Service Locate or Create Objects Defined in a Fully Qualified Type Name Field in Sitecore

<TL;DR>

This is — without a doubt — the longest blog post I have ever written — and hopefully to ever write as it nearly destroyed me πŸ˜‰ — so will distill the main points in this TL;DR synopsis.

Most bits in Sitecore Experience Forms use objects/service class instances sourced from the Sitecore IoC container but not all. Things not sourced from the Sitecore IoC container are defined on Items in the following folders:

.

Why?

Β―\_(ツ)_/Β―

This is most likely due to their fully qualified type names being defined in a type field on Items contained in these folders, and sourcing these from the Sitecore IoC is not a thing OOTB in Sitecore as far as I am aware (reflection is used to create them):

Moreover, this is the same paradigm found in Web Forms for Marketers (WFFM) for some of its parts (Save Actions are an example).

Well, this paradigm bothers me a lot — I strongly feel that virtually everything should be sourced from the Sitecore IoC container as it promotes SOLID principles, a discussion I will leave for another time — so went ahead and built a system of Sitecore pipelines and service classes to:

  1. Get the fully qualified type name string out of a field of an Item.
  2. Resolve the Type from the string from #1.
  3. Try to find the Type in the Sitecore IoC container using Service Locator (before whinging about using Service Locator for this, keep in mind that it would be impossible to inject everything from the IoC container into a class instance’s constructor in order to find it). If found, return to the caller. Otherwise, proceed to #4.
  4. Create an instance of the Type using Reflection. Return the result to the caller.

Most of the code in the solution that follows are classes which serve as custom pipeline processors for 5 custom pipelines. Pipelines in Sitecore — each being an embodiment of the chain-of-responsibility pattern — are extremely flexible and extendable, hence the reason for going with this approach.

I plan on putting this solution up on GitHub in coming days (or weeks depending on timing) so it is more easily digestible than in a blost post. For now, Just have a scan of the code below.

Note: This solution is just a Proof of concept (PoC). I have not rigorously tested this solution; have no idea what its performance is nor the performance impact it may have; and definitely will not be held responsible if something goes wrong if you decided to use this code in any of your solutions. Use at your own risk!

</TL;DR>

Now that we have that out of the way, let’s jump right into it.

I first created the following abstract class to serve as the base for all pipeline processors in this solution:

using Sitecore.Pipelines;

namespace Sandbox.Foundation.ObjectResolution.Pipelines
{
	public abstract class ResolveProcessor<TPipelineArgs> where TPipelineArgs : PipelineArgs
	{
		public void Process(TPipelineArgs args)
		{
			if (!CanProcess(args))
			{
				return;
			}

			Execute(args);
		}

		protected virtual bool CanProcess(TPipelineArgs args) => args != null;

		protected virtual void AbortPipeline(TPipelineArgs args) => args?.AbortPipeline();

		protected virtual void Execute(TPipelineArgs args)
		{
		}
	}
}

The Execute() method on all pipeline processors will only run when the processor’s CanProcess() method returns true. Also, pipeline processors have the ability to abort the pipeline where they are called.

I then created the following abstract class for all service classes which call a pipeline to “resolve” a particular thing:

using Sitecore.Abstractions;
using Sitecore.Pipelines;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers
{
	public abstract class PipelineObjectResolver<TArguments, TPipelineArguemnts, TResult> where TPipelineArguemnts : PipelineArgs
	{
		private readonly BaseCorePipelineManager _corePipelineManager;

		protected PipelineObjectResolver(BaseCorePipelineManager corePipelineManager)
		{
			_corePipelineManager = corePipelineManager;
		}

		public TResult Resolve(TArguments arguments)
		{
			TPipelineArguemnts args = CreatePipelineArgs(arguments);
			RunPipeline(GetPipelineName(), args);
			return GetObject(args);
		}

		protected abstract TResult GetObject(TPipelineArguemnts args);

		protected abstract TPipelineArguemnts CreatePipelineArgs(TArguments arguments);

		protected abstract string GetPipelineName();

		protected virtual void RunPipeline(string pipelineName, PipelineArgs args) => _corePipelineManager.Run(pipelineName, args);
	}
}

Each service class will “resolve” a particular thing with arguments passed to their Resolve() method — these service class’ Resolve() method will take in a TArguments type which serves as the input arguments for it. They will then delegate to a pipeline via the RunPipeline() method to do the resolving. Each will also parse the results returned by the pipeline via the GetObject() method.

Moving forward in this post, I will group each resolving pipeline with their service classes under a <pipeline name /> section.

<resolveItem />

I then moved on to creating a custom pipeline to “resolve” a Sitecore Item. The following class serves as its arguments data transfer object (DTO):

using System.Collections.Generic;
using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;
using Sitecore.Pipelines;

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem
{
	public class ResolveItemArgs : PipelineArgs
	{
		public Database Database { get; set; }

		public string ItemPath { get; set; }

		public Language Language { get; set; }

		public IList<IItemResolver> ItemResolvers { get; set; } = new List<IItemResolver>();

		public Item Item { get; set; }
	}
}

The resolution of an Item will be done by a collection of IItemResolver instances — these are defined further down in this post — which ultimately do the resolution of the Item.

Next, I created the following arguments class for IItemResolver instances:

using Sitecore.Data;
using Sitecore.Globalization;

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers
{
	public class ItemResolverArguments
	{
		public Database Database { get; set; }

		public Language Language { get; set; }

		public string ItemPath { get; set; }
	}
}

Since I hate calling the “new” keyword directly on classes, I created the following factory interface which will construct the argument objects for both the pipeline and service classes for resolving an Item:

using Sitecore.Data;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ItemResolvers
{
	public interface IItemResolverArgumentsFactory
	{
		ItemResolverArguments CreateItemResolverArguments(ResolveTypeArgs args);

		ItemResolverArguments CreateItemResolverArguments(ResolveItemArgs args);

		ItemResolverArguments CreateItemResolverArguments(Database database = null, Language language = null, string itemPath = null);

		ResolveItemArgs CreateResolveItemArgs(ItemResolverArguments arguments);

		ResolveItemArgs CreateResolveItemArgs(Database database = null, Language language = null, string itemPath = null);
	}
}

Here is the class that implements the interface above:

using Sitecore.Data;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ItemResolvers
{
	public class ItemResolverArgumentsFactory : IItemResolverArgumentsFactory
	{
		public ItemResolverArguments CreateItemResolverArguments(ResolveTypeArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateItemResolverArguments(args.Database, args.Language, args.ItemPath);
		}

		public ItemResolverArguments CreateItemResolverArguments(ResolveItemArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateItemResolverArguments(args.Database, args.Language, args.ItemPath);
		}

		public ItemResolverArguments CreateItemResolverArguments(Database database = null, Language language = null, string itemPath = null)
		{
			return new ItemResolverArguments
			{
				Database = database,
				Language = language,
				ItemPath = itemPath
			};
		}

		public ResolveItemArgs CreateResolveItemArgs(ItemResolverArguments arguments)
		{
			if (arguments == null)
			{
				return null;
			}

			return CreateResolveItemArgs(arguments.Database, arguments.Language, arguments.ItemPath);
		}

		public ResolveItemArgs CreateResolveItemArgs(Database database = null, Language language = null, string itemPath = null)
		{
			return new ResolveItemArgs
			{
				Database = database,
				Language = language,
				ItemPath = itemPath
			};
		}
	}
}

It just creates argument types for the pipeline and service classes.

The following interface is for classes that “resolve” Items based on arguments set on an ItemResolverArguments instance:

using Sitecore.Data.Items;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers
{
	public interface IItemResolver
	{
		Item Resolve(ItemResolverArguments arguments);
	}
}

I created a another interface for an IItemResolver which resolves an Item from a Sitecore Database:

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers
{
	public interface IDatabaseItemResolver : IItemResolver
	{
	}
}

The purpose of this interface is so I can register it and the following class which implements it in the Sitecore IoC container:

using Sitecore.Data.Items;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers
{
	public class DatabaseItemResolver : IDatabaseItemResolver
	{
		public Item Resolve(ItemResolverArguments arguments)
		{
			if (!CanResolveItem(arguments))
			{
				return null;
			}

			if(arguments.Language == null)
			{
				return arguments.Database.GetItem(arguments.ItemPath);
			}

			return arguments.Database.GetItem(arguments.ItemPath, arguments.Language);
		}

		protected virtual bool CanResolveItem(ItemResolverArguments arguments) => arguments != null && arguments.Database != null && !string.IsNullOrWhiteSpace(arguments.ItemPath);
	}
}

The instance of the class above will return a Sitecore Item if a Database and Item path (this can be an Item ID) are supplied via the ItemResolverArguments instance passed to its Reolve() method.

Now, let’s start constructing the processors for the pipeline:

First, I created an interface and class for adding a “default” IItemResolver to a collection of IItemResolver defined on the pipeline’s arguments object:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem.AddDefaultItemResolverProcessor
{
	public interface IAddDefaultItemResolver
	{
		void Process(ResolveItemArgs args);
	}
}
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem.AddDefaultItemResolverProcessor
{
	public class AddDefaultItemResolver : ResolveProcessor<ResolveItemArgs>, IAddDefaultItemResolver
	{
		private readonly IDatabaseItemResolver _databaseItemResolver;

		public AddDefaultItemResolver(IDatabaseItemResolver databaseItemResolver)
		{
			_databaseItemResolver = databaseItemResolver;
		}

		protected override bool CanProcess(ResolveItemArgs args) => base.CanProcess(args) && args.ItemResolvers != null;

		protected override void Execute(ResolveItemArgs args) => args.ItemResolvers.Add(GetTypeResolver());

		protected virtual IItemResolver GetTypeResolver() => _databaseItemResolver;
	}
}

In the above class, I’m injecting the IDatabaseItemResolver instance — this was shown further up in this post — into the constructor of this class, and then adding it to the collection of resolvers.

