see how we did.

Let’s test this by restarting the current Sitecore instance:

$serviceType = [Foundation.Kernel.Services.RestartServer.IRestartServerService]
$service = [Sitecore.DependencyInjection.ServiceLocator]::ServiceProvider.GetService($serviceType) -as $serviceType  #use service locator to get the IRestartServerService service
$service.RestartCurrentServer() #Let's call the method to restart the current server (CM)

As expected, my Sitecore instance froze up as it was restarting. I then saw this in my logs:

Let’s now restart the remote Sitecore instance:

$serviceType = [Foundation.Kernel.Services.RestartServer.IRestartServerService]
$service = [Sitecore.DependencyInjection.ServiceLocator]::ServiceProvider.GetService($serviceType) -as $serviceType  #use service locator to get the IRestartServerService service
$service.RestartRemoteServer("Sandbox")  #Let's call the method to restart the remote server (CD)

Also as expected, my Sitecore instance froze up as it was restarting — remember, I am testing this on a single development instance of Sitecore where I don’t have a separate CM and CD . I then saw this in my logs:

Let me know if you have questions/comments/fears/dreams/hopes/apsirations/whatever by dropping a comment. 😉

Yet Another Post on Sitecore Content Editor Warnings

05/17/2020 11:01 / Leave a comment

Over the years, I’ve written posts on adding custom Content Editor Warnings. Content Editor Warnings give visual cues at the top of an Item in the Content Editor to either take action on something about the Item, or to just convey information about the Item — perhaps the Item is read-only, or maybe there is something wrong with the item; you can do all kinds of stuff with these, just use your imagination on what you would like to convey to your content authors.

The way to add these is to create a custom processor for the <getContentEditorWarnings> pipeline in Sitecore. There really isn’t anything more to it.

Moreover, you can even use Sitecore PowerShell Extensions to create these though I did not do this for this post. Sorry, Sitecore MVP Michael West. 😉

Today, I am sharing a recent example of two Content Editor Warnings which I had worked on which convey to content authors they almost have, or have too many child items within a Media Library folder.

Some code on this post reuses service classes found on my previous post where I discussed how to create a custom MasterDataView driven by a custom pipeline; I recommend having a read of that previous post first before proceeding further in order to have complete grounding on some of the service classes I am using in the solution below.

I had to make a tweak to the ITooManySubItemsService service found on my previous post — I had to make the GetNumberOfItemsToStartWarningUser() and GetMaximumNumberOfItemsInFolder() methods public as I needed to get these two values within the Content Editor Warnings in order to display these values in messages to the content authors via the Content Editor Warning. This service determines these values based on a Config Object service which can also be overriden by each individual piece of functionality in my solution (i.e. the maximum number of child items set on the pipeline processor would override the Config Object service’s value):

using Foundation.Validation.Models.TooManySubItems;

namespace Foundation.Validation.Services.TooManySubItems
{
	public interface ITooManySubItemsService
	{
		bool HasAlmostTooManySubItems(TooManySubItemsServiceParameters parameters);

		bool HasTooManySubItems(TooManySubItemsServiceParameters parameters);

		int GetNumberOfItemsToStartWarningUser(TooManySubItemsServiceParameters parameters); // I've added this

		int GetMaximumNumberOfItemsInFolder(TooManySubItemsServiceParameters parameters); // I've added this
	}
}

Here is the modified implementation of the interface above. All I did was change the signature on GetNumberOfItemsToStartWarningUser() and GetMaximumNumberOfItemsInFolder() to be public instead of protected:

using System.Collections.Generic;
using System.Linq;

using Sitecore.Data.Items;

using Foundation.Validation.Models.TooManySubItems;
using Foundation.Validation.Services.TooManySubItems;

namespace Feature.Validation.Services.TooManySubItems
{
	public class TooManySubItemsService : ITooManySubItemsService
	{
		private readonly TooManySubItemsSettings _settings;

		public TooManySubItemsService(TooManySubItemsSettings settings)
		{
			_settings = settings;
		}

		public bool HasAlmostTooManySubItems(TooManySubItemsServiceParameters parameters)
		{
			int numberOfItemsToStartWarningUser = GetNumberOfItemsToStartWarningUser(parameters);
			int maximumNumberOfItemsInFolder = GetMaximumNumberOfItemsInFolder(parameters);
			if (parameters?.Item == null || numberOfItemsToStartWarningUser < 1 || maximumNumberOfItemsInFolder < 1)
			{
				return false;
			}

			IEnumerable<Item> items = GetItemsWithoutTemplateIds(parameters?.Item.Children, parameters?.TemplateIdsToIgnore);
			return items.Count() >= numberOfItemsToStartWarningUser && items.Count() < maximumNumberOfItemsInFolder;
		}

		public bool HasTooManySubItems(TooManySubItemsServiceParameters parameters)
		{
			int maximumNumberOfItemsInFolder = GetMaximumNumberOfItemsInFolder(parameters);
			if (parameters?.Item == null || maximumNumberOfItemsInFolder < 1)
			{
				return false;
			}

			IEnumerable<Item> items = GetItemsWithoutTemplateIds(parameters?.Item.Children, parameters?.TemplateIdsToIgnore);
			return items.Count() >= maximumNumberOfItemsInFolder;
		}

		public int GetNumberOfItemsToStartWarningUser(TooManySubItemsServiceParameters parameters)
		{
			if (parameters == null || _settings == null)
			{
				return 0;
			}

			if (parameters.NumberOfItemsToStartWarningUser > 0)
			{
				return parameters.NumberOfItemsToStartWarningUser;
			}

			return _settings.NumberOfItemsToStartWarningUser;
		}

		public int GetMaximumNumberOfItemsInFolder(TooManySubItemsServiceParameters parameters)
		{
			if (parameters == null || _settings == null)
			{
				return 0;
			}

			if (parameters.MaximumNumberOfItemsInFolder > 0)
			{
				return parameters.MaximumNumberOfItemsInFolder;
			}

			return _settings.MaximumNumberOfItemsInFolder;
		}

		protected virtual IEnumerable<Item> GetItemsWithoutTemplateIds(IEnumerable<Item> items, IEnumerable<string> templateIds)
		{
			if (items == null)
			{
				return Enumerable.Empty<Item>();
			}

			if(templateIds == null || !templateIds.Any())
			{
				return items;
			}

			return items.Where(item => templateIds.All(templateId => templateId != item.TemplateID.ToString())).ToList();
		}
	}
}

The processors which are defined below will give content authors the ability to take action on the Content Editor Warnings. The options are basically just as collection of link text and Sheer UI commands. In this example, content authors are given the option to create new Media Library folders. The following class is used when sourcing these from each processor’s configuration definition (see the Sitecore patch configuration file further down in this post):

namespace Foundation.Kernel.Models.Pipelines.ContentEditorWarnings
{
	public class ContentEditorWarningOption
	{
		public string Text { get; set; }

		public string Link { get; set; }
	}
}

Since the two Content Editor Warning processors are doing very similiar things, I abstracted out most of their logic into a base abstract class, and put it hooks for overriding methods on it; this is an example of the Template Method Pattern for you Design Pattern junkies 😉

using System.Collections.Generic;

using Sitecore.Data.Items;
using Sitecore.Pipelines.GetContentEditorWarnings;

using Foundation.Kernel.Models.Pipelines.ContentEditorWarnings;

using Foundation.Validation.Models.TooManySubItems;
using Foundation.Validation.Services.TooManySubItems.Factories;
using Foundation.Validation.Services.TooManySubItems;
using Foundation.Kernel.Services.FeatureToggle;

namespace Feature.ContentEditor.Pipelines.GetContentEditorWarnings
{
	public abstract class BaseTooManyChildItemsWarningProcessor : IFeatureToggleable, ITooManySubItemsFeature
	{
		private readonly ITooManySubItemsFeatureToggleService _tooManySubItemsFeatureToggleService;
		private readonly ITooManySubItemsServiceParametersFactory _tooManySubItemsServiceParametersFactory;
		private readonly ITooManySubItemsService _tooManySubItemsService;

		public bool Enabled { get; set; }

		protected string MediaLibraryBasePath { get; set; }

		public List<string> TemplateIdsToIgnore { get; set; } = new List<string>();

		public int NumberOfItemsToStartWarningUser { get; set; }

		public int MaximumNumberOfItemsInFolder { get; set; }

		protected List<ContentEditorWarningOption> ContentEditorWarningOptions { get; set; } = new List<ContentEditorWarningOption>();

		public BaseTooManyChildItemsWarningProcessor(ITooManySubItemsFeatureToggleService tooManySubItemsFeatureToggleService, ITooManySubItemsServiceParametersFactory tooManySubItemsServiceParametersFactory, ITooManySubItemsService tooManySubItemsService)
		{
			_tooManySubItemsFeatureToggleService = tooManySubItemsFeatureToggleService;
			_tooManySubItemsServiceParametersFactory = tooManySubItemsServiceParametersFactory;
			_tooManySubItemsService = tooManySubItemsService;
		}

		public void Process(GetContentEditorWarningsArgs args)
		{
			if(!IsEnabled() || !IsInMediaLibrary(args?.Item))
			{
				return;
			}

			TooManySubItemsServiceParameters parameters = CreateParameters(args?.Item, this);
			if(parameters == null)
			{
				return;
			}

			if(!ShouldDisplayWarning(parameters))
			{
				return;
			}

			int maximumNumberOfItemsInFolder = GetMaximumNumberOfItemsInFolder(parameters);
			string warningTitle = GetWarningTitle(args, maximumNumberOfItemsInFolder);
			string warningMessage = GetWarningMessage(args, maximumNumberOfItemsInFolder);
			AddWarning(args, warningTitle, warningMessage, ContentEditorWarningOptions);
		}

		protected virtual bool IsEnabled() => _tooManySubItemsFeatureToggleService.IsEnabled(this);

		protected virtual bool IsInMediaLibrary(Item item)
		{
			if(string.IsNullOrWhiteSpace(item.Paths.FullPath))
			{
				return false;
			}

			return item.Paths.FullPath.Contains(MediaLibraryBasePath);
		}

		protected virtual TooManySubItemsServiceParameters CreateParameters(Item item, ITooManySubItemsFeature feature) => _tooManySubItemsServiceParametersFactory.CreateParameters(item, feature);

		protected abstract bool ShouldDisplayWarning(TooManySubItemsServiceParameters parameters);

		protected abstract string GetWarningTitle(GetContentEditorWarningsArgs args, int maximumNumberOfItemsInFolder);

		protected abstract string GetWarningMessage(GetContentEditorWarningsArgs args, int maximumNumberOfItemsInFolder);

		protected virtual int GetMaximumNumberOfItemsInFolder(TooManySubItemsServiceParameters parameters) =>_tooManySubItemsService.GetMaximumNumberOfItemsInFolder(parameters);

		protected virtual bool HasAlmostTooManySubItems(TooManySubItemsServiceParameters parameters) => _tooManySubItemsService.HasAlmostTooManySubItems(parameters);

		protected virtual bool HasTooManySubItems(TooManySubItemsServiceParameters parameters) => _tooManySubItemsService.HasTooManySubItems(parameters);

		protected virtual void AddWarning(GetContentEditorWarningsArgs args, string title, string message, IEnumerable<ContentEditorWarningOption> options)
		{
			if(args == null)
			{
				return;
			}

			GetContentEditorWarningsArgs.ContentEditorWarning warning = CreateNewContentEditorWarning(args);
			if(warning == null)
			{
				return;
			}

			warning.Title = title;
			warning.Text = message;
			AddOptions(warning, options);
		}

		protected virtual GetContentEditorWarningsArgs.ContentEditorWarning CreateNewContentEditorWarning(GetContentEditorWarningsArgs args) => args?.Add();

		protected virtual void AddOptions(GetContentEditorWarningsArgs.ContentEditorWarning warning, IEnumerable<ContentEditorWarningOption> options)
		{
			if(warning == null || options == null)
			{
				return;
			}

			foreach(ContentEditorWarningOption option in options)
			{
				if(string.IsNullOrWhiteSpace(option.Text) || string.IsNullOrWhiteSpace(option.Link)) continue;
				warning.AddOption(option.Text, option.Link);
			}
		}
	}
}

The class above will only display the Content Editor Warning when the feature is enabled (see my previous post where I discuss how this works using Sitecore configuration feature toggles); the item is in the Media Library; and the ShouldDisplayWarning() method returns true — this must be implemented by subclasses of this abstract base class.

If the Content Editor Warning should display, the Content Editor Warning’s title is retrieved via the GetWarningTitle() method, and its message is retrieved via the GetWarningMessage() method — both of these methods must be implemented by its subclasses.

These are then added to the a new GetContentEditorWarningsArgs.ContentEditorWarning instance created from the GetContentEditorWarningsArgs instance with the options defined in the configuration for the processor.

I then created the following interface for the purposes of registering its implementation in the Sitecore IoC container; this is optional as you could just register it with its implementation type being its service type.

using Sitecore.Pipelines.GetContentEditorWarnings;

namespace Feature.ContentEditor.Pipelines.GetContentEditorWarnings
{
	public interface IAlmostTooManyChildItemsWarningProcessor
	{
		void Process(GetContentEditorWarningsArgs args);
	}
}

Here is the implementation of the interface above. This is the processor class to show content authors when they are approaching too many child items:

using Sitecore.Pipelines.GetContentEditorWarnings;

using Foundation.Validation.Models.TooManySubItems;
using Foundation.Validation.Services.TooManySubItems.Factories;
using Foundation.Validation.Services.TooManySubItems;

namespace Feature.ContentEditor.Pipelines.GetContentEditorWarnings
{
	public class AlmostTooManyChildItemsWarningProcessor : BaseTooManyChildItemsWarningProcessor, IAlmostTooManyChildItemsWarningProcessor
	{
		private string AlmostAtMaxiumTitle { get; set; }

		private string AlmostAtMaxiumMessageFormat { get; set; }

		public AlmostTooManyChildItemsWarningProcessor(ITooManySubItemsFeatureToggleService tooManySubItemsFeatureToggleService, ITooManySubItemsServiceParametersFactory tooManySubItemsServiceParametersFactory, ITooManySubItemsService tooManySubItemsService)
			: base(tooManySubItemsFeatureToggleService, tooManySubItemsServiceParametersFactory, tooManySubItemsService)
		{
		}

		protected override bool ShouldDisplayWarning(TooManySubItemsServiceParameters parameters) => HasAlmostTooManySubItems(parameters);

		protected override string GetWarningTitle(GetContentEditorWarningsArgs args, int maximumNumberOfItemsInFolder) => AlmostAtMaxiumTitle;

		protected override string GetWarningMessage(GetContentEditorWarningsArgs args, int maximumNumberOfItemsInFolder) => string.Format(AlmostAtMaxiumMessageFormat, args?.Item?.Children?.Count, maximumNumberOfItemsInFolder);
	}
}

The implementation above is using the AlmostAtMaxiumTitle and AlmostAtMaxiumMessageFormat strings set via the Sitecore Configuration Factory onto the class instance; these are used when displaying messaging to content authors.

Also, this implementation is using the HasAlmostTooManySubItems() method defined on its base class which ultimately makes a call to the ITooManySubItemsService service class to ascertain whether the folder/item almost has too many child items.

Just as I had done above, I created an interface for the other Content Editor Warning, only for the purpose of registering it in the Sitecore IoC container.

using Sitecore.Pipelines.GetContentEditorWarnings;

namespace Feature.ContentEditor.Pipelines.GetContentEditorWarnings
{
	public interface ITooManyChildItemsWarningProcessor
	{
		void Process(GetContentEditorWarningsArgs args);
	}
}

Here is the implementation of the interface above:

using Sitecore.Pipelines.GetContentEditorWarnings;

using Foundation.Validation.Models.TooManySubItems;
using Foundation.Validation.Services.TooManySubItems.Factories;
using Foundation.Validation.Services.TooManySubItems;

namespace Feature.ContentEditor.Pipelines.GetContentEditorWarnings
{
	public class TooManyChildItemsWarningProcessor : BaseTooManyChildItemsWarningProcessor, ITooManyChildItemsWarningProcessor
	{
		private string AtMaxiumTitle { get; set; }

		private string AtMaxiumMessageFormat { get; set; }

		public TooManyChildItemsWarningProcessor(ITooManySubItemsFeatureToggleService tooManySubItemsFeatureToggleService, ITooManySubItemsServiceParametersFactory tooManySubItemsServiceParametersFactory, ITooManySubItemsService tooManySubItemsService)
			: base(tooManySubItemsFeatureToggleService, tooManySubItemsServiceParametersFactory, tooManySubItemsService)
		{
		}

		protected override bool ShouldDisplayWarning(TooManySubItemsServiceParameters parameters) => HasTooManySubItems(parameters);

		protected override string GetWarningTitle(GetContentEditorWarningsArgs args, int maximumNumberOfItemsInFolder) => AtMaxiumTitle;

		protected override string GetWarningMessage(GetContentEditorWarningsArgs args, int maximumNumberOfItemsInFolder) => string.Format(AtMaxiumMessageFormat, args?.Item?.Children?.Count, maximumNumberOfItemsInFolder);
	}
}

The class above is using the AtMaxiumTitle and AtMaxiumMessageFormat strings set via the Sitecore Configuration Factory from the processor’s configuration definition (see the Sitecore configuration patch file below for both processor definitions), and uses the HasTooManySubItems() method defined on the base class which also just delegates to the ITooManySubItemsService service class.

I then registered everything above in the following Sitecore patch configuration file:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/" xmlns:set="http://www.sitecore.net/xmlconfig/set/" xmlns:role="http://www.sitecore.net/xmlconfig/role/">
	<sitecore>
		<pipelines>
			<getContentEditorWarnings>
				<processor type="Feature.ContentEditor.Pipelines.GetContentEditorWarnings.IAlmostTooManyChildItemsWarningProcessor, Feature.ContentEditor" patch:before="processor[1]" resolve="true">
					<Enabled>true</Enabled>
					<MediaLibraryBasePath>/sitecore/media library/</MediaLibraryBasePath>
					<AlmostAtMaxiumTitle>This Item Almost Has Too Many Subitems Underneath It!</AlmostAtMaxiumTitle>
					<AlmostAtMaxiumMessageFormat>This item has {0} media libary items underneath it!  The maximum number of subitems allowed is {1}. Consider creating a new media library folder at this time.</AlmostAtMaxiumMessageFormat>
					<!-- By setting these, you can override the default values set for the entire feature set
										<NumberOfItemsToStartWarningUser>95</NumberOfItemsToStartWarningUser>
										<MaximumNumberOfItemsInFolder>100</MaximumNumberOfItemsInFolder>
					-->
					<ContentEditorWarningOptions hint="list">
						<Option type="Foundation.Kernel.Models.Pipelines.ContentEditorWarnings.ContentEditorWarningOption, Foundation.Kernel">
							<Text>New Media Folder</Text>
							<Link>media:newfolder</Link>
						</Option>
					</ContentEditorWarningOptions>
				</processor>
				<processor type="Feature.ContentEditor.Pipelines.GetContentEditorWarnings.ITooManyChildItemsWarningProcessor, Feature.ContentEditor" patch:before="processor[1]" resolve="true">
					<Enabled>true</Enabled>
					<MediaLibraryBasePath>/sitecore/media library/</MediaLibraryBasePath>
					<AtMaxiumTitle>This Item Has Too Many Subitems Underneath It!</AtMaxiumTitle>
					<AtMaxiumMessageFormat>This item has {0} media libary items underneath it! The maximum number of subitems allowed is {1}. It's time to create a new media library folder for more items to upload.</AtMaxiumMessageFormat>
					<!-- By setting these, you can override the default values set for the entire feature set
										<NumberOfItemsToStartWarningUser>95</NumberOfItemsToStartWarningUser>
										<MaximumNumberOfItemsInFolder>100</MaximumNumberOfItemsInFolder>
					-->
					<ContentEditorWarningOptions hint="list">
						<Option type="Foundation.Kernel.Models.Pipelines.ContentEditorWarnings.ContentEditorWarningOption, Foundation.Kernel">
							<Text>New Media Folder</Text>
							<Link>media:newfolder</Link>
						</Option>
					</ContentEditorWarningOptions>
				</processor>
			</getContentEditorWarnings>
		</pipelines>
		<services>
			<register
				serviceType="Feature.ContentEditor.Pipelines.GetContentEditorWarnings.IAlmostTooManyChildItemsWarningProcessor, Feature.ContentEditor"
				implementationType="Feature.ContentEditor.Pipelines.GetContentEditorWarnings.AlmostTooManyChildItemsWarningProcessor, Feature.ContentEditor"
				lifetime="Singleton" />
			<register
				serviceType="Feature.ContentEditor.Pipelines.GetContentEditorWarnings.ITooManyChildItemsWarningProcessor, Feature.ContentEditor"
				implementationType="Feature.ContentEditor.Pipelines.GetContentEditorWarnings.TooManyChildItemsWarningProcessor, Feature.ContentEditor"
				lifetime="Singleton" />
		</services>
	</sitecore>
</configuration>

Let’s see what these two processors do.

When looking at an Item which is approaching too many child items, we see the following:

When we have a look at an Item which has more than the maximum number set for child items, we see the following:

Please drop a comment if you have questions/comments, or would like to share how you’ve used Content Editor Warnings on projects you have worked on.

Alter the Appearance of the Sitecore Content Tree using a Pipeline-backed MasterDataView

05/16/2020 18:22 / Leave a comment

About 4 years ago, I blogged about creating a custom MasterDataView class to change the appearance of Items in the content tree.

One thing that bugged me back then was how this particular piece of Sitecore functionality wasn’t backed by a pipeline of some sort which gave me an idea on creating a custom MasterDataView which would delegate to a custom pipeline to alter how Items display in the content tree but I never got to it; as a matter of fact, I forgot all about it once I moved to Australia at the time — it’s easy to forget things when you are trying to dodge viscious magpies and venomous spiders 😉

However, I recently rethought of this idea due to a project I had worked on where I had to notify content authors that they had almost or too many child items in Media Folders in the Media Library. In this post, I am going to share this solution with you, and it heavily uses code from my previous post — I suggest having a read of that before proceeding.

I also want to call out that I’ve omitted code which registers most services used on this post in the Sitecore IoC container for brevity. If you want to learn about Dependency Injection on Sitecore, I highly recommend watching this presentation on YouTube.

Like any Sitecore pipeline, we need a PipelineArgs class of some sort, and the following is just that:

using Sitecore.Collections;
using Sitecore.Data.Items;
using Sitecore.Pipelines;

namespace Foundation.Kernel.Pipelines.DataViewChildItems
{
	public class DataViewChildItemsArgs : PipelineArgs
	{
		public ItemCollection Children { get; set; }

		public Item Parent { get; set; }

		public DataViewChildItemsArgs()
		{
		}

		public DataViewChildItemsArgs(ItemCollection children, Item parent)
		{
			Children = children;
			Parent = parent;
		}
	}
}

The GetChildItems() method on Sitecore.Web.UI.HtmlControls.MasterDataView, or those which inherit from it, take in an ItemCollection of children and their parent Item in the content tree. This is why I have these two properties on the DataViewChildItemsArgs class above — we are going to pass these to all processors of our custom pipeline.

On my recent project, I wanted to give the ability to have things be turned on and off via a feature toggle in Sitecore configuration, both at a global and invidual piece functionality level (i.e. have a global settings object with an Enabled property but also another Enabled property on each pipeline processor so we can turn the entire thing off, or just a piece of it).

The follow interface is to go with each bit of functionality that can be turned on/off:

namespace Foundation.Kernel.Services.FeatureToggle
{
	public interface IFeatureToggleable
	{
		bool Enabled { get; set; }
	}
}

We also need a service to read these Enabled properties, and determine if something should be turned on/off. The following is the interface for this service:

namespace Foundation.Kernel.Services.FeatureToggle
{
	public interface IFeatureToggleService
	{
		bool IsEnabled(params IFeatureToggleable[] toggleables);
	}
}

Here’s the implementation of the interface above:

using System.Collections.Generic;
using System.Linq;

namespace Foundation.Kernel.Services.FeatureToggle
{
	public class FeatureToggleService : IFeatureToggleService
	{
		public bool IsEnabled(params IFeatureToggleable[] toggleables) => !ShouldTurnOff(toggleables);

		protected virtual bool ShouldTurnOff(IEnumerable<IFeatureToggleable> toggleables)
		{
			if (toggleables == null || !toggleables.Any())
			{
				return true;
			}

			return toggleables.Any(toggleable => !toggleable.Enabled);
		}
	}
}

It takes in a collection of IFeatureToggleable, and returns false if any of the IFeatureToggleable has an Enabled property value of “false”.

I then define a base class for pipeline processors of the custom pipeline:

using Foundation.Kernel.Services.FeatureToggle;

namespace Foundation.Kernel.Pipelines.DataViewChildItems
{
	public abstract class DataViewChildItemsProcessor : IFeatureToggleable
	{
		private readonly IFeatureToggleService _featureToggleService;

		public bool Enabled { get; set; }

		protected bool AbortPipelineAfterExecution { get; set; }

		protected DataViewChildItemsProcessor(IFeatureToggleService featureToggleService)
		{
			_featureToggleService = featureToggleService;
		}

		public void Process(DataViewChildItemsArgs args)
		{
			if (!IsEnabled() || !ShouldExecute(args))
			{
				return;
			}

			GetChildItems(args);
			if (!ShouldAbortPipeline(args))
			{
				return;
			}

			args.AbortPipeline();
		}

		protected virtual bool IsEnabled() => _featureToggleService.IsEnabled(this);

		protected abstract bool ShouldExecute(DataViewChildItemsArgs args);

		protected abstract void GetChildItems(DataViewChildItemsArgs args);

		protected virtual bool ShouldAbortPipeline(DataViewChildItemsArgs args) => AbortPipelineAfterExecution;
	}
}

Any pipeline processor which implements the base class above must consume the IFeatureToggleService instance above — ideally from the Sitecore IoC container which I have done further down below but you could also use Poor Man’s DI for this which I do not recommend as we have a native IoC container in Sitecore 😉

Now, let’s dive into setting up the custom MasterDataView. The following Config Object are settings for this class, and it contains values for both the custom pipeline’s domain and the pipeline’s name (I decided to group this by pipeline domain as I can see entry points on other overridable methods on the MasterDataView class which could be driven by other custom pipelines in this domain):

using Foundation.DependencyInjection;
using Foundation.DependencyInjection.Enums;

namespace Foundation.Kernel.Models.DataViews
{
	[ServiceConfigObject(ConfigPath = "moduleSettings/foundation/kernel/pipelineDrivenDataViewSettings", Lifetime = Lifetime.Singleton)]
	public class PipelineDrivenDataViewSettings
	{
		public string PipelineDomain { get; set; }

		public string PipelineName { get; set;  }
	}
}

I then created the following MasterDataView which inherits from the OOTB Sitecore.Buckets.Forms.BucketDataView in Sitecore.Buckets.dll as the OOTB MasterDataView which ships with Sitecore is this one — I could have gone ahead and created yet another pipeline processor for Buckets but I decided against this for now:

using Sitecore.Abstractions;
using Sitecore.Buckets.Forms;
using Sitecore.Collections;
using Sitecore.Data.Items;
using Sitecore.DependencyInjection;

using Foundation.Kernel.Pipelines.DataViewChildItems;
using Foundation.Kernel.Models.DataViews;

namespace Foundation.Kernel.DataViews
{
	public class PipelineDrivenDataView : BucketDataView
	{
		protected override void GetChildItems(ItemCollection children, Item parent)
		{
			base.GetChildItems(children, parent);
			DataViewChildItemsArgs args = CreateDataViewChildItemsArgs(children, parent);
			if(args == null)
			{
				return;
			}

			ICorePipeline corePipeline = GetService<ICorePipeline>();
			PipelineDrivenDataViewSettings settings = GetSettings();

			if (corePipeline == null || string.IsNullOrWhiteSpace(settings?.PipelineDomain) || string.IsNullOrWhiteSpace(settings?.PipelineName))
			{
				return;
			}

			corePipeline.Run(settings.PipelineName, args, settings.PipelineDomain);
		}

		protected virtual ICorePipeline GetCorePipeline() => GetService<ICorePipeline>();

		protected virtual PipelineDrivenDataViewSettings GetSettings() => GetService<PipelineDrivenDataViewSettings>();

		protected virtual TService GetService<TService>() where TService : class => ServiceLocator.ServiceProvider.GetService(typeof(TService)) as TService;

		protected virtual DataViewChildItemsArgs CreateDataViewChildItemsArgs(ItemCollection children, Item parent) => new DataViewChildItemsArgs(children, parent);
	}
}

The MasterDataView above creates a new DataViewChildItemsArgs instance by passing the Children ItemCollection and parent; the custom pipeline will ultimately modify just the Children collection but I built this being mindful that other pipeline processors might need to change the Parent Item for their purposes; I just don’t have this as an example on this post.

This DataViewChildItemsArgs instance is then passed to a call to the custom pipeline within the defined domain.