I then created the following interface and implementation class to doing the “resolving” of the Item:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem.ResolveItemProcessor
{
	public interface IResolveItem
	{
		void Process(ResolveItemArgs args);
	}
}
using System.Linq;

using Sitecore.Data.Items;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem.ResolveItemProcessor
{
	public class ResolveItem : ResolveProcessor<ResolveItemArgs>, IResolveItem
	{
		private readonly IItemResolverArgumentsFactory _itemResolverArgumentsFactory;


		public ResolveItem(IItemResolverArgumentsFactory itemResolverArgumentsFactory)
		{
			_itemResolverArgumentsFactory = itemResolverArgumentsFactory;
		}

		protected override bool CanProcess(ResolveItemArgs args) => base.CanProcess(args) && args.Database != null && !string.IsNullOrWhiteSpace(args.ItemPath) && args.ItemResolvers.Any();

		protected override void Execute(ResolveItemArgs args) => args.Item = GetItem(args);

		protected virtual Item GetItem(ResolveItemArgs args)
		{
			ItemResolverArguments arguments = CreateItemResolverArguments(args);
			if (arguments == null)
			{
				return null;
			}

			foreach (IItemResolver resolver in args.ItemResolvers)
			{
				Item item = resolver.Resolve(arguments);
				if (item != null)
				{
					return item;
				}
			}

			return null;
		}

		protected virtual ItemResolverArguments CreateItemResolverArguments(ResolveItemArgs args) => _itemResolverArgumentsFactory.CreateItemResolverArguments(args);
	}
}

The class above just iterates over all IItemResolver instances on the PipelineArgs instance; passes an ItemResolverArguments instance the Resolve() method on each — the ItemResolverArguments instance is created from a factory — and returns the first Item found by one of the IItemResolver instances. If none were found, null is returned.

Now, we need to create a service class that calls the custom pipeline. I created the following class to act as a settings class for the service.

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers
{
	public class ItemResolverServiceSettings
	{
		public string ResolveItemPipelineName { get; set; }
	}
}

An instance of this class will be injected into the service — the instance is created by the Sitecore Configuration Factory — and its ResolveItemPipelineName property will contain a value from Sitecore Configuration (see the Sitecore patch configuration file towards the bottom of this blog post).

I then created the following interface for the service — it’s just another IItemResolver — so I can register it in the Sitecore IoC container:

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers
{
	public interface IItemResolverService : IItemResolver
	{
	}
}

The following class implements the interface above:

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers;
using Sitecore.Abstractions;
using Sitecore.Data.Items;

using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ItemResolvers;


using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers
{
	public class ItemResolverService : PipelineObjectResolver<ItemResolverArguments, ResolveItemArgs, Item>, IItemResolverService
	{
		private readonly ItemResolverServiceSettings _settings;
		private readonly IItemResolverArgumentsFactory _itemResolverArgumentsFactory;

		public ItemResolverService(ItemResolverServiceSettings settings, IItemResolverArgumentsFactory itemResolverArgumentsFactory, BaseCorePipelineManager corePipelineManager)
			: base(corePipelineManager)
		{
			_settings = settings;
			_itemResolverArgumentsFactory = itemResolverArgumentsFactory;
		}

		protected override Item GetObject(ResolveItemArgs args)
		{
			return args.Item;
		}

		protected override ResolveItemArgs CreatePipelineArgs(ItemResolverArguments arguments) => _itemResolverArgumentsFactory.CreateResolveItemArgs(arguments);

		protected override string GetPipelineName() => _settings.ResolveItemPipelineName;
	}
}

The above class subclasses the abstract PipelineObjectResolver class I had shown further above in this post. Most of the magic happens in that base class — for those interested in design patterns, this is an example of the Template Method pattern if you did not know — and all subsequent custom pipeline wrapping service classes will follow this same pattern.

I’m not going to go much into detail on the above class as it should be self-evident on what’s happening after looking at the PipelineObjectResolver further up in this post.

<resolveType />

I then started code for the next pipeline — a pipeline to resolve Types.

I created the following PipelineArgs subclass class whose instances will serve as arguments to this new pipeline:

using System;
using System.Collections.Generic;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;
using Sitecore.Pipelines;

using Sandbox.Foundation.ObjectResolution.Services.Cachers;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType
{
	public class ResolveTypeArgs : PipelineArgs
	{
		public Database Database { get; set; }

		public string ItemPath { get; set; }

		public Language Language { get; set; }

		public IItemResolver ItemResolver { get; set; }

		public Item Item { get; set; }

		public string TypeFieldName { get; set; }

		public string TypeName { get; set; }

		public IList<ITypeResolver> TypeResolvers { get; set; } = new List<ITypeResolver>();

		public ITypeCacher TypeCacher { get; set; }

		public Type Type { get; set; }

		public bool UseTypeCache { get; set; }
	}
}

I then created the following class to serve as an arguments object for services that will resolve types:

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers
{
	public class TypeResolverArguments
	{
		public Database Database { get; set; }

		public Language Language { get; set; }

		public string ItemPath { get; set; }

		public Item Item { get; set; }

		public string TypeFieldName { get; set; }

		public string TypeName { get; set; }

		public bool UseTypeCache { get; set; }
	}
}

As I had done for the previous resolver, I created a factory to create arguments for both the PipelineArgs and arguments used by the service classes. Here is the interface for that factory class:

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.TypeResolvers
{
	public interface ITypeResolverArgumentsFactory
	{
		TypeResolverArguments CreateTypeResolverArguments(ResolveObjectArgs args);

		TypeResolverArguments CreateTypeResolverArguments(LocateObjectArgs args);

		TypeResolverArguments CreateTypeResolverArguments(CreateObjectArgs args);

		TypeResolverArguments CreateTypeResolverArguments(ResolveTypeArgs args);

		TypeResolverArguments CreateTypeResolverArguments(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, bool useTypeCache = false);

		ResolveTypeArgs CreateResolveTypeArgs(TypeResolverArguments arguments);

		ResolveTypeArgs CreateResolveTypeArgs(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, bool useTypeCache = false);
	}
}

The following class implements the interface above:

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.TypeResolvers
{
	public class TypeResolverArgumentsFactory : ITypeResolverArgumentsFactory
	{
		public TypeResolverArguments CreateTypeResolverArguments(ResolveObjectArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateTypeResolverArguments(args.Database, args.Language, args.ItemPath, args.Item, args.TypeFieldName, args.TypeName, args.UseTypeCache);
		}

		public TypeResolverArguments CreateTypeResolverArguments(LocateObjectArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateTypeResolverArguments(args.Database, args.Language, args.ItemPath, args.Item, args.TypeFieldName, args.TypeName, args.UseTypeCache);
		}

		public TypeResolverArguments CreateTypeResolverArguments(CreateObjectArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateTypeResolverArguments(args.Database, args.Language, args.ItemPath, args.Item, args.TypeFieldName, args.TypeName, args.UseTypeCache);
		}

		public TypeResolverArguments CreateTypeResolverArguments(ResolveTypeArgs args)
		{
			return CreateTypeResolverArguments(args.Database, args.Language, args.ItemPath, args.Item, args.TypeFieldName, args.TypeName, args.UseTypeCache);
		}

		public TypeResolverArguments CreateTypeResolverArguments(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, bool useTypeCache = false)
		{
			return new TypeResolverArguments
			{
				Database = database,
				Language = language,
				ItemPath = itemPath,
				Item = item,
				TypeFieldName = typeFieldName,
				TypeName = typeName,
				UseTypeCache = useTypeCache
			};
		}

		public ResolveTypeArgs CreateResolveTypeArgs(TypeResolverArguments arguments)
		{
			if (arguments == null)
			{
				return null;
			}

			return CreateResolveTypeArgs(arguments.Database, arguments.Language, arguments.ItemPath, arguments.Item, arguments.TypeFieldName, arguments.TypeName, arguments.UseTypeCache);
		}

		public ResolveTypeArgs CreateResolveTypeArgs(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, bool useTypeCache = false)
		{
			return new ResolveTypeArgs
			{
				Database = database,
				Language = language,
				ItemPath = itemPath,
				Item = item,
				TypeFieldName = typeFieldName,
				TypeName = typeName,
				UseTypeCache = useTypeCache
			};
		}
	}
}

I’m not going to discuss much on the class above — it just creates instances of TypeResolverArguments and ResolveTypeArgs based on a variety of things provided to each method.

I then created the following interface for a pipeline processor to resolve an Item and set it on the passed PipelineArgs instance if one wasn’t provided by the caller or set by another processor:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetItemResolverProcessor
{
	public interface ISetItemResolver
	{
		void Process(ResolveTypeArgs args);
	}
}

The following class implements the interface above:

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetItemResolverProcessor
{
	public class SetItemResolver : ResolveProcessor<ResolveTypeArgs>, ISetItemResolver
	{
		private readonly IItemResolverService _itemResolverService;

		public SetItemResolver(IItemResolverService itemResolverService)
		{
			_itemResolverService = itemResolverService;
		}

		protected override bool CanProcess(ResolveTypeArgs args) => base.CanProcess(args) && args.Database != null && !string.IsNullOrWhiteSpace(args.ItemPath);

		protected override void Execute(ResolveTypeArgs args) => args.ItemResolver = GetItemResolver();

		protected virtual IItemResolver GetItemResolver() => _itemResolverService;
	}
}

In the class above, I’m injecting an instance of a IItemResolverService into its constructor, and setting it on the ItemResolver property of the ResolveTypeArgs instance.

Does this IItemResolverService interface look familiar? It should as it’s the IItemResolverService defined further up in this post which calls the <resolveItem /> pipeline.

Now we need a processor to resolve the Item. The following interface and class do this:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.ResolveTypeProcessor
{
	public interface IResolveItem
	{
		void Process(ResolveTypeArgs args);
	}
}
using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ItemResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.ResolveTypeProcessor
{
	public class ResolveItem : ResolveProcessor<ResolveTypeArgs>, IResolveItem
	{
		private readonly IItemResolverArgumentsFactory _itemResolverArgumentsFactory;

		public ResolveItem(IItemResolverArgumentsFactory itemResolverArgumentsFactory)
		{
			_itemResolverArgumentsFactory = itemResolverArgumentsFactory;
		}

		protected override bool CanProcess(ResolveTypeArgs args) => base.CanProcess(args) && args.Database != null && args.ItemResolver != null;

		protected override void Execute(ResolveTypeArgs args) => args.Item = args.ItemResolver.Resolve(CreateTypeResolverArguments(args));

		protected virtual ItemResolverArguments CreateTypeResolverArguments(ResolveTypeArgs args) => _itemResolverArgumentsFactory.CreateItemResolverArguments(args);
	}
}

The class above just delegates to the IItemResolver instance on the ResolveTypeArgs instance to resolve the Item.