I then defined the new pipeline along with the custom MasterDataView, both defined above, in the Sitecore configuration patch file below:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/" xmlns:set="http://www.sitecore.net/xmlconfig/set/" xmlns:role="http://www.sitecore.net/xmlconfig/role/">
	<sitecore>
		<dataviews>
			<dataview name="Master">
				<patch:attribute name="assembly">Foundation.Kernel</patch:attribute>
				<patch:attribute name="type">Foundation.Kernel.DataViews.PipelineDrivenDataView</patch:attribute>
			</dataview>
		</dataviews>
		<moduleSettings>
			<foundation>
				<kernel>
					<pipelineDrivenDataViewSettings type="Foundation.Kernel.Models.DataViews.PipelineDrivenDataViewSettings, Foundation.Kernel" singleInstance="true">
						<PipelineDomain>masterDataView</PipelineDomain>
						<PipelineName>dataviewChildItems</PipelineName >
					</pipelineDrivenDataViewSettings>
				</kernel>
			</foundation>
		</moduleSettings>
		<pipelines>
			<group groupName="masterDataView" name="masterDataView">
				<pipelines>
					<dataviewChildItems>
					</dataviewChildItems>
				</pipelines>
			</group>
		</pipelines>
	</sitecore>
</configuration>

I wanted to abstract out the logic which determines if an Item has almost or too many child items as the project I was working on had more than one customization of the content editor to let content authors know it’s time to create a new folder for their items — dont worry I’ll blog about some of these in the future 😉 — so I defined the following interface for turning these individual bits of functionality on and off:

using Foundation.Kernel.Services.FeatureToggle;

namespace Foundation.Validation.Services.TooManySubItems
{
	public interface ITooManySubItemsFeatureToggleService
	{
		bool IsEnabled(IFeatureToggleable toggleable);
	}
}

Here’s the implementation of the IFeatureToggleable interface above — this is a service Config Object which will be the global settings object to turn on and off the entire feature set of these Content Editor customizations — and will be injected into the implementation of the ITooManySubItemsFeatureToggleService further below:

using Foundation.DependencyInjection;
using Foundation.DependencyInjection.Enums;

using Foundation.Kernel.Services.FeatureToggle;

namespace Foundation.Validation.Models.TooManySubItems
{
	[ServiceConfigObject(ConfigPath = "moduleSettings/foundation/validation/tooManySubItemsSettings ", Lifetime = Lifetime.Singleton)]
	public class TooManySubItemsSettings : IFeatureToggleable
	{
		public bool Enabled { get; set; }

		public int NumberOfItemsToStartWarningUser{ get; set; }

		public int MaximumNumberOfItemsInFolder { get; set; }
	}
}

The Config Object above also has values on the number of child items on when to start warning the content authors they have almost too many child items, and also a value on when there are too many child items.

I then defined the TooManySubItemsSettings Config Object in the Sitecore patch configuration file below:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/" xmlns:set="http://www.sitecore.net/xmlconfig/set/" xmlns:role="http://www.sitecore.net/xmlconfig/role/">
	<sitecore>
		<moduleSettings>
			<foundation>
				<validation>
					<tooManySubItemsSettings type="Foundation.Validation.Models.TooManySubItems.TooManySubItemsSettings, Foundation.Validation" singleInstance="true">
						<Enabled>true</Enabled>
						<!-- <MaximumNumberOfItemsInFolder> must be set and greater than zero in order for the feature to work.  In other words, default Sitecore functionality will execute
							when this isn't set (it's essentially like setting <Enabled>false</Enabled> above; you can't warn users they are approaching a maximum number of items in a folder
							when there is no maximum value set.
						-->
						<NumberOfItemsToStartWarningUser>2</NumberOfItemsToStartWarningUser>
						<MaximumNumberOfItemsInFolder>4</MaximumNumberOfItemsInFolder>
					</tooManySubItemsSettings>
				</validation>
			</foundation>
		</moduleSettings>
	</sitecore>
</configuration>

For testing, I set the values on when to warning content authors to a low number for testing but ideally, MaximumNumberOfItemsInFolder should be 100 child Items, and I chose 95 child Items for NumberOfItemsToStartWarningUser in the production version of this.

Now, we need an implementation of the ITooManySubItemsFeatureToggleService interface above. The following is just that:

using Foundation.Kernel.Services.FeatureToggle;

using Foundation.Validation.Models.TooManySubItems;
using Foundation.Validation.Services.TooManySubItems;

namespace Feature.Validation.Services.TooManySubItems
{
	public class TooManySubItemsFeatureToggleService : ITooManySubItemsFeatureToggleService
	{
		private readonly TooManySubItemsSettings _settings;
		private readonly IFeatureToggleService _featureToggleService;

		public TooManySubItemsFeatureToggleService(TooManySubItemsSettings settings, IFeatureToggleService featureToggleService)
		{
			_settings = settings;
			_featureToggleService = featureToggleService;
		}

		public bool IsEnabled(IFeatureToggleable toggleable) => _featureToggleService.IsEnabled(_settings, toggleable);
	}
}

The class above will delegate to the IFeatureToggleService instance to determine if the entire feature set of visual cues to the content authors should be turned on/off, or if an invidual piece of functionality should be turned on/off; each IFeatureToggleable will also pass itself to this service so that it can determine whether it should be turned on/off.

Most of the features I had built for this will warn content authors for when they are approaching too many child Items and also convey there are too many child items but there were a few where I only had to let content authors know when they had reached the maximum number of child Items under an item. Due to this, I broke all of these values out into the following interfaces:

namespace Foundation.Validation.Services.TooManySubItems
{
	public interface ITooManySubItemsMaxItemsInFolderFeature
	{
		int MaximumNumberOfItemsInFolder { get; set; }
	}
}

The above interface is only for features which will let the content authors know when they are reached too many child Items.

namespace Foundation.Validation.Services.TooManySubItems
{
	public interface ITooManySubItemsWarnUserFeature
	{
		int NumberOfItemsToStartWarningUser { get; set; }
	}
}

The ITooManySubItemsWarnUserFeature is only for features that will warn users that they approaching too many child Items.

using System.Collections.Generic;

namespace Foundation.Validation.Services.TooManySubItems
{
	public interface ITooManySubItemsFeature : ITooManySubItemsMaxItemsInFolderFeature, ITooManySubItemsWarnUserFeature
	{
		List<string> TemplateIdsToIgnore { get; set; }
	}
}

The above interface is an amalgam of the two interfaces above, and also includes a collection of Template IDs to ignore during the almost or has too many child Items check — I had included this in case there are reasons for ignoring certain child Items with certain templates but am not using this in this blog post.

Due to the need of passing a bunch of stuff to the service which determines that an Item has almost or too many child Items, I created the following parameters object class:

using System.Collections.Generic;

using Sitecore.Data.Items;

namespace Foundation.Validation.Models.TooManySubItems
{
	public class TooManySubItemsServiceParameters
	{
		public Item Item { get; set; }

		public int NumberOfItemsToStartWarningUser { get; set; }

		public int MaximumNumberOfItemsInFolder { get; set; }

		public List<string> TemplateIdsToIgnore { get; set; } = new List<string>();
	}
}

I then created a factory object to create TooManySubItemsServiceParameters instances above. The following is an interface for this service:

using System.Collections.Generic;

using Sitecore.Data.Items;

using Foundation.Validation.Models.TooManySubItems;

namespace Foundation.Validation.Services.TooManySubItems.Factories
{
	public interface ITooManySubItemsServiceParametersFactory
	{
		TooManySubItemsServiceParameters CreateParameters(TooManySubItemsCommandServiceParameters parameters); // not used in this post; I will discuss in a future post

		TooManySubItemsServiceParameters CreateParameters(Item item, ITooManySubItemsFeature feature);

		TooManySubItemsServiceParameters CreateParameters(Item item, int numberOfItemsToStartWarningUser, int maximumNumberOfItemsInFolder, List<string> templateIdsToIgnore);
	}
}

Here’s the implementation of the interface above:

using System.Collections.Generic;
using System.Linq;

using Sitecore.Data.Items;

using Foundation.Validation.Models.TooManySubItems;
using Foundation.Validation.Services.TooManySubItems;
using Foundation.Validation.Services.TooManySubItems.Factories;

namespace Feature.Validation.Services.TooManySubItems.Factories
{
	public class TooManySubItemsServiceParametersFactory : ITooManySubItemsServiceParametersFactory
	{
		// not used in this post; I will discuss in a future post
		public TooManySubItemsServiceParameters CreateParameters(TooManySubItemsCommandServiceParameters parameters) => CreateParameters(GetItem(parameters), 0, parameters.Feature.MaximumNumberOfItemsInFolder, parameters.TemplateIdsToIgnore);

		protected virtual Item GetItem(TooManySubItemsCommandServiceParameters parameters) => parameters?.Context.Items.FirstOrDefault();

		public TooManySubItemsServiceParameters CreateParameters(Item item, ITooManySubItemsFeature feature) => CreateParameters(item, feature.NumberOfItemsToStartWarningUser, feature.MaximumNumberOfItemsInFolder, feature.TemplateIdsToIgnore);

		public TooManySubItemsServiceParameters CreateParameters(Item item, int numberOfItemsToStartWarningUser, int maximumNumberOfItemsInFolder, List<string> templateIdsToIgnore)
		{
			return new TooManySubItemsServiceParameters
			{
				Item = item,
				NumberOfItemsToStartWarningUser = numberOfItemsToStartWarningUser,
				MaximumNumberOfItemsInFolder = maximumNumberOfItemsInFolder,
				TemplateIdsToIgnore = templateIdsToIgnore
			};
		}
	}
}

It’s basically just creating TooManySubItemsServiceParameters instances based on values passed.

We are ready to define the service which determines if an Item has almost or too many child Items. The following interface is for that service:

using Foundation.Validation.Models.TooManySubItems;

namespace Foundation.Validation.Services.TooManySubItems
{
	public interface ITooManySubItemsService
	{
		bool HasAlmostTooManySubItems(TooManySubItemsServiceParameters parameters);

		bool HasTooManySubItems(TooManySubItemsServiceParameters parameters);
	}
}

The following is the implementation of the interface defined above:

using System.Collections.Generic;
using System.Linq;

using Sitecore.Data.Items;

using Foundation.Validation.Models.TooManySubItems;
using Foundation.Validation.Services.TooManySubItems;

namespace Feature.Validation.Services.TooManySubItems
{
	public class TooManySubItemsService : ITooManySubItemsService
	{
		private readonly TooManySubItemsSettings _settings;

		public TooManySubItemsService(TooManySubItemsSettings settings)
		{
			_settings = settings;
		}

		public bool HasAlmostTooManySubItems(TooManySubItemsServiceParameters parameters)
		{
			int numberOfItemsToStartWarningUser = GetNumberOfItemsToStartWarningUser(parameters);
			int maximumNumberOfItemsInFolder = GetMaximumNumberOfItemsInFolder(parameters);
			if (parameters?.Item == null || numberOfItemsToStartWarningUser < 1 || maximumNumberOfItemsInFolder < 1)
			{
				return false;
			}

			IEnumerable<Item> items = GetItemsWithoutTemplateIds(parameters?.Item.Children, parameters?.TemplateIdsToIgnore);
			return items.Count() >= numberOfItemsToStartWarningUser && items.Count() < maximumNumberOfItemsInFolder;
		}

		public bool HasTooManySubItems(TooManySubItemsServiceParameters parameters)
		{
			int maximumNumberOfItemsInFolder = GetMaximumNumberOfItemsInFolder(parameters);
			if (parameters?.Item == null || maximumNumberOfItemsInFolder < 1)
			{
				return false;
			}

			IEnumerable<Item> items = GetItemsWithoutTemplateIds(parameters?.Item.Children, parameters?.TemplateIdsToIgnore);
			return items.Count() >= maximumNumberOfItemsInFolder;
		}

		protected virtual int GetNumberOfItemsToStartWarningUser(TooManySubItemsServiceParameters parameters)
		{
			if (parameters == null || _settings == null)
			{
				return 0;
			}

			if (parameters.NumberOfItemsToStartWarningUser > 0)
			{
				return parameters.NumberOfItemsToStartWarningUser;
			}

			return _settings.NumberOfItemsToStartWarningUser;
		}

		protected virtual int GetMaximumNumberOfItemsInFolder(TooManySubItemsServiceParameters parameters)
		{
			if (parameters == null || _settings == null)
			{
				return 0;
			}

			if (parameters.MaximumNumberOfItemsInFolder > 0)
			{
				return parameters.MaximumNumberOfItemsInFolder;
			}

			return _settings.MaximumNumberOfItemsInFolder;
		}

		protected virtual IEnumerable<Item> GetItemsWithoutTemplateIds(IEnumerable<Item> items, IEnumerable<string> templateIds)
		{
			if (items == null)
			{
				return Enumerable.Empty<Item>();
			}

			if(templateIds == null || !templateIds.Any())
			{
				return items;
			}

			return items.Where(item => templateIds.All(templateId => templateId != item.TemplateID.ToString())).ToList();
		}
	}
}

The HasAlmostTooManySubItems() method above determines if the passed Item has almost too many child items but not greater than or equal to the maximum number of child items as that check is governed by the HasTooManySubItems() method — it determines if the number of child items equals or exceeds the maximum number of child Items passed via the Parameters object; both of these methods only look at Items who do not have Template IDs which are in the TemplateIdsToIgnore list though we are not using this on this blog post.

Since we are modifying the appear of Item names in the Content Tree, I wanted to put markup for this in a nice place. I decided to use Handlebars.Net for this solution — in an earlier iteration of this project, I had this markup in a Sitecore configuration file all HTML encoded but it seemed like a cumbersome solution especially if the markup had to be changed so I went with this alternative approach instead as I had a good experience using Handlebars.Net over 2 years ago — but to my dismay, the current version of Handlebars.Net did not come with its OOTB ViewEngineFileSystem any longer as older versions had, so I had to create one myself. This required me to create the following service class for dealing with files but I’m ultimately just delegating to methods on Sitecore.IO.FileUtil (this lives in Sitecore.Kernel.dll) through this service:

namespace Foundation.Kernel.Services.IO
{
	public interface IFileUtilService
	{
		bool Exists(string path);

		string MakePath(string part1, string part2);

		string ReadFromFile(string path);
	}
}

The following implements the interface above but just delegates to methods on Sitecore.IO.FileUtil:

using Sitecore.IO;

namespace Foundation.Kernel.Services.IO
{
	public class FileUtilService : IFileUtilService
	{
		public bool Exists(string path) => FileUtil.Exists(path);

		public string MakePath(string part1, string part2) => FileUtil.MakePath(part1, part2);

		public string ReadFromFile(string path) => FileUtil.ReadFromFile(path);
	}
}

I then created a subclass of HandlebarsDotNet.ViewEngineFileSystem; this adapter class talks to the file system for HandlebarsDotNet:

using HandlebarsDotNet;

using Foundation.Kernel.Services.IO;

namespace Feature.Token.Services
{
	public class HandlebarsViewEngineFileSystem : ViewEngineFileSystem
	{
		private readonly IFileUtilService _fileUtilService;

		public HandlebarsViewEngineFileSystem(IFileUtilService fileUtilService)
		{
			_fileUtilService = fileUtilService;
		}

		public override bool FileExists(string filePath) => _fileUtilService.Exists(filePath);

		public override string GetFileContent(string filename) => _fileUtilService.ReadFromFile(filename);

		protected override string CombinePath(string dir, string otherFileName) => _fileUtilService.MakePath(dir, otherFileName);
	}
}

I then wrapped HandlebarsDotNet’s main static class in a service class so I can inject things together using DI. The following interface is for this service class:

using System;
using System.IO;

using HandlebarsDotNet;

namespace Feature.Token.Services
{
	public interface IHandlebarsService
	{
		Action<TextWriter, object> Compile(TextReader template);

		Func<object, string> Compile(string template);

		Func<object, string> CompileView(string templatePath);

		void RegisterHelper(string helperName, HandlebarsHelper helperFunction);

		void RegisterHelper(string helperName, HandlebarsBlockHelper helperFunction);

		void RegisterTemplate(string templateName, Action<TextWriter, object> template);

		void RegisterTemplate(string templateName, string template);
	}
}

We now need to implement the interface above:

using System;
using System.IO;

using HandlebarsDotNet;

namespace Feature.Token.Services
{
	public class HandlebarsService : IHandlebarsService
	{
		private ViewEngineFileSystem _viewEngineFileSystem;

		public HandlebarsService(ViewEngineFileSystem viewEngineFileSystem)
		{
			_viewEngineFileSystem = viewEngineFileSystem;
		}

		private readonly object _locker = new object();
		private IHandlebars _instance;
		private IHandlebars Instance
		{
			get
			{
				if(_instance  == null)
				{
					lock(_locker)
					{
						_instance = Create();
					}
				}

				return _instance;
			}
		}

		private IHandlebars Create(HandlebarsConfiguration configuration = null)
		{
			IHandlebars handlebars = Handlebars.Create(configuration);
			handlebars.Configuration.FileSystem = _viewEngineFileSystem;
			return handlebars;
		}

		public Action<TextWriter, object> Compile(TextReader template) => Instance.Compile(template);

		public Func<object, string> Compile(string template) => Instance.Compile(template);

		public Func<object, string> CompileView(string templatePath) => Instance.CompileView(templatePath);

		public void RegisterHelper(string helperName, HandlebarsHelper helperFunction) => Instance.RegisterHelper(helperName, helperFunction);

		public void RegisterHelper(string helperName, HandlebarsBlockHelper helperFunction) => Instance.RegisterHelper(helperName, helperFunction);

		public void RegisterTemplate(string templateName, Action<TextWriter, object> template) => Instance.RegisterTemplate(templateName, template);

		public void RegisterTemplate(string templateName, string template) => Instance.RegisterTemplate(templateName, template);
	}
}

I’m injecting the ViewEngineFileSystem service — this is an instance of the HandlebarsViewEngineFileSystem above but I stick it into the IoC contain with a service type of ViewEngineFileSystem — into this class so we can create a new IHandlebars instance using Handlebars’s Create() method, and then it gets stored in an internal Singleton in the class.

Next, we need a service to replace tokens (no, not Sitecore tokens such as $name, $id, etc) but tokens in handlebars template strings or files:

using System.Collections.Generic;

namespace Foundation.Token.Services
{
	public interface ITemplatedTokenReplacer
	{
		string ReplaceTokens(string input, IDictionary<string, string> tokens);

		string ReplaceTokens(string templateSource, object tokens);

		string ReplaceTokensFromView(string viewPath, IDictionary<string, string> tokens);

		string ReplaceTokensFromView(string viewPath, object tokens);

		void ClearAllCaches();

		void ClearTemplateCache();

		void ClearViewsCache();
	}
}

The implementation of the interface above will need to “cache” compiled Handlebars.Net templates as the documentation calls out that compiling their templates is an expensive operation and recommend caching these compilations so I am using the following interface to create services which cache things:

namespace Foundation.Kernel.Services.Cache
{
    public interface ICacher<TKey, TObject>
    {
        void Add(TKey key, TObject obj);

        bool ContainsKey(TKey key);

        TObject Get(TKey key);

        void Clear();
    }
}

Classes which implement this base class below will be caching their things in a ConcurrentDictionary:

using System.Collections.Concurrent;
using System.Collections.Generic;

namespace Foundation.Kernel.Services.Cache
{
    public abstract class Cacher<TKey, TObject>
    {
        private IDictionary<TKey, TObject> _cache;

        protected Cacher()
        {
            _cache = CreateCache();
        }

        protected virtual IDictionary<TKey, TObject> CreateCache() => new ConcurrentDictionary<TKey, TObject>();

        public void Add(TKey key, TObject obj) => _cache[key] = obj;

        public TObject Get(TKey key) => ContainsKey(key) ? _cache[key] : default(TObject);

        public bool ContainsKey(TKey key) => _cache.ContainsKey(key);

        public void Clear() => _cache.Clear();
    }
}

We will be caching compilations of Handlebars.Net template strings:

using System;

using Foundation.Kernel.Services.Cache;

namespace Feature.Token.Services.Cachers
{
	public interface ICompiledTemplateCache : ICacher<string, Func<object, string>>
	{
	}
}

using System;

using Foundation.Kernel.Services.Cache;

namespace Feature.Token.Services.Cachers
{
	public class CompiledTemplateCache : Cacher<string, Func<object, string>>, ICompiledTemplateCache
	{
	}
}

We will also be caching compilations of Handlebars.Net template strings sourced from files:

using System;

using Foundation.Kernel.Services.Cache;

namespace Feature.Token.Services.Cachers
{
	public interface ICompiledViewTemplateCache : ICacher<string, Func<object, string>>
	{
	}
}

using System;

using Foundation.Kernel.Services.Cache;

namespace Feature.Token.Services.Cachers
{
	public class CompiledViewTemplateCache : Cacher<string, Func<object, string>>, ICompiledViewTemplateCache
	{

	}
}

Finally, we can talk about the implemenation of ITemplatedTokenReplacer 😉 :

using System;
using System.Collections.Concurrent;
using System.Collections.Generic;
using System.IO;

using HandlebarsDotNet;

using Foundation.Token.Services;

using Feature.Token.Services.Cachers;

namespace Feature.Token.Services
{
	public class HandlebarsTokenReplacer : ITemplatedTokenReplacer
	{
		private readonly IHandlebarsService _handlebarsService;

		private readonly ICompiledTemplateCache _compiledTemplateCache;
		private readonly ICompiledViewTemplateCache _compiledViewTemplateCache;

		public HandlebarsTokenReplacer(IHandlebarsService handlebarsService, ICompiledTemplateCache compiledTemplateCache, ICompiledViewTemplateCache compiledViewTemplateCache)
		{
			_handlebarsService = handlebarsService;
			_compiledTemplateCache = compiledTemplateCache;
			_compiledViewTemplateCache = compiledViewTemplateCache;
		}

		public string ReplaceTokens(string input, IDictionary<string, string> tokens) => ReplaceTokens(input, (object)tokens);

		public string ReplaceTokens(string templateSource, object tokens)
		{
			var compiled = GetCompiledTemplateFromCache(templateSource);
			if (compiled == null)
			{
				compiled = Compile(templateSource);
				AddCompiledTemplateToCache(templateSource, compiled);
			}

			return ReplaceTokens(compiled, tokens);
		}

		protected virtual Func<object, string> GetCompiledTemplateFromCache(string templateSource) => _compiledTemplateCache.Get(templateSource);

		protected virtual Func<object, string> Compile(string viewPath) => _handlebarsService.Compile(viewPath);

		protected virtual void AddCompiledTemplateToCache(string templateSource, Func<object, string> compiled) => _compiledTemplateCache.Add(templateSource, compiled);

		protected virtual string ReplaceTokens(Func<object, string> template, object tokens)
		{
			if(template == null)
			{
				return string.Empty;
			}

			return template(tokens);
		}

		public string ReplaceTokensFromView(string viewPath, IDictionary<string, string> tokens) => ReplaceTokensFromView(viewPath, (object)tokens);

		public string ReplaceTokensFromView(string viewPath, object tokens)
		{
			var compiled = GetCompiledViewTemplateFromCache(viewPath);
			if(compiled == null)
			{
				compiled = CompileView(viewPath);
				AddCompiledViewTemplateToCache(viewPath, compiled);
			}

			return ReplaceTokens(compiled, tokens);
		}

		protected virtual Func<object, string> GetCompiledViewTemplateFromCache(string viewPath) => _compiledViewTemplateCache.Get(viewPath);

		protected virtual Func<object, string> CompileView(string viewPath) => _handlebarsService.CompileView(viewPath);

		protected virtual void AddCompiledViewTemplateToCache(string viewPath, Func<object, string> compiled) => _compiledViewTemplateCache.Add(viewPath, compiled);

		protected virtual Action<TextWriter, object> Compile(TextReader template) => _handlebarsService.Compile(template);

		protected virtual void RegisterHelper(string helperName, HandlebarsHelper helperFunction) => _handlebarsService.RegisterHelper(helperName, helperFunction);

		protected virtual void RegisterHelper(string helperName, HandlebarsBlockHelper helperFunction) => _handlebarsService.RegisterHelper(helperName, helperFunction);

		protected virtual void RegisterTemplate(string templateName, Action<TextWriter, object> template) => _handlebarsService.RegisterTemplate(templateName, template);

		protected virtual void RegisterTemplate(string templateName, string template) => _handlebarsService.RegisterTemplate(templateName, template);

		public void ClearAllCaches()
		{
			ClearTemplateCache();
			ClearViewsCache();
		}

		public void ClearTemplateCache() => _compiledTemplateCache.Clear();

		public void ClearViewsCache() => _compiledViewTemplateCache.Clear();
	}
}

Ultimately, the class above delegates calls to IHandlebarsService for the most part. Lookups are done to replace tokens in templates before compiling to see if these compilations were cached. If there were not cached, they are compiled and then cached. The resulting token replacement strings are returned for both template string replacements, and those sourced from template files.

I also have methods to clear the two caches.

Next, I created a custom FileWatcher to clear the Compile Views cache of Handlebars.Net template file compliations. Since FileWatchers are defined in the Web.config, I decided to create a service class which will control the logic which my cusotm FileWatcher will completely delegate its functionality to. The following interface is for that service class:

namespace Feature.Token.Services
{
	public interface IHandlebarsViewFilesWatcherService
	{
		void Created(string fullPath);

		void Deleted(string filePath);

		void Renamed(string filePath, string oldFilePath);
	}
}

The service class will take in a service Config Object defined in a Sitecore configuration file further below:

using Foundation.DependencyInjection;
using Foundation.DependencyInjection.Enums;

namespace Feature.Token.Models.FileWatchers
{
	[ServiceConfigObject(ConfigPath = "moduleSettings/feature/token/handlebarsViewFilesWatcherServiceSettings", Lifetime = Lifetime.Singleton)]
	public class HandlebarsViewFilesWatcherServiceSettings
	{
		public string CreatedLogInfoMessageFormat { get; set; }

		public string DeletedLogInfoMessageFormat { get; set; }

		public string RenamedLogInfoMessageFormat { get; set; }

		public string ClearViewsCacheLogInfoMessage { get; set; }
	}
}

Here is the implemenation of the interface above:

using Sitecore.Abstractions;

using Foundation.Token.Services;

using Feature.Token.Models.FileWatchers;

namespace Feature.Token.Services
{
	public class HandlebarsViewFilesWatcherService : IHandlebarsViewFilesWatcherService
	{
		private readonly HandlebarsViewFilesWatcherServiceSettings _settings;
		private readonly ITemplatedTokenReplacer _replacer;
		private readonly BaseLog _log;

		public HandlebarsViewFilesWatcherService(HandlebarsViewFilesWatcherServiceSettings settings, ITemplatedTokenReplacer replacer, BaseLog log)
		{
			_settings = settings;
			_replacer = replacer;
			_log = log;
		}

		public void Created(string fullPath)
		{
			LogInfo(string.Format(_settings.CreatedLogInfoMessageFormat, fullPath), this);
			ClearViewsCacheLogInfo();
		}

		public void Deleted(string filePath)
		{
			LogInfo(string.Format(_settings.DeletedLogInfoMessageFormat, filePath), this);
			ClearViewsCacheLogInfo();
		}

		public void Renamed(string filePath, string oldFilePath)
		{
			LogInfo(string.Format(_settings.RenamedLogInfoMessageFormat, filePath, oldFilePath), this);
			ClearViewsCacheLogInfo();
		}

		protected virtual void LogInfo(string message, object owner) => _log.Info(message, owner);

		protected virtual void ClearViewsCacheLogInfo()
		{
			ClearViewsCache();
			LogInfo(_settings.ClearViewsCacheLogInfoMessage, this);
		}

		protected virtual void ClearViewsCache() => _replacer.ClearViewsCache();
	}
}

If a Handlebars.Net template file is modified, added, renamed or deleted, the Handlebars.Net Views Cache is cleared so that changes will be reflected in the Content Tree immediately.

I then created the “real” FileWatcher class; this is the class which will be registered in my Web.config to make this work:

using Sitecore.DependencyInjection;
using Sitecore.IO;

using Feature.Token.Services;

namespace Feature.Token.FileWatchers
{
	public class HandlebarsViewFilesWatcher : FileWatcher
	{
		public HandlebarsViewFilesWatcher()
			: base("watchers/handlebars")
		{
		}

		protected override void Created(string fullPath) => GetService<IHandlebarsViewFilesWatcherService>().Created(fullPath);

		protected override void Deleted(string filePath) => GetService<IHandlebarsViewFilesWatcherService>().Deleted(filePath);

		protected override void Renamed(string filePath, string oldFilePath) => GetService<IHandlebarsViewFilesWatcherService>().Renamed(filePath, oldFilePath);

		protected TService GetService<TService>() where TService : class => ServiceLocator.ServiceProvider.GetService(typeof(TService)) as TService;
	}
}

With that in place, I defined it in my Web.config here:


  <!-- More stuff here -->

 <system.webServer>
    <modules runAllManagedModulesForAllRequests="true">

	  <!-- More stuff here -->

	  <!-- Handlerbars view files watcher -->
	  <add type="Feature.Token.FileWatchers.HandlebarsViewFilesWatcher, Feature.Token" name="HandlebarsViewFilesWatcher"/>

	    <!-- More stuff here -->
	</modules>
</system.webServer>

<!-- More stuff here -->

Now, we need a custom Sitecore patch configuration file to wire-up all of the services defined above for token replacement along with the settings object for the FileWatcher service:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/" xmlns:set="http://www.sitecore.net/xmlconfig/set/" xmlns:role="http://www.sitecore.net/xmlconfig/role/">
  <sitecore>
	  <moduleSettings>
		  <feature>
			  <token>
				  <handlebarsViewFilesWatcherServiceSettings type="Feature.Token.Models.FileWatchers.HandlebarsViewFilesWatcherServiceSettings, Feature.Token" singleInstance="true">
					  <CreatedLogInfoMessageFormat>Handlebars view file created or modified: {0}.</CreatedLogInfoMessageFormat>
					  <DeletedLogInfoMessageFormat>Handlebars view file deleted: {0}.</DeletedLogInfoMessageFormat>
					  <RenamedLogInfoMessageFormat>Handlebars view file renamed: {0}. Old path: {1}</RenamedLogInfoMessageFormat>
					  <ClearViewsCacheLogInfoMessage>Token Views Cache Cleared.</ClearViewsCacheLogInfoMessage>
				  </handlebarsViewFilesWatcherServiceSettings>
			  </token>
		  </feature>
	  </moduleSettings>
	  <services>
		  <register serviceType="Feature.Token.Services.IHandlebarsService, Feature.Token"
					implementationType="Feature.Token.Services.HandlebarsService, Feature.Token"
					lifetime="Singleton" />
		  <register serviceType="Foundation.Token.Services.ITemplatedTokenReplacer, Foundation.Token"
					implementationType="Feature.Token.Services.HandlebarsTokenReplacer, Feature.Token"
					lifetime="Singleton" />
		  <register serviceType="HandlebarsDotNet.ViewEngineFileSystem, Handlebars"
					implementationType="Feature.Token.Services.HandlebarsViewEngineFileSystem, Feature.Token"
					lifetime="Singleton" />
		  <register serviceType="Feature.Token.Services.IHandlebarsViewFilesWatcherService, Feature.Token"
					implementationType="Feature.Token.Services.HandlebarsViewFilesWatcherService, Feature.Token"
					lifetime="Singleton" />
		  <register serviceType="Feature.Token.Services.Cachers.ICompiledTemplateCache, Feature.Token"
					implementationType="Feature.Token.Services.Cachers.CompiledTemplateCache, Feature.Token"
					lifetime="Singleton" />
		  <register serviceType="Feature.Token.Services.Cachers.ICompiledViewTemplateCache, Feature.Token"
					implementationType="Feature.Token.Services.Cachers.CompiledViewTemplateCache, Feature.Token"
					lifetime="Singleton" />
	  </services>
	  <watchers>
		  <handlebars>
			  <folder>/Views</folder>
			  <filter>*.hbs</filter>
		  </handlebars>
	  </watchers>
  </sitecore>
</configuration>

Are you still with me? 😉

Now, let’s define some other service classes which just wrap static method calls on things in the Sitecore Api; I wanted to source these all from the Sitecore IoC container, and not all things in the Sitecore Api are in the IoC container so I’ll just stick them in there. I’m not going to explain too much about these except that they are used in subsequent classes further down:

This interface with its implemenation wraps calls on the Sitecore.Data.ID class:

using System;

using Sitecore.Data;

namespace Foundation.Kernel.Services.UniqueIdentifier
{
    public interface IIDService
    {
        bool IsNullOrEmpty(ID id);

        bool TryParse(string value, out ID id);

        bool TryParse(object value, out ID id);

        ID Parse(string value);

        ID Parse(object value);

        ID CreateNewID();

        ID CreateNewID(string id); // not used in this post

        ID CreateNewID(Guid id);  // not used in this post
    }
}

using System;

using Sitecore.Data;

using Foundation.Kernel.Services.UniqueIdentifier.Factories;

namespace Foundation.Kernel.Services.UniqueIdentifier
{
    public class IDService : IIDService
    {
        private readonly IIDFactory _idFactory;   // not used in this post

        public IDService(IIDFactory idFactory)
        {
            _idFactory = idFactory;   // not used in this post
        }

        public bool IsNullOrEmpty(ID id) => ID.IsNullOrEmpty(id);

        public bool TryParse(string value, out ID id) => ID.TryParse(value, out id);

        public bool TryParse(object value, out ID id) => ID.TryParse(value, out id);

        public ID Parse(string value) => ID.Parse(value);

        public ID Parse(object value) => ID.Parse(value);

        public ID CreateNewID() => _idFactory.CreateNewID();

        public ID CreateNewID(string id) => _idFactory.CreateNewID(id);   // not used in this post

        public ID CreateNewID(Guid id) => _idFactory.CreateNewID(id);   // not used in this post
    }
}

This interface with its implemenation creates a FieldList instance from a FieldCollection instance along with pointers to methods for changing field values being placed from the FieldCollection into a new FieldList instance (this will be used further down in this post when modifying how Items appear in the content tree):

using System;

using Sitecore.Collections;
using Sitecore.Data;
using Sitecore.Data.Fields;

namespace Foundation.Kernel.Services.Fields.Factories
{
	public interface IFieldsFactory
	{
		FieldList CreateNewFieldList(FieldCollection fieldCollection, Func<Field, ID> idProvider, Func<Field, string> valueProvider);

		FieldList CreateNewFieldList();
	}
}

using System;

using Sitecore.Collections;
using Sitecore.Data;
using Sitecore.Data.Fields;

namespace Foundation.Kernel.Services.Fields.Factories
{
	public class FieldsFactory : IFieldsFactory
	{
		public FieldList CreateNewFieldList(FieldCollection fieldCollection, Func<Field, ID> idProvider, Func<Field, string> valueProvider)
		{
			FieldList fieldList = CreateNewFieldList();
			foreach (Field field in fieldCollection)
			{
				ID id = idProvider(field);
				string value = valueProvider(field);
				fieldList.Add(id, value);
			}

			return fieldList;
		}

		public FieldList CreateNewFieldList() => new FieldList();
	}
}

This interface and its implementation wrap calls to Sitecore.Globalization.Translate:

namespace Foundation.Kernel.Services.Globalization
{
	public interface ITranslateService
	{
		string TranslateText(string key);
	}
}

namespace Foundation.Kernel.Services.Globalization
{
	public class TranslateService : ITranslateService
	{
		public string TranslateText(string key) => Sitecore.Globalization.Translate.Text(key);
	}
}

This interface and its implementation wrap calls to Sitecore.Resources.Images; this will be used when dealing with Icon paths:

using Sitecore.Web.UI;

namespace Foundation.Kernel.Services.Media.Resources
{
	public interface IImagesService
	{
		string GetThemedImageSource(string image);

		string GetThemedImageSource(string image, ImageDimension dimension);
	}
}

using Sitecore.Resources;
using Sitecore.Web.UI;

namespace Foundation.Kernel.Services.Media.Resources
{
	public class ImagesService : IImagesService
	{
		public string GetThemedImageSource(string image) => Images.GetThemedImageSource(image);

		public string GetThemedImageSource(string image, ImageDimension dimension) => Images.GetThemedImageSource(image, dimension);
	}
}

This interface and its implementation will create instances of the Item class but with modified values sourced from another Item instance — this is used when changing the Item name for display in the content tree, and these items are “temporary”:

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

namespace Foundation.Kernel.Services.Items.Factories
{
	public interface IItemFactory
	{
		Item CreateAlteredItem(Item item, string itemName, string iconPath, ID templateId, ID branchId, Language language, Version version);

		Item CreateNewItem(ID itemID, ItemData data, Database database, bool isTemporary);

		ItemDefinition CreateItemDefinition(ID itemID, string itemName, ID templateID, ID branchId);

		ItemData CreateItemData(ItemDefinition definition, Language language, Version version, FieldList fields);
	}
}

using System;

using Sitecore;
using Sitecore.Collections;
using Sitecore.Data;
using Sitecore.Data.Fields;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Foundation.Kernel.Services.Globalization;
using Foundation.Kernel.Services.Media.Resources;
using Foundation.Kernel.Services.UniqueIdentifier;
using Foundation.Kernel.Services.Fields.Factories;

namespace Foundation.Kernel.Services.Items.Factories
{
	public class ItemFactory : IItemFactory
	{
		private readonly IIDService _idService;
		private readonly IFieldsFactory _fieldsFactory;
		private readonly ITranslateService _translateService;
		private readonly IImagesService _imagesService;

		public ItemFactory(IIDService idService, IFieldsFactory fieldsFactory, ITranslateService translateService, IImagesService imagesService)
		{
			_idService = idService;
			_fieldsFactory = fieldsFactory;
			_translateService = translateService;
			_imagesService = imagesService;
		}

		public Item CreateAlteredItem(Item item, string itemName, string iconPath, ID templateId, ID branchId, Language language, Sitecore.Data.Version version)
		{
			if (item == null || IsNullOrEmpty(templateId))
			{
				return null;
			}

			ItemDefinition definition = CreateItemDefinition(item.ID, itemName, templateId, branchId);
			if (definition == null)
			{
				return null;
			}

			FieldList fields = CreateNewFieldList(item?.Fields, field => field.ID, field => GetAlteredItemFieldValue(field, itemName, iconPath));
			if (fields == null)
			{
				return null;
			}

			return CreateNewItem(item.ID, CreateItemData(definition, language, version, fields), item.Database, true);
		}

		protected virtual bool IsNullOrEmpty(ID id) => _idService.IsNullOrEmpty(id);

		protected virtual string GetAlteredItemFieldValue(Field field, string itemName, string iconPath)
		{
			string value = field.Value;
			if (field.ID == GetDisplayNameFieldId() && !string.IsNullOrWhiteSpace(itemName))
			{
				value = TranslateText(itemName);
			}
			else if (field.ID == GetIconFieldId() && !string.IsNullOrWhiteSpace(iconPath))
			{
				value = GetThemedImageSource(iconPath);
			}

			return value;
		}

		protected virtual ID GetDisplayNameFieldId() => FieldIDs.DisplayName;

		protected virtual ID GetIconFieldId() => FieldIDs.Icon;

		protected virtual string TranslateText(string key) => _translateService.TranslateText(key);

		protected virtual string GetThemedImageSource(string image) => _imagesService.GetThemedImageSource(image);

		protected virtual FieldList CreateNewFieldList(FieldCollection fieldCollection, Func<Field, ID> idProvider, Func<Field, string> valueProvider) => _fieldsFactory.CreateNewFieldList(fieldCollection, idProvider, valueProvider);

		public Item CreateNewItem(ID itemID, ItemData data, Database database, bool isTemporary)
		{
			return new Item(itemID, data, database)
			{
				RuntimeSettings = { Temporary = isTemporary }
			};
		}

		public ItemDefinition CreateItemDefinition(ID itemID, string itemName, ID templateID, ID branchId) => new ItemDefinition(itemID, itemName, templateID, branchId);

		public ItemData CreateItemData(ItemDefinition definition, Language language, Sitecore.Data.Version version, FieldList fields) => new ItemData(definition, language, version, fields);
	}
}

This interface and its implementation wrap calls to the Sitecore.Data.Version class:

using Sitecore.Data;

namespace Foundation.Kernel.Services.Versoning
{
	public interface IVersionService
	{
		Version GetLatestVersion();
	}
}

using Sitecore.Data;

namespace Foundation.Kernel.Services.Versoning
{
	public class VersionService : IVersionService
	{
		public Version GetLatestVersion() => Version.Latest;
	}
}

This interface and its implementation wrap calls to the Sitecore.Globalization.Language class:

using Sitecore;
using Sitecore.Globalization;

namespace Foundation.Kernel.Services.Globalization
{
    public interface ILanguageService
    {
        bool TryParse(string name, out Language result);

        Language Parse(string name);

        Language GetContextLanguage();

		Language GetLanguageInvariant();
	}
}

using Sitecore;
using Sitecore.Globalization;

namespace Foundation.Kernel.Services.Globalization
{
    public class LanguageService : ILanguageService
    {
        public bool TryParse(string name, out Language result) => Language.TryParse(name, out result);

        public Language Parse(string name) => Language.Parse(name);

        public Language GetContextLanguage() => Context.Language;

		public Language GetLanguageInvariant() => Language.Invariant;
	}
}

Let’s tie everything together in the following implentation of the DataViewChildItemsProcessor class defined towards the top of this post:

using System;
using System.Collections.Generic;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Foundation.Token.Services;

using Foundation.Kernel.Pipelines.DataViewChildItems;
using Foundation.Kernel.Services.FeatureToggle;
using Foundation.Kernel.Services.Items.Factories;
using Foundation.Kernel.Services.Versoning;
using Foundation.Kernel.Services.Globalization;

using Foundation.Validation.Services.TooManySubItems.Factories;
using Foundation.Validation.Services.TooManySubItems;
using Foundation.Validation.Models.TooManySubItems;

namespace Feature.ContentEditor.Pipelines.DataViewChildItems
{
	public class MediaItemTooManyChildItems : DataViewChildItemsProcessor, IMediaItemTooManyChildItems
	{
		private readonly ITooManySubItemsFeatureToggleService _tooManySubItemsFeatureToggleService;
		private readonly ITooManySubItemsServiceParametersFactory _tooManySubItemsServiceParametersFactory;
		private readonly ITooManySubItemsService _tooManySubItemsService;
		private readonly ITemplatedTokenReplacer _templatedTokenReplacer;
		private readonly IItemFactory _itemFactory;
		private readonly IVersionService _versionService;
		private readonly ILanguageService _languageService;

		private string MediaLibraryBasePath { get; set; }

		public List<string> TemplateIdsToIgnore { get; set; } = new List<string>();

		public int NumberOfItemsToStartWarningUser { get; set; }

		private string AlmostAtMaxiumIconPath { get; set; }

		private string AlmostAtMaxiumMessageViewPath { get; set; }

		public int MaximumNumberOfItemsInFolder { get; set; }

		private string AtMaxiumIconPath { get; set; }

		private string AtMaxiumMessageViewPath { get; set; }

		public MediaItemTooManyChildItems(IFeatureToggleService featureToggleService, ITooManySubItemsFeatureToggleService tooManySubItemsFeatureToggleService, ITooManySubItemsServiceParametersFactory tooManySubItemsServiceParametersFactory, ITooManySubItemsService tooManySubItemsService, ITemplatedTokenReplacer templatedTokenReplacer,  IItemFactory itemFactory, IVersionService versionService, ILanguageService languageService)
			: base(featureToggleService)
		{
			_tooManySubItemsFeatureToggleService = tooManySubItemsFeatureToggleService;
			_tooManySubItemsServiceParametersFactory = tooManySubItemsServiceParametersFactory;
			_tooManySubItemsService = tooManySubItemsService;
			_templatedTokenReplacer = templatedTokenReplacer;
			_itemFactory = itemFactory;
			_versionService = versionService;
			_languageService = languageService;
		}

		protected override bool ShouldExecute(DataViewChildItemsArgs args)
		{
			return IsMediaLibraryBasePathSet()
				&& HasRequiredParameters(args)
				&& IsInMediaLibrary(args?.Parent);
		}

		protected override bool IsEnabled() => _tooManySubItemsFeatureToggleService.IsEnabled(this);

		protected virtual bool IsMediaLibraryBasePathSet() => !string.IsNullOrWhiteSpace(GetMediaLibraryBasePath());

		protected virtual bool HasRequiredParameters(DataViewChildItemsArgs args) => args?.Parent != null && args?.Children != null;

		protected virtual bool HasAlmostTooManySubItems(TooManySubItemsServiceParameters parameters) => _tooManySubItemsService.HasAlmostTooManySubItems(parameters);

		protected virtual bool HasTooManySubItems(TooManySubItemsServiceParameters parameters) => _tooManySubItemsService.HasTooManySubItems(parameters);

		protected override void GetChildItems(DataViewChildItemsArgs args)
		{
			if (!HasRequiredParameters(args))
			{
				return;
			}

			for (int i = args.Children.Count - 1; i >= 0; i--)
			{
				Item child = args.Children[i];
				if(!IsInMediaLibrary(child) || IsMediaLibraryRootItem(child))
				{
					continue;
				}

				TooManySubItemsServiceParameters parameters = CreateParameters(child, this);
				bool hasAlmostTooManySubItems = HasAlmostTooManySubItems(parameters);
				bool hasTooManySubItems = HasTooManySubItems(parameters);
				if (!hasAlmostTooManySubItems && !hasTooManySubItems)
				{
					continue;
				}

				string itemName = string.Empty;
				string iconPath = string.Empty;
				if (hasAlmostTooManySubItems)
				{
					itemName = GetAlmostAtMaxiumMessage(child, GetAlmostAtMaxiumIconPath());
				}
				else if (hasTooManySubItems)
				{
					itemName = GetAtMaxiumMessage(child, GetAtMaxiumIconPath());
				}

				Item alteredItem = GetAlteredItem(child, itemName, iconPath, child.TemplateID);
				if(alteredItem == null)
				{
					return;
				}

				args.Children.RemoveAt(i);
				args.Children.Insert(i, alteredItem);
			}
		}

		protected virtual bool IsInMediaLibrary(Item item)
		{
			string mediaLibraryBasePath = GetMediaLibraryBasePath();
			if (item == null || string.IsNullOrWhiteSpace(mediaLibraryBasePath))
			{
				return false;
			}

			return item.Paths.FullPath.StartsWith(mediaLibraryBasePath, StringComparison.OrdinalIgnoreCase);
		}

		protected virtual bool IsMediaLibraryRootItem(Item item)
		{
			string mediaLibraryBasePath = GetMediaLibraryBasePath();
			if (item == null || string.IsNullOrWhiteSpace(mediaLibraryBasePath))
			{
				return false;
			}

			return item.Paths.FullPath.Equals(mediaLibraryBasePath, StringComparison.OrdinalIgnoreCase);
		}

		protected virtual string GetMediaLibraryBasePath() => MediaLibraryBasePath;

		protected virtual TooManySubItemsServiceParameters CreateParameters(Item item, ITooManySubItemsFeature feature) => _tooManySubItemsServiceParametersFactory.CreateParameters(item, feature);

		protected virtual string GetAlmostAtMaxiumIconPath() => AlmostAtMaxiumIconPath;

		protected virtual string GetAtMaxiumIconPath() => AtMaxiumIconPath;

		protected virtual string GetAlmostAtMaxiumMessage(Item item, string iconPath) => ReplaceTokensFromView(GetAlmostAtMaxiumMessageViewPath(), new { ItemName = item.Name, IconPath = iconPath, ChildItemsCount = GetChildItemsCount(item) });

		protected virtual string GetAlmostAtMaxiumMessageViewPath() => AlmostAtMaxiumMessageViewPath;

		protected virtual string GetAtMaxiumMessage(Item item, string iconPath) => ReplaceTokensFromView(GetAtMaxiumMessageViewPath(), new { ItemName = item.Name, IconPath = iconPath, ChildItemsCount = GetChildItemsCount(item) });

		protected virtual string GetAtMaxiumMessageViewPath() => AtMaxiumMessageViewPath;

		protected virtual int GetChildItemsCount(Item item) => item.Children.Count;

		protected virtual string ReplaceTokensFromView(string viewPath, object tokens) => _templatedTokenReplacer.ReplaceTokensFromView(viewPath, tokens);

		protected virtual Item GetAlteredItem(Item item, string itemName, string iconPath, ID templateId) => CreateAlteredItem(item, itemName, iconPath, templateId, ID.Null, GetLanguageInvariant(), GetLatestVersion());

		protected virtual Item CreateAlteredItem(Item item, string itemName, string iconPath, ID templateId, ID branchId, Language language, Sitecore.Data.Version version) => _itemFactory.CreateAlteredItem(item, itemName, iconPath, templateId, branchId, language, version);

		protected virtual Language GetLanguageInvariant() => _languageService.GetLanguageInvariant();

		protected virtual Sitecore.Data.Version GetLatestVersion() => _versionService.GetLatestVersion();
	}
}

I’m not going to explain this entire class as there’s a lot of service delegation happening here but the gist is we will only create an “altered” item when the item in the Children collection on the DataViewChildItemsArgs instance is in the media library, and has almost, or does have too many child items. We then replace the child item in the DataViewChildItemsArgs Children collection with the “altered” item whose name includes the original item’s name and the icon associated with “almost has too many child items” or “has too many child items”; these are retrieved from their respective methods.

I then registered the pipeline processor above in the Sitecore configuration patch file below:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/" xmlns:set="http://www.sitecore.net/xmlconfig/set/" xmlns:role="http://www.sitecore.net/xmlconfig/role/">
	<sitecore>
		<pipelines>
			<group name="masterDataView">
				<pipelines>
					<dataviewChildItems>
						<processor type="Feature.ContentEditor.Pipelines.DataViewChildItems.IMediaItemTooManyChildItems, Feature.ContentEditor" resolve="true">
							<Enabled>true</Enabled>
							<AbortPipelineAfterExecution>false</AbortPipelineAfterExecution>
							<MediaLibraryBasePath>/sitecore/media library/</MediaLibraryBasePath>
							<AlmostAtMaxiumIconPath>-/icon/Applicationsv2/16x16/sign_warning.png</AlmostAtMaxiumIconPath>
							<AtMaxiumIconPath>-/icon/Apps/16x16/Stop.png</AtMaxiumIconPath>
							<AlmostAtMaxiumMessageViewPath>/Views/DataViewChildItems/MediaItemTooManyChildItems/AlmostAtMaxiumMessageTemplate.hbs</AlmostAtMaxiumMessageViewPath>
							<AtMaxiumMessageViewPath>/Views/DataViewChildItems/MediaItemTooManyChildItems/AtMaxiumMessageTemplate.hbs</AtMaxiumMessageViewPath>
							<!-- By setting these, you can override the default values set for the entire feature set
										<NumberOfItemsToStartWarningUser>95</NumberOfItemsToStartWarningUser>
										<MaximumNumberOfItemsInFolder>100</MaximumNumberOfItemsInFolder>
							-->
						</processor>
					</dataviewChildItems>
				</pipelines>
			</group>
		</pipelines>
		<services>
			<register
				serviceType="Feature.ContentEditor.Pipelines.DataViewChildItems.IMediaItemTooManyChildItems, Feature.ContentEditor"
				implementationType="Feature.ContentEditor.Pipelines.DataViewChildItems.MediaItemTooManyChildItems, Feature.ContentEditor"
				lifetime="Singleton" />
		</services>
	</sitecore>
</configuration>

This is what’s inside of /Views/DataViewChildItems/MediaItemTooManyChildItems/AlmostAtMaxiumMessageTemplate.hbs; this a Handlebars.Net template file:

{{ItemName}}&nbsp;<img src="{{IconPath}}" />&nbsp;<span style="color: #999900;">({{ChildItemsCount}} child items)</span>

This is what’s inside of /Views/DataViewChildItems/MediaItemTooManyChildItems/AtMaxiumMessageTemplate.hbs; this a Handlebars.Net template file:

{{ItemName}}&nbsp;<img src="{{IconPath}}" />&nbsp;<span style="color: red;">({{ChildItemsCount}} child items)</span>

Let’s have a look at what this does. The following is what the tree in my Media Library looks like with this turned on:

One thing I want to point out is that I have not rigorously tested this solution so use at your own risk.

Also, after discussing this solution with Sitecore MVPs Akshay Sura and Kamruz Jaman, Akshay brought up a great idea of having a custom MasterDataView being driving by the Sitecore Rules Engine. I thought it was a great idea, and maybe some day in the future I might blog about this but, honestly, I think this might be something that you, my dear reader, should have a stab at, and give back to the community if you find such a solution.

Until next time, keep on Sitecoring.

Magically Register Sitecore Configuration Objects in the Sitecore IoC Container using a custom Attribute

05/16/2020 11:43 / Leave a comment

About a year and half ago, Sitecore MVP Alan Coates blogged about having Sitecore Configuration Objects (aka Config Objects) being sourced from the Sitecore IoC container, and then injected into service classes that need them. He did this on a theme of Helix Principles but in reality, the ability to create Config Objects has existed since the Configuration Factory was released on version 6.x — don’t ask me which exact version the Configuration Factory was released as this was many projects, many grey hairs, and many country moves ago albeit it’s not something new (you can search through some of my vintage blog posts all the way back to the beginning where I have used these), and the ability to stick these into the Sitecore IoC container has existed since version 8.2 — this is when Sitecore rolled out its IoC container with native Dependency Injection support.

However, he was correct on the statement that it is something which is often overlooked as I continue to ¯\_(ツ)_/¯ (/shrug on Slack 😉 ) — or maybe even (ノಠ益ಠ)ノ彡┻━┻ — when I see solutions where everyone dumps everything configuration-driven in a Sitecore setting. I hope this blog post will further reinforce the practice of employing config objects in your solutions — or hopefully make the Sitecore settings junkies adopt this alternative approach instead — especially when I’m going to discuss how I’ve been wiring-up these config objects into the Sitecore IoC container using a custom Attribute decorating classes which represent these Config Objects along with a Foundation layer module configurator to put these into the IoC container; this is an approach I have been doing for the past 2 years.

Virtually all of my posts in 2018 — see my last post of 2018 for an example — created and stuck Config Objects into the IoC container for injection into servlice classes where needed. I had done all of these using code which created and registered these into the IoC container in a Configurator for a particular Helix layer module. At the time, it felt a bit awkward to me as I felt the knowledge of the configuration path to these was a bit removed from the classes which represent these objects, so I came up with the following way to define these configuration paths closer to the class definitions of the Config Objects (you can’t really get any closer than having the path be somewhere on the class, and this is done through a custom Attribute).

First, we need to custom Attribute which will decorate classes which represent the Config Objects:

using System;

using Foundation.DependencyInjection.Enums;

namespace Foundation.DependencyInjection
{
    [AttributeUsage(AttributeTargets.Class, Inherited = false)]
    public class ServiceConfigObjectAttribute : Attribute
    {
        public Lifetime Lifetime { get; set; } = Lifetime.Singleton;

		public string ConfigPath { get; set; }

		public Type ServiceType { get; set; }
	}
}

This solution involves assembly scanning using wildcards. I adapted Kam Figy‘s solution around registering MvC Controllers into the IoC container (see the end of https://kamsar.net/index.php/2016/08/Dependency-Injection-in-Sitecore-8-2/ for this) to make some of this magic happen but created a class with interface to abstract some of this out:

using System.Collections.Generic;
using System.Reflection;

namespace Foundation.DependencyInjection.Services.Assemblies
{
    public interface IAssemblyRepository
    {
        IEnumerable<Assembly> GetAssemblies(IEnumerable<string> assemblyFilters);

        IEnumerable<Assembly> GetAssemblies();

        Assembly GetCallingAssembly();
    }
}

using System;
using System.Linq;
using System.Reflection;
using System.Collections.Generic;
using System.Text.RegularExpressions;

namespace Foundation.DependencyInjection.Services.Assemblies
{
    public class AssemblyRepository : IAssemblyRepository
    {
        public IEnumerable<Assembly> GetAssemblies(IEnumerable<string> assemblyFilters)
        {
            var assemblyNames = new HashSet<string>(assemblyFilters.Where(filter => !filter.Contains('*')));
            var wildcardNames = assemblyFilters.Where(filter => filter.Contains('*')).ToArray();

            return GetAssemblies().Where(assembly =>
            {
                var nameToMatch = assembly.GetName().Name;
                if (assemblyNames.Contains(nameToMatch)) return true;

                return wildcardNames.Any(wildcard => IsWildcardMatch(nameToMatch, wildcard));
            }).ToList();
        }

        protected virtual bool IsWildcardMatch(string input, string wildcards)
        {
            return Regex.IsMatch(input, "^" + Regex.Escape(wildcards).Replace("\\*", ".*").Replace("\\?", ".") + "$", RegexOptions.IgnoreCase);
        }

        public IEnumerable<Assembly> GetAssemblies() => AppDomain.CurrentDomain.GetAssemblies();

        public Assembly GetCallingAssembly() => Assembly.GetCallingAssembly();
    }
}

The class above returns a collection of Assemblies which match a collection of wildcards passed to it.

I then created a factory class with interface to create the class instance above:

namespace Foundation.DependencyInjection.Services.Assemblies.Factories
{
    public interface IAssemblyRepositoryFactory
    {
        IAssemblyRepository CreateAssemblyRepository();
    }
}

namespace Foundation.DependencyInjection.Services.Assemblies.Factories
{
    public class AssemblyRepositoryFactory : IAssemblyRepositoryFactory
    {
        public IAssemblyRepository CreateAssemblyRepository() => new AssemblyRepository();
    }
}

The class above has a method which creates the instance of the AssemblyRepository class instance as its interface.