Next, we need a processor to get the fully qualified type name from the Item. The following interface and class are for a processor that does just that:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetTypeNameProcessor
{
	public interface ISetTypeName
	{
		void Process(ResolveTypeArgs args);
	}
}
namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetTypeNameProcessor
{
	public class SetTypeName : ResolveProcessor<ResolveTypeArgs>, ISetTypeName
	{
		protected override bool CanProcess(ResolveTypeArgs args) => base.CanProcess(args) && args.Item != null && !string.IsNullOrWhiteSpace(args.TypeFieldName);

		protected override void Execute(ResolveTypeArgs args) => args.TypeName = args.Item[args.TypeFieldName];
	}
}

The class above just gets the value from the field where the fully qualified type is defined — the name of the field where the fully qualified type name is defined should be set by the caller of this pipeline.
I then defined the following interface and class which will sort out what the Type object is based on a fully qualified type name passed to it:

using System;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers
{
	public interface ITypeResolver
	{
		Type Resolve(TypeResolverArguments arguments);
	}
}

I then created the following interface for a service class that will delegate to Sitecore.Reflection.ReflectionUtil to get a Type with a provided fully qualified type name:

using System;

namespace Sandbox.Foundation.ObjectResolution.Services.Reflection
{
	public interface IReflectionUtilService
	{
		Type GetTypeInfo(string type);

		object CreateObject(Type type);

		object CreateObject(Type type, object[] parameters);
	}
}

Here’s the class that implements the interface above:

using System;

using Sitecore.Reflection;

namespace Sandbox.Foundation.ObjectResolution.Services.Reflection
{
	public class ReflectionUtilService : IReflectionUtilService
	{
		public Type GetTypeInfo(string type)
		{
			return ReflectionUtil.GetTypeInfo(type);
		}

		public object CreateObject(Type type)
		{
			return ReflectionUtil.CreateObject(type);
		}

		public object CreateObject(Type type, object[] parameters)
		{
			return ReflectionUtil.CreateObject(type, parameters);
		}
	}
}

The class above also creates objects via the ReflectionUtil static class with a passed type and constructor arguments — this will be used in the <createObject /> pipeline further down in this post.

I then defined the following interface for a class that will leverage the IReflectionUtilService service above:

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers
{
	public interface IReflectionTypeResolver : ITypeResolver
	{
	}
}

This is the class that implements the interface above:

using System;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Reflection;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers
{
	public class ReflectionTypeResolver : IReflectionTypeResolver
	{
		private readonly IReflectionUtilService _reflectionUtilService;

		public ReflectionTypeResolver(IReflectionUtilService reflectionUtilService)
		{
			_reflectionUtilService = reflectionUtilService;
		}

		public Type Resolve(TypeResolverArguments arguments)
		{
			if (string.IsNullOrWhiteSpace(arguments?.TypeName))
			{
				return null;
			}

			return GetTypeInfo(arguments.TypeName);
		}

		protected virtual Type GetTypeInfo(string typeName) => _reflectionUtilService.GetTypeInfo(typeName);
	}
}

The class above just delegates to the IReflectionUtilService to get the Type with the supplied fully qualified type name.

I then created the following interface and class to represent a pipeline processor to add the ITypeResolver above to the collection of ITypeResolver on the ResolveTypeArgs instance passed to it:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.AddDefaultTypeResolverProcessor
{
	public interface IAddDefaultTypeResolver
	{
		void Process(ResolveTypeArgs args);
	}
}
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.AddDefaultTypeResolverProcessor
{
	public class AddDefaultTypeResolver : ResolveProcessor<ResolveTypeArgs>, IAddDefaultTypeResolver
	{
		private readonly IReflectionTypeResolver _reflectionTypeResolver;

		public AddDefaultTypeResolver(IReflectionTypeResolver reflectionTypeResolver)
		{
			_reflectionTypeResolver = reflectionTypeResolver;
		}

		protected override bool CanProcess(ResolveTypeArgs args) => base.CanProcess(args) && args.TypeResolvers != null;

		protected override void Execute(ResolveTypeArgs args) => args.TypeResolvers.Add(GetTypeResolver());

		protected virtual ITypeResolver GetTypeResolver() => _reflectionTypeResolver;
	}
}

There isn’t much going on in the class above. The Execute() method just adds the IReflectionTypeResolver to the TypeResolvers collection.

When fishing through the Sitecore Experience Forms assemblies, I noticed the OOTB code was “caching” Types it had resolved from Type fields.. I decided to employ the same approach, and defined the following interface for an object that caches Types:

using System;

namespace Sandbox.Foundation.ObjectResolution.Services.Cachers
{
	public interface ITypeCacher
	{
		void AddTypeToCache(string typeName, Type type);

		Type GetTypeFromCache(string typeName);
	}
}

Here is the class that implements the interface above:

using System;
using System.Collections.Concurrent;

namespace Sandbox.Foundation.ObjectResolution.Services.Cachers
{
	public class TypeCacher : ITypeCacher
	{
		private static readonly ConcurrentDictionary<string, Type> TypeCache = new ConcurrentDictionary<string, Type>();

		public void AddTypeToCache(string typeName, Type type)
		{
			if (string.IsNullOrWhiteSpace(typeName) || type == null)
			{
				return;
			}

			TypeCache.TryAdd(typeName, type);
		}

		public Type GetTypeFromCache(string typeName)
		{
			if (string.IsNullOrWhiteSpace(typeName))
			{
				return null;
			}

			Type type;
			if (!TypeCache.TryGetValue(typeName, out type))
			{
				return null;
			}

			return type;
		}
	}
}

The AddTypeToCache() method does exactly what the method name says — it will add the supplied Type to cache with the provided type name as the key into the ConcurrentDictionary dictionary on this class.

The GetTypeFromCache() method above tries to get a Type from the ConcurrentDictionary instance on this class, and returns to the caller if it was found. If it wasn’t found, null is returned.

The following interface and class serve as a pipeline processor to set a ITypeCacher instance on the ResolveTypeArgs instance passed to it:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetTypeCacherProcessor
{
	public interface ISetTypeCacher
	{
		void Process(ResolveTypeArgs args);
	}
}
using Sandbox.Foundation.ObjectResolution.Services.Cachers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetTypeCacherProcessor
{
	public class SetTypeCacher : ResolveProcessor<ResolveTypeArgs>, ISetTypeCacher
	{
		private readonly ITypeCacher _typeCacher;

		public SetTypeCacher(ITypeCacher typeCacher)
		{
			_typeCacher = typeCacher;
		}

		protected override bool CanProcess(ResolveTypeArgs args) => base.CanProcess(args) && args.UseTypeCache && args.TypeCacher == null;

		protected override void Execute(ResolveTypeArgs args) => args.TypeCacher = GetTypeCacher();

		protected virtual ITypeCacher GetTypeCacher() => _typeCacher;
	}
}

There isn’t much going on in the class above except the injection of the ITypeCacher instance defined further up, and setting that instance on the ResolveTypeArgs instance if it hasn’t already been set.

Now, we need to resolve the Type. The following interface and its implementation class do just that:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.ResolveTypeProcessor
{
	public interface IResolveType
	{
		void Process(ResolveTypeArgs args);
	}
}
using System;
using System.Linq;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.ResolveTypeProcessor
{
	public class ResolveType : ResolveProcessor<ResolveTypeArgs>, IResolveType
	{
		private readonly ITypeResolverArgumentsFactory _typeResolverArgumentsFactory;

		public ResolveType(ITypeResolverArgumentsFactory typeResolverArgumentsFactory)
		{
			_typeResolverArgumentsFactory = typeResolverArgumentsFactory;
		}

		protected override bool CanProcess(ResolveTypeArgs args) => base.CanProcess(args) && args.TypeResolvers != null && args.TypeResolvers.Any() && !string.IsNullOrWhiteSpace(args.TypeName);

		protected override void Execute(ResolveTypeArgs args) => args.Type = Resolve(args);

		protected virtual Type Resolve(ResolveTypeArgs args)
		{
			Type type = null;
			if (args.UseTypeCache)
			{
				type = GetTypeFromCache(args);
			}

			if (type == null)
			{
				type = GetTypeInfo(args);
			}

			return type;
		}

		protected virtual Type GetTypeInfo(ResolveTypeArgs args)
		{
			TypeResolverArguments arguments = CreateTypeResolverArguments(args);
			if (arguments == null)
			{
				return null;
			}

			foreach (ITypeResolver typeResolver in args.TypeResolvers)
			{
				Type type = typeResolver.Resolve(arguments);
				if (type != null)
				{
					return type;
				}
			}

			return null;
		}

		protected virtual Type GetTypeFromCache(ResolveTypeArgs args) => args.TypeCacher.GetTypeFromCache(args.TypeName);

		protected virtual TypeResolverArguments CreateTypeResolverArguments(ResolveTypeArgs args) => _typeResolverArgumentsFactory.CreateTypeResolverArguments(args);
	}
}

Just as I had done in the <resolveItem /> pipeline further up in this post, the above processor class will iterate over a collection of “resolvers” on the PipelineArgs instance — in this case it’s the TypeResolvers — and pass an arguments instance to each’s Resolve() method. This arguments instance is created from a factory defined further up in this post.

I then created the following settings class for the service class that will wrap the <resolveType /> pipeline:

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers
{
	public class TypeResolverServiceSettings
	{
		public string ResolveTypePipelineName { get; set; }
	}
}

The value on the ResolveTypePipelineName property will come from the Sitecore patch file towards the bottom of this post.

I then created the following interface for the service class that will wrap the pipeline — if you are a design patterns buff, this is an example of the adapter pattern:

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers
{
	public interface ITypeResolverService : ITypeResolver
	{
	}
}

The following class implements the interface above:

using System;

using Sitecore.Abstractions;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers
{
	public class TypeResolverService : PipelineObjectResolver<TypeResolverArguments, ResolveTypeArgs, Type>, ITypeResolverService
	{
		private readonly TypeResolverServiceSettings _settings;
		private readonly ITypeResolverArgumentsFactory _typeResolverArgumentsFactory;

		public TypeResolverService(TypeResolverServiceSettings settings, ITypeResolverArgumentsFactory typeResolverArgumentsFactory, BaseCorePipelineManager corePipelineManager)
			: base(corePipelineManager)
		{
			_settings = settings;
			_typeResolverArgumentsFactory = typeResolverArgumentsFactory;
		}

		protected override Type GetObject(ResolveTypeArgs args)
		{
			return args.Type;
		}

		protected override ResolveTypeArgs CreatePipelineArgs(TypeResolverArguments arguments) => _typeResolverArgumentsFactory.CreateResolveTypeArgs(arguments);

		protected override string GetPipelineName() => _settings.ResolveTypePipelineName;
	}
}

I’m not going to go into details about the class above as it’s just like the other service class which wraps the <resolveItem /> defined further above in this post.