Next, I create an enumeration to define the lifetimes of the service classes — I can’t think of a reason why you would want these Config Objects to be anything but a Singleton but who knows, you might have a reason:

namespace Foundation.DependencyInjection.Enums
{
    public enum Lifetime
    {
        Transient,
        Singleton,
        Scoped
    }
}

Following this, I created some Extension Methods of IServiceCollection so I can find all classes decorated with the ServiceConfigObjectAttribute class defined above; use the Sitecore Configuration Factory service to create their instances; and register them in the IoC container with the appropriate service type — if none is provided, it’ll use the class type — and lifetime defined:

using System;
using System.Collections.Generic;
using System.Globalization;
using System.Linq;
using System.Reflection;
using System.Runtime.CompilerServices;
using System.Web.Http;
using System.Web.Mvc;

using Microsoft.Extensions.DependencyInjection;

using Sitecore.Abstractions;

using Foundation.DependencyInjection.Enums;
using Foundation.DependencyInjection.Services.Assemblies;
using Foundation.DependencyInjection.Services.Assemblies.Factories;

namespace Foundation.DependencyInjection.Extensions
{
    public static class ServiceCollectionExtensions
    {
		private static readonly IAssemblyRepository _assemblyRepository;

        static ServiceCollectionExtensions()
        {
            _assemblyRepository = CreateAssemblyRepository();
        }

        private static IAssemblyRepository CreateAssemblyRepository() => CreateAssemblyRepositoryFactory()?.CreateAssemblyRepository();

        private static IAssemblyRepositoryFactory CreateAssemblyRepositoryFactory() => new AssemblyRepositoryFactory();

		public static void AddClassesWithServiceConfigObjectAttribute(this IServiceCollection serviceCollection, params string[] assemblyFilters)
		{
			var assemblies = GetAssemblies(assemblyFilters);
			serviceCollection.AddClassesWithServiceConfigObjectAttribute(assemblies);
		}

		public static Assembly[] GetAssemblies(IEnumerable<string> assemblyFilters) => _assemblyRepository.GetAssemblies(assemblyFilters)?.ToArray();

		public static void AddClassesWithServiceConfigObjectAttribute(this IServiceCollection serviceCollection, params Assembly[] assemblies)
        {
            var typesWithAttributes = assemblies
                .Where(assembly => !assembly.IsDynamic)
                .SelectMany(GetExportedTypes)
                .Where(type => !type.IsAbstract && !type.IsGenericTypeDefinition)
                .Select(type => new { type.GetCustomAttribute<ServiceConfigObjectAttribute>()?.ServiceType, ImplementationType = type, type.GetCustomAttribute<ServiceConfigObjectAttribute>()?.ConfigPath, type.GetCustomAttribute<ServiceConfigObjectAttribute>()?.Lifetime })
                .Where(t => t.Lifetime != null);

            foreach (var type in typesWithAttributes)
            {
                AddConfigObject(serviceCollection, type.ServiceType == null ? type.ImplementationType : type.ServiceType, type.Lifetime.Value, type.ConfigPath);
            }
        }

		private static void AddConfigObject(IServiceCollection serviceCollection, Type serviceType, Lifetime lifetime, string configPath)
        {
            if (serviceCollection == null || serviceType == null || string.IsNullOrWhiteSpace(configPath))
            {
                return;
            }

            serviceCollection.Add(CreateServiceDescriptor(serviceType, provider => CreateConfigObject(provider, configPath), GetServiceLifetime(lifetime)));
        }

		private static ServiceDescriptor CreateServiceDescriptor(Type serviceType, Func<IServiceProvider, object> factory, ServiceLifetime lifetime) => new ServiceDescriptor(serviceType, factory, lifetime);

		private static object CreateConfigObject(IServiceProvider provider, string configPath)
        {
            BaseFactory factory = provider.GetService<BaseFactory>();
            return factory.CreateObject(configPath, true);
        }

		private static ServiceLifetime GetServiceLifetime(Lifetime lifetime)
        {
            if (lifetime == Lifetime.Singleton)
            {
                return ServiceLifetime.Singleton;
            }

            if (lifetime == Lifetime.Transient)
            {
                return ServiceLifetime.Transient;
            }

            return ServiceLifetime.Transient;
        }
	}
}

Now, we need to have a configurator to call the extension method in the class above. I first defined a base configurator which will have a method to return the assembly wildcards — it’s virtual just in case you need to target different assemblies (I’m sure there’s a better place to put these wildcards but I stuck them here for now):

namespace Foundation.DependencyInjection.Configurators
{
    public abstract class BaseAssemblyFiltersServicesConfigurator : IServicesConfigurator
    {
		private static readonly string[] _defaultAssemblyFilters = new string[] { "Foundation.*", "Feature.*" };

		protected virtual string[] GetAssemblyFilters() => _defaultAssemblyFilters;
    }
}

The following configurator inherits the base configurator above, and just calls the AddClassesWithServiceConfigObjectAttribute() extension method defined in the ServiceCollectionExtensions class above, and passes the assembly wildcard collection defined in the BaseAssemblyFiltersServicesConfigurator class above:

using Microsoft.Extensions.DependencyInjection;

using Foundation.DependencyInjection.Extensions;

namespace Foundation.DependencyInjection.Configurators
{
    public class ServiceConfigObjectAttributeServicesConfigurator : BaseAssemblyFiltersServicesConfigurator
	{
		public override void Configure(IServiceCollection serviceCollection) => serviceCollection.AddClassesWithServiceConfigObjectAttribute(GetAssemblyFilters());
	}
}

I then registered the configurator above in a Sitecore patch configuration file:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/" xmlns:set="http://www.sitecore.net/xmlconfig/set/" xmlns:role="http://www.sitecore.net/xmlconfig/role/">
  <sitecore>
    <services>
        <configurator type= "Foundation.DependencyInjection.Configurators.ServiceConfigObjectAttributeServicesConfigurator, Foundation.DependencyInjection"/>
    </services>
  </sitecore>
</configuration>

Alright, now that we have all of this out of the way, let’s see how we can use all of the stuff above.

I created all of the following for a future blog post — and also for a project I had recently worked on — but I’ll show these now to demonstrate how this all works, and to also save me time on writing that future post 😉

The following class is a Config Object which has the name of a Sheer UI client command, and a delay value for that command to be invoked inside the Sitecore client:

using Foundation.DependencyInjection;
using Foundation.DependencyInjection.Enums;

namespace Foundation.Kernel.Models.Client
{
	[ServiceConfigObject(ConfigPath = "moduleSettings/foundation/kernel/clientServiceSettings", Lifetime = Lifetime.Singleton)]
	public class ClientServiceSettings
	{
		public string LoadItemClientCommandName { get; set; }

		public int LoadItemClientCommandDelay { get; set; }
	}
}

Here’s what it looks like in a Sitecore patch configuration file:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/" xmlns:set="http://www.sitecore.net/xmlconfig/set/" xmlns:role="http://www.sitecore.net/xmlconfig/role/">
  <sitecore>
	  <moduleSettings>
		  <foundation>
			  <kernel>
				  <clientServiceSettings type="Foundation.Kernel.Models.Client.ClientServiceSettings, Foundation.Kernel" singleInstance="true">
					  <LoadItemClientCommandName>item:load</LoadItemClientCommandName>
					  <LoadItemClientCommandDelay>1</LoadItemClientCommandDelay>
				  </clientServiceSettings>
			  </kernel>
		  </foundation>
	  </moduleSettings>
  </sitecore>
</configuration>

Let’s define another Config Object but something which is a little more “complex” than the example above.

I created the following class to represent a Sheer UI command — ultimately, these will be stored in a Dictionary so I can find a command format by key:

namespace Foundation.Kernel.Models.Client
{
	public class Command
	{
		public string Name { get; set; }

		public string CommandFormat { get; set; }
	}
}

Next, I need a service type/implementation to manage Command class instances above, and ultimately wrap a Dictionary containing information for these Commands:

using Foundation.Kernel.Models.Client;

namespace Foundation.Kernel.Services.Client
{
	public interface IClientCommandService
	{
		string GetClientCommand(string name, params string[] arguments);

		Command GetCommand(string name);
	}
}

Here’s the implementation of the interface above:

using System.Collections.Generic;

using Foundation.DependencyInjection;
using Foundation.DependencyInjection.Enums;

using Foundation.Kernel.Models.Client;

namespace Foundation.Kernel.Services.Client
{
	[ServiceConfigObject(ConfigPath = "moduleSettings/foundation/kernel/clientCommandService ", ServiceType = typeof(IClientCommandService), Lifetime = Lifetime.Singleton)]
	public class ClientCommandService : IClientCommandService
	{
		private readonly IDictionary<string, Command> _commands = new Dictionary<string, Command>();

		protected void AddClientCommand(string key, Command command)
		{
			if(string.IsNullOrWhiteSpace(key) || command == null)
			{
				return;
			}

			_commands[key] = command;
		}

		public string GetClientCommand(string name, params string[] arguments)
		{
			string commandFormat = GetCommandFormat(name);
			if(string.IsNullOrWhiteSpace(commandFormat))
			{
				return string.Empty;
			}

			return string.Format(commandFormat, arguments);
		}

		protected virtual string GetCommandFormat(string name) => GetCommand(name)?.CommandFormat;

		public Command GetCommand(string name) => _commands[name];
	}
}

So if I were to call the GetClientCommand() method on the service class above like this:

IClientCommandService clientCommandService; // make pretend this was injected in a class that's using it
clientCommandService.GetClientCommand("item:load") // this would return item:load(id={0}) so that we can do a string.Format() on it while providing an Item ID (this is used to load (or reload) an Item in the Content Editor

We would get a item:load(id={0}) so that we could supply an Item ID to replace {0}.

Here’s the Sitecore patch configuration file which represents the Config Object above:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/" xmlns:set="http://www.sitecore.net/xmlconfig/set/" xmlns:role="http://www.sitecore.net/xmlconfig/role/">
  <sitecore>
	  <services>
		  <configurator type="Foundation.Kernel.Configurators.KernelConfigurator, Foundation.Kernel"/>
	  </services>
	  <moduleSettings>
		  <foundation>
			  <kernel>
				  <clientCommandService type="Foundation.Kernel.Services.Client.ClientCommandService, Foundation.Kernel" singleInstance="true">
					  <Commands hint="list:AddClientCommand">
						  <command key="item:load" type="Foundation.Kernel.Models.Client.Command, Foundation.Kernel">
							  <Name>$(key)</Name>
							  <CommandFormat>item:load(id={0})</CommandFormat>
						  </command>
					  </Commands>
				  </clientCommandService>
			  </kernel>
		  </foundation>
	  </moduleSettings>
  </sitecore>
</configuration>

Here’s what both Config Objects looking like on /sitecore/admin/showservicesconfig.aspx after all the code above runs:

Now that the two configuration objects are in the IoC container, we can inject them into the follow service. Here’s the interface of that service:

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Web.UI.HtmlControls;

namespace Foundation.Kernel.Services.Client
{
	public interface IClientService
	{
		void RefreshItem(Item item);

		void RefreshItem(ID itemId);

		ClientCommand Timer(string eventName, int delay);

		void Alert(string message);
	}
}

Here’s the implementation the service:

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Web.UI.HtmlControls;

using Foundation.Kernel.Services.Client.SheerUI;
using Foundation.Kernel.Services.UniqueIdentifier;
using Foundation.Kernel.Models.Client;

namespace Foundation.Kernel.Services.Client
{
	public class ClientService : IClientService
	{
		private readonly ClientServiceSettings _settings;
		private readonly IIDService _idService;
		private readonly ISheerResponseService _sheerResponseService;
		private readonly IClientCommandService _clientCommandService;
		private readonly IClientResponseService _clientResponseService;

		public ClientService(ClientServiceSettings settings, IIDService idService, ISheerResponseService sheerResponseService, IClientCommandService clientCommandService, IClientResponseService clientResponseService)
		{
			_settings = settings; // config object was injected here
			_idService = idService;
			_sheerResponseService = sheerResponseService;
			_clientCommandService = clientCommandService; // another config object injected here
			_clientResponseService = clientResponseService;
		}

		public void RefreshItem(Item item) => RefreshItem(item?.ID);

		public void RefreshItem(ID itemId)
		{
			if(IsNullOrEmpty(itemId))
			{
				return;
			}

			string command = GetClientCommand(GetLoadItemClientCommandName(), itemId.ToString());
			if(string.IsNullOrWhiteSpace(command))
			{
				return;
			}

			Timer(command, GetLoadItemClientCommandDelay());
		}

		protected virtual bool IsNullOrEmpty(ID id) => _idService.IsNullOrEmpty(id);

		protected virtual string GetLoadItemClientCommandName() => _settings.LoadItemClientCommandName;

		protected virtual string GetClientCommand(string name, params string[] arguments) => _clientCommandService.GetClientCommand(name, arguments);

		protected virtual int GetLoadItemClientCommandDelay() => _settings.LoadItemClientCommandDelay;

		public ClientCommand Timer(string eventName, int delay) => _clientResponseService.Timer(eventName, delay);

		public void Alert(string message) => _sheerResponseService.Alert(message);
	}
}

The class above consumes instances of the ClientServiceSettings and IClientCommandService Config Objects along with other injected services which I am omitting for brevity – I believe I may have covered these other service classes in previous blog posts, and may cover some others in future blog posts — but the basic idea of this class is to wrap methods to functionality of Sheer UI to send Alert messages, refresh an item in the content tree of the Contend Editor, or to invoke another client command (via the Timer() method).

Most of my posts moving forward will use the ServiceConfigObjectAttribute above so be sure to understand what’s going on here in order to fully know what’s going on in those future posts.

magic

Service Locate or Create Objects Defined in a Fully Qualified Type Name Field in Sitecore

05/28/2018 17:09 / Leave a comment

<TL;DR>

This is — without a doubt — the longest blog post I have ever written — and hopefully to ever write as it nearly destroyed me 😉 — so will distill the main points in this TL;DR synopsis.

Most bits in Sitecore Experience Forms use objects/service class instances sourced from the Sitecore IoC container but not all. Things not sourced from the Sitecore IoC container are defined on Items in the following folders:

Why?

¯\_(ツ)_/¯

This is most likely due to their fully qualified type names being defined in a type field on Items contained in these folders, and sourcing these from the Sitecore IoC is not a thing OOTB in Sitecore as far as I am aware (reflection is used to create them):

Moreover, this is the same paradigm found in Web Forms for Marketers (WFFM) for some of its parts (Save Actions are an example).

Well, this paradigm bothers me a lot — I strongly feel that virtually everything should be sourced from the Sitecore IoC container as it promotes SOLID principles, a discussion I will leave for another time — so went ahead and built a system of Sitecore pipelines and service classes to:

Get the fully qualified type name string out of a field of an Item.
Resolve the Type from the string from #1.
Try to find the Type in the Sitecore IoC container using Service Locator (before whinging about using Service Locator for this, keep in mind that it would be impossible to inject everything from the IoC container into a class instance’s constructor in order to find it). If found, return to the caller. Otherwise, proceed to #4.
Create an instance of the Type using Reflection. Return the result to the caller.

Most of the code in the solution that follows are classes which serve as custom pipeline processors for 5 custom pipelines. Pipelines in Sitecore — each being an embodiment of the chain-of-responsibility pattern — are extremely flexible and extendable, hence the reason for going with this approach.

I plan on putting this solution up on GitHub in coming days (or weeks depending on timing) so it is more easily digestible than in a blost post. For now, Just have a scan of the code below.

Note: This solution is just a Proof of concept (PoC). I have not rigorously tested this solution; have no idea what its performance is nor the performance impact it may have; and definitely will not be held responsible if something goes wrong if you decided to use this code in any of your solutions. Use at your own risk!

</TL;DR>

Now that we have that out of the way, let’s jump right into it.

I first created the following abstract class to serve as the base for all pipeline processors in this solution:

using Sitecore.Pipelines;

namespace Sandbox.Foundation.ObjectResolution.Pipelines
{
	public abstract class ResolveProcessor<TPipelineArgs> where TPipelineArgs : PipelineArgs
	{
		public void Process(TPipelineArgs args)
		{
			if (!CanProcess(args))
			{
				return;
			}

			Execute(args);
		}

		protected virtual bool CanProcess(TPipelineArgs args) => args != null;

		protected virtual void AbortPipeline(TPipelineArgs args) => args?.AbortPipeline();

		protected virtual void Execute(TPipelineArgs args)
		{
		}
	}
}

The Execute() method on all pipeline processors will only run when the processor’s CanProcess() method returns true. Also, pipeline processors have the ability to abort the pipeline where they are called.

I then created the following abstract class for all service classes which call a pipeline to “resolve” a particular thing:

using Sitecore.Abstractions;
using Sitecore.Pipelines;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers
{
	public abstract class PipelineObjectResolver<TArguments, TPipelineArguemnts, TResult> where TPipelineArguemnts : PipelineArgs
	{
		private readonly BaseCorePipelineManager _corePipelineManager;

		protected PipelineObjectResolver(BaseCorePipelineManager corePipelineManager)
		{
			_corePipelineManager = corePipelineManager;
		}

		public TResult Resolve(TArguments arguments)
		{
			TPipelineArguemnts args = CreatePipelineArgs(arguments);
			RunPipeline(GetPipelineName(), args);
			return GetObject(args);
		}

		protected abstract TResult GetObject(TPipelineArguemnts args);

		protected abstract TPipelineArguemnts CreatePipelineArgs(TArguments arguments);

		protected abstract string GetPipelineName();

		protected virtual void RunPipeline(string pipelineName, PipelineArgs args) => _corePipelineManager.Run(pipelineName, args);
	}
}

Each service class will “resolve” a particular thing with arguments passed to their Resolve() method — these service class’ Resolve() method will take in a TArguments type which serves as the input arguments for it. They will then delegate to a pipeline via the RunPipeline() method to do the resolving. Each will also parse the results returned by the pipeline via the GetObject() method.

Moving forward in this post, I will group each resolving pipeline with their service classes under a <pipeline name /> section.

<resolveItem />

I then moved on to creating a custom pipeline to “resolve” a Sitecore Item. The following class serves as its arguments data transfer object (DTO):

using System.Collections.Generic;
using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;
using Sitecore.Pipelines;

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem
{
	public class ResolveItemArgs : PipelineArgs
	{
		public Database Database { get; set; }

		public string ItemPath { get; set; }

		public Language Language { get; set; }

		public IList<IItemResolver> ItemResolvers { get; set; } = new List<IItemResolver>();

		public Item Item { get; set; }
	}
}

The resolution of an Item will be done by a collection of IItemResolver instances — these are defined further down in this post — which ultimately do the resolution of the Item.

Next, I created the following arguments class for IItemResolver instances:

using Sitecore.Data;
using Sitecore.Globalization;

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers
{
	public class ItemResolverArguments
	{
		public Database Database { get; set; }

		public Language Language { get; set; }

		public string ItemPath { get; set; }
	}
}

Since I hate calling the “new” keyword directly on classes, I created the following factory interface which will construct the argument objects for both the pipeline and service classes for resolving an Item:

using Sitecore.Data;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ItemResolvers
{
	public interface IItemResolverArgumentsFactory
	{
		ItemResolverArguments CreateItemResolverArguments(ResolveTypeArgs args);

		ItemResolverArguments CreateItemResolverArguments(ResolveItemArgs args);

		ItemResolverArguments CreateItemResolverArguments(Database database = null, Language language = null, string itemPath = null);

		ResolveItemArgs CreateResolveItemArgs(ItemResolverArguments arguments);

		ResolveItemArgs CreateResolveItemArgs(Database database = null, Language language = null, string itemPath = null);
	}
}

Here is the class that implements the interface above:

using Sitecore.Data;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ItemResolvers
{
	public class ItemResolverArgumentsFactory : IItemResolverArgumentsFactory
	{
		public ItemResolverArguments CreateItemResolverArguments(ResolveTypeArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateItemResolverArguments(args.Database, args.Language, args.ItemPath);
		}

		public ItemResolverArguments CreateItemResolverArguments(ResolveItemArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateItemResolverArguments(args.Database, args.Language, args.ItemPath);
		}

		public ItemResolverArguments CreateItemResolverArguments(Database database = null, Language language = null, string itemPath = null)
		{
			return new ItemResolverArguments
			{
				Database = database,
				Language = language,
				ItemPath = itemPath
			};
		}

		public ResolveItemArgs CreateResolveItemArgs(ItemResolverArguments arguments)
		{
			if (arguments == null)
			{
				return null;
			}

			return CreateResolveItemArgs(arguments.Database, arguments.Language, arguments.ItemPath);
		}

		public ResolveItemArgs CreateResolveItemArgs(Database database = null, Language language = null, string itemPath = null)
		{
			return new ResolveItemArgs
			{
				Database = database,
				Language = language,
				ItemPath = itemPath
			};
		}
	}
}

It just creates argument types for the pipeline and service classes.

The following interface is for classes that “resolve” Items based on arguments set on an ItemResolverArguments instance:

using Sitecore.Data.Items;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers
{
	public interface IItemResolver
	{
		Item Resolve(ItemResolverArguments arguments);
	}
}

I created a another interface for an IItemResolver which resolves an Item from a Sitecore Database:

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers
{
	public interface IDatabaseItemResolver : IItemResolver
	{
	}
}

The purpose of this interface is so I can register it and the following class which implements it in the Sitecore IoC container:

using Sitecore.Data.Items;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers
{
	public class DatabaseItemResolver : IDatabaseItemResolver
	{
		public Item Resolve(ItemResolverArguments arguments)
		{
			if (!CanResolveItem(arguments))
			{
				return null;
			}

			if(arguments.Language == null)
			{
				return arguments.Database.GetItem(arguments.ItemPath);
			}

			return arguments.Database.GetItem(arguments.ItemPath, arguments.Language);
		}

		protected virtual bool CanResolveItem(ItemResolverArguments arguments) => arguments != null && arguments.Database != null && !string.IsNullOrWhiteSpace(arguments.ItemPath);
	}
}

The instance of the class above will return a Sitecore Item if a Database and Item path (this can be an Item ID) are supplied via the ItemResolverArguments instance passed to its Reolve() method.

Now, let’s start constructing the processors for the pipeline:

First, I created an interface and class for adding a “default” IItemResolver to a collection of IItemResolver defined on the pipeline’s arguments object:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem.AddDefaultItemResolverProcessor
{
	public interface IAddDefaultItemResolver
	{
		void Process(ResolveItemArgs args);
	}
}

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem.AddDefaultItemResolverProcessor
{
	public class AddDefaultItemResolver : ResolveProcessor<ResolveItemArgs>, IAddDefaultItemResolver
	{
		private readonly IDatabaseItemResolver _databaseItemResolver;

		public AddDefaultItemResolver(IDatabaseItemResolver databaseItemResolver)
		{
			_databaseItemResolver = databaseItemResolver;
		}

		protected override bool CanProcess(ResolveItemArgs args) => base.CanProcess(args) && args.ItemResolvers != null;

		protected override void Execute(ResolveItemArgs args) => args.ItemResolvers.Add(GetTypeResolver());

		protected virtual IItemResolver GetTypeResolver() => _databaseItemResolver;
	}
}

In the above class, I’m injecting the IDatabaseItemResolver instance — this was shown further up in this post — into the constructor of this class, and then adding it to the collection of resolvers.

I then created the following interface and implementation class to doing the “resolving” of the Item:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem.ResolveItemProcessor
{
	public interface IResolveItem
	{
		void Process(ResolveItemArgs args);
	}
}

using System.Linq;

using Sitecore.Data.Items;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem.ResolveItemProcessor
{
	public class ResolveItem : ResolveProcessor<ResolveItemArgs>, IResolveItem
	{
		private readonly IItemResolverArgumentsFactory _itemResolverArgumentsFactory;


		public ResolveItem(IItemResolverArgumentsFactory itemResolverArgumentsFactory)
		{
			_itemResolverArgumentsFactory = itemResolverArgumentsFactory;
		}

		protected override bool CanProcess(ResolveItemArgs args) => base.CanProcess(args) && args.Database != null && !string.IsNullOrWhiteSpace(args.ItemPath) && args.ItemResolvers.Any();

		protected override void Execute(ResolveItemArgs args) => args.Item = GetItem(args);

		protected virtual Item GetItem(ResolveItemArgs args)
		{
			ItemResolverArguments arguments = CreateItemResolverArguments(args);
			if (arguments == null)
			{
				return null;
			}

			foreach (IItemResolver resolver in args.ItemResolvers)
			{
				Item item = resolver.Resolve(arguments);
				if (item != null)
				{
					return item;
				}
			}

			return null;
		}

		protected virtual ItemResolverArguments CreateItemResolverArguments(ResolveItemArgs args) => _itemResolverArgumentsFactory.CreateItemResolverArguments(args);
	}
}

The class above just iterates over all IItemResolver instances on the PipelineArgs instance; passes an ItemResolverArguments instance the Resolve() method on each — the ItemResolverArguments instance is created from a factory — and returns the first Item found by one of the IItemResolver instances. If none were found, null is returned.

Now, we need to create a service class that calls the custom pipeline. I created the following class to act as a settings class for the service.

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers
{
	public class ItemResolverServiceSettings
	{
		public string ResolveItemPipelineName { get; set; }
	}
}

An instance of this class will be injected into the service — the instance is created by the Sitecore Configuration Factory — and its ResolveItemPipelineName property will contain a value from Sitecore Configuration (see the Sitecore patch configuration file towards the bottom of this blog post).

I then created the following interface for the service — it’s just another IItemResolver — so I can register it in the Sitecore IoC container:

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers
{
	public interface IItemResolverService : IItemResolver
	{
	}
}

The following class implements the interface above:

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers;
using Sitecore.Abstractions;
using Sitecore.Data.Items;

using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ItemResolvers;


using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers
{
	public class ItemResolverService : PipelineObjectResolver<ItemResolverArguments, ResolveItemArgs, Item>, IItemResolverService
	{
		private readonly ItemResolverServiceSettings _settings;
		private readonly IItemResolverArgumentsFactory _itemResolverArgumentsFactory;

		public ItemResolverService(ItemResolverServiceSettings settings, IItemResolverArgumentsFactory itemResolverArgumentsFactory, BaseCorePipelineManager corePipelineManager)
			: base(corePipelineManager)
		{
			_settings = settings;
			_itemResolverArgumentsFactory = itemResolverArgumentsFactory;
		}

		protected override Item GetObject(ResolveItemArgs args)
		{
			return args.Item;
		}

		protected override ResolveItemArgs CreatePipelineArgs(ItemResolverArguments arguments) => _itemResolverArgumentsFactory.CreateResolveItemArgs(arguments);

		protected override string GetPipelineName() => _settings.ResolveItemPipelineName;
	}
}

The above class subclasses the abstract PipelineObjectResolver class I had shown further above in this post. Most of the magic happens in that base class — for those interested in design patterns, this is an example of the Template Method pattern if you did not know — and all subsequent custom pipeline wrapping service classes will follow this same pattern.

I’m not going to go much into detail on the above class as it should be self-evident on what’s happening after looking at the PipelineObjectResolver further up in this post.

<resolveType />

I then started code for the next pipeline — a pipeline to resolve Types.

I created the following PipelineArgs subclass class whose instances will serve as arguments to this new pipeline:

using System;
using System.Collections.Generic;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;
using Sitecore.Pipelines;

using Sandbox.Foundation.ObjectResolution.Services.Cachers;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType
{
	public class ResolveTypeArgs : PipelineArgs
	{
		public Database Database { get; set; }

		public string ItemPath { get; set; }

		public Language Language { get; set; }

		public IItemResolver ItemResolver { get; set; }

		public Item Item { get; set; }

		public string TypeFieldName { get; set; }

		public string TypeName { get; set; }

		public IList<ITypeResolver> TypeResolvers { get; set; } = new List<ITypeResolver>();

		public ITypeCacher TypeCacher { get; set; }

		public Type Type { get; set; }

		public bool UseTypeCache { get; set; }
	}
}

I then created the following class to serve as an arguments object for services that will resolve types:

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers
{
	public class TypeResolverArguments
	{
		public Database Database { get; set; }

		public Language Language { get; set; }

		public string ItemPath { get; set; }

		public Item Item { get; set; }

		public string TypeFieldName { get; set; }

		public string TypeName { get; set; }

		public bool UseTypeCache { get; set; }
	}
}

As I had done for the previous resolver, I created a factory to create arguments for both the PipelineArgs and arguments used by the service classes. Here is the interface for that factory class:

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.TypeResolvers
{
	public interface ITypeResolverArgumentsFactory
	{
		TypeResolverArguments CreateTypeResolverArguments(ResolveObjectArgs args);

		TypeResolverArguments CreateTypeResolverArguments(LocateObjectArgs args);

		TypeResolverArguments CreateTypeResolverArguments(CreateObjectArgs args);

		TypeResolverArguments CreateTypeResolverArguments(ResolveTypeArgs args);

		TypeResolverArguments CreateTypeResolverArguments(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, bool useTypeCache = false);

		ResolveTypeArgs CreateResolveTypeArgs(TypeResolverArguments arguments);

		ResolveTypeArgs CreateResolveTypeArgs(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, bool useTypeCache = false);
	}
}

The following class implements the interface above:

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.TypeResolvers
{
	public class TypeResolverArgumentsFactory : ITypeResolverArgumentsFactory
	{
		public TypeResolverArguments CreateTypeResolverArguments(ResolveObjectArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateTypeResolverArguments(args.Database, args.Language, args.ItemPath, args.Item, args.TypeFieldName, args.TypeName, args.UseTypeCache);
		}

		public TypeResolverArguments CreateTypeResolverArguments(LocateObjectArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateTypeResolverArguments(args.Database, args.Language, args.ItemPath, args.Item, args.TypeFieldName, args.TypeName, args.UseTypeCache);
		}

		public TypeResolverArguments CreateTypeResolverArguments(CreateObjectArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateTypeResolverArguments(args.Database, args.Language, args.ItemPath, args.Item, args.TypeFieldName, args.TypeName, args.UseTypeCache);
		}

		public TypeResolverArguments CreateTypeResolverArguments(ResolveTypeArgs args)
		{
			return CreateTypeResolverArguments(args.Database, args.Language, args.ItemPath, args.Item, args.TypeFieldName, args.TypeName, args.UseTypeCache);
		}

		public TypeResolverArguments CreateTypeResolverArguments(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, bool useTypeCache = false)
		{
			return new TypeResolverArguments
			{
				Database = database,
				Language = language,
				ItemPath = itemPath,
				Item = item,
				TypeFieldName = typeFieldName,
				TypeName = typeName,
				UseTypeCache = useTypeCache
			};
		}

		public ResolveTypeArgs CreateResolveTypeArgs(TypeResolverArguments arguments)
		{
			if (arguments == null)
			{
				return null;
			}

			return CreateResolveTypeArgs(arguments.Database, arguments.Language, arguments.ItemPath, arguments.Item, arguments.TypeFieldName, arguments.TypeName, arguments.UseTypeCache);
		}

		public ResolveTypeArgs CreateResolveTypeArgs(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, bool useTypeCache = false)
		{
			return new ResolveTypeArgs
			{
				Database = database,
				Language = language,
				ItemPath = itemPath,
				Item = item,
				TypeFieldName = typeFieldName,
				TypeName = typeName,
				UseTypeCache = useTypeCache
			};
		}
	}
}

I’m not going to discuss much on the class above — it just creates instances of TypeResolverArguments and ResolveTypeArgs based on a variety of things provided to each method.