Still following? We’re almost there. πŸ˜‰

<locateObject />

So we now have a way to resolve Items and Types, we now need to find a Type from an Item in the IoC container. I created a PipelineArgs class for a pipeline that does just that:

using System;
using System.Collections.Generic;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;
using Sitecore.Pipelines;

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject
{
	public class LocateObjectArgs : PipelineArgs
	{
		public Database Database { get; set; }

		public string ItemPath { get; set; }

		public Language Language { get; set; }

		public Item Item { get; set; }

		public string TypeFieldName { get; set; }

		public string TypeName { get; set; }

		public bool UseTypeCache { get; set; }

		public ITypeResolver TypeResolver { get; set; }

		public Type Type { get; set; }

		public IList<IObjectLocator> Locators { get; set; } = new List<IObjectLocator>();

		public object Object { get; set; }
	}
}

In reality, this next pipeline can supply an object from anywhere — it doesn’t have to be from an IoC container but that’s what I’m doing here. I did, however, make it extendable so you can source an object from wherever you want, even from the Post Office. πŸ˜‰

I then created the following arguments object for service classes that will “locate” objects:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators
{
	public class ObjectLocatorArguments
	{
		public Database Database { get; set; }

		public Language Language { get; set; }

		public string ItemPath { get; set; }

		public Item Item { get; set; }

		public string TypeFieldName { get; set; }

		public string TypeName { get; set; }

		public Type Type { get; set; }

		public bool UseTypeCache { get; set; }
	}
}

As I had done for the previous two “resolvers”, I created a factory to create arguments objects — both for the pipeline and service classes:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectLocators
{
	public interface IObjectLocatorArgumentsFactory
	{
		ObjectLocatorArguments CreateObjectLocatorArguments(ResolveObjectArgs args);

		ObjectLocatorArguments CreateObjectLocatorArguments(LocateObjectArgs args);

		ObjectLocatorArguments CreateObjectLocatorArguments(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false);

		LocateObjectArgs CreateLocateObjectArgs(ObjectLocatorArguments arguments);

		LocateObjectArgs CreateLocateObjectArgs(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false);
	}
}
using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectLocators
{
	public class ObjectLocatorArgumentsFactory : IObjectLocatorArgumentsFactory
	{
		public ObjectLocatorArguments CreateObjectLocatorArguments(ResolveObjectArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateObjectLocatorArguments(args.Database, args.Language, args.ItemPath, args.Item, args.TypeFieldName, args.TypeName, args.Type, args.UseTypeCache);
		}

		public ObjectLocatorArguments CreateObjectLocatorArguments(LocateObjectArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateObjectLocatorArguments(args.Database, args.Language, args.ItemPath, args.Item, args.TypeFieldName, args.TypeName, args.Type, args.UseTypeCache);
		}

		public ObjectLocatorArguments CreateObjectLocatorArguments(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false)
		{
			return new ObjectLocatorArguments
			{
				Database = database,
				Language = language,
				ItemPath = itemPath,
				Item = item,
				TypeFieldName = typeFieldName,
				TypeName = typeName,
				Type = type
			};
		}

		public LocateObjectArgs CreateLocateObjectArgs(ObjectLocatorArguments arguments)
		{
			if (arguments == null)
			{
				return null;
			}

			return CreateLocateObjectArgs(arguments.Database, arguments.Language, arguments.ItemPath, arguments.Item, arguments.TypeFieldName, arguments.TypeName, arguments.Type, arguments.UseTypeCache);
		}

		public LocateObjectArgs CreateLocateObjectArgs(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false)
		{
			return new LocateObjectArgs
			{
				Database = database,
				Language = language,
				ItemPath = itemPath,
				Item = item,
				TypeFieldName = typeFieldName,
				TypeName = typeName,
				Type = type
			};
		}
	}
}

The above class implements the interface above. It just creates arguments for both the pipeline and service classes.

I then defined the following interface for a pipeline processor to set the ITypeResolver (defined way up above in this post):

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.SetTypeResolverProcessor
{
	public interface ISetTypeResolver
	{
		void Process(LocateObjectArgs args);
	}
}

This class implements the interface above:

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.SetTypeResolverProcessor
{
	public class SetTypeResolver : ResolveProcessor<LocateObjectArgs>, ISetTypeResolver
	{
		private readonly ITypeResolverService _typeResolverService;

		public SetTypeResolver(ITypeResolverService typeResolverService)
		{
			_typeResolverService = typeResolverService;
		}

		protected override bool CanProcess(LocateObjectArgs args) => base.CanProcess(args) && args.TypeResolver == null;

		protected override void Execute(LocateObjectArgs args)
		{
			args.TypeResolver = GetTypeResolver();
		}

		protected virtual ITypeResolver GetTypeResolver() => _typeResolverService;
	}
}

In the class above, I’m injecting the ITypeResolverService into its constructor — this is the service class that wraps the <resolveType /> pipeline defined further up — and set it on the LocateObjectArgs instance if it’s not already set.

Next, I created the following interface for a processor that will “resolve” the type from the TypeResolver set on the LocateObjectArgs instance:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.ResolveTypeProcessor
{
	public interface IResolveType
	{
		void Process(LocateObjectArgs args);
	}
}

The following class implements the interface above:

using System;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.ResolveTypeProcessor
{
	public class ResolveType : ResolveProcessor<LocateObjectArgs>, IResolveType
	{
		private readonly ITypeResolverArgumentsFactory _typeResolverArgumentsFactory;

		public ResolveType(ITypeResolverArgumentsFactory typeResolverArgumentsFactory)
		{
			_typeResolverArgumentsFactory = typeResolverArgumentsFactory;
		}

		protected override bool CanProcess(LocateObjectArgs args) => base.CanProcess(args) && args.Type == null && args.TypeResolver != null;

		protected override void Execute(LocateObjectArgs args)
		{
			args.Type = Resolve(args);
		}

		protected virtual Type Resolve(LocateObjectArgs args)
		{
			TypeResolverArguments arguments = CreateTypeResolverArguments(args);
			if (arguments == null)
			{
				return null;
			}

			return args.TypeResolver.Resolve(arguments);
		}

		protected virtual TypeResolverArguments CreateTypeResolverArguments(LocateObjectArgs args) => _typeResolverArgumentsFactory.CreateTypeResolverArguments(args);
	}
}

The class above just “resolves” the type from the TypeResolver set on the LocateObjectArgs instance. Nothing more to see. πŸ˜‰

I then defined the following interface for a family of classes that “locate” objects from somewhere (perhaps a magical place. πŸ˜‰ ):

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators
{
	public interface IObjectLocator
	{
		object Resolve(ObjectLocatorArguments arguments);
	}
}

Well, we can’t use much magic in this solution, so I’m going to “locate” things in the Sitecore IoC container, so defined the following interface for a class that will employ Service Locator to find it in the Sitecore IoC container:

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators
{
	public interface IServiceProviderLocator : IObjectLocator
	{
	}
}

This class implements the interface above:

using System;

using Sitecore.DependencyInjection;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators
{
	public class ServiceProviderLocator : IServiceProviderLocator
	{
		private readonly IServiceProvider _serviceProvider;

		public ServiceProviderLocator()
		{
			_serviceProvider = GetServiceProvider();
		}

		protected virtual IServiceProvider GetServiceProvider()
		{
			return ServiceLocator.ServiceProvider;
		}

		public object Resolve(ObjectLocatorArguments arguments)
		{
			if (arguments == null || arguments.Type == null)
			{
				return null;
			}

			return GetService(arguments.Type);
		}

		protected virtual object GetService(Type type) => _serviceProvider.GetService(type);
	}
}

In the class above, I’m just passing a type to the System.IServiceProvider’s GetService() method — the IServiceProvider instance is grabbed from the ServiceProvider static member on Sitecore.DependencyInjection.ServiceLocator static class.

Next, I need a processor class to add an instance of the Service Locator IObjectLocator class above to the collection of IObjectLocator instances on the LocateObjectArgs instance, so I defined the following interface for a processor class that does just that:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.AddDefaultObjectLocatorProcessor
{
	public interface IAddDefaultObjectLocator
	{
		void Process(LocateObjectArgs args);
	}
}

Here’s the implementation class for the interface above:

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.AddDefaultObjectLocatorProcessor
{
	public class AddDefaultObjectLocator : ResolveProcessor<LocateObjectArgs>, IAddDefaultObjectLocator
	{
		private readonly IServiceProviderLocator _serviceProviderLocator;

		public AddDefaultObjectLocator(IServiceProviderLocator serviceProviderLocator)
		{
			_serviceProviderLocator = serviceProviderLocator;
		}

		protected override bool CanProcess(LocateObjectArgs args) => base.CanProcess(args) && args.Locators != null;

		protected override void Execute(LocateObjectArgs args) => args.Locators.Add(GetObjectLocator());

		protected virtual IObjectLocator GetObjectLocator() => _serviceProviderLocator;
	}
}

It’s just adding the IServiceProviderLocator instance to the collection of Locators set on the LocateObjectArgs instance.

Great, so we have things that can “locate” objects but need to have a processor that does the execution of that step to actually find those objects. The following interface is for a processor class that does just that:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.LocateObjectProcessor
{
	public interface ILocateObject
	{
		void Process(LocateObjectArgs args);
	}
}

And here’s its implementation class:

using System.Linq;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.LocateObjectProcessor
{
	public class LocateObject : ResolveProcessor<LocateObjectArgs>, ILocateObject
	{
		private readonly IObjectLocatorArgumentsFactory _objectLocatorArgumentsFactory;

		public LocateObject(IObjectLocatorArgumentsFactory objectLocatorArgumentsFactory)
		{
			_objectLocatorArgumentsFactory = objectLocatorArgumentsFactory;
		}

		protected override bool CanProcess(LocateObjectArgs args) => base.CanProcess(args) && args.Locators != null && args.Locators.Any() && args.Type != null;

		protected override void Execute(LocateObjectArgs args) => args.Object = Resolve(args);

		protected virtual object Resolve(LocateObjectArgs args)
		{
			ObjectLocatorArguments arguments = CreateObjectLocatorArguments(args);
			if (arguments == null)
			{
				return null;
			}

			foreach (IObjectLocator objectLocator in args.Locators)
			{
				object obj = objectLocator.Resolve(arguments);
				if (obj != null)
				{
					return obj;
				}
			}

			return null;
		}

		protected virtual ObjectLocatorArguments CreateObjectLocatorArguments(LocateObjectArgs args) => _objectLocatorArgumentsFactory.CreateObjectLocatorArguments(args);
	}
}

As I had done in the previous pipelines, I’m just iterating over a collection of classes that “resolve” for a particular thing — here I’m iterating over all IObjectLocator instances set on the LocateObjectArgs instance. If one of them find the object we are looking for, we just set it on the LocateObjectArgs instance.

As I had done for the other pipelines, I created a service class that wraps the new pipeline I am creating. The following class serves as a settings class for that service class:

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators
{
	public class ObjectLocatorServiceSettings
	{
		public string LocateObjectPipelineName { get; set; }
	}
}

An instance of the class above will be created by the Sitecore Configuration Factory, and its LocateObjectPipelineName property will contain a value defined in the Sitecore patch file further down in this post.