I then created the following interface for a pipeline processor to resolve an Item and set it on the passed PipelineArgs instance if one wasn’t provided by the caller or set by another processor:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetItemResolverProcessor
{
	public interface ISetItemResolver
	{
		void Process(ResolveTypeArgs args);
	}
}

The following class implements the interface above:

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetItemResolverProcessor
{
	public class SetItemResolver : ResolveProcessor<ResolveTypeArgs>, ISetItemResolver
	{
		private readonly IItemResolverService _itemResolverService;

		public SetItemResolver(IItemResolverService itemResolverService)
		{
			_itemResolverService = itemResolverService;
		}

		protected override bool CanProcess(ResolveTypeArgs args) => base.CanProcess(args) && args.Database != null && !string.IsNullOrWhiteSpace(args.ItemPath);

		protected override void Execute(ResolveTypeArgs args) => args.ItemResolver = GetItemResolver();

		protected virtual IItemResolver GetItemResolver() => _itemResolverService;
	}
}

In the class above, I’m injecting an instance of a IItemResolverService into its constructor, and setting it on the ItemResolver property of the ResolveTypeArgs instance.

Does this IItemResolverService interface look familiar? It should as it’s the IItemResolverService defined further up in this post which calls the <resolveItem /> pipeline.

Now we need a processor to resolve the Item. The following interface and class do this:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.ResolveTypeProcessor
{
	public interface IResolveItem
	{
		void Process(ResolveTypeArgs args);
	}
}

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ItemResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.ResolveTypeProcessor
{
	public class ResolveItem : ResolveProcessor<ResolveTypeArgs>, IResolveItem
	{
		private readonly IItemResolverArgumentsFactory _itemResolverArgumentsFactory;

		public ResolveItem(IItemResolverArgumentsFactory itemResolverArgumentsFactory)
		{
			_itemResolverArgumentsFactory = itemResolverArgumentsFactory;
		}

		protected override bool CanProcess(ResolveTypeArgs args) => base.CanProcess(args) && args.Database != null && args.ItemResolver != null;

		protected override void Execute(ResolveTypeArgs args) => args.Item = args.ItemResolver.Resolve(CreateTypeResolverArguments(args));

		protected virtual ItemResolverArguments CreateTypeResolverArguments(ResolveTypeArgs args) => _itemResolverArgumentsFactory.CreateItemResolverArguments(args);
	}
}

The class above just delegates to the IItemResolver instance on the ResolveTypeArgs instance to resolve the Item.

Next, we need a processor to get the fully qualified type name from the Item. The following interface and class are for a processor that does just that:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetTypeNameProcessor
{
	public interface ISetTypeName
	{
		void Process(ResolveTypeArgs args);
	}
}

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetTypeNameProcessor
{
	public class SetTypeName : ResolveProcessor<ResolveTypeArgs>, ISetTypeName
	{
		protected override bool CanProcess(ResolveTypeArgs args) => base.CanProcess(args) && args.Item != null && !string.IsNullOrWhiteSpace(args.TypeFieldName);

		protected override void Execute(ResolveTypeArgs args) => args.TypeName = args.Item[args.TypeFieldName];
	}
}

The class above just gets the value from the field where the fully qualified type is defined — the name of the field where the fully qualified type name is defined should be set by the caller of this pipeline.
I then defined the following interface and class which will sort out what the Type object is based on a fully qualified type name passed to it:

using System;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers
{
	public interface ITypeResolver
	{
		Type Resolve(TypeResolverArguments arguments);
	}
}

I then created the following interface for a service class that will delegate to Sitecore.Reflection.ReflectionUtil to get a Type with a provided fully qualified type name:

using System;

namespace Sandbox.Foundation.ObjectResolution.Services.Reflection
{
	public interface IReflectionUtilService
	{
		Type GetTypeInfo(string type);

		object CreateObject(Type type);

		object CreateObject(Type type, object[] parameters);
	}
}

Here’s the class that implements the interface above:

using System;

using Sitecore.Reflection;

namespace Sandbox.Foundation.ObjectResolution.Services.Reflection
{
	public class ReflectionUtilService : IReflectionUtilService
	{
		public Type GetTypeInfo(string type)
		{
			return ReflectionUtil.GetTypeInfo(type);
		}

		public object CreateObject(Type type)
		{
			return ReflectionUtil.CreateObject(type);
		}

		public object CreateObject(Type type, object[] parameters)
		{
			return ReflectionUtil.CreateObject(type, parameters);
		}
	}
}

The class above also creates objects via the ReflectionUtil static class with a passed type and constructor arguments — this will be used in the <createObject /> pipeline further down in this post.

I then defined the following interface for a class that will leverage the IReflectionUtilService service above:

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers
{
	public interface IReflectionTypeResolver : ITypeResolver
	{
	}
}

This is the class that implements the interface above:

using System;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Reflection;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers
{
	public class ReflectionTypeResolver : IReflectionTypeResolver
	{
		private readonly IReflectionUtilService _reflectionUtilService;

		public ReflectionTypeResolver(IReflectionUtilService reflectionUtilService)
		{
			_reflectionUtilService = reflectionUtilService;
		}

		public Type Resolve(TypeResolverArguments arguments)
		{
			if (string.IsNullOrWhiteSpace(arguments?.TypeName))
			{
				return null;
			}

			return GetTypeInfo(arguments.TypeName);
		}

		protected virtual Type GetTypeInfo(string typeName) => _reflectionUtilService.GetTypeInfo(typeName);
	}
}

The class above just delegates to the IReflectionUtilService to get the Type with the supplied fully qualified type name.

I then created the following interface and class to represent a pipeline processor to add the ITypeResolver above to the collection of ITypeResolver on the ResolveTypeArgs instance passed to it:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.AddDefaultTypeResolverProcessor
{
	public interface IAddDefaultTypeResolver
	{
		void Process(ResolveTypeArgs args);
	}
}

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.AddDefaultTypeResolverProcessor
{
	public class AddDefaultTypeResolver : ResolveProcessor<ResolveTypeArgs>, IAddDefaultTypeResolver
	{
		private readonly IReflectionTypeResolver _reflectionTypeResolver;

		public AddDefaultTypeResolver(IReflectionTypeResolver reflectionTypeResolver)
		{
			_reflectionTypeResolver = reflectionTypeResolver;
		}

		protected override bool CanProcess(ResolveTypeArgs args) => base.CanProcess(args) && args.TypeResolvers != null;

		protected override void Execute(ResolveTypeArgs args) => args.TypeResolvers.Add(GetTypeResolver());

		protected virtual ITypeResolver GetTypeResolver() => _reflectionTypeResolver;
	}
}

There isn’t much going on in the class above. The Execute() method just adds the IReflectionTypeResolver to the TypeResolvers collection.

When fishing through the Sitecore Experience Forms assemblies, I noticed the OOTB code was “caching” Types it had resolved from Type fields.. I decided to employ the same approach, and defined the following interface for an object that caches Types:

using System;

namespace Sandbox.Foundation.ObjectResolution.Services.Cachers
{
	public interface ITypeCacher
	{
		void AddTypeToCache(string typeName, Type type);

		Type GetTypeFromCache(string typeName);
	}
}

Here is the class that implements the interface above:

using System;
using System.Collections.Concurrent;

namespace Sandbox.Foundation.ObjectResolution.Services.Cachers
{
	public class TypeCacher : ITypeCacher
	{
		private static readonly ConcurrentDictionary<string, Type> TypeCache = new ConcurrentDictionary<string, Type>();

		public void AddTypeToCache(string typeName, Type type)
		{
			if (string.IsNullOrWhiteSpace(typeName) || type == null)
			{
				return;
			}

			TypeCache.TryAdd(typeName, type);
		}

		public Type GetTypeFromCache(string typeName)
		{
			if (string.IsNullOrWhiteSpace(typeName))
			{
				return null;
			}

			Type type;
			if (!TypeCache.TryGetValue(typeName, out type))
			{
				return null;
			}

			return type;
		}
	}
}

The AddTypeToCache() method does exactly what the method name says — it will add the supplied Type to cache with the provided type name as the key into the ConcurrentDictionary dictionary on this class.

The GetTypeFromCache() method above tries to get a Type from the ConcurrentDictionary instance on this class, and returns to the caller if it was found. If it wasn’t found, null is returned.

The following interface and class serve as a pipeline processor to set a ITypeCacher instance on the ResolveTypeArgs instance passed to it:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetTypeCacherProcessor
{
	public interface ISetTypeCacher
	{
		void Process(ResolveTypeArgs args);
	}
}

using Sandbox.Foundation.ObjectResolution.Services.Cachers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetTypeCacherProcessor
{
	public class SetTypeCacher : ResolveProcessor<ResolveTypeArgs>, ISetTypeCacher
	{
		private readonly ITypeCacher _typeCacher;

		public SetTypeCacher(ITypeCacher typeCacher)
		{
			_typeCacher = typeCacher;
		}

		protected override bool CanProcess(ResolveTypeArgs args) => base.CanProcess(args) && args.UseTypeCache && args.TypeCacher == null;

		protected override void Execute(ResolveTypeArgs args) => args.TypeCacher = GetTypeCacher();

		protected virtual ITypeCacher GetTypeCacher() => _typeCacher;
	}
}

There isn’t much going on in the class above except the injection of the ITypeCacher instance defined further up, and setting that instance on the ResolveTypeArgs instance if it hasn’t already been set.

Now, we need to resolve the Type. The following interface and its implementation class do just that:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.ResolveTypeProcessor
{
	public interface IResolveType
	{
		void Process(ResolveTypeArgs args);
	}
}

using System;
using System.Linq;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.ResolveTypeProcessor
{
	public class ResolveType : ResolveProcessor<ResolveTypeArgs>, IResolveType
	{
		private readonly ITypeResolverArgumentsFactory _typeResolverArgumentsFactory;

		public ResolveType(ITypeResolverArgumentsFactory typeResolverArgumentsFactory)
		{
			_typeResolverArgumentsFactory = typeResolverArgumentsFactory;
		}

		protected override bool CanProcess(ResolveTypeArgs args) => base.CanProcess(args) && args.TypeResolvers != null && args.TypeResolvers.Any() && !string.IsNullOrWhiteSpace(args.TypeName);

		protected override void Execute(ResolveTypeArgs args) => args.Type = Resolve(args);

		protected virtual Type Resolve(ResolveTypeArgs args)
		{
			Type type = null;
			if (args.UseTypeCache)
			{
				type = GetTypeFromCache(args);
			}

			if (type == null)
			{
				type = GetTypeInfo(args);
			}

			return type;
		}

		protected virtual Type GetTypeInfo(ResolveTypeArgs args)
		{
			TypeResolverArguments arguments = CreateTypeResolverArguments(args);
			if (arguments == null)
			{
				return null;
			}

			foreach (ITypeResolver typeResolver in args.TypeResolvers)
			{
				Type type = typeResolver.Resolve(arguments);
				if (type != null)
				{
					return type;
				}
			}

			return null;
		}

		protected virtual Type GetTypeFromCache(ResolveTypeArgs args) => args.TypeCacher.GetTypeFromCache(args.TypeName);

		protected virtual TypeResolverArguments CreateTypeResolverArguments(ResolveTypeArgs args) => _typeResolverArgumentsFactory.CreateTypeResolverArguments(args);
	}
}

Just as I had done in the <resolveItem /> pipeline further up in this post, the above processor class will iterate over a collection of “resolvers” on the PipelineArgs instance — in this case it’s the TypeResolvers — and pass an arguments instance to each’s Resolve() method. This arguments instance is created from a factory defined further up in this post.

I then created the following settings class for the service class that will wrap the <resolveType /> pipeline:

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers
{
	public class TypeResolverServiceSettings
	{
		public string ResolveTypePipelineName { get; set; }
	}
}

The value on the ResolveTypePipelineName property will come from the Sitecore patch file towards the bottom of this post.

I then created the following interface for the service class that will wrap the pipeline — if you are a design patterns buff, this is an example of the adapter pattern:

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers
{
	public interface ITypeResolverService : ITypeResolver
	{
	}
}

The following class implements the interface above:

using System;

using Sitecore.Abstractions;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers
{
	public class TypeResolverService : PipelineObjectResolver<TypeResolverArguments, ResolveTypeArgs, Type>, ITypeResolverService
	{
		private readonly TypeResolverServiceSettings _settings;
		private readonly ITypeResolverArgumentsFactory _typeResolverArgumentsFactory;

		public TypeResolverService(TypeResolverServiceSettings settings, ITypeResolverArgumentsFactory typeResolverArgumentsFactory, BaseCorePipelineManager corePipelineManager)
			: base(corePipelineManager)
		{
			_settings = settings;
			_typeResolverArgumentsFactory = typeResolverArgumentsFactory;
		}

		protected override Type GetObject(ResolveTypeArgs args)
		{
			return args.Type;
		}

		protected override ResolveTypeArgs CreatePipelineArgs(TypeResolverArguments arguments) => _typeResolverArgumentsFactory.CreateResolveTypeArgs(arguments);

		protected override string GetPipelineName() => _settings.ResolveTypePipelineName;
	}
}

I’m not going to go into details about the class above as it’s just like the other service class which wraps the <resolveItem /> defined further above in this post.

Still following? We’re almost there. 😉

<locateObject />

So we now have a way to resolve Items and Types, we now need to find a Type from an Item in the IoC container. I created a PipelineArgs class for a pipeline that does just that:

using System;
using System.Collections.Generic;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;
using Sitecore.Pipelines;

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject
{
	public class LocateObjectArgs : PipelineArgs
	{
		public Database Database { get; set; }

		public string ItemPath { get; set; }

		public Language Language { get; set; }

		public Item Item { get; set; }

		public string TypeFieldName { get; set; }

		public string TypeName { get; set; }

		public bool UseTypeCache { get; set; }

		public ITypeResolver TypeResolver { get; set; }

		public Type Type { get; set; }

		public IList<IObjectLocator> Locators { get; set; } = new List<IObjectLocator>();

		public object Object { get; set; }
	}
}

In reality, this next pipeline can supply an object from anywhere — it doesn’t have to be from an IoC container but that’s what I’m doing here. I did, however, make it extendable so you can source an object from wherever you want, even from the Post Office. 😉

I then created the following arguments object for service classes that will “locate” objects:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators
{
	public class ObjectLocatorArguments
	{
		public Database Database { get; set; }

		public Language Language { get; set; }

		public string ItemPath { get; set; }

		public Item Item { get; set; }

		public string TypeFieldName { get; set; }

		public string TypeName { get; set; }

		public Type Type { get; set; }

		public bool UseTypeCache { get; set; }
	}
}

As I had done for the previous two “resolvers”, I created a factory to create arguments objects — both for the pipeline and service classes:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectLocators
{
	public interface IObjectLocatorArgumentsFactory
	{
		ObjectLocatorArguments CreateObjectLocatorArguments(ResolveObjectArgs args);

		ObjectLocatorArguments CreateObjectLocatorArguments(LocateObjectArgs args);

		ObjectLocatorArguments CreateObjectLocatorArguments(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false);

		LocateObjectArgs CreateLocateObjectArgs(ObjectLocatorArguments arguments);

		LocateObjectArgs CreateLocateObjectArgs(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false);
	}
}

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectLocators
{
	public class ObjectLocatorArgumentsFactory : IObjectLocatorArgumentsFactory
	{
		public ObjectLocatorArguments CreateObjectLocatorArguments(ResolveObjectArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateObjectLocatorArguments(args.Database, args.Language, args.ItemPath, args.Item, args.TypeFieldName, args.TypeName, args.Type, args.UseTypeCache);
		}

		public ObjectLocatorArguments CreateObjectLocatorArguments(LocateObjectArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateObjectLocatorArguments(args.Database, args.Language, args.ItemPath, args.Item, args.TypeFieldName, args.TypeName, args.Type, args.UseTypeCache);
		}

		public ObjectLocatorArguments CreateObjectLocatorArguments(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false)
		{
			return new ObjectLocatorArguments
			{
				Database = database,
				Language = language,
				ItemPath = itemPath,
				Item = item,
				TypeFieldName = typeFieldName,
				TypeName = typeName,
				Type = type
			};
		}

		public LocateObjectArgs CreateLocateObjectArgs(ObjectLocatorArguments arguments)
		{
			if (arguments == null)
			{
				return null;
			}

			return CreateLocateObjectArgs(arguments.Database, arguments.Language, arguments.ItemPath, arguments.Item, arguments.TypeFieldName, arguments.TypeName, arguments.Type, arguments.UseTypeCache);
		}

		public LocateObjectArgs CreateLocateObjectArgs(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false)
		{
			return new LocateObjectArgs
			{
				Database = database,
				Language = language,
				ItemPath = itemPath,
				Item = item,
				TypeFieldName = typeFieldName,
				TypeName = typeName,
				Type = type
			};
		}
	}
}

The above class implements the interface above. It just creates arguments for both the pipeline and service classes.

I then defined the following interface for a pipeline processor to set the ITypeResolver (defined way up above in this post):

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.SetTypeResolverProcessor
{
	public interface ISetTypeResolver
	{
		void Process(LocateObjectArgs args);
	}
}

This class implements the interface above:

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.SetTypeResolverProcessor
{
	public class SetTypeResolver : ResolveProcessor<LocateObjectArgs>, ISetTypeResolver
	{
		private readonly ITypeResolverService _typeResolverService;

		public SetTypeResolver(ITypeResolverService typeResolverService)
		{
			_typeResolverService = typeResolverService;
		}

		protected override bool CanProcess(LocateObjectArgs args) => base.CanProcess(args) && args.TypeResolver == null;

		protected override void Execute(LocateObjectArgs args)
		{
			args.TypeResolver = GetTypeResolver();
		}

		protected virtual ITypeResolver GetTypeResolver() => _typeResolverService;
	}
}

In the class above, I’m injecting the ITypeResolverService into its constructor — this is the service class that wraps the <resolveType /> pipeline defined further up — and set it on the LocateObjectArgs instance if it’s not already set.

Next, I created the following interface for a processor that will “resolve” the type from the TypeResolver set on the LocateObjectArgs instance:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.ResolveTypeProcessor
{
	public interface IResolveType
	{
		void Process(LocateObjectArgs args);
	}
}

The following class implements the interface above:

using System;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.ResolveTypeProcessor
{
	public class ResolveType : ResolveProcessor<LocateObjectArgs>, IResolveType
	{
		private readonly ITypeResolverArgumentsFactory _typeResolverArgumentsFactory;

		public ResolveType(ITypeResolverArgumentsFactory typeResolverArgumentsFactory)
		{
			_typeResolverArgumentsFactory = typeResolverArgumentsFactory;
		}

		protected override bool CanProcess(LocateObjectArgs args) => base.CanProcess(args) && args.Type == null && args.TypeResolver != null;

		protected override void Execute(LocateObjectArgs args)
		{
			args.Type = Resolve(args);
		}

		protected virtual Type Resolve(LocateObjectArgs args)
		{
			TypeResolverArguments arguments = CreateTypeResolverArguments(args);
			if (arguments == null)
			{
				return null;
			}

			return args.TypeResolver.Resolve(arguments);
		}

		protected virtual TypeResolverArguments CreateTypeResolverArguments(LocateObjectArgs args) => _typeResolverArgumentsFactory.CreateTypeResolverArguments(args);
	}
}

The class above just “resolves” the type from the TypeResolver set on the LocateObjectArgs instance. Nothing more to see. 😉

I then defined the following interface for a family of classes that “locate” objects from somewhere (perhaps a magical place. 😉 ):

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators
{
	public interface IObjectLocator
	{
		object Resolve(ObjectLocatorArguments arguments);
	}
}

Well, we can’t use much magic in this solution, so I’m going to “locate” things in the Sitecore IoC container, so defined the following interface for a class that will employ Service Locator to find it in the Sitecore IoC container:

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators
{
	public interface IServiceProviderLocator : IObjectLocator
	{
	}
}

This class implements the interface above:

using System;

using Sitecore.DependencyInjection;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators
{
	public class ServiceProviderLocator : IServiceProviderLocator
	{
		private readonly IServiceProvider _serviceProvider;

		public ServiceProviderLocator()
		{
			_serviceProvider = GetServiceProvider();
		}

		protected virtual IServiceProvider GetServiceProvider()
		{
			return ServiceLocator.ServiceProvider;
		}

		public object Resolve(ObjectLocatorArguments arguments)
		{
			if (arguments == null || arguments.Type == null)
			{
				return null;
			}

			return GetService(arguments.Type);
		}

		protected virtual object GetService(Type type) => _serviceProvider.GetService(type);
	}
}

In the class above, I’m just passing a type to the System.IServiceProvider’s GetService() method — the IServiceProvider instance is grabbed from the ServiceProvider static member on Sitecore.DependencyInjection.ServiceLocator static class.

Next, I need a processor class to add an instance of the Service Locator IObjectLocator class above to the collection of IObjectLocator instances on the LocateObjectArgs instance, so I defined the following interface for a processor class that does just that:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.AddDefaultObjectLocatorProcessor
{
	public interface IAddDefaultObjectLocator
	{
		void Process(LocateObjectArgs args);
	}
}

Here’s the implementation class for the interface above:

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.AddDefaultObjectLocatorProcessor
{
	public class AddDefaultObjectLocator : ResolveProcessor<LocateObjectArgs>, IAddDefaultObjectLocator
	{
		private readonly IServiceProviderLocator _serviceProviderLocator;

		public AddDefaultObjectLocator(IServiceProviderLocator serviceProviderLocator)
		{
			_serviceProviderLocator = serviceProviderLocator;
		}

		protected override bool CanProcess(LocateObjectArgs args) => base.CanProcess(args) && args.Locators != null;

		protected override void Execute(LocateObjectArgs args) => args.Locators.Add(GetObjectLocator());

		protected virtual IObjectLocator GetObjectLocator() => _serviceProviderLocator;
	}
}

It’s just adding the IServiceProviderLocator instance to the collection of Locators set on the LocateObjectArgs instance.

Great, so we have things that can “locate” objects but need to have a processor that does the execution of that step to actually find those objects. The following interface is for a processor class that does just that:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.LocateObjectProcessor
{
	public interface ILocateObject
	{
		void Process(LocateObjectArgs args);
	}
}

And here’s its implementation class:

using System.Linq;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.LocateObjectProcessor
{
	public class LocateObject : ResolveProcessor<LocateObjectArgs>, ILocateObject
	{
		private readonly IObjectLocatorArgumentsFactory _objectLocatorArgumentsFactory;

		public LocateObject(IObjectLocatorArgumentsFactory objectLocatorArgumentsFactory)
		{
			_objectLocatorArgumentsFactory = objectLocatorArgumentsFactory;
		}

		protected override bool CanProcess(LocateObjectArgs args) => base.CanProcess(args) && args.Locators != null && args.Locators.Any() && args.Type != null;

		protected override void Execute(LocateObjectArgs args) => args.Object = Resolve(args);

		protected virtual object Resolve(LocateObjectArgs args)
		{
			ObjectLocatorArguments arguments = CreateObjectLocatorArguments(args);
			if (arguments == null)
			{
				return null;
			}

			foreach (IObjectLocator objectLocator in args.Locators)
			{
				object obj = objectLocator.Resolve(arguments);
				if (obj != null)
				{
					return obj;
				}
			}

			return null;
		}

		protected virtual ObjectLocatorArguments CreateObjectLocatorArguments(LocateObjectArgs args) => _objectLocatorArgumentsFactory.CreateObjectLocatorArguments(args);
	}
}

As I had done in the previous pipelines, I’m just iterating over a collection of classes that “resolve” for a particular thing — here I’m iterating over all IObjectLocator instances set on the LocateObjectArgs instance. If one of them find the object we are looking for, we just set it on the LocateObjectArgs instance.

As I had done for the other pipelines, I created a service class that wraps the new pipeline I am creating. The following class serves as a settings class for that service class:

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators
{
	public class ObjectLocatorServiceSettings
	{
		public string LocateObjectPipelineName { get; set; }
	}
}

An instance of the class above will be created by the Sitecore Configuration Factory, and its LocateObjectPipelineName property will contain a value defined in the Sitecore patch file further down in this post.

I then created the following interface for the service class that will wrap this new pipeline:

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators
{
	public interface IObjectLocatorService : IObjectLocator
	{
	}
}

Here’s the class that implements the interface above:

using Sitecore.Abstractions;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectLocators;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators
{
	public class ObjectLocatorService : PipelineObjectResolver<ObjectLocatorArguments, LocateObjectArgs, object>, IObjectLocatorService
	{
		private readonly ObjectLocatorServiceSettings _settings;
		private readonly IObjectLocatorArgumentsFactory _objectLocatorArgumentsFactory;

		public ObjectLocatorService(ObjectLocatorServiceSettings settings, IObjectLocatorArgumentsFactory objectLocatorArgumentsFactory, BaseCorePipelineManager corePipelineManager)
			: base(corePipelineManager)
		{
			_settings = settings;
			_objectLocatorArgumentsFactory = objectLocatorArgumentsFactory;
		}

		protected override object GetObject(LocateObjectArgs args)
		{
			return args.Object;
		}

		protected override LocateObjectArgs CreatePipelineArgs(ObjectLocatorArguments arguments) => _objectLocatorArgumentsFactory.CreateLocateObjectArgs(arguments);

		protected override string GetPipelineName() => _settings.LocateObjectPipelineName;
	}
}

I’m not going talk much about the class above — it’s following the same pattern as the other classes that wrap their respective pipelines.

<createObject />

So what happens when we cannot find an object via the <locateObject /> pipeline? Well, let’s create it.

I defined the following PipelineArgs class for a new pipeline that creates objects:

using System;
using System.Collections.Generic;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;
using Sitecore.Pipelines;

using Sandbox.Foundation.ObjectResolution.Services.Cachers;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject
{
	public class CreateObjectArgs : PipelineArgs
	{
		public Database Database { get; set; }

		public string ItemPath { get; set; }

		public Language Language { get; set; }

		public Item Item { get; set; }

		public string TypeFieldName { get; set; }

		public string TypeName { get; set; }

		public ITypeResolver TypeResolver { get; set; }

		public Type Type { get; set; }

		public object[] Parameters { get; set; }

		public IList<IObjectCreator> Creators { get; set; } = new List<IObjectCreator>();

		public object Object { get; set; }

		public bool UseTypeCache { get; set; }

		public ITypeCacher TypeCacher { get; set; }
	}
}

I then defined the following class for service classes that create objects:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators
{
	public class ObjectCreatorArguments
	{
		public Database Database { get; set; }

		public Language Language { get; set; }

		public string ItemPath { get; set; }

		public Item Item { get; set; }

		public string TypeFieldName { get; set; }

		public string TypeName { get; set; }

		public Type Type { get; set; }

		public bool UseTypeCache { get; set; }

		public object[] Parameters { get; set; }
	}
}

Since the “new” keyword promotes tight coupling between classes, I created the following factory interface for classes that create the two arguments types shown above:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectCreators
{
	public interface IObjectCreatorArgumentsFactory
	{
		ObjectCreatorArguments CreateObjectCreatorArguments(ResolveObjectArgs args);

		ObjectCreatorArguments CreateObjectCreatorArguments(CreateObjectArgs args);

		ObjectCreatorArguments CreateObjectCreatorArguments(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false, object[] parameters = null);

		CreateObjectArgs CreateCreateObjectArgs(ObjectCreatorArguments arguments);

		CreateObjectArgs CreateCreateObjectArgs(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false, object[] parameters = null);

	}
}

The following class implements the interface above:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectCreators
{
	public class ObjectCreatorArgumentsFactory : IObjectCreatorArgumentsFactory
	{
		public ObjectCreatorArguments CreateObjectCreatorArguments(ResolveObjectArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateObjectCreatorArguments(args.Database, args.Language, args.ItemPath, args.Item, args.TypeFieldName, args.TypeName, args.Type, args.UseTypeCache, args.ObjectCreationParameters);
		}

		public ObjectCreatorArguments CreateObjectCreatorArguments(CreateObjectArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateObjectCreatorArguments(args.Database, args.Language, args.ItemPath, args.Item, args.TypeFieldName, args.TypeName, args.Type, args.UseTypeCache, args.Parameters);
		}

		public ObjectCreatorArguments CreateObjectCreatorArguments(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false, object[] parameters = null)
		{
			return new ObjectCreatorArguments
			{
				Database = database,
				Language = language,
				ItemPath = itemPath,
				Item = item,
				TypeFieldName = typeFieldName,
				TypeName = typeName,
				Type = type,
				Parameters = parameters
			};
		}

		public CreateObjectArgs CreateCreateObjectArgs(ObjectCreatorArguments arguments)
		{
			if (arguments == null)
			{
				return null;
			}

			return CreateCreateObjectArgs(arguments.Database, arguments.Language, arguments.ItemPath, arguments.Item, arguments.TypeFieldName, arguments.TypeName, arguments.Type, arguments.UseTypeCache, arguments.Parameters);
		}

		public CreateObjectArgs CreateCreateObjectArgs(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false, object[] parameters = null)
		{
			return new CreateObjectArgs
			{
				Database = database,
				Language = language,
				ItemPath = itemPath,
				Item = item,
				TypeFieldName = typeFieldName,
				TypeName = typeName,
				Type = type,
				UseTypeCache = useTypeCache,
				Parameters = parameters
			};
		}
	}
}

The class above just creates CreateObjectArgs and ObjectCreatorArguments instances.

Let’s jump into the bits that comprise the new pipeline.

The following interface is for a processor class that sets the ITypeResolver on the CreateObjectArgs instance:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.SetTypeResolverProcessor
{
	public interface ISetTypeResolver
	{
		void Process(CreateObjectArgs args);
	}
}

Here’s the processor class that implements the interface above:

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.SetTypeResolverProcessor
{
	public class SetTypeResolver : ResolveProcessor<CreateObjectArgs>, ISetTypeResolver
	{
		private readonly ITypeResolverService _typeResolverService;

		public SetTypeResolver(ITypeResolverService typeResolverService)
		{
			_typeResolverService = typeResolverService;
		}

		protected override bool CanProcess(CreateObjectArgs args) => base.CanProcess(args) && args.Type == null && args.TypeResolver == null;

		protected override void Execute(CreateObjectArgs args)
		{
			args.TypeResolver = GetTypeResolver();
		}

		protected virtual ITypeResolver GetTypeResolver() => _typeResolverService;
	}
}

Nothing special going on — we’ve seen something like this before further up in this post.

Now, we need a processor to “resolve” types. The following interface is for a processor class which does just that:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.ResolveTypeProcessor
{
	public interface IResolveType
	{
		void Process(CreateObjectArgs args);
	}
}

And here is the processor class that implements the interface above:

using System;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.ResolveTypeProcessor
{
	public class ResolveType : ResolveProcessor<CreateObjectArgs>, IResolveType
	{
		private readonly ITypeResolverArgumentsFactory _typeResolverArgumentsFactory;

		public ResolveType(ITypeResolverArgumentsFactory typeResolverArgumentsFactory)
		{
			_typeResolverArgumentsFactory = typeResolverArgumentsFactory;
		}

		protected override bool CanProcess(CreateObjectArgs args) => base.CanProcess(args) && args.Type == null && args.TypeResolver != null;

		protected override void Execute(CreateObjectArgs args)
		{
			args.Type = Resolve(args);
		}

		protected virtual Type Resolve(CreateObjectArgs args)
		{
			TypeResolverArguments arguments = CreateTypeResolverArguments(args);
			if (arguments == null)
			{
				return null;
			}

			return args.TypeResolver.Resolve(arguments);
		}

		protected virtual TypeResolverArguments CreateTypeResolverArguments(CreateObjectArgs args) => _typeResolverArgumentsFactory.CreateTypeResolverArguments(args);
	}
}

I’m not going to discuss much on this as we’ve already seen something like this further up in this post.

I then defined the following interface for a family of classes that create objects:

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators
{
	public interface IObjectCreator
	{
		object Resolve(ObjectCreatorArguments arguments);
	}
}

Since I’m not good at arts and crafts, we’ll have to use reflection to create objects. The following interface is for a class that uses reflection to create objects:

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators
{
	public interface IReflectionObjectCreator : IObjectCreator
	{
	}
}

The following class implements the interface above:

using System.Linq;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Services.Reflection;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators
{
	public class ReflectionObjectCreator : IReflectionObjectCreator
	{
		private readonly IReflectionUtilService _reflectionUtilService;

		public ReflectionObjectCreator(IReflectionUtilService reflectionUtilService)
		{
			_reflectionUtilService = reflectionUtilService;
		}

		public object Resolve(ObjectCreatorArguments arguments)
		{
			if (arguments == null || arguments.Type == null)
			{
				return null;
			}

			if (arguments.Parameters == null || !arguments.Parameters.Any())
			{
				return _reflectionUtilService.CreateObject(arguments.Type);
			}

			return _reflectionUtilService.CreateObject(arguments.Type, arguments.Parameters);
		}
	}
}

This class above just delegates to the IReflectionUtilService instance — this is defined way up above in this post — injected into it for creating objects.

Now we need to put this IReflectionObjectCreator somewhere so it can be used to create objects. The following interface is for a processor class that adds this to a collection of other IObjectCreator defined on the CreateObjectArgs instance:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.AddDefaultObjectCreatorProcessor
{
	public interface IAddDefaultObjectCreator
	{
		void Process(CreateObjectArgs args);
	}
}

And here is the magic behind the interface above:

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.AddDefaultObjectCreatorProcessor
{
	public class AddDefaultObjectCreator : ResolveProcessor<CreateObjectArgs>, IAddDefaultObjectCreator
	{
		private readonly IReflectionObjectCreator _reflectionObjectCreator;

		public AddDefaultObjectCreator(IReflectionObjectCreator reflectionObjectCreator)
		{
			_reflectionObjectCreator = reflectionObjectCreator;
		}

		protected override bool CanProcess(CreateObjectArgs args) => base.CanProcess(args) && args.Creators != null;

		protected override void Execute(CreateObjectArgs args) => args.Creators.Add(GetObjectLocator());

		protected virtual IObjectCreator GetObjectLocator() => _reflectionObjectCreator;
	}
}

We are just adding the IReflectionObjectCreator instance to the Creators collection on the CreateObjectArgs instance.

Now, we need a processor that delegates to each IObjectCreator instance in the collection on the CreateObjectArgs instance. The following interface is for a processor that does that:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.CreateObjectProcessor
{
	public interface ICreateObject
	{
		void Process(CreateObjectArgs args);
	}
}

Here’s the above interface’s implementation class:

using System.Linq;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.CreateObjectProcessor
{
	public class CreateObject : ResolveProcessor<CreateObjectArgs>, ICreateObject
	{
		private readonly IObjectCreatorArgumentsFactory _objectCreatorArgumentsFactory;

		public CreateObject(IObjectCreatorArgumentsFactory objectCreatorArgumentsFactory)
		{
			_objectCreatorArgumentsFactory = objectCreatorArgumentsFactory;
		}

		protected override bool CanProcess(CreateObjectArgs args) => base.CanProcess(args) && args.Creators.Any();

		protected override void Execute(CreateObjectArgs args)
		{
			args.Object = CreateObjectFromArguments(args);
		}

		protected virtual object CreateObjectFromArguments(CreateObjectArgs args)
		{
			ObjectCreatorArguments arguments = CreateObjectCreatorArguments(args);
			if (arguments == null)
			{
				return null;
			}

			foreach (IObjectCreator objectCreator in args.Creators)
			{
				object result = CreateObjectFromArguments(objectCreator, arguments);
				if (result != null)
				{
					return result;
				}
			}

			return null;
		}

		protected virtual ObjectCreatorArguments CreateObjectCreatorArguments(CreateObjectArgs args) => _objectCreatorArgumentsFactory.CreateObjectCreatorArguments(args);

		protected virtual object CreateObjectFromArguments(IObjectCreator objectCreator, ObjectCreatorArguments arguments) => objectCreator.Resolve(arguments);
	}
}

The above class just iterates over the IObjectCreator collection on the CreateObjectArgs instance, and tries to create an object using each. The IObjectCreatorArgumentsFactory instance assists in creating the ObjectCreatorArguments instance from the CreateObjectArgs instance so it can make such calls on each IObjectCreator instance.

If an object is created from one them, it just uses that and stops the iteration.

It’s probably a good idea to only cache Types when an object was actually created from the Type. The following interface is for a processor that sets a ITypeCacher on the CreateObjectArgs instance — this class will add the Type to a cache (perhaps in a bank somewhere on the Cayman Islands? 😉 ):

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.SetTypeCacherProcessor
{
	public interface ISetTypeCacher
	{
		void Process(CreateObjectArgs args);
	}
}

Here’s the implementation class for the interface above:

using Sandbox.Foundation.ObjectResolution.Services.Cachers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.SetTypeCacherProcessor
{
	public class SetTypeCacher : ResolveProcessor<CreateObjectArgs>, ISetTypeCacher
	{
		private readonly ITypeCacher _typeCacher;

		public SetTypeCacher(ITypeCacher typeCacher)
		{
			_typeCacher = typeCacher;
		}

		protected override bool CanProcess(CreateObjectArgs args) => base.CanProcess(args) && args.UseTypeCache && args.TypeCacher == null;

		protected override void Execute(CreateObjectArgs args) => args.TypeCacher = _typeCacher;
	}
}

It’s just setting the injected ITypeCacher — the implementation class is defined further up in this post — on the CreateObjectArgs instance.

Now, we need to use the ITypeCacher to cache the type. The following interface is for a processor class delegates to the ITypeCacher instance to cache the Type:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.CacheTypeProcessor
{
	public interface ICacheType
	{
		void Process(CreateObjectArgs args);
	}
}

Here is the process class which implements the interface above:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.CacheTypeProcessor
{
	public class CacheType : ResolveProcessor<CreateObjectArgs>, ICacheType
	{
		protected override bool CanProcess(CreateObjectArgs args) => base.CanProcess(args) && !string.IsNullOrWhiteSpace(args.TypeName) && args.Type != null && args.UseTypeCache && args.TypeCacher != null;

		protected override void Execute(CreateObjectArgs args) => AddTypeToCache(args);

		protected virtual void AddTypeToCache(CreateObjectArgs args) => args.TypeCacher.AddTypeToCache(args.TypeName, args.Type);
	}
}

It should be self-explanatory what’s happening here. If not, please drop a comment below.

Now, we need a service class that wraps this new pipeline. I created the following settings class for that service:

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators
{
	public class ObjectCreatorServiceSettings
	{
		public string CreateObjectPipelineName { get; set; }
	}
}

An instance of this class is created by the Sitecore Configuration Factory just as the other ones in this post are.

I then defined the following interface for the service class that will wrap this new pipeline — it’s just another IObjectCreator:

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators
{
	public interface IObjectCreatorService : IObjectCreator
	{
	}
}

This class implements the interface above:

using Sitecore.Abstractions;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectCreators;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators
{
	public class ObjectCreatorService : PipelineObjectResolver<ObjectCreatorArguments, CreateObjectArgs, object>, IObjectCreatorService
	{
		private readonly ObjectCreatorServiceSettings _settings;
		private readonly IObjectCreatorArgumentsFactory _objectCreatorArgumentsFactory;

		public ObjectCreatorService(ObjectCreatorServiceSettings settings, IObjectCreatorArgumentsFactory objectCreatorArgumentsFactory, BaseCorePipelineManager corePipelineManager)
			: base(corePipelineManager)
		{
			_settings = settings;
			_objectCreatorArgumentsFactory = objectCreatorArgumentsFactory;
		}

		protected override object GetObject(CreateObjectArgs args)
		{
			return args.Object;
		}

		protected override CreateObjectArgs CreatePipelineArgs(ObjectCreatorArguments arguments) => _objectCreatorArgumentsFactory.CreateCreateObjectArgs(arguments);

		protected override string GetPipelineName() => _settings.CreateObjectPipelineName;
	}
}

I’m not going to go into details on the above as you have seen this pattern further above in this post.

<resolveObject />

Now we need a way to glue together all pipelines created above. The following PipelineArgs class is for — yet another pipeline 😉 — that glues everything together:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;
using Sitecore.Pipelines;

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject
{
	public class ResolveObjectArgs : PipelineArgs
	{
		public Database Database { get; set; }

		public string ItemPath { get; set; }

		public Language Language { get; set; }

		public Item Item { get; set; }

		public string TypeFieldName { get; set; }

		public string TypeName { get; set; }

		public ITypeResolver TypeResolver { get; set; }

		public Type Type { get; set; }

		public IObjectLocator ObjectLocator;

		public bool FoundInContainer { get; set; }

		public IObjectCreator ObjectCreator;

		public bool UseTypeCache { get; set; }

		public object[] ObjectCreationParameters { get; set; }

		public object Object { get; set; }
	}
}

I also created the following class for the service class that will wrap this new pipeline:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectResolvers
{
	public class ObjectResolverArguments
	{
		public Database Database { get; set; }

		public Language Language { get; set; }

		public string ItemPath { get; set; }

		public Item Item { get; set; }

		public string TypeFieldName { get; set; }

		public string TypeName { get; set; }

		public Type Type { get; set; }

		public bool UseTypeCache { get; set; }

		public object[] ObjectCreationParameters { get; set; }
	}
}

I bet you are guessing that I’m going to create another factory for these two classes above. Yep, you are correct. Here is the interface for that factory:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectResolvers
{
	public interface IObjectResolverArgumentsFactory
	{
		ObjectResolverArguments CreateObjectResolverArguments(Database database, string itemPath, string typeFieldName, Language language, object[] objectCreationParameters);

		ObjectResolverArguments CreateObjectResolverArguments(Item item, string typeFieldName, bool useTypeCache, object[] objectCreationParameters);

		ResolveObjectArgs CreateResolveObjectArgs(ObjectResolverArguments arguments);

		ResolveObjectArgs CreateResolveObjectArgs(Database database = null, string itemPath = null, Language language = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false, object[] objectCreationParameters = null);

	}
}

The following class implements the factory interface above:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectResolvers
{
	public class ObjectResolverArgumentsFactory : IObjectResolverArgumentsFactory
	{
		public ObjectResolverArguments CreateObjectResolverArguments(Database database, string itemPath, string typeFieldName, Language language, object[] objectCreationParameters)
		{
			return new ObjectResolverArguments
			{
				Database = database,
				ItemPath = itemPath,
				TypeFieldName = typeFieldName,
				Language = language,
				ObjectCreationParameters = objectCreationParameters
			};
		}

		public ObjectResolverArguments CreateObjectResolverArguments(Item item, string typeFieldName, bool useTypeCache, object[] objectCreationParameters)
		{
			return new ObjectResolverArguments
			{
				Item = item,
				TypeFieldName = typeFieldName,
				UseTypeCache = useTypeCache,
				ObjectCreationParameters = objectCreationParameters
			};
		}

		public ResolveObjectArgs CreateResolveObjectArgs(ObjectResolverArguments arguments)
		{
			if (arguments == null)
			{
				return null;
			}

			return CreateResolveObjectArgs(arguments.Database, arguments.ItemPath, arguments.Language, arguments.Item, arguments.TypeFieldName, arguments.TypeName, arguments.Type, arguments.UseTypeCache, arguments.ObjectCreationParameters);
		}

		public ResolveObjectArgs CreateResolveObjectArgs(Item item, string typeFieldName, object[] objectCreationParameters)
		{
			return new ResolveObjectArgs
			{
				Item = item,
				TypeFieldName = typeFieldName,
				ObjectCreationParameters = objectCreationParameters
			};
		}

		public ResolveObjectArgs CreateResolveObjectArgs(Database database = null, string itemPath = null, Language language = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false, object[] objectCreationParameters = null)
		{
			return new ResolveObjectArgs
			{
				Database = database,
				ItemPath = itemPath,
				Language = language,
				Item = item,
				TypeFieldName = typeFieldName,
				TypeName = typeName,
				Type= type,
				UseTypeCache = useTypeCache,
				ObjectCreationParameters = objectCreationParameters
			};
		}
	}
}

The following interface is for a processor class that sets the ITypeResolver on the ResolveObjectArgs instance:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject
{
	public interface ISetTypeResolver
	{
		void Process(ResolveObjectArgs args);
	}
}

Here’s its implementation class:

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject
{
	public class SetTypeResolver : ResolveProcessor<ResolveObjectArgs>, ISetTypeResolver
	{
		private readonly ITypeResolverService _typeResolverService;

		public SetTypeResolver(ITypeResolverService typeResolverService)
		{
			_typeResolverService = typeResolverService;
		}

		protected override bool CanProcess(ResolveObjectArgs args) => base.CanProcess(args) && args.TypeResolver == null;

		protected override void Execute(ResolveObjectArgs args)
		{
			args.TypeResolver = GetTypeResolver();
		}

		protected virtual ITypeResolver GetTypeResolver() => _typeResolverService;
	}
}

We have already seen this twice, so I won’t discuss it again. 😉

Next, we need to resolve the type. The following interface is for a processor class that does that type resolution:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.ResolveTypeProcessor
{
	public interface IResolveType
	{
		void Process(ResolveObjectArgs args);
	}
}

Here’s the class that implements the interface above:

using System;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.ResolveTypeProcessor
{
	public class ResolveType : ResolveProcessor<ResolveObjectArgs>, IResolveType
	{
		private readonly ITypeResolverArgumentsFactory _typeResolverArgumentsFactory;

		public ResolveType(ITypeResolverArgumentsFactory typeResolverArgumentsFactory)
		{
			_typeResolverArgumentsFactory = typeResolverArgumentsFactory;
		}

		protected override bool CanProcess(ResolveObjectArgs args) => base.CanProcess(args) && args.Type == null && args.TypeResolver != null;

		protected override void Execute(ResolveObjectArgs args)
		{
			args.Type = Resolve(args);
		}

		protected virtual Type Resolve(ResolveObjectArgs args)
		{
			TypeResolverArguments arguments = CreateTypeResolverArguments(args);
			if (arguments == null)
			{
				return null;
			}

			return args.TypeResolver.Resolve(arguments);
		}

		protected virtual TypeResolverArguments CreateTypeResolverArguments(ResolveObjectArgs args) => _typeResolverArgumentsFactory.CreateTypeResolverArguments(args);
	}
}

I’m also not going to discuss this as I’ve done this somewhere up above. 😉

Now we need a processor to “locate” objects in the Sitecore IoC container. The following interface is for a processor class that does just that:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.SetObjectLocatorProcessor
{
	public interface ISetObjectLocator
	{
		void Process(ResolveObjectArgs args);
	}
}

The following class implements the interface above:

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.SetObjectLocatorProcessor
{
	public class SetObjectLocator : ResolveProcessor<ResolveObjectArgs>, ISetObjectLocator
	{
		private readonly IObjectLocatorService _objectLocatorService;

		public SetObjectLocator(IObjectLocatorService objectLocatorService)
		{
			_objectLocatorService = objectLocatorService;
		}

		protected override bool CanProcess(ResolveObjectArgs args) => base.CanProcess(args) && args.ObjectLocator == null;

		protected override void Execute(ResolveObjectArgs args) => args.ObjectLocator = GetObjectLocator();

		protected virtual IObjectLocator GetObjectLocator() => _objectLocatorService;
	}
}

The class above just sets the IObjectLocatorService — this is the service class which wraps the <locateObject /> pipeline defined further up in this post — on the ResolveObjectArgs instance.

I then created the following interface to delegate to the ObjectLocator property on the ResolveObjectArgs to “locate” the object:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.LocateObjectProcessor
{
	public interface ILocateObject
	{
		void Process(ResolveObjectArgs args);
	}
}

And here’s the class that implements this interface above:

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectLocators;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.LocateObjectProcessor
{
	public class LocateObject : ResolveProcessor<ResolveObjectArgs>, ILocateObject
	{
		private readonly IObjectLocatorArgumentsFactory _objectLocatorArgumentsFactory;

		public LocateObject(IObjectLocatorArgumentsFactory objectLocatorArgumentsFactory)
		{
			_objectLocatorArgumentsFactory = objectLocatorArgumentsFactory;
		}

		protected override bool CanProcess(ResolveObjectArgs args) => base.CanProcess(args) && args.Object == null && args.ObjectLocator != null;

		protected override void Execute(ResolveObjectArgs args)
		{
			args.Object = Locate(args);
			args.FoundInContainer = args.Object != null;
			if (!args.FoundInContainer)
			{
				return;
			}

			AbortPipeline(args);
		}

		protected virtual object Locate(ResolveObjectArgs args) => args.ObjectLocator.Resolve(CreateObjectLocatorArguments(args));

		protected virtual ObjectLocatorArguments CreateObjectLocatorArguments(ResolveObjectArgs args) => _objectLocatorArgumentsFactory.CreateObjectLocatorArguments(args);
	}
}

The above class just tries to “locate” the object using the ObjectLocator set on the ResolveObjectArgs instance.

In the event we can’t find the object via the IObjectLocator, we should create the object instead. I created the following interface to set an IObjectCreator instance on the ResolveObjectArgs instance:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.SetObjectCreatorProcessor
{
	public interface ISetObjectCreator
	{
		void Process(ResolveObjectArgs args);
	}
}

And here’s its implementation class:

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.SetObjectCreatorProcessor
{
	public class SetObjectCreator : ResolveProcessor<ResolveObjectArgs>, ISetObjectCreator
	{
		private readonly IObjectCreatorService _objectCreatorService;

		public SetObjectCreator(IObjectCreatorService objectCreatorService)
		{
			_objectCreatorService = objectCreatorService;
		}

		protected override bool CanProcess(ResolveObjectArgs args) => base.CanProcess(args) && args.ObjectCreator == null;

		protected override void Execute(ResolveObjectArgs args) => args.ObjectCreator = GetObjectCreator();

		protected virtual IObjectCreator GetObjectCreator() => _objectCreatorService;
	}
}

The class above just sets the IObjectCreatorService — this is the service class which wraps the <createObject /> pipeline defined further up in this post — on the ResolveObjectArgs instance.

Next, we need to delegate to this IObjectCreator to create the object. The following interface is for a class that creates objects:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.CreateObjectProcessor
{
	public interface ICreateObject
	{
		void Process(ResolveObjectArgs args);
	}
}

And here’s the implementation of the interface above:

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectCreators;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.CreateObjectProcessor
{
	public class CreateObject : ResolveProcessor<ResolveObjectArgs>, ICreateObject
	{
		private readonly IObjectCreatorArgumentsFactory _objectCreatorArgumentsFactory;

		public CreateObject(IObjectCreatorArgumentsFactory objectCreatorArgumentsFactory)
		{
			_objectCreatorArgumentsFactory = objectCreatorArgumentsFactory;
		}
		protected override bool CanProcess(ResolveObjectArgs args) => base.CanProcess(args) && args.Object == null && args.ObjectCreator != null;

		protected override void Execute(ResolveObjectArgs args) => args.Object = Resolve(args);

		protected virtual object Resolve(ResolveObjectArgs args) => args.ObjectCreator.Resolve(CreateObjectCreatorArguments(args));

		protected virtual ObjectCreatorArguments CreateObjectCreatorArguments(ResolveObjectArgs args) => _objectCreatorArgumentsFactory.CreateObjectCreatorArguments(args);
	}
}

The class above just delegates to the IObjectCreator instance of the ResolveObjectArgs instance to create the object

Like the other 4 pipelines — holy cannoli, Batman, there are 5 pipelines in total in this solution! — I created a service class that wraps this new pipeline. The following class serves as a settings class for this service:

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectResolvers
{
	public class ObjectResolverServiceSettings
	{
		public string ResolveObjectPipelineName { get; set; }

		public bool UseTypeCache { get; set; }
	}
}

An instance of the above is created by the Sitecore Configuration Factory.

The following interface defines a family of classes that “resolve” objects. Unlike the other pipelines, we will only have one class that implements this interface:

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectResolvers;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectResolvers
{
	public interface IObjectResolver
	{
		TObject Resolve<TObject>(ObjectResolverArguments arguments) where TObject : class;

		object Resolve(ObjectResolverArguments arguments);
	}
}

The following class implements the interface above:

using Sitecore.Abstractions;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectResolvers;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectResolvers
{
	public class ObjectResolverService : PipelineObjectResolver<ObjectResolverArguments, ResolveObjectArgs, object>, IObjectResolver
	{
		private readonly ObjectResolverServiceSettings _settings;
		private readonly IObjectResolverArgumentsFactory _objectResolverArgumentsFactory;

		public ObjectResolverService(ObjectResolverServiceSettings settings, IObjectResolverArgumentsFactory objectResolverArgumentsFactory, BaseCorePipelineManager corePipelineManager)
			: base(corePipelineManager)
		{
			_settings = settings;
			_objectResolverArgumentsFactory = objectResolverArgumentsFactory;
		}

		public TObject Resolve<TObject>(ObjectResolverArguments arguments) where TObject : class
		{
			return Resolve(arguments) as TObject;
		}

		protected override object GetObject(ResolveObjectArgs args)
		{
			return args.Object;
		}

		protected override ResolveObjectArgs CreatePipelineArgs(ObjectResolverArguments arguments) => _objectResolverArgumentsFactory.CreateResolveObjectArgs(arguments);

		protected override string GetPipelineName() => _settings.ResolveObjectPipelineName;
	}
}