I then created the following interface for the service class that will wrap this new pipeline:

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators
{
	public interface IObjectLocatorService : IObjectLocator
	{
	}
}

Here’s the class that implements the interface above:

using Sitecore.Abstractions;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectLocators;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators
{
	public class ObjectLocatorService : PipelineObjectResolver<ObjectLocatorArguments, LocateObjectArgs, object>, IObjectLocatorService
	{
		private readonly ObjectLocatorServiceSettings _settings;
		private readonly IObjectLocatorArgumentsFactory _objectLocatorArgumentsFactory;

		public ObjectLocatorService(ObjectLocatorServiceSettings settings, IObjectLocatorArgumentsFactory objectLocatorArgumentsFactory, BaseCorePipelineManager corePipelineManager)
			: base(corePipelineManager)
		{
			_settings = settings;
			_objectLocatorArgumentsFactory = objectLocatorArgumentsFactory;
		}

		protected override object GetObject(LocateObjectArgs args)
		{
			return args.Object;
		}

		protected override LocateObjectArgs CreatePipelineArgs(ObjectLocatorArguments arguments) => _objectLocatorArgumentsFactory.CreateLocateObjectArgs(arguments);

		protected override string GetPipelineName() => _settings.LocateObjectPipelineName;
	}
}

I’m not going talk much about the class above — it’s following the same pattern as the other classes that wrap their respective pipelines.

<createObject />

So what happens when we cannot find an object via the <locateObject /> pipeline? Well, let’s create it.

I defined the following PipelineArgs class for a new pipeline that creates objects:

using System;
using System.Collections.Generic;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;
using Sitecore.Pipelines;

using Sandbox.Foundation.ObjectResolution.Services.Cachers;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject
{
	public class CreateObjectArgs : PipelineArgs
	{
		public Database Database { get; set; }

		public string ItemPath { get; set; }

		public Language Language { get; set; }

		public Item Item { get; set; }

		public string TypeFieldName { get; set; }

		public string TypeName { get; set; }

		public ITypeResolver TypeResolver { get; set; }

		public Type Type { get; set; }

		public object[] Parameters { get; set; }

		public IList<IObjectCreator> Creators { get; set; } = new List<IObjectCreator>();

		public object Object { get; set; }

		public bool UseTypeCache { get; set; }

		public ITypeCacher TypeCacher { get; set; }
	}
}

I then defined the following class for service classes that create objects:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators
{
	public class ObjectCreatorArguments
	{
		public Database Database { get; set; }

		public Language Language { get; set; }

		public string ItemPath { get; set; }

		public Item Item { get; set; }

		public string TypeFieldName { get; set; }

		public string TypeName { get; set; }

		public Type Type { get; set; }

		public bool UseTypeCache { get; set; }

		public object[] Parameters { get; set; }
	}
}

Since the “new” keyword promotes tight coupling between classes, I created the following factory interface for classes that create the two arguments types shown above:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectCreators
{
	public interface IObjectCreatorArgumentsFactory
	{
		ObjectCreatorArguments CreateObjectCreatorArguments(ResolveObjectArgs args);

		ObjectCreatorArguments CreateObjectCreatorArguments(CreateObjectArgs args);

		ObjectCreatorArguments CreateObjectCreatorArguments(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false, object[] parameters = null);

		CreateObjectArgs CreateCreateObjectArgs(ObjectCreatorArguments arguments);

		CreateObjectArgs CreateCreateObjectArgs(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false, object[] parameters = null);

	}
}

The following class implements the interface above:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectCreators
{
	public class ObjectCreatorArgumentsFactory : IObjectCreatorArgumentsFactory
	{
		public ObjectCreatorArguments CreateObjectCreatorArguments(ResolveObjectArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateObjectCreatorArguments(args.Database, args.Language, args.ItemPath, args.Item, args.TypeFieldName, args.TypeName, args.Type, args.UseTypeCache, args.ObjectCreationParameters);
		}

		public ObjectCreatorArguments CreateObjectCreatorArguments(CreateObjectArgs args)
		{
			if (args == null)
			{
				return null;
			}

			return CreateObjectCreatorArguments(args.Database, args.Language, args.ItemPath, args.Item, args.TypeFieldName, args.TypeName, args.Type, args.UseTypeCache, args.Parameters);
		}

		public ObjectCreatorArguments CreateObjectCreatorArguments(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false, object[] parameters = null)
		{
			return new ObjectCreatorArguments
			{
				Database = database,
				Language = language,
				ItemPath = itemPath,
				Item = item,
				TypeFieldName = typeFieldName,
				TypeName = typeName,
				Type = type,
				Parameters = parameters
			};
		}

		public CreateObjectArgs CreateCreateObjectArgs(ObjectCreatorArguments arguments)
		{
			if (arguments == null)
			{
				return null;
			}

			return CreateCreateObjectArgs(arguments.Database, arguments.Language, arguments.ItemPath, arguments.Item, arguments.TypeFieldName, arguments.TypeName, arguments.Type, arguments.UseTypeCache, arguments.Parameters);
		}

		public CreateObjectArgs CreateCreateObjectArgs(Database database = null, Language language = null, string itemPath = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false, object[] parameters = null)
		{
			return new CreateObjectArgs
			{
				Database = database,
				Language = language,
				ItemPath = itemPath,
				Item = item,
				TypeFieldName = typeFieldName,
				TypeName = typeName,
				Type = type,
				UseTypeCache = useTypeCache,
				Parameters = parameters
			};
		}
	}
}

The class above just creates CreateObjectArgs and ObjectCreatorArguments instances.

Let’s jump into the bits that comprise the new pipeline.

The following interface is for a processor class that sets the ITypeResolver on the CreateObjectArgs instance:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.SetTypeResolverProcessor
{
	public interface ISetTypeResolver
	{
		void Process(CreateObjectArgs args);
	}
}

Here’s the processor class that implements the interface above:

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.SetTypeResolverProcessor
{
	public class SetTypeResolver : ResolveProcessor<CreateObjectArgs>, ISetTypeResolver
	{
		private readonly ITypeResolverService _typeResolverService;

		public SetTypeResolver(ITypeResolverService typeResolverService)
		{
			_typeResolverService = typeResolverService;
		}

		protected override bool CanProcess(CreateObjectArgs args) => base.CanProcess(args) && args.Type == null && args.TypeResolver == null;

		protected override void Execute(CreateObjectArgs args)
		{
			args.TypeResolver = GetTypeResolver();
		}

		protected virtual ITypeResolver GetTypeResolver() => _typeResolverService;
	}
}

Nothing special going on — we’ve seen something like this before further up in this post.

Now, we need a processor to “resolve” types. The following interface is for a processor class which does just that:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.ResolveTypeProcessor
{
	public interface IResolveType
	{
		void Process(CreateObjectArgs args);
	}
}

And here is the processor class that implements the interface above:

using System;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.ResolveTypeProcessor
{
	public class ResolveType : ResolveProcessor<CreateObjectArgs>, IResolveType
	{
		private readonly ITypeResolverArgumentsFactory _typeResolverArgumentsFactory;

		public ResolveType(ITypeResolverArgumentsFactory typeResolverArgumentsFactory)
		{
			_typeResolverArgumentsFactory = typeResolverArgumentsFactory;
		}

		protected override bool CanProcess(CreateObjectArgs args) => base.CanProcess(args) && args.Type == null && args.TypeResolver != null;

		protected override void Execute(CreateObjectArgs args)
		{
			args.Type = Resolve(args);
		}

		protected virtual Type Resolve(CreateObjectArgs args)
		{
			TypeResolverArguments arguments = CreateTypeResolverArguments(args);
			if (arguments == null)
			{
				return null;
			}

			return args.TypeResolver.Resolve(arguments);
		}

		protected virtual TypeResolverArguments CreateTypeResolverArguments(CreateObjectArgs args) => _typeResolverArgumentsFactory.CreateTypeResolverArguments(args);
	}
}

I’m not going to discuss much on this as we’ve already seen something like this further up in this post.

I then defined the following interface for a family of classes that create objects:

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators
{
	public interface IObjectCreator
	{
		object Resolve(ObjectCreatorArguments arguments);
	}
}

Since I’m not good at arts and crafts, we’ll have to use reflection to create objects. The following interface is for a class that uses reflection to create objects:

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators
{
	public interface IReflectionObjectCreator : IObjectCreator
	{
	}
}

The following class implements the interface above:

using System.Linq;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Services.Reflection;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators
{
	public class ReflectionObjectCreator : IReflectionObjectCreator
	{
		private readonly IReflectionUtilService _reflectionUtilService;

		public ReflectionObjectCreator(IReflectionUtilService reflectionUtilService)
		{
			_reflectionUtilService = reflectionUtilService;
		}

		public object Resolve(ObjectCreatorArguments arguments)
		{
			if (arguments == null || arguments.Type == null)
			{
				return null;
			}

			if (arguments.Parameters == null || !arguments.Parameters.Any())
			{
				return _reflectionUtilService.CreateObject(arguments.Type);
			}

			return _reflectionUtilService.CreateObject(arguments.Type, arguments.Parameters);
		}
	}
}

This class above just delegates to the IReflectionUtilService instance — this is defined way up above in this post — injected into it for creating objects.

Now we need to put this IReflectionObjectCreator somewhere so it can be used to create objects. The following interface is for a processor class that adds this to a collection of other IObjectCreator defined on the CreateObjectArgs instance:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.AddDefaultObjectCreatorProcessor
{
	public interface IAddDefaultObjectCreator
	{
		void Process(CreateObjectArgs args);
	}
}

And here is the magic behind the interface above:

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.AddDefaultObjectCreatorProcessor
{
	public class AddDefaultObjectCreator : ResolveProcessor<CreateObjectArgs>, IAddDefaultObjectCreator
	{
		private readonly IReflectionObjectCreator _reflectionObjectCreator;

		public AddDefaultObjectCreator(IReflectionObjectCreator reflectionObjectCreator)
		{
			_reflectionObjectCreator = reflectionObjectCreator;
		}

		protected override bool CanProcess(CreateObjectArgs args) => base.CanProcess(args) && args.Creators != null;

		protected override void Execute(CreateObjectArgs args) => args.Creators.Add(GetObjectLocator());

		protected virtual IObjectCreator GetObjectLocator() => _reflectionObjectCreator;
	}
}

We are just adding the IReflectionObjectCreator instance to the Creators collection on the CreateObjectArgs instance.

Now, we need a processor that delegates to each IObjectCreator instance in the collection on the CreateObjectArgs instance. The following interface is for a processor that does that:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.CreateObjectProcessor
{
	public interface ICreateObject
	{
		void Process(CreateObjectArgs args);
	}
}

Here’s the above interface’s implementation class:

using System.Linq;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.CreateObjectProcessor
{
	public class CreateObject : ResolveProcessor<CreateObjectArgs>, ICreateObject
	{
		private readonly IObjectCreatorArgumentsFactory _objectCreatorArgumentsFactory;

		public CreateObject(IObjectCreatorArgumentsFactory objectCreatorArgumentsFactory)
		{
			_objectCreatorArgumentsFactory = objectCreatorArgumentsFactory;
		}

		protected override bool CanProcess(CreateObjectArgs args) => base.CanProcess(args) && args.Creators.Any();

		protected override void Execute(CreateObjectArgs args)
		{
			args.Object = CreateObjectFromArguments(args);
		}

		protected virtual object CreateObjectFromArguments(CreateObjectArgs args)
		{
			ObjectCreatorArguments arguments = CreateObjectCreatorArguments(args);
			if (arguments == null)
			{
				return null;
			}

			foreach (IObjectCreator objectCreator in args.Creators)
			{
				object result = CreateObjectFromArguments(objectCreator, arguments);
				if (result != null)
				{
					return result;
				}
			}

			return null;
		}

		protected virtual ObjectCreatorArguments CreateObjectCreatorArguments(CreateObjectArgs args) => _objectCreatorArgumentsFactory.CreateObjectCreatorArguments(args);

		protected virtual object CreateObjectFromArguments(IObjectCreator objectCreator, ObjectCreatorArguments arguments) => objectCreator.Resolve(arguments);
	}
}

The above class just iterates over the IObjectCreator collection on the CreateObjectArgs instance, and tries to create an object using each. The IObjectCreatorArgumentsFactory instance assists in creating the ObjectCreatorArguments instance from the CreateObjectArgs instance so it can make such calls on each IObjectCreator instance.

If an object is created from one them, it just uses that and stops the iteration.

It’s probably a good idea to only cache Types when an object was actually created from the Type. The following interface is for a processor that sets a ITypeCacher on the CreateObjectArgs instance — this class will add the Type to a cache (perhaps in a bank somewhere on the Cayman Islands? πŸ˜‰ ):

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.SetTypeCacherProcessor
{
	public interface ISetTypeCacher
	{
		void Process(CreateObjectArgs args);
	}
}

Here’s the implementation class for the interface above:

using Sandbox.Foundation.ObjectResolution.Services.Cachers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.SetTypeCacherProcessor
{
	public class SetTypeCacher : ResolveProcessor<CreateObjectArgs>, ISetTypeCacher
	{
		private readonly ITypeCacher _typeCacher;

		public SetTypeCacher(ITypeCacher typeCacher)
		{
			_typeCacher = typeCacher;
		}

		protected override bool CanProcess(CreateObjectArgs args) => base.CanProcess(args) && args.UseTypeCache && args.TypeCacher == null;

		protected override void Execute(CreateObjectArgs args) => args.TypeCacher = _typeCacher;
	}
}

It’s just setting the injected ITypeCacher — the implementation class is defined further up in this post — on the CreateObjectArgs instance.

Now, we need to use the ITypeCacher to cache the type. The following interface is for a processor class delegates to the ITypeCacher instance to cache the Type:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.CacheTypeProcessor
{
	public interface ICacheType
	{
		void Process(CreateObjectArgs args);
	}
}

Here is the process class which implements the interface above:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.CacheTypeProcessor
{
	public class CacheType : ResolveProcessor<CreateObjectArgs>, ICacheType
	{
		protected override bool CanProcess(CreateObjectArgs args) => base.CanProcess(args) && !string.IsNullOrWhiteSpace(args.TypeName) && args.Type != null && args.UseTypeCache && args.TypeCacher != null;

		protected override void Execute(CreateObjectArgs args) => AddTypeToCache(args);

		protected virtual void AddTypeToCache(CreateObjectArgs args) => args.TypeCacher.AddTypeToCache(args.TypeName, args.Type);
	}
}

It should be self-explanatory what’s happening here. If not, please drop a comment below.

Now, we need a service class that wraps this new pipeline. I created the following settings class for that service:

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators
{
	public class ObjectCreatorServiceSettings
	{
		public string CreateObjectPipelineName { get; set; }
	}
}

An instance of this class is created by the Sitecore Configuration Factory just as the other ones in this post are.

I then defined the following interface for the service class that will wrap this new pipeline — it’s just another IObjectCreator:

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators
{
	public interface IObjectCreatorService : IObjectCreator
	{
	}
}

This class implements the interface above:

using Sitecore.Abstractions;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectCreators;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators
{
	public class ObjectCreatorService : PipelineObjectResolver<ObjectCreatorArguments, CreateObjectArgs, object>, IObjectCreatorService
	{
		private readonly ObjectCreatorServiceSettings _settings;
		private readonly IObjectCreatorArgumentsFactory _objectCreatorArgumentsFactory;

		public ObjectCreatorService(ObjectCreatorServiceSettings settings, IObjectCreatorArgumentsFactory objectCreatorArgumentsFactory, BaseCorePipelineManager corePipelineManager)
			: base(corePipelineManager)
		{
			_settings = settings;
			_objectCreatorArgumentsFactory = objectCreatorArgumentsFactory;
		}

		protected override object GetObject(CreateObjectArgs args)
		{
			return args.Object;
		}

		protected override CreateObjectArgs CreatePipelineArgs(ObjectCreatorArguments arguments) => _objectCreatorArgumentsFactory.CreateCreateObjectArgs(arguments);

		protected override string GetPipelineName() => _settings.CreateObjectPipelineName;
	}
}

I’m not going to go into details on the above as you have seen this pattern further above in this post.

<resolveObject />

Now we need a way to glue together all pipelines created above. The following PipelineArgs class is for — yet another pipeline πŸ˜‰ — that glues everything together:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;
using Sitecore.Pipelines;

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject
{
	public class ResolveObjectArgs : PipelineArgs
	{
		public Database Database { get; set; }

		public string ItemPath { get; set; }

		public Language Language { get; set; }

		public Item Item { get; set; }

		public string TypeFieldName { get; set; }

		public string TypeName { get; set; }

		public ITypeResolver TypeResolver { get; set; }

		public Type Type { get; set; }

		public IObjectLocator ObjectLocator;

		public bool FoundInContainer { get; set; }

		public IObjectCreator ObjectCreator;

		public bool UseTypeCache { get; set; }

		public object[] ObjectCreationParameters { get; set; }

		public object Object { get; set; }
	}
}

I also created the following class for the service class that will wrap this new pipeline:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectResolvers
{
	public class ObjectResolverArguments
	{
		public Database Database { get; set; }

		public Language Language { get; set; }

		public string ItemPath { get; set; }

		public Item Item { get; set; }

		public string TypeFieldName { get; set; }

		public string TypeName { get; set; }

		public Type Type { get; set; }

		public bool UseTypeCache { get; set; }

		public object[] ObjectCreationParameters { get; set; }
	}
}

I bet you are guessing that I’m going to create another factory for these two classes above. Yep, you are correct. Here is the interface for that factory:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectResolvers
{
	public interface IObjectResolverArgumentsFactory
	{
		ObjectResolverArguments CreateObjectResolverArguments(Database database, string itemPath, string typeFieldName, Language language, object[] objectCreationParameters);

		ObjectResolverArguments CreateObjectResolverArguments(Item item, string typeFieldName, bool useTypeCache, object[] objectCreationParameters);

		ResolveObjectArgs CreateResolveObjectArgs(ObjectResolverArguments arguments);

		ResolveObjectArgs CreateResolveObjectArgs(Database database = null, string itemPath = null, Language language = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false, object[] objectCreationParameters = null);

	}
}

The following class implements the factory interface above:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;

namespace Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectResolvers
{
	public class ObjectResolverArgumentsFactory : IObjectResolverArgumentsFactory
	{
		public ObjectResolverArguments CreateObjectResolverArguments(Database database, string itemPath, string typeFieldName, Language language, object[] objectCreationParameters)
		{
			return new ObjectResolverArguments
			{
				Database = database,
				ItemPath = itemPath,
				TypeFieldName = typeFieldName,
				Language = language,
				ObjectCreationParameters = objectCreationParameters
			};
		}

		public ObjectResolverArguments CreateObjectResolverArguments(Item item, string typeFieldName, bool useTypeCache, object[] objectCreationParameters)
		{
			return new ObjectResolverArguments
			{
				Item = item,
				TypeFieldName = typeFieldName,
				UseTypeCache = useTypeCache,
				ObjectCreationParameters = objectCreationParameters
			};
		}

		public ResolveObjectArgs CreateResolveObjectArgs(ObjectResolverArguments arguments)
		{
			if (arguments == null)
			{
				return null;
			}

			return CreateResolveObjectArgs(arguments.Database, arguments.ItemPath, arguments.Language, arguments.Item, arguments.TypeFieldName, arguments.TypeName, arguments.Type, arguments.UseTypeCache, arguments.ObjectCreationParameters);
		}

		public ResolveObjectArgs CreateResolveObjectArgs(Item item, string typeFieldName, object[] objectCreationParameters)
		{
			return new ResolveObjectArgs
			{
				Item = item,
				TypeFieldName = typeFieldName,
				ObjectCreationParameters = objectCreationParameters
			};
		}

		public ResolveObjectArgs CreateResolveObjectArgs(Database database = null, string itemPath = null, Language language = null, Item item = null, string typeFieldName = null, string typeName = null, Type type = null, bool useTypeCache = false, object[] objectCreationParameters = null)
		{
			return new ResolveObjectArgs
			{
				Database = database,
				ItemPath = itemPath,
				Language = language,
				Item = item,
				TypeFieldName = typeFieldName,
				TypeName = typeName,
				Type= type,
				UseTypeCache = useTypeCache,
				ObjectCreationParameters = objectCreationParameters
			};
		}
	}
}

The following interface is for a processor class that sets the ITypeResolver on the ResolveObjectArgs instance:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject
{
	public interface ISetTypeResolver
	{
		void Process(ResolveObjectArgs args);
	}
}

Here’s its implementation class:

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject
{
	public class SetTypeResolver : ResolveProcessor<ResolveObjectArgs>, ISetTypeResolver
	{
		private readonly ITypeResolverService _typeResolverService;

		public SetTypeResolver(ITypeResolverService typeResolverService)
		{
			_typeResolverService = typeResolverService;
		}

		protected override bool CanProcess(ResolveObjectArgs args) => base.CanProcess(args) && args.TypeResolver == null;

		protected override void Execute(ResolveObjectArgs args)
		{
			args.TypeResolver = GetTypeResolver();
		}

		protected virtual ITypeResolver GetTypeResolver() => _typeResolverService;
	}
}

We have already seen this twice, so I won’t discuss it again. πŸ˜‰

Next, we need to resolve the type. The following interface is for a processor class that does that type resolution:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.ResolveTypeProcessor
{
	public interface IResolveType
	{
		void Process(ResolveObjectArgs args);
	}
}