I then register every single thing above — and I mean EVERYTHING — in the Sitecore IoC via the following IServicesConfigurator class:

using System;

using Microsoft.Extensions.DependencyInjection;

using Sitecore.Abstractions;
using Sitecore.DependencyInjection;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectResolvers;
using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.AddDefaultObjectCreatorProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.CacheTypeProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.CreateObjectProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.ResolveTypeProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.SetTypeCacherProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.SetTypeResolverProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.AddDefaultObjectLocatorProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.LocateObjectProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem.AddDefaultItemResolverProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem.ResolveItemProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.SetObjectCreatorProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.SetObjectLocatorProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.AddDefaultTypeResolverProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetItemResolverProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetTypeNameProcessor;
using Sandbox.Foundation.ObjectResolution.Services.Cachers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Reflection;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution
{
	public class ObjectResolutionConfigurator : IServicesConfigurator
	{
		public void Configure(IServiceCollection serviceCollection)
		{
			ConfigureCachers(serviceCollection);
			ConfigureFactories(serviceCollection);
			ConfigureItemResolvers(serviceCollection);
			ConfigureTypeResolvers(serviceCollection);
			ConfigureObjectCreators(serviceCollection);
			ConfigureObjectLocators(serviceCollection);
			ConfigureObjectResolvers(serviceCollection);
			ConfigureResolveItemPipelineProcessors(serviceCollection);
			ConfigureResolveTypePipelineProcessors(serviceCollection);
			ConfigureLocateObjectPipelineProcessors(serviceCollection);
			ConfigureCreateObjectPipelineProcessors(serviceCollection);
			ConfigureResolveObjectPipelineProcessors(serviceCollection);
			ConfigureOtherServices(serviceCollection);
		}

		private void ConfigureCachers(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<ITypeCacher, TypeCacher>();
		}

		private void ConfigureFactories(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IItemResolverArgumentsFactory, ItemResolverArgumentsFactory>();
			serviceCollection.AddSingleton<ITypeResolverArgumentsFactory, TypeResolverArgumentsFactory>();
			serviceCollection.AddSingleton<IObjectLocatorArgumentsFactory, ObjectLocatorArgumentsFactory>();
			serviceCollection.AddSingleton<IObjectCreatorArgumentsFactory, ObjectCreatorArgumentsFactory>();
			serviceCollection.AddSingleton<IObjectResolverArgumentsFactory, ObjectResolverArgumentsFactory>();
		}

		private void ConfigureItemResolvers(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IDatabaseItemResolver, DatabaseItemResolver>();
			serviceCollection.AddSingleton(GetItemResolverServiceSetting);
			serviceCollection.AddSingleton<IItemResolverService, ItemResolverService>();
		}

		private ItemResolverServiceSettings GetItemResolverServiceSetting(IServiceProvider provider)
		{
			return CreateConfigObject<ItemResolverServiceSettings>(provider, "moduleSettings/foundation/objectResolution/itemResolverServiceSettings");
		}

		private void ConfigureTypeResolvers(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IReflectionTypeResolver, ReflectionTypeResolver>();
			serviceCollection.AddSingleton(GetTypeResolverServiceSettings);
			serviceCollection.AddSingleton<ITypeResolverService, TypeResolverService>();
		}

		private TypeResolverServiceSettings GetTypeResolverServiceSettings(IServiceProvider provider)
		{
			return CreateConfigObject<TypeResolverServiceSettings>(provider, "moduleSettings/foundation/objectResolution/typeResolverServiceSettings");
		}

		private void ConfigureObjectCreators(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IReflectionObjectCreator, ReflectionObjectCreator>();
			serviceCollection.AddSingleton(GetObjectCreatorServiceSettings);
			serviceCollection.AddSingleton<IObjectCreatorService, ObjectCreatorService>();
		}

		private ObjectCreatorServiceSettings GetObjectCreatorServiceSettings(IServiceProvider provider)
		{
			return CreateConfigObject<ObjectCreatorServiceSettings>(provider, "moduleSettings/foundation/objectResolution/objectCreatorServiceSettings");
		}

		private void ConfigureObjectLocators(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IServiceProviderLocator, ServiceProviderLocator>();
			serviceCollection.AddSingleton(GetObjectLocatorServiceSettings);
			serviceCollection.AddSingleton<IObjectLocatorService, ObjectLocatorService>();
		}

		private ObjectLocatorServiceSettings GetObjectLocatorServiceSettings(IServiceProvider provider)
		{
			return CreateConfigObject<ObjectLocatorServiceSettings>(provider, "moduleSettings/foundation/objectResolution/objectLocatorServiceSettings");
		}

		private void ConfigureObjectResolvers(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IReflectionObjectCreator, ReflectionObjectCreator>();
			serviceCollection.AddSingleton(GetObjectResolverServiceSettings);
			serviceCollection.AddSingleton<IObjectResolver, ObjectResolverService>();
		}

		private ObjectResolverServiceSettings GetObjectResolverServiceSettings(IServiceProvider provider)
		{
			return CreateConfigObject<ObjectResolverServiceSettings>(provider, "moduleSettings/foundation/objectResolution/objectResolverServiceSettings");
		}

		private void ConfigureResolveItemPipelineProcessors(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IAddDefaultItemResolver, AddDefaultItemResolver>();
			serviceCollection.AddSingleton<IResolveItem, ResolveItem>();
		}

		private void ConfigureResolveTypePipelineProcessors(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<ISetItemResolver, SetItemResolver>();
			serviceCollection.AddSingleton<Pipelines.ResolveType.ResolveTypeProcessor.IResolveItem, Pipelines.ResolveType.ResolveTypeProcessor.ResolveItem>();
			serviceCollection.AddSingleton<ISetTypeName, SetTypeName>();
			serviceCollection.AddSingleton<IAddDefaultTypeResolver, AddDefaultTypeResolver>();
			serviceCollection.AddSingleton<Pipelines.ResolveType.SetTypeCacherProcessor.ISetTypeCacher, Pipelines.ResolveType.SetTypeCacherProcessor.SetTypeCacher>();
			serviceCollection.AddSingleton<Pipelines.ResolveType.ResolveTypeProcessor.IResolveType, Pipelines.ResolveType.ResolveTypeProcessor.ResolveType>();
		}

		private void ConfigureLocateObjectPipelineProcessors(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<Pipelines.LocateObject.SetTypeResolverProcessor.ISetTypeResolver, Pipelines.LocateObject.SetTypeResolverProcessor.SetTypeResolver>();
			serviceCollection.AddSingleton<Pipelines.LocateObject.ResolveTypeProcessor.IResolveType, Pipelines.LocateObject.ResolveTypeProcessor.ResolveType>();
			serviceCollection.AddSingleton<IAddDefaultObjectLocator, AddDefaultObjectLocator>();
			serviceCollection.AddSingleton<ILocateObject, LocateObject>();
		}

		private void ConfigureCreateObjectPipelineProcessors(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<ISetTypeResolver, SetTypeResolver>();
			serviceCollection.AddSingleton<IResolveType, ResolveType>();
			serviceCollection.AddSingleton<IAddDefaultObjectCreator, AddDefaultObjectCreator>();
			serviceCollection.AddSingleton<ICreateObject, CreateObject>();
			serviceCollection.AddSingleton<ISetTypeCacher, SetTypeCacher>();
			serviceCollection.AddSingleton<ICacheType, CacheType>();
		}

		private void ConfigureResolveObjectPipelineProcessors(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<Pipelines.ResolveObject.ISetTypeResolver, Pipelines.ResolveObject.SetTypeResolver>();
			serviceCollection.AddSingleton<Pipelines.ResolveObject.ResolveTypeProcessor.IResolveType, Pipelines.ResolveObject.ResolveTypeProcessor.ResolveType>();
			serviceCollection.AddSingleton<ISetObjectLocator, SetObjectLocator>();
			serviceCollection.AddSingleton<Pipelines.ResolveObject.LocateObjectProcessor.ILocateObject, Pipelines.ResolveObject.LocateObjectProcessor.LocateObject>();
			serviceCollection.AddSingleton<ISetObjectCreator, SetObjectCreator>();
			serviceCollection.AddSingleton<Pipelines.ResolveObject.CreateObjectProcessor.ICreateObject, Pipelines.ResolveObject.CreateObjectProcessor.CreateObject>();
		}

		private void ConfigureOtherServices(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IReflectionUtilService, ReflectionUtilService>();
		}

		private TConfigObject CreateConfigObject<TConfigObject>(IServiceProvider provider, string path) where TConfigObject : class
		{
			BaseFactory factory = GetService<BaseFactory>(provider);
			return factory.CreateObject(path, true) as TConfigObject;
		}

		private TService GetService<TService>(IServiceProvider provider)
		{
			return provider.GetService<TService>();
		}
	}
}

Finally, I strung all the pieces together using the following Sitecore patch config file:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/">
	<sitecore>
		<services>
			<configurator type="Sandbox.Foundation.ObjectResolution.ObjectResolutionConfigurator, Sandbox.Foundation.ObjectResolution" />
		</services>

		<pipelines>
			<resolveItem>
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem.AddDefaultItemResolverProcessor.IAddDefaultItemResolver, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem.ResolveItemProcessor.IResolveItem, Sandbox.Foundation.ObjectResolution" resolve="true" />
			</resolveItem>
			<resolveType>
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetItemResolverProcessor.ISetItemResolver, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.ResolveTypeProcessor.IResolveItem, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetTypeNameProcessor.ISetTypeName, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.AddDefaultTypeResolverProcessor.IAddDefaultTypeResolver, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetTypeCacherProcessor.ISetTypeCacher, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.ResolveTypeProcessor.IResolveType, Sandbox.Foundation.ObjectResolution" resolve="true" />
			</resolveType>
			<locateObject>
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.SetTypeResolverProcessor.ISetTypeResolver, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.ResolveTypeProcessor.IResolveType, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.AddDefaultObjectLocatorProcessor.IAddDefaultObjectLocator, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.LocateObjectProcessor.ILocateObject, Sandbox.Foundation.ObjectResolution" resolve="true" />
			</locateObject>
			<createObject>
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.SetTypeResolverProcessor.ISetTypeResolver, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.ResolveTypeProcessor.IResolveType, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.AddDefaultObjectCreatorProcessor.IAddDefaultObjectCreator, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.CreateObjectProcessor.ICreateObject, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.SetTypeCacherProcessor.ISetTypeCacher, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.CacheTypeProcessor.ICacheType, Sandbox.Foundation.ObjectResolution" resolve="true" />
			</createObject>
			<resolveObject>
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.ISetTypeResolver, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.ResolveTypeProcessor.IResolveType, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.SetObjectLocatorProcessor.ISetObjectLocator, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.LocateObjectProcessor.ILocateObject, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.SetObjectCreatorProcessor.ISetObjectCreator, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.CreateObjectProcessor.ICreateObject, Sandbox.Foundation.ObjectResolution" resolve="true" />
			</resolveObject>
		</pipelines>

		<moduleSettings>
			<foundation>
				<objectResolution>
					<itemResolverServiceSettings type="Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers.ItemResolverServiceSettings, Sandbox.Foundation.ObjectResolution" singleInstance="true">
						<ResolveItemPipelineName>resolveItem</ResolveItemPipelineName>
					</itemResolverServiceSettings>
					<typeResolverServiceSettings type="Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers.TypeResolverServiceSettings, Sandbox.Foundation.ObjectResolution" singleInstance="true">
						<ResolveTypePipelineName>resolveType</ResolveTypePipelineName>
					</typeResolverServiceSettings>
					<objectLocatorServiceSettings type="Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators.ObjectLocatorServiceSettings, Sandbox.Foundation.ObjectResolution" singleInstance="true">
						<LocateObjectPipelineName>locateObject</LocateObjectPipelineName>
					</objectLocatorServiceSettings>
					<objectCreatorServiceSettings type="Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators.ObjectCreatorServiceSettings, Sandbox.Foundation.ObjectResolution" singleInstance="true">
						<CreateObjectPipelineName>createObject</CreateObjectPipelineName>
					</objectCreatorServiceSettings>
					<objectResolverServiceSettings type="Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectResolvers.ObjectResolverServiceSettings, Sandbox.Foundation.ObjectResolution" singleInstance="true">
						<ResolveObjectPipelineName>resolveObject</ResolveObjectPipelineName>
						<UseTypeCache>true</UseTypeCache>
					</objectResolverServiceSettings>
				</objectResolution>
			</foundation>
		</moduleSettings>
</sitecore>
</configuration>

In my next post, I will be using the entire system above for resolving custom Forms Submit Actions from the Sitecore IoC container. Stay tuned for that post.

If you have made it this far, hats off to you. 😉

Sorry for throwing so much at you, but that’s what I do. 😉

On closing, I would like to mention that the system above could be used for resolving types from the Sitecore IoC container for WFFM but this is something that I will not investigate. If you happen to get this to work on WFFM, please share in a comment below.

Until next time, keep on Sitecoring.

Grab Sitecore Experience Forms Configuration Settings from a Custom SQL Server Database Table

05/10/2018 22:29 / 1 Comment on Grab Sitecore Experience Forms Configuration Settings from a Custom SQL Server Database Table

Just the other day, I poking around Sitecore Experience Forms to see what’s customisable and have pretty much concluded virtually everything is.

morpheus

How?

Just have a look at http://[instance]/sitecore/admin/showservicesconfig.aspx of your Sitecore instance and scan for “ExperienceForms”. You will also discover lots of its service class are registered in Sitecore’s IoC container — such makes it easy to swap things out with your own service implementation classes as long as they implement those service types defined in the container.

Since I love to tinkering with all things in Sitecore — most especially when it comes to customising bits of it — I decided to have a crack at replacing IFormsConfigurationSettings — more specifically Sitecore.ExperienceForms.Configuration.IFormsConfigurationSettings in Sitecore.ExperienceForms.dll which represents Sitecore configuration settings for Experience Forms — as it appeared to be something simple enough to do.

The IFormsConfigurationSettings interface represents the following configuration settings:

config-settings-ootb

So, what did I do to customise it?

I wrote a bunch of code — it’s all in this post — which pulls these settings from a custom SQL Server database table.

Why did I do that? Well, I did it because I could. 😉

Years ago, long before my Sitecore days, I worked on ASP.NET Web Applications which had their configuration settings stored in SQL Server databases. Whether this was, or still is, a good idea is a discussion for another time though you are welcome to drop a comment below with your thoughts.

However, for the meantime, just roll with it as the point of this post is to show that you can customise virtually everything in Experience Forms, and I’m just showing one example.

I first created the following class which implements IFormsConfigurationSettings:

using Sitecore.ExperienceForms.Configuration;

namespace Sandbox.Foundation.Forms.Models.Configuration
{
	public class SandboxFormsConfigurationSettings : IFormsConfigurationSettings
	{
		public string ConnectionStringName { get; set; }

		public string FieldsPrefix { get; set; }

		public string FieldsIndexName { get; set; }
	}
}

You might be asking “Mike, why did you create an implementation class when Experience Forms already provides one ‘out of the box’?”

Well, all the properties defined in Sitecore.ExperienceForms.Configuration.IFormsConfigurationSettings — these are the same properties that you see in the implementation class above — lack mutators on them in the interface. My implementation class of IFormsConfigurationSettings adds them in — I hate baking method calls in property accessors as it doesn’t seem clean to me. ¯\_(ツ)_/¯

When I had a look at the “out of the box” implementation class of IFormsConfigurationSettings, I discovered direct calls to the GetSetting() method on the Sitecore.Configuration.Settings static class — this lives in Sitecore.Kernel.dll — but that doesn’t help me with setting those properties, hence the custom IFormsConfigurationSettings class above.

Next, I used the following SQL script to create my custom settings database table:

USE [ExperienceFormsSettings]
GO

CREATE TABLE [dbo].[FormsConfigurationSettings](
	[FieldsPrefix] [nvarchar](max) NULL,
	[FieldsIndexName] [nvarchar](max) NULL,
	[ConnectionStringName] [nvarchar](max) NULL
) ON [PRIMARY] TEXTIMAGE_ON [PRIMARY]
GO

I then inserted the settings from the configuration file snapshot above into my new table (I’ve omitted the SQL insert statement for this):

config-database

Now we need a way to retrieve these settings from the database. The following interface will be for factory classes which create instances of Sitecore.Data.DataProviders.Sql.SqlDataApi — this lives in Sitecore.Kernel.dll — with the passed connection strings:

using Sitecore.Data.DataProviders.Sql;

namespace Sandbox.Foundation.Forms.Services.Factories
{
	public interface ISqlDataApiFactory
	{
		SqlDataApi CreateSqlDataApi(string connectionString);
	}
}

Well, we can’t do much with an interface without having some class implement it. The following class implements the interface above:

using Sitecore.Data.DataProviders.Sql;
using Sitecore.Data.SqlServer;

namespace Sandbox.Foundation.Forms.Services.Factories
{
	public class SqlDataApiFactory : ISqlDataApiFactory
	{
		public SqlDataApi CreateSqlDataApi(string connectionString)
		{
			if(string.IsNullOrWhiteSpace(connectionString))
			{
				return null;
			}

			return new SqlServerDataApi(connectionString);
		}
	}
}

It’s just creating an instance of the SqlServerDataApi class. Nothing special about it at all.

Ironically, I do have to save my own configuration settings in Sitecore Configuration — this would include the the connection string name to the database that contains my new table as well as a few other things.

An instance of the following class will contain these settings — have a look at /sitecore/moduleSettings/foundation/forms/repositorySettings in the Sitecore patch file near the bottom of this post but be sure to come back up here when you are finished 😉 — and this instance will be put into the Sitecore IoC container so it can be injected in an instance of a class I’ll talk about further down in this post:

namespace Sandbox.Foundation.Forms.Models.Configuration
{
	public class RepositorySettings
	{
		public string ConnectionStringName { get; set; }

		public string GetSettingsSql { get; set; }

		public string ConnectionStringNameColumnName { get; set; }

		public string FieldsPrefixColumnName { get; set; }

		public string FieldsIndexNameColumnName { get; set; }

		public int NotFoundOrdinal { get; set; }
	}
}

I then defined the following interface for repository classes which retrieve IFormsConfigurationSettings instances:

using Sitecore.ExperienceForms.Configuration;

namespace Sandbox.Foundation.Forms.Repositories.Configuration
{
	public interface ISettingsRepository
	{
		IFormsConfigurationSettings GetFormsConfigurationSettings();
	}
}

Here’s the implementation class for the interface above:

using System;
using System.Data;
using System.Linq;

using Sitecore.Abstractions;
using Sitecore.Data.DataProviders.Sql;
using Sitecore.ExperienceForms.Configuration;
using Sitecore.ExperienceForms.Diagnostics;

using Sandbox.Foundation.Forms.Models.Configuration;
using Sandbox.Foundation.Forms.Services.Factories;

namespace Sandbox.Foundation.Forms.Repositories.Configuration
{
	public class SettingsRepository : ISettingsRepository
	{
		private readonly RepositorySettings _repositorySettings;
		private readonly BaseSettings _settings;
		private readonly int _notFoundOrdinal;
		private readonly ILogger _logger;
		private readonly SqlDataApi _sqlDataApi;

		public SettingsRepository(RepositorySettings repositorySettings, BaseSettings settings, ILogger logger, ISqlDataApiFactory sqlDataApiFactory)
		{
			_repositorySettings = repositorySettings;
			_settings = settings;
			_notFoundOrdinal = GetNotFoundOrdinal();
			_logger = logger;
			_sqlDataApi = GetSqlDataApi(sqlDataApiFactory);
		}

		protected virtual SqlDataApi GetSqlDataApi(ISqlDataApiFactory sqlDataApiFactory)
		{
			return sqlDataApiFactory.CreateSqlDataApi(GetConnectionString());
		}

		protected virtual string GetConnectionString()
		{
			return _settings.GetConnectionString(GetConnectionStringName());
		}

		protected virtual string GetConnectionStringName()
		{
			return _repositorySettings.ConnectionStringName;
		}

		public IFormsConfigurationSettings GetFormsConfigurationSettings()
		{
			try
			{
				return _sqlDataApi.CreateObjectReader(GetSqlQuery(), GetParameters(), GetMaterializer()).FirstOrDefault();
			}
			catch (Exception ex)
			{
				LogError(ex);

			}

			return CreateFormsConfigurationSettingsNullObject();
		}

		protected virtual string GetSqlQuery()
		{
			return _repositorySettings.GetSettingsSql;
		}

		protected virtual object[] GetParameters()
		{
			return Enumerable.Empty<object>().ToArray();
		}

		protected virtual Func<IDataReader, IFormsConfigurationSettings> GetMaterializer()
		{
			return new Func<IDataReader, IFormsConfigurationSettings>(ParseFormsConfigurationSettings);
		}

		protected virtual IFormsConfigurationSettings ParseFormsConfigurationSettings(IDataReader dataReader)
		{
			return new SandboxFormsConfigurationSettings
			{
				ConnectionStringName = GetString(dataReader, GetConnectionStringNameColumnName()),
				FieldsPrefix = GetString(dataReader, GetFieldsPrefixColumnName()),
				FieldsIndexName = GetString(dataReader, GetFieldsIndexNameColumnName())
			};
		}

		protected virtual string GetString(IDataReader dataReader, string columnName)
		{
			if(dataReader == null || string.IsNullOrWhiteSpace(columnName))
			{
				return string.Empty;

			}

			int ordinal = GetOrdinal(dataReader, columnName);
			if(ordinal == _notFoundOrdinal)
			{
				return string.Empty;
			}

			return dataReader.GetString(ordinal);
		}

		protected virtual int GetOrdinal(IDataReader dataReader, string columnName)
		{
			if(dataReader == null || string.IsNullOrWhiteSpace(columnName))
			{
				return _notFoundOrdinal;
			}

			try
			{
				return dataReader.GetOrdinal(columnName);
			}
			catch(IndexOutOfRangeException)
			{
				return _notFoundOrdinal;
			}
		}

		protected virtual int GetNotFoundOrdinal()
		{
			return _repositorySettings.NotFoundOrdinal;
		}

		protected virtual void LogError(Exception exception)
		{
			_logger.LogError(ToString(), exception, this);
		}

		protected virtual string GetConnectionStringNameColumnName()
		{
			return _repositorySettings.ConnectionStringNameColumnName;
		}

		protected virtual string GetFieldsPrefixColumnName()
		{
			return _repositorySettings.FieldsPrefixColumnName;
		}

		protected virtual string GetFieldsIndexNameColumnName()
		{
			return _repositorySettings.FieldsIndexNameColumnName;
		}

		protected virtual IFormsConfigurationSettings CreateFormsConfigurationSettingsNullObject()
		{
			return new SandboxFormsConfigurationSettings
			{
				ConnectionStringName = string.Empty,
				FieldsIndexName = string.Empty,
				FieldsPrefix = string.Empty
			};
		}
	}
}

I’m not going to go into details of all the code above but will talk about some important pieces.

The GetFormsConfigurationSettings() method above creates an instance of the IFormsConfigurationSettings instance using the SqlDataApi instance created from the injected factory service — this was defined above — with the SQL query provided from configuration along with the GetMaterializer() method which just uses the ParseFormsConfigurationSettings() method to create an instance of the IFormsConfigurationSettings by grabbing data from the IDataReader instance.

Phew, I’m out of breath as that was a mouthful. 😉

I then registered all of my service classes above in the Sitecore IoC container using the following the configurator — aka a class that implements the IServicesConfigurator interface:

using System;

using Microsoft.Extensions.DependencyInjection;

using Sitecore.Abstractions;
using Sitecore.DependencyInjection;
using Sitecore.ExperienceForms.Configuration;

using Sandbox.Foundation.Forms.Repositories.Configuration;
using Sandbox.Foundation.Forms.Models.Configuration;

using Sandbox.Foundation.Forms.Services.Factories;

namespace Sandbox.Foundation.Forms
{
	public class SettingsConfigurator : IServicesConfigurator
	{
		public void Configure(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton(provider => GetRepositorySettings(provider));
			serviceCollection.AddSingleton<ISqlDataApiFactory, SqlDataApiFactory>();
			serviceCollection.AddSingleton<ISettingsRepository, SettingsRepository>();
			serviceCollection.AddSingleton(provider => GetFormsConfigurationSettings(provider));
		}

		private RepositorySettings GetRepositorySettings(IServiceProvider provider)
		{
			return CreateConfigObject<RepositorySettings>(provider, "moduleSettings/foundation/forms/repositorySettings");
		}

		private TConfigObject CreateConfigObject<TConfigObject>(IServiceProvider provider, string path) where TConfigObject : class
		{
			BaseFactory factory = GetService<BaseFactory>(provider);
			return factory.CreateObject(path, true) as TConfigObject;
		}

		private IFormsConfigurationSettings GetFormsConfigurationSettings(IServiceProvider provider)
		{
			ISettingsRepository repository = GetService<ISettingsRepository>(provider);
			return repository.GetFormsConfigurationSettings();
		}

		private TService GetService<TService>(IServiceProvider provider)
		{
			return provider.GetService<TService>();
		}
	}
}

One thing to note is the GetRepositorySettings() method above uses the Configuration Factory — this is represented by the BaseFactory abstract class which lives in the Sitecore IoC container “out of the box” — to create an instance of the RepositorySettings class, defined further up in this post, using the settings in the following Sitecore patch file:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/">
	<sitecore>
		<services>
			<configurator type="Sandbox.Foundation.Forms.SettingsConfigurator, Sandbox.Foundation.Forms" />
			<register serviceType="Sitecore.ExperienceForms.Configuration.IFormsConfigurationSettings, Sitecore.ExperienceForms">
				<patch:delete />
			</register>
		</services>

		<moduleSettings>
			<foundation>
				<forms>
					<repositorySettings type="Sandbox.Foundation.Forms.Models.Configuration.RepositorySettings, Sandbox.Foundation.Forms" singleInstance="true">
						<ConnectionStringName>ExperienceFormsSettings</ConnectionStringName>
						<GetSettingsSql>SELECT TOP (1) {0}ConnectionStringName{1},{0}FieldsPrefix{1},{0}FieldsIndexName{1} FROM {0}FormsConfigurationSettings{1}</GetSettingsSql>
						<ConnectionStringNameColumnName>ConnectionStringName</ConnectionStringNameColumnName>
						<FieldsPrefixColumnName>FieldsPrefix</FieldsPrefixColumnName>
						<FieldsIndexNameColumnName>FieldsIndexName</FieldsIndexNameColumnName>
						<NotFoundOrdinal>-1</NotFoundOrdinal>
					</repositorySettings>
				</forms>
			</foundation>
		</moduleSettings>
	</sitecore>
</configuration>

I want to point out that I’m deleting the Sitecore.ExperienceForms.Configuration.IFormsConfigurationSettings service from Sitecore’s configuration as I am adding it back in to the Sitecore IoC container with my own via the configurator above.

After deploying everything, I waited for my Sitecore instance to reload.

Once Sitecore was responsive again, I navigated to “Forms” on the Sitecore Launch Pad and made sure everything had still worked as before.

It did.

Trust me, it did. 😉

living-in-db

If you have any questions/comments on any of the above, or would just like to drop a line to say “hello”, then please share in a comment below.

Otherwise, until next time, keep on Sitecoring.

Encrypt Sitecore Experience Forms Data in Powerful Ways

05/03/2018 22:38 / 1 Comment on Encrypt Sitecore Experience Forms Data in Powerful Ways

Last week, I was honoured to co-present Sitecore Experience Forms alongside my dear friend — and fellow trollster 😉 — Sitecore MVP Kamruz Jaman at SUGCON EU 2018. We had a blast showing the ins and outs of Experience Forms, and of course trolled a bit whilst on the main stage.

During our talk, Kamruz had mentioned the possibility of replacing the “Out of the Box” (OOTB) Sitecore.ExperienceForms.Data.IFormDataProvider — this lives in Sitecore.ExperienceForms.dll — whose class implementations serve as Repository objects for storing or retrieving from some datastore (in Experience Forms this is MS SQL Server OOTB) with another to encrypt/decrypt data when saving to or retrieving from the datastore.

Well, I had done something exactly like this for Web Forms for Marketers (WFFM) about five years ago — be sure to have a read my blog post on this before proceeding as it gives context to the rest of this blog post — so thought it would be appropriate for me to have a swing at doing this for Experience Forms.

I first created an interface for classes that will encrypt/decrypt strings — this is virtually the same interface I had used in my older post on encrypting data in WFFM:

namespace Sandbox.Foundation.Forms.Services.Encryption
{
	public interface IEncryptor
	{
		string Encrypt(string key, string input);

		string Decrypt(string key, string input);
	}
}

I then created a class to encrypt/decrypt strings using the RC2 encryption algorithm — I had also poached this from my older post on encrypting data in WFFM (please note, this encryption algorithm is not the most robust so do not use this in any production environment. Please be sure to use something more robust):

using System.Text;
using System.Security.Cryptography;

namespace Sandbox.Foundation.Forms.Services.Encryption
{
	public class RC2Encryptor : IEncryptor
	{
		public string Encrypt(string key, string input)
		{
			byte[] inputArray = UTF8Encoding.UTF8.GetBytes(input);
			RC2CryptoServiceProvider rc2 = new RC2CryptoServiceProvider();
			rc2.Key = UTF8Encoding.UTF8.GetBytes(key);
			rc2.Mode = CipherMode.ECB;
			rc2.Padding = PaddingMode.PKCS7;
			ICryptoTransform cTransform = rc2.CreateEncryptor();
			byte[] resultArray = cTransform.TransformFinalBlock(inputArray, 0, inputArray.Length);
			rc2.Clear();
			return System.Convert.ToBase64String(resultArray, 0, resultArray.Length);
		}

		public string Decrypt(string key, string input)
		{
			byte[] inputArray = System.Convert.FromBase64String(input);
			RC2CryptoServiceProvider rc2 = new RC2CryptoServiceProvider();
			rc2.Key = UTF8Encoding.UTF8.GetBytes(key);
			rc2.Mode = CipherMode.ECB;
			rc2.Padding = PaddingMode.PKCS7;
			ICryptoTransform cTransform = rc2.CreateDecryptor();
			byte[] resultArray = cTransform.TransformFinalBlock(inputArray, 0, inputArray.Length);
			rc2.Clear();
			return UTF8Encoding.UTF8.GetString(resultArray);
		}
	}
}

Next, I created the following class to store settings I need for encrypting and decrypting data using the RC2 algorithm class above:

namespace Sandbox.Foundation.Forms.Models
{
	public class FormEncryptionSettings
	{
		public string EncryptionKey { get; set; }
	}
}

The encryption key above is needed for the RC2 algorithm to encrypt/decrypt data. I set this key in a config object defined in a Sitecore patch configuration file towards the bottom of this post.

I then created an interface for classes that will encrypt/decrypt FormEntry instances (FormEntry objects contain submitted data from form submissions):

using Sitecore.ExperienceForms.Data.Entities;

namespace Sandbox.Foundation.Forms.Services.Encryption
{
	public interface IFormEntryEncryptor
	{
		void EncryptFormEntry(FormEntry entry);

		void DecryptFormEntry(FormEntry entry);
	}
}

The following class implements the interface above:

using System.Linq;

using Sitecore.ExperienceForms.Data.Entities;

using Sandbox.Foundation.Forms.Models;

namespace Sandbox.Foundation.Forms.Services.Encryption
{
	public class FormEntryEncryptor : IFormEntryEncryptor
	{
		private readonly FormEncryptionSettings _formEncryptionSettings;
		private readonly IEncryptor _encryptor;

		public FormEntryEncryptor(FormEncryptionSettings formEncryptionSettings, IEncryptor encryptor)
		{
			_formEncryptionSettings = formEncryptionSettings;
			_encryptor = encryptor;
		}

		public void EncryptFormEntry(FormEntry entry)
		{
			if (!HasFields(entry))
			{
				return;
			}

			foreach (FieldData field in entry.Fields)
			{
				EncryptField(field);
			}
		}

		protected virtual void EncryptField(FieldData field)
		{
			if(field == null)
			{
				return;
			}

			field.FieldName = Encrypt(field.FieldName);
			field.Value = Encrypt(field.Value);
			field.ValueType = Encrypt(field.ValueType);
		}

		protected virtual string Encrypt(string input)
		{
			return _encryptor.Encrypt(_formEncryptionSettings.EncryptionKey, input);
		}

		public void DecryptFormEntry(FormEntry entry)
		{
			if (!HasFields(entry))
			{
				return;
			}

			foreach (FieldData field in entry.Fields)
			{
				DecryptField(field);
			}
		}

		protected virtual bool HasFields(FormEntry entry)
		{
			return entry != null
					&& entry.Fields != null
					&& entry.Fields.Any();
		}

		protected virtual void DecryptField(FieldData field)
		{
			if(field == null)
			{
				return;
			}

			field.FieldName = Decrypt(field.FieldName);
			field.Value = Decrypt(field.Value);
			field.ValueType = Decrypt(field.ValueType);
		}

		protected virtual string Decrypt(string input)
		{
			return _encryptor.Decrypt(_formEncryptionSettings.EncryptionKey, input);
		}
	}
}

The EncryptFormEntry() method above iterates over all FieldData objects contained on the FormEntry instance, and passes them to the EncryptField() mehod which encrypts the FieldName, Value and ValueType properties on them.

Likewise, the DecryptFormEntry() method iterates over all FieldData objects contained on the FormEntry instance, and passes them to the DecryptField() mehod which decrypts the same properties mentioned above.