Here’s the class that implements the interface above:

using System;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.ResolveTypeProcessor
{
	public class ResolveType : ResolveProcessor<ResolveObjectArgs>, IResolveType
	{
		private readonly ITypeResolverArgumentsFactory _typeResolverArgumentsFactory;

		public ResolveType(ITypeResolverArgumentsFactory typeResolverArgumentsFactory)
		{
			_typeResolverArgumentsFactory = typeResolverArgumentsFactory;
		}

		protected override bool CanProcess(ResolveObjectArgs args) => base.CanProcess(args) && args.Type == null && args.TypeResolver != null;

		protected override void Execute(ResolveObjectArgs args)
		{
			args.Type = Resolve(args);
		}

		protected virtual Type Resolve(ResolveObjectArgs args)
		{
			TypeResolverArguments arguments = CreateTypeResolverArguments(args);
			if (arguments == null)
			{
				return null;
			}

			return args.TypeResolver.Resolve(arguments);
		}

		protected virtual TypeResolverArguments CreateTypeResolverArguments(ResolveObjectArgs args) => _typeResolverArgumentsFactory.CreateTypeResolverArguments(args);
	}
}

I’m also not going to discuss this as I’ve done this somewhere up above. πŸ˜‰

Now we need a processor to “locate” objects in the Sitecore IoC container. The following interface is for a processor class that does just that:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.SetObjectLocatorProcessor
{
	public interface ISetObjectLocator
	{
		void Process(ResolveObjectArgs args);
	}
}

The following class implements the interface above:

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.SetObjectLocatorProcessor
{
	public class SetObjectLocator : ResolveProcessor<ResolveObjectArgs>, ISetObjectLocator
	{
		private readonly IObjectLocatorService _objectLocatorService;

		public SetObjectLocator(IObjectLocatorService objectLocatorService)
		{
			_objectLocatorService = objectLocatorService;
		}

		protected override bool CanProcess(ResolveObjectArgs args) => base.CanProcess(args) && args.ObjectLocator == null;

		protected override void Execute(ResolveObjectArgs args) => args.ObjectLocator = GetObjectLocator();

		protected virtual IObjectLocator GetObjectLocator() => _objectLocatorService;
	}
}

The class above just sets the IObjectLocatorService — this is the service class which wraps the <locateObject /> pipeline defined further up in this post — on the ResolveObjectArgs instance.

I then created the following interface to delegate to the ObjectLocator property on the ResolveObjectArgs to “locate” the object:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.LocateObjectProcessor
{
	public interface ILocateObject
	{
		void Process(ResolveObjectArgs args);
	}
}

And here’s the class that implements this interface above:

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectLocators;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.LocateObjectProcessor
{
	public class LocateObject : ResolveProcessor<ResolveObjectArgs>, ILocateObject
	{
		private readonly IObjectLocatorArgumentsFactory _objectLocatorArgumentsFactory;

		public LocateObject(IObjectLocatorArgumentsFactory objectLocatorArgumentsFactory)
		{
			_objectLocatorArgumentsFactory = objectLocatorArgumentsFactory;
		}

		protected override bool CanProcess(ResolveObjectArgs args) => base.CanProcess(args) && args.Object == null && args.ObjectLocator != null;

		protected override void Execute(ResolveObjectArgs args)
		{
			args.Object = Locate(args);
			args.FoundInContainer = args.Object != null;
			if (!args.FoundInContainer)
			{
				return;
			}

			AbortPipeline(args);
		}

		protected virtual object Locate(ResolveObjectArgs args) => args.ObjectLocator.Resolve(CreateObjectLocatorArguments(args));

		protected virtual ObjectLocatorArguments CreateObjectLocatorArguments(ResolveObjectArgs args) => _objectLocatorArgumentsFactory.CreateObjectLocatorArguments(args);
	}
}

The above class just tries to “locate” the object using the ObjectLocator set on the ResolveObjectArgs instance.

In the event we can’t find the object via the IObjectLocator, we should create the object instead. I created the following interface to set an IObjectCreator instance on the ResolveObjectArgs instance:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.SetObjectCreatorProcessor
{
	public interface ISetObjectCreator
	{
		void Process(ResolveObjectArgs args);
	}
}

And here’s its implementation class:

using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.SetObjectCreatorProcessor
{
	public class SetObjectCreator : ResolveProcessor<ResolveObjectArgs>, ISetObjectCreator
	{
		private readonly IObjectCreatorService _objectCreatorService;

		public SetObjectCreator(IObjectCreatorService objectCreatorService)
		{
			_objectCreatorService = objectCreatorService;
		}

		protected override bool CanProcess(ResolveObjectArgs args) => base.CanProcess(args) && args.ObjectCreator == null;

		protected override void Execute(ResolveObjectArgs args) => args.ObjectCreator = GetObjectCreator();

		protected virtual IObjectCreator GetObjectCreator() => _objectCreatorService;
	}
}

The class above just sets the IObjectCreatorService — this is the service class which wraps the <createObject /> pipeline defined further up in this post — on the ResolveObjectArgs instance.

Next, we need to delegate to this IObjectCreator to create the object. The following interface is for a class that creates objects:

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.CreateObjectProcessor
{
	public interface ICreateObject
	{
		void Process(ResolveObjectArgs args);
	}
}

And here’s the implementation of the interface above:

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectCreators;

namespace Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.CreateObjectProcessor
{
	public class CreateObject : ResolveProcessor<ResolveObjectArgs>, ICreateObject
	{
		private readonly IObjectCreatorArgumentsFactory _objectCreatorArgumentsFactory;

		public CreateObject(IObjectCreatorArgumentsFactory objectCreatorArgumentsFactory)
		{
			_objectCreatorArgumentsFactory = objectCreatorArgumentsFactory;
		}
		protected override bool CanProcess(ResolveObjectArgs args) => base.CanProcess(args) && args.Object == null && args.ObjectCreator != null;

		protected override void Execute(ResolveObjectArgs args) => args.Object = Resolve(args);

		protected virtual object Resolve(ResolveObjectArgs args) => args.ObjectCreator.Resolve(CreateObjectCreatorArguments(args));

		protected virtual ObjectCreatorArguments CreateObjectCreatorArguments(ResolveObjectArgs args) => _objectCreatorArgumentsFactory.CreateObjectCreatorArguments(args);
	}
}

The class above just delegates to the IObjectCreator instance of the ResolveObjectArgs instance to create the object

Like the other 4 pipelines — holy cannoli, Batman, there are 5 pipelines in total in this solution! — I created a service class that wraps this new pipeline. The following class serves as a settings class for this service:

namespace Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectResolvers
{
	public class ObjectResolverServiceSettings
	{
		public string ResolveObjectPipelineName { get; set; }

		public bool UseTypeCache { get; set; }
	}
}

An instance of the above is created by the Sitecore Configuration Factory.

The following interface defines a family of classes that “resolve” objects. Unlike the other pipelines, we will only have one class that implements this interface:

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectResolvers;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectResolvers
{
	public interface IObjectResolver
	{
		TObject Resolve<TObject>(ObjectResolverArguments arguments) where TObject : class;

		object Resolve(ObjectResolverArguments arguments);
	}
}

The following class implements the interface above:

using Sitecore.Abstractions;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectResolvers;

namespace Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectResolvers
{
	public class ObjectResolverService : PipelineObjectResolver<ObjectResolverArguments, ResolveObjectArgs, object>, IObjectResolver
	{
		private readonly ObjectResolverServiceSettings _settings;
		private readonly IObjectResolverArgumentsFactory _objectResolverArgumentsFactory;

		public ObjectResolverService(ObjectResolverServiceSettings settings, IObjectResolverArgumentsFactory objectResolverArgumentsFactory, BaseCorePipelineManager corePipelineManager)
			: base(corePipelineManager)
		{
			_settings = settings;
			_objectResolverArgumentsFactory = objectResolverArgumentsFactory;
		}

		public TObject Resolve<TObject>(ObjectResolverArguments arguments) where TObject : class
		{
			return Resolve(arguments) as TObject;
		}

		protected override object GetObject(ResolveObjectArgs args)
		{
			return args.Object;
		}

		protected override ResolveObjectArgs CreatePipelineArgs(ObjectResolverArguments arguments) => _objectResolverArgumentsFactory.CreateResolveObjectArgs(arguments);

		protected override string GetPipelineName() => _settings.ResolveObjectPipelineName;
	}
}

I then register every single thing above — and I mean EVERYTHING — in the Sitecore IoC via the following IServicesConfigurator class:

using System;

using Microsoft.Extensions.DependencyInjection;

using Sitecore.Abstractions;
using Sitecore.DependencyInjection;

using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectResolvers;
using Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.AddDefaultObjectCreatorProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.CacheTypeProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.CreateObjectProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.ResolveTypeProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.SetTypeCacherProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.SetTypeResolverProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.AddDefaultObjectLocatorProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.LocateObjectProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem.AddDefaultItemResolverProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem.ResolveItemProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.SetObjectCreatorProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.SetObjectLocatorProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.AddDefaultTypeResolverProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetItemResolverProcessor;
using Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetTypeNameProcessor;
using Sandbox.Foundation.ObjectResolution.Services.Cachers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.ObjectResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Factories.Resolvers.TypeResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Reflection;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ItemResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectCreators;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectLocators;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.ObjectResolvers;
using Sandbox.Foundation.ObjectResolution.Services.Resolvers.TypeResolvers;

namespace Sandbox.Foundation.ObjectResolution
{
	public class ObjectResolutionConfigurator : IServicesConfigurator
	{
		public void Configure(IServiceCollection serviceCollection)
		{
			ConfigureCachers(serviceCollection);
			ConfigureFactories(serviceCollection);
			ConfigureItemResolvers(serviceCollection);
			ConfigureTypeResolvers(serviceCollection);
			ConfigureObjectCreators(serviceCollection);
			ConfigureObjectLocators(serviceCollection);
			ConfigureObjectResolvers(serviceCollection);
			ConfigureResolveItemPipelineProcessors(serviceCollection);
			ConfigureResolveTypePipelineProcessors(serviceCollection);
			ConfigureLocateObjectPipelineProcessors(serviceCollection);
			ConfigureCreateObjectPipelineProcessors(serviceCollection);
			ConfigureResolveObjectPipelineProcessors(serviceCollection);
			ConfigureOtherServices(serviceCollection);
		}