I then created an interface for classes that will serve as factories for IFormDataProvider instances:

using Sitecore.ExperienceForms.Data;
using Sitecore.ExperienceForms.Data.SqlServer;

namespace Sandbox.Foundation.Forms.Services.Factories
{
	public interface IFormDataProviderFactory
	{
		IFormDataProvider CreateNewSqlFormDataProvider(ISqlDataApiFactory sqlDataApiFactory);
	}
}

The following class implements the interface above:

using Sitecore.ExperienceForms.Data;
using Sitecore.ExperienceForms.Data.SqlServer;

namespace Sandbox.Foundation.Forms.Services.Factories
{
	public class FormDataProviderFactory : IFormDataProviderFactory
	{
		public IFormDataProvider CreateNewSqlFormDataProvider(ISqlDataApiFactory sqlDataApiFactory)
		{
			return new SqlFormDataProvider(sqlDataApiFactory);
		}
	}
}

The CreateNewSqlFormDataProvider() method above does exactly was the method name says. You’ll see it being used in the following class below.

This next class ultimately becomes the new IFormDataProvider instance but decorates the OOTB one which is created from the factory class above:

using System;
using System.Collections.Generic;
using System.Linq;


using Sitecore.ExperienceForms.Data;
using Sitecore.ExperienceForms.Data.Entities;
using Sitecore.ExperienceForms.Data.SqlServer;

using Sandbox.Foundation.Forms.Services.Encryption;
using Sandbox.Foundation.Forms.Services.Factories;

namespace Sandbox.Foundation.Forms.Services.Data
{
	public class FormEncryptionDataProvider : IFormDataProvider
	{
		private readonly IFormDataProvider _innerProvider;
		private readonly IFormEntryEncryptor _formEntryEncryptor;

		public FormEncryptionDataProvider(ISqlDataApiFactory sqlDataApiFactory, IFormDataProviderFactory formDataProviderFactory, IFormEntryEncryptor formEntryEncryptor)
		{
			_innerProvider = CreateInnerProvider(sqlDataApiFactory, formDataProviderFactory);
			_formEntryEncryptor = formEntryEncryptor;
		}

		protected virtual IFormDataProvider CreateInnerProvider(ISqlDataApiFactory sqlDataApiFactory, IFormDataProviderFactory formDataProviderFactory)
		{
			return formDataProviderFactory.CreateNewSqlFormDataProvider(sqlDataApiFactory);
		}

		public void CreateEntry(FormEntry entry)
		{
			EncryptFormEntryField(entry);
			_innerProvider.CreateEntry(entry);
		}

		protected virtual void EncryptFormEntryField(FormEntry entry)
		{
			_formEntryEncryptor.EncryptFormEntry(entry);
		}

		public void DeleteEntries(Guid formId)
		{
			_innerProvider.DeleteEntries(formId);
		}

		public IReadOnlyCollection<FormEntry> GetEntries(Guid formId, DateTime? startDate, DateTime? endDate)
		{
			IReadOnlyCollection<FormEntry>  entries = _innerProvider.GetEntries(formId, startDate, endDate);
			if(entries == null || !entries.Any())
			{
				return entries;
			}

			foreach(FormEntry entry in entries)
			{
				DecryptFormEntryField(entry);
			}

			return entries;
		}

		protected virtual void DecryptFormEntryField(FormEntry entry)
		{
			_formEntryEncryptor.DecryptFormEntry(entry);
		}
	}
}

The class above does delegation to the IFormEntryEncryptor instance to encrypt the FormEntry data and then passes the FormEntry to the inner provider for saving.

For decrypting, it retrieves the data from the inner provider, and then decrypts it via the IFormEntryEncryptor instance before returning to the caller.

Finally, I created an IServicesConfigurator class to wire everything up into the Sitecore container (I hope you are using Sitecore Dependency Injection capabilities as this comes OOTB — there are no excuses for not using this!!!!!!):

using System;

using Microsoft.Extensions.DependencyInjection;

using Sitecore.Abstractions;
using Sitecore.DependencyInjection;
using Sitecore.ExperienceForms.Data;

using Sandbox.Foundation.Forms.Models;
using Sandbox.Foundation.Forms.Services.Encryption;
using Sandbox.Foundation.Forms.Services.Data;
using Sandbox.Foundation.Forms.Services.Factories;

namespace Sandbox.Foundation.Forms
{
	public class FormsServicesConfigurator : IServicesConfigurator
	{
		public void Configure(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton(provider => GetFormEncryptionSettings(provider));
			serviceCollection.AddSingleton<IEncryptor, RC2Encryptor>();
			serviceCollection.AddSingleton<IFormEntryEncryptor, FormEntryEncryptor>();
			serviceCollection.AddSingleton<IFormDataProviderFactory, FormDataProviderFactory>();
			serviceCollection.AddSingleton<IFormDataProvider, FormEncryptionDataProvider>();
		}

		private FormEncryptionSettings GetFormEncryptionSettings(IServiceProvider provider)
		{
			return CreateConfigObject<FormEncryptionSettings>(provider, "moduleSettings/foundation/forms/formEncryptionSettings");
		}

		private TConfigObject CreateConfigObject<TConfigObject>(IServiceProvider provider, string path) where TConfigObject : class
		{
			BaseFactory factory = GetService<BaseFactory>(provider);
			return factory.CreateObject(path, true) as TConfigObject;
		}

		private TService GetService<TService>(IServiceProvider provider)
		{
			return provider.GetService<TService>();
		}
	}
}

Everything above is normal service class registration except for the stuff in the GetFormEncryptionSettings() method. Here, I’m creating an instance of a FormEncryptionSettings class but am instantiating it using the Sitecore Configuration Factory for the configuration object defined in the Sitecore patch configuration file below, and am making that available for being injected into classes that need it (the FormEntryEncryptor above uses it).

I then wired everything together using the following Sitecore patch configuration file:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/">
	<sitecore>
		<services>
			<configurator type="Sandbox.Foundation.Forms.FormsServicesConfigurator, Sandbox.Foundation.Forms" />
			<register serviceType="Sitecore.ExperienceForms.IFormDataProvider, Sitecore.ExperienceForms">
				<patch:delete />
			</register>
		</services>
		<moduleSettings>
			<foundation>
				<forms>
					<formEncryptionSettings type="Sandbox.Foundation.Forms.Models.FormEncryptionSettings, Sandbox.Foundation.Forms" singleInstance="true">
						<!-- I stole this from https://sitecorejunkie.com/2013/06/21/encrypt-web-forms-for-marketers-fields-in-sitecore/ -->
						<EncryptionKey>88bca90e90875a</EncryptionKey>
					</formEncryptionSettings>
				</forms>
			</foundation>
		</moduleSettings>
	</sitecore>
</configuration>

I want to call out that I’m deleting the OOTB IFormDataProvider above using a patch:delete. I’m re-adding it via the IServicesConfigurator above using the decorator class previously shown above.

Let’s take this for a spin.

I first created a new form (this is under “Forms” on the Sitecore Launchepad ):

I then put it on a page with an MVC Layout; published everything; navigated to the test page with the form created above; filled out the form; and then clicked the submit button:

Let’s see if the data was encrypted. I opened up SQL Server Management Studio and ran a query on the FormEntry table in my Experience Forms Database:

As you can see the data was encrypted.

Let’s export the data to make sure it gets decrypted. We can do that by exporting the data as a CSV from Forms in the Sitecore Launchpad:

As you can see the data is decrypted in the CSV:

I do want to mention that Sitecore MVP João Neto had provided two other methods for encrypting data in Experience Forms in a post he wrote last January. I recommend having a read of that.

Until next time, see you on the Sitecore Slack 😉

Inject Dependencies Into Sitecore MVC Razor Views Using a SitecoreHelper Extension Method

12/29/2015 01:07 / 2 Comments on Inject Dependencies Into Sitecore MVC Razor Views Using a SitecoreHelper Extension Method

Last week before the Christmas holiday break, I came up with a solution similar to what I am going to show here except that I had used the Simple Injector Dependency Injection framework in that solution (if you would like me to add a blog post on that approach, please let me know in a comment).

I wanted a “quick and dirty” solution — well, I guess this is really in the eye of the beholder on whether the following is a good idea or not, but I’m throwing it out there just in case it helps out someone — where I could inject a dependency into an MVC Razor view via an HtmlHelper extension method, and in that solution, I used this approach for injecting an object instance which grabs values from a Sitecore Dictionary Domain. I am going to recreate this solution here though using the Sitecore Configuration Factory (we’re all not using Simple Injector in our solutions but the Sitecore Configuration Factory is available to all of us via the Sitecore API).

I first defined the following interface for class instances which return a value for a given dictionary entry key:

using Sitecore.Globalization;

namespace Sitecore.Sandbox.Dictionaries
{
    public interface ITranslator
    {
        string Text(string key, params object[] parameters);

        string Text(TranslateOptions options, string key, params object[] parameters);
    }
}

The following class implements the interface above:

using Sitecore.Diagnostics;
using Sitecore.Globalization;

namespace Sitecore.Sandbox.Dictionaries
{
    public class DomainDictionaryTranslator : ITranslator
    {
        public string Domain { get; set; }

        public virtual string Text(string key, params object[] parameters)
        {
            AssertDomainDictionary();
            Assert.ArgumentNotNullOrEmpty(key, "key");
            return Translate.TextByDomain(Domain, key, parameters);
        }

        public virtual string Text(TranslateOptions options, string key, params object[] parameters)
        {
            AssertDomainDictionary();
            Assert.ArgumentNotNullOrEmpty(key, "key");
            return Translate.TextByDomain(Domain, options, key, parameters);
        }

        protected virtual void AssertDomainDictionary()
        {
            Assert.IsNotNullOrEmpty(Domain, "The Domain must be set!");
        }
    }
}

Client code of the class above must supply the Domain name for the Sitecore Dictionary via the Domain property on the class.

Client code can then use either Text method by supplying a key for the lookup — both methods just delegate to the corresponding static methods defined on the Sitecore.Globalization.Translate class.

We now need classes that serve as Factories. I created the following interface for such classes:

namespace Sitecore.Sandbox.Helpers.Sitecore
{
    public interface IFactory
    {
        T CreateObject<T>(string configPath, bool assert) where T : class;
    }
}

The following class implements the above interface, and basically has one method that delegates to the static CreateObject() method on the Sitecore.Configuration.Factory class:

using Sitecore.Configuration;

namespace Sitecore.Sandbox.Helpers.Sitecore
{
    public class ConfigurationFactory : IFactory
    {
        public T CreateObject<T>(string configPath, bool assert) where T : class
        {
            return Factory.CreateObject(configPath, assert) as T;
        }
    }
}

Now, we need an extension method on the Sitecore.Mvc.Helpers.SitecoreHelper class — this lives in Sitecore.Mvc.dll — so that we can leverage the code defined above (check out Sitecore MVP Kevin Brechbühl’s blog post where he talks about this approach as well as another):

using Sitecore.Configuration;
using Sitecore.Diagnostics;
using Sitecore.Mvc.Helpers;

namespace Sitecore.Sandbox.Helpers.Sitecore
{
    public static class ConfigurationFactoryHelper
    {
        private static IFactory ConfigurationFactory { get; set; }

        static ConfigurationFactoryHelper()
        {
            ConfigurationFactory = CreateFactory();
        }

        public static T CreateObject<T>(this SitecoreHelper sitecoreHelper, string configPath, bool assert) where T : class
        {
            return ConfigurationFactory.CreateObject<T>(configPath, assert);
        }

        private static IFactory CreateFactory()
        {
            IFactory factory = Factory.CreateObject("configurationFactory", true) as IFactory;
            Assert.IsNotNull(factory, "The configurationFactory must be defined in configuration!");
            return factory;
        }
    }
}

We are instantiating an instance of the ConfigurationFactory class defined above via the Sitecore Configuration Factory, and then setting it on a static property in this class — all members and methods on this class must be static since it contains extension methods.

The CreateObject() method just delegates to the ConfigurationFactory class instance’s CreateObject() method and returns its value.

I then glued everything together using the following Sitecore patch configuration file:

<?xml version="1.0" encoding="utf-8" ?>
<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/">
  <sitecore>
    <configurationFactory type="Sitecore.Sandbox.Helpers.Sitecore.ConfigurationFactory, Sitecore.Sandbox" singleInstance="true" />
    <domainDictionaryTranslator type="Sitecore.Sandbox.Dictionaries.DomainDictionaryTranslator, Sitecore.Sandbox" singleInstance="true">
      <Domain>MyCoolDictionary</Domain>
    </domainDictionaryTranslator>
  </sitecore>
</configuration>

Let’s see this in action!

First, we need a Dictionary Domain. I created one with the following folder with entries:

Now, we new a Razor view to make this work. I created the following, and mapped it to my home page’s presentation details:

@using Sitecore.Mvc;
@using Sitecore.Sandbox.Helpers.Sitecore
@using Sitecore.Sandbox.Dictionaries

@{
    var translator = Html.Sitecore().CreateObject<ITranslator>("domainDictionaryTranslator", true);
    if (translator == null)
    {
        return;
    }

    var labelOne = translator.Text("mycooldictionary.somelabels.labelone");
    var labelTwo = translator.Text("mycooldictionary.somelabels.labeltwo");
    if (string.IsNullOrWhiteSpace(labelOne) && string.IsNullOrWhiteSpace(labelTwo))
    {
        return;
    }
}

<div>
    @if (!string.IsNullOrWhiteSpace(labelOne))
    {
        <h2>@labelOne</h2>
    }

    @if (!string.IsNullOrWhiteSpace(labelTwo))
    {
        <h2>@labelTwo</h2>
    }
</div>

After building and deploying, I navigated to my home page. As you can see, the dictionary entry values display:

If you have any thoughts on this, please drop a comment.

Make Incompatible Class Interfaces Work Together using the Adapter Pattern in Sitecore

06/17/2015 00:10 / Leave a comment

This post is a continuation of a series of blog posts I’m putting together around using design patterns in Sitecore, and will share a “proof of concept” on employing the Adapter pattern — a structural pattern used when you need classes of different interfaces to work together. In other words, you need one class’ interface to “adapt” to another.

Believe it or not, most developers — and hopefully most reading this post — are already quite familiar with the Adapter pattern even if it’s not recognizable by name.

How so?

Well, I don’t know about you but I spend a lot of time making code from different APIs work together. I typically have to do this when making use of a third-party library that I cannot change, and usually do this by having one class “wrap” another and its methods. Commonly, the Adapter pattern is known as a “wrapper”.

I showcased the following “proof of concept” during my presentation at SUGCON Europe 2015. This code flips images upside down after they are uploaded to the Media Library — yeah, I know, pretty useful, right? 😉 Keep in mind this code is for educational purposes only, and serves no utility in any practical sense in your Sitecore solutions — if you do have a business need for flipping images upside down after uploading them to the Media Library, please share in a comment.

I first started off with the following interface:

using Sitecore.Data.Items;

namespace Sitecore.Sandbox.Resources.Media
{
    public interface IMediaImageFlipper
    {
        MediaItem MediaItem { get; set; }

        void Flip();
    }
}

Classes that implement the interface above basically flip images within Sitecore.Data.Items.MediaItem instances — this is defined in Sitecore.Kernel.dll — upside down via their Flip() method.

The following class implements the above interface:

using System;
using System.Collections.Generic;
using System.Linq;
using System.IO;

using Sitecore.Data.Items;
using Sitecore.Diagnostics;

using ImageProcessor;

namespace Sitecore.Sandbox.Resources.Media
{
    public class ImageFactoryFlipper : IMediaImageFlipper
    {
        public MediaItem MediaItem { get; set; }

        private List<string> TargetMimeTypes { get; set; }

        private ImageFactory ImageFactory { get; set; }

        public ImageFactoryFlipper()
            : this(new ImageFactory())
        {
        }

        public ImageFactoryFlipper(ImageFactory imageFactory)
        {
            TargetMimeTypes = new List<string>();
            Assert.ArgumentNotNull(imageFactory, "imageFactory");
            ImageFactory = imageFactory;
        }

        public void Flip()
        {
            if (!ShouldFlip(MediaItem))
            {
                return;
            }

            using (MemoryStream outputStream = new MemoryStream())
            {
                ImageFactory.Load(MediaItem.GetMediaStream()).Rotate(180.0f).Save(outputStream);

                using (new EditContext(MediaItem))
                {
                    MediaItem.InnerItem.Fields["Blob"].SetBlobStream(outputStream);
                }
            }
        }

        protected virtual bool ShouldFlip(MediaItem mediaItem)
        {
            if (mediaItem == null || string.IsNullOrWhiteSpace(mediaItem.MimeType) || !TargetMimeTypes.Any() || ImageFactory == null)
            {
                return false;
            }

            return TargetMimeTypes.Any(targetMimeType => string.Equals(targetMimeType, mediaItem.MimeType, StringComparison.CurrentCultureIgnoreCase));
        }
    }
}

In the above class, I am “wrapping” an ImageFactory class instance — this class comes with the ImageProcessor .NET library which does some image manipulation (I found this .NET library via a Google search and have no idea how good it is, but it’s good enough for this “proof of concept”) — and inject it using Poor man’s dependency injection via the default constructor.

The Flip() method is where the magic happens. It calls the ShouldFlip() method which ascertains whether the MediaItem property is set on the class instance and whether the image found within it should be flipped — an image should be flipped if it has a MIME type that is within the list of MIME types that are injected into the class instance via the Sitecore Configuration Factory (see the patch configuration file below).

If the image should be flipped, the Flip() method uses the ImageFactory instance to flip the image upside down — it does this by rotating it 180 degrees — and then saves the flipped image contained within the MemoryStream instance into the MediaItem’s Blob field (this is where images are saved on Media Library Items).

Now that we have a class that flips images, we need a MediaCreator — a subclass of Sitecore.Resources.Media.MediaCreator (this lives in Sitecore.Kernel.dll) — to leverage an instance of the IMediaImageFlipper to do the image manipulation. The follow class does this:

using System.IO;

using Sitecore.Data.Items;
using Sitecore.Resources.Media;

namespace Sitecore.Sandbox.Resources.Media
{
    public class ImageFlipperMediaCreator : MediaCreator
    {
        private IMediaImageFlipper Flipper { get; set; }

        public override Item CreateFromStream(Stream stream, string filePath, bool setStreamIfEmpty, MediaCreatorOptions options)
        {
            MediaItem mediaItem = base.CreateFromStream(stream, filePath, setStreamIfEmpty, options);
            if (Flipper == null)
            {
                return mediaItem;
            }

            Flipper.MediaItem = mediaItem;
            Flipper.Flip();
            return mediaItem;
        }
    }
}

After an image is uploaded to the Media Library, we pass the new MediaItem to the IMediaImageFlipper instance — this instance is injected using the Sitecore Configuration Factory (see the configuration file below) — and invoke its Flip() method to flip the image, and return the new MediaItem when complete.

I then utilize an instance of the MediaCreator above in a subclass of Resources.Media.MediaProvider.MediaProvider (I am going to replace the “out of the box” MediaProvider with the following class using the configuration file below):

using Sitecore.Diagnostics;
using Sitecore.Resources.Media;

namespace Sitecore.Sandbox.Resources.Media
{
    public class ImageFlipperMediaProvider : MediaProvider
    {
        private MediaCreator FlipperCreator { get; set; }

        public override MediaCreator Creator
        {
            get
            {
                return FlipperCreator ?? base.Creator;
            }
            set
            {
                Assert.ArgumentNotNull(value, "value");
                FlipperCreator = value;
            }
        }
    }
}

The MediaCreator that lives in the FlipperCreator property is injected into the class instance through the Sitecore Configuration Factory (see the patch configuration file below), and is returned by the Creator property’s accessor if it’s not null.

I then registered all of the above in Sitecore using the following patch configuration file:

<?xml version="1.0" encoding="utf-8" ?>
<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/">
  <sitecore>
    <mediaLibrary>
      <mediaProvider>
        <patch:attribute name="type">Sitecore.Sandbox.Resources.Media.ImageFlipperMediaProvider, Sitecore.Sandbox</patch:attribute>
        <FlipperCreator type="Sitecore.Sandbox.Resources.Media.ImageFlipperMediaCreator, Sitecore.Sandbox">
          <Flipper type="Sitecore.Sandbox.Resources.Media.ImageFactoryFlipper, Sitecore.Sandbox">
            <TargetMimeTypes hint="list">
              <TargetMimeType>image/jpeg</TargetMimeType>
              <TargetMimeType>image/png</TargetMimeType>
            </TargetMimeTypes>
          </Flipper>
		    </FlipperCreator>
      </mediaProvider>
    </mediaLibrary>
  </sitecore>
</configuration>

Let’s test this.

I selected the following images for uploading to the Media Library:

As you can see, all uploaded images were flipped upside down:

If you have any thoughts on this, or examples where you’ve employed the Adapter pattern in your Sitecore solutions, please share in a comment.

Until next time, have a Sitecorelicious day!

Leverage the Sitecore Configuration Factory: Inject Value Types as Dependencies

07/09/2014 23:19 / 4 Comments on Leverage the Sitecore Configuration Factory: Inject Value Types as Dependencies

In a previous post, I had mentioned primitive types cannot be injected into classes via Sitecore’s Configuration Factory, and further learned through exploring and experimentation that this applies to all value types in C#.

However, after some digging in Sitecore.Configuration.Factory — this lives in Sitecore.Kernel.dll — I discovered the CreateFromFactoryMethod() method which calls a static method — this method is defined in an XML attribute named “factoryMethod” — on a class defined in the “type” attribute on the XML configuration element being processed, and felt I could take advantage of this hidden gem for injecting value types into my configuration-defined classes.

Despite the fact the method defined in the “factoryMethod” attribute must be static, I decided to define an interface for classes that do value type conversions from strings, and created the following interface (don’t worry, I haven’t completely lost my mind — yes, I did say it requires a static method — but do bear with me until we get further down in this post 😉 ):

namespace Sitecore.Sandbox.Configuration
{
    public interface IValueTypesConverter
    {
        bool ConvertToBoolean(string argument);

        char ConvertToCharacter(string argument);

        decimal ConvertToDecimal(string argument);

        double ConvertToDouble(string argument);

        float ConvertToFloat(string argument);

        int ConvertToInteger(string argument);
    }
}

I then created the following class to implement the interface above:

using Sitecore.Diagnostics;

namespace Sitecore.Sandbox.Configuration
{
    public class ValueTypesConverter : IValueTypesConverter
    {
        public bool ConvertToBoolean(string argument)
        {
            bool value;
            Assert.ArgumentCondition(bool.TryParse(argument, out value), "argument", "argument is not a boolean!");
            return value;
        }

        public char ConvertToCharacter(string argument)
        {
            char value;
            Assert.ArgumentCondition(char.TryParse(argument, out value), "argument", "argument is not a character!");
            return value;
        }

        public decimal ConvertToDecimal(string argument)
        {
            decimal value;
            Assert.ArgumentCondition(decimal.TryParse(argument, out value), "argument", "argument is not a decimal!");
            return value;
        }

        public double ConvertToDouble(string argument)
        {
            double value;
            Assert.ArgumentCondition(double.TryParse(argument, out value), "argument", "argument is not a double!");
            return value;
        }

        public float ConvertToFloat(string argument)
        {
            float value;
            Assert.ArgumentCondition(float.TryParse(argument, out value), "argument", "argument is not a float!");
            return value;
        }

        public int ConvertToInteger(string argument)
        {
            int value;
            Assert.ArgumentCondition(int.TryParse(argument, out value), "argument", "argument is not an integer!");
            return value;
        }
    }
}

Each method in the class above calls its specific value type’s TryParse() method to convert the passed string to the value type. We ensure the argument was in the correct format: an assertion is done to check if the argument was of the type the method was expecting.

I then created the following adapter which wraps an instance of a class that implements the interface defined above:

using Sitecore.Configuration;

namespace Sitecore.Sandbox.Configuration
{
    public class TypesConverter
    {
        static TypesConverter()
        {
            ValueTypesConverter = Factory.CreateObject("valueTypesConverter", true) as IValueTypesConverter;
        }

        public static bool ConvertToBoolean(string argument)
        {
            return ValueTypesConverter.ConvertToBoolean(argument);
        }

        public static char ConvertToCharacter(string argument)
        {
            return ValueTypesConverter.ConvertToCharacter(argument);
        }

        public static decimal ConvertToDecimal(string argument)
        {
            return ValueTypesConverter.ConvertToDecimal(argument);
        }

        public static double ConvertToDouble(string argument)
        {
            return ValueTypesConverter.ConvertToDouble(argument);
        }

        public static float ConvertToFloat(string argument)
        {
            return ValueTypesConverter.ConvertToFloat(argument);
        }

        public static int ConvertToInteger(string argument)
        {
            return ValueTypesConverter.ConvertToInteger(argument);
        }

        private static IValueTypesConverter ValueTypesConverter { get; set; }
    }
}

The class above creates an instance of the ValueTypesConverter class via the Sitecore.Configuration.Factory.CreateObject() method. I felt defining the class that implements the IValueTypesConverter interface in Sitecore configuration would allow for customization if one would ever need to do so.

Further, all methods in the class above just delegate calls to the ValueTypesConverter instance.

For testing, I created the following class to serve as a <renderField> pipeline processor:

using System.Text;

using Sitecore.Diagnostics;
using Sitecore.Pipelines.RenderField;

namespace Sitecore.Sandbox.Pipelines.RenderField
{
    public class ValueTypesTest
    {
        public void Process(RenderFieldArgs args)
        {
            Assert.ArgumentNotNull(args, "args");
            StringBuilder htmlBuilder = new StringBuilder();
            htmlBuilder.AppendFormat("SomeBoolean ==> {0} <br />", SomeBoolean);
            htmlBuilder.AppendFormat("SomeCharacter ==> {0} <br />", SomeCharacter);
            htmlBuilder.AppendFormat("SomeDecimal ==> {0} <br />", SomeDecimal);
            htmlBuilder.AppendFormat("SomeDouble ==> {0} <br />", SomeDouble);
            htmlBuilder.AppendFormat("SomeFloat ==> {0} <br />", SomeFloat);
            htmlBuilder.AppendFormat("SomeInteger ==> {0}", SomeInteger);
            args.Result.FirstPart = htmlBuilder.ToString();
        }

        private bool SomeBoolean { get; set; }

        private char SomeCharacter { get; set; }

        private decimal SomeDecimal { get; set; }

        private double SomeDouble { get; set; }

        private float SomeFloat { get; set; }

        private int SomeInteger { get; set; }
    }
}

The class above defines properties that will be populated magically by Sitecore’s Configuration Factory, and builds a string of HTML to be rendered on the front-end.

I wired everything together in the following Sitecore configuration file:

<?xml version="1.0" encoding="utf-8" ?>
<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/">
  <sitecore>
    <pipelines>
      <renderField>
        <processor type="Sitecore.Sandbox.Pipelines.RenderField.ValueTypesTest, Sitecore.Sandbox">
          <SomeBoolean type="Sitecore.Sandbox.Configuration.TypesConverter, Sitecore.Sandbox" factoryMethod="ConvertToBoolean" arg0="true" />
          <SomeCharacter type="Sitecore.Sandbox.Configuration.TypesConverter, Sitecore.Sandbox" factoryMethod="ConvertToCharacter" arg0="b" />
          <SomeDecimal type="Sitecore.Sandbox.Configuration.TypesConverter, Sitecore.Sandbox" factoryMethod="ConvertToDecimal" arg0="0.1" />
          <SomeDouble type="Sitecore.Sandbox.Configuration.TypesConverter, Sitecore.Sandbox" factoryMethod="ConvertToDouble" arg0="1234.5678" />
          <SomeFloat type="Sitecore.Sandbox.Configuration.TypesConverter, Sitecore.Sandbox" factoryMethod="ConvertToFloat" arg0=".98765" />
          <SomeInteger type="Sitecore.Sandbox.Configuration.TypesConverter, Sitecore.Sandbox" factoryMethod="ConvertToInteger" arg0="2" />
        </processor>
      </renderField>
    </pipelines>
    <valueTypesConverter type="Sitecore.Sandbox.Configuration.ValueTypesConverter, Sitecore.Sandbox" />
  </sitecore>
</configuration>

When I loaded my home page, I saw that all value types defined in configuration were accounted for:

If you have any thoughts on this, or ideas around implementing this in a different way, please share in a comment.

SitecoreJunkie.com

Category Archives: Dependency Injection

Restart Your Sitecore Content Management (CM) and Content Delivery (CD) Instances using Custom Events

Yet Another Post on Sitecore Content Editor Warnings

Alter the Appearance of the Sitecore Content Tree using a Pipeline-backed MasterDataView

Magically Register Sitecore Configuration Objects in the Sitecore IoC Container using a custom Attribute

Service Locate or Create Objects Defined in a Fully Qualified Type Name Field in Sitecore

Grab Sitecore Experience Forms Configuration Settings from a Custom SQL Server Database Table

Encrypt Sitecore Experience Forms Data in Powerful Ways

Inject Dependencies Into Sitecore MVC Razor Views Using a SitecoreHelper Extension Method

Make Incompatible Class Interfaces Work Together using the Adapter Pattern in Sitecore

Leverage the Sitecore Configuration Factory: Inject Value Types as Dependencies

Post navigation