		private void ConfigureCachers(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<ITypeCacher, TypeCacher>();
		}

		private void ConfigureFactories(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IItemResolverArgumentsFactory, ItemResolverArgumentsFactory>();
			serviceCollection.AddSingleton<ITypeResolverArgumentsFactory, TypeResolverArgumentsFactory>();
			serviceCollection.AddSingleton<IObjectLocatorArgumentsFactory, ObjectLocatorArgumentsFactory>();
			serviceCollection.AddSingleton<IObjectCreatorArgumentsFactory, ObjectCreatorArgumentsFactory>();
			serviceCollection.AddSingleton<IObjectResolverArgumentsFactory, ObjectResolverArgumentsFactory>();
		}

		private void ConfigureItemResolvers(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IDatabaseItemResolver, DatabaseItemResolver>();
			serviceCollection.AddSingleton(GetItemResolverServiceSetting);
			serviceCollection.AddSingleton<IItemResolverService, ItemResolverService>();
		}

		private ItemResolverServiceSettings GetItemResolverServiceSetting(IServiceProvider provider)
		{
			return CreateConfigObject<ItemResolverServiceSettings>(provider, "moduleSettings/foundation/objectResolution/itemResolverServiceSettings");
		}

		private void ConfigureTypeResolvers(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IReflectionTypeResolver, ReflectionTypeResolver>();
			serviceCollection.AddSingleton(GetTypeResolverServiceSettings);
			serviceCollection.AddSingleton<ITypeResolverService, TypeResolverService>();
		}

		private TypeResolverServiceSettings GetTypeResolverServiceSettings(IServiceProvider provider)
		{
			return CreateConfigObject<TypeResolverServiceSettings>(provider, "moduleSettings/foundation/objectResolution/typeResolverServiceSettings");
		}

		private void ConfigureObjectCreators(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IReflectionObjectCreator, ReflectionObjectCreator>();
			serviceCollection.AddSingleton(GetObjectCreatorServiceSettings);
			serviceCollection.AddSingleton<IObjectCreatorService, ObjectCreatorService>();
		}

		private ObjectCreatorServiceSettings GetObjectCreatorServiceSettings(IServiceProvider provider)
		{
			return CreateConfigObject<ObjectCreatorServiceSettings>(provider, "moduleSettings/foundation/objectResolution/objectCreatorServiceSettings");
		}

		private void ConfigureObjectLocators(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IServiceProviderLocator, ServiceProviderLocator>();
			serviceCollection.AddSingleton(GetObjectLocatorServiceSettings);
			serviceCollection.AddSingleton<IObjectLocatorService, ObjectLocatorService>();
		}

		private ObjectLocatorServiceSettings GetObjectLocatorServiceSettings(IServiceProvider provider)
		{
			return CreateConfigObject<ObjectLocatorServiceSettings>(provider, "moduleSettings/foundation/objectResolution/objectLocatorServiceSettings");
		}

		private void ConfigureObjectResolvers(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IReflectionObjectCreator, ReflectionObjectCreator>();
			serviceCollection.AddSingleton(GetObjectResolverServiceSettings);
			serviceCollection.AddSingleton<IObjectResolver, ObjectResolverService>();
		}

		private ObjectResolverServiceSettings GetObjectResolverServiceSettings(IServiceProvider provider)
		{
			return CreateConfigObject<ObjectResolverServiceSettings>(provider, "moduleSettings/foundation/objectResolution/objectResolverServiceSettings");
		}

		private void ConfigureResolveItemPipelineProcessors(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IAddDefaultItemResolver, AddDefaultItemResolver>();
			serviceCollection.AddSingleton<IResolveItem, ResolveItem>();
		}

		private void ConfigureResolveTypePipelineProcessors(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<ISetItemResolver, SetItemResolver>();
			serviceCollection.AddSingleton<Pipelines.ResolveType.ResolveTypeProcessor.IResolveItem, Pipelines.ResolveType.ResolveTypeProcessor.ResolveItem>();
			serviceCollection.AddSingleton<ISetTypeName, SetTypeName>();
			serviceCollection.AddSingleton<IAddDefaultTypeResolver, AddDefaultTypeResolver>();
			serviceCollection.AddSingleton<Pipelines.ResolveType.SetTypeCacherProcessor.ISetTypeCacher, Pipelines.ResolveType.SetTypeCacherProcessor.SetTypeCacher>();
			serviceCollection.AddSingleton<Pipelines.ResolveType.ResolveTypeProcessor.IResolveType, Pipelines.ResolveType.ResolveTypeProcessor.ResolveType>();
		}

		private void ConfigureLocateObjectPipelineProcessors(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<Pipelines.LocateObject.SetTypeResolverProcessor.ISetTypeResolver, Pipelines.LocateObject.SetTypeResolverProcessor.SetTypeResolver>();
			serviceCollection.AddSingleton<Pipelines.LocateObject.ResolveTypeProcessor.IResolveType, Pipelines.LocateObject.ResolveTypeProcessor.ResolveType>();
			serviceCollection.AddSingleton<IAddDefaultObjectLocator, AddDefaultObjectLocator>();
			serviceCollection.AddSingleton<ILocateObject, LocateObject>();
		}

		private void ConfigureCreateObjectPipelineProcessors(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<ISetTypeResolver, SetTypeResolver>();
			serviceCollection.AddSingleton<IResolveType, ResolveType>();
			serviceCollection.AddSingleton<IAddDefaultObjectCreator, AddDefaultObjectCreator>();
			serviceCollection.AddSingleton<ICreateObject, CreateObject>();
			serviceCollection.AddSingleton<ISetTypeCacher, SetTypeCacher>();
			serviceCollection.AddSingleton<ICacheType, CacheType>();
		}

		private void ConfigureResolveObjectPipelineProcessors(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<Pipelines.ResolveObject.ISetTypeResolver, Pipelines.ResolveObject.SetTypeResolver>();
			serviceCollection.AddSingleton<Pipelines.ResolveObject.ResolveTypeProcessor.IResolveType, Pipelines.ResolveObject.ResolveTypeProcessor.ResolveType>();
			serviceCollection.AddSingleton<ISetObjectLocator, SetObjectLocator>();
			serviceCollection.AddSingleton<Pipelines.ResolveObject.LocateObjectProcessor.ILocateObject, Pipelines.ResolveObject.LocateObjectProcessor.LocateObject>();
			serviceCollection.AddSingleton<ISetObjectCreator, SetObjectCreator>();
			serviceCollection.AddSingleton<Pipelines.ResolveObject.CreateObjectProcessor.ICreateObject, Pipelines.ResolveObject.CreateObjectProcessor.CreateObject>();
		}

		private void ConfigureOtherServices(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IReflectionUtilService, ReflectionUtilService>();
		}

		private TConfigObject CreateConfigObject<TConfigObject>(IServiceProvider provider, string path) where TConfigObject : class
		{
			BaseFactory factory = GetService<BaseFactory>(provider);
			return factory.CreateObject(path, true) as TConfigObject;
		}

		private TService GetService<TService>(IServiceProvider provider)
		{
			return provider.GetService<TService>();
		}
	}
}

Finally, I strung all the pieces together using the following Sitecore patch config file:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/">
	<sitecore>
		<services>
			<configurator type="Sandbox.Foundation.ObjectResolution.ObjectResolutionConfigurator, Sandbox.Foundation.ObjectResolution" />
		</services>

		<pipelines>
			<resolveItem>
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem.AddDefaultItemResolverProcessor.IAddDefaultItemResolver, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveItem.ResolveItemProcessor.IResolveItem, Sandbox.Foundation.ObjectResolution" resolve="true" />
			</resolveItem>
			<resolveType>
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetItemResolverProcessor.ISetItemResolver, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.ResolveTypeProcessor.IResolveItem, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetTypeNameProcessor.ISetTypeName, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.AddDefaultTypeResolverProcessor.IAddDefaultTypeResolver, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.SetTypeCacherProcessor.ISetTypeCacher, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveType.ResolveTypeProcessor.IResolveType, Sandbox.Foundation.ObjectResolution" resolve="true" />
			</resolveType>
			<locateObject>
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.SetTypeResolverProcessor.ISetTypeResolver, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.ResolveTypeProcessor.IResolveType, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.AddDefaultObjectLocatorProcessor.IAddDefaultObjectLocator, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.LocateObject.LocateObjectProcessor.ILocateObject, Sandbox.Foundation.ObjectResolution" resolve="true" />
			</locateObject>
			<createObject>
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.SetTypeResolverProcessor.ISetTypeResolver, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.ResolveTypeProcessor.IResolveType, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.AddDefaultObjectCreatorProcessor.IAddDefaultObjectCreator, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.CreateObjectProcessor.ICreateObject, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.SetTypeCacherProcessor.ISetTypeCacher, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.CreateObject.CacheTypeProcessor.ICacheType, Sandbox.Foundation.ObjectResolution" resolve="true" />
			</createObject>
			<resolveObject>
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.ISetTypeResolver, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.ResolveTypeProcessor.IResolveType, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.SetObjectLocatorProcessor.ISetObjectLocator, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.LocateObjectProcessor.ILocateObject, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.SetObjectCreatorProcessor.ISetObjectCreator, Sandbox.Foundation.ObjectResolution" resolve="true" />
				<processor type="Sandbox.Foundation.ObjectResolution.Pipelines.ResolveObject.CreateObjectProcessor.ICreateObject, Sandbox.Foundation.ObjectResolution" resolve="true" />
			</resolveObject>
		</pipelines>

		<moduleSettings>
			<foundation>
				<objectResolution>
					<itemResolverServiceSettings type="Sandbox.Foundation.ObjectResolution.Models.Resolvers.ItemResolvers.ItemResolverServiceSettings, Sandbox.Foundation.ObjectResolution" singleInstance="true">
						<ResolveItemPipelineName>resolveItem</ResolveItemPipelineName>
					</itemResolverServiceSettings>
					<typeResolverServiceSettings type="Sandbox.Foundation.ObjectResolution.Models.Resolvers.TypeResolvers.TypeResolverServiceSettings, Sandbox.Foundation.ObjectResolution" singleInstance="true">
						<ResolveTypePipelineName>resolveType</ResolveTypePipelineName>
					</typeResolverServiceSettings>
					<objectLocatorServiceSettings type="Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectLocators.ObjectLocatorServiceSettings, Sandbox.Foundation.ObjectResolution" singleInstance="true">
						<LocateObjectPipelineName>locateObject</LocateObjectPipelineName>
					</objectLocatorServiceSettings>
					<objectCreatorServiceSettings type="Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectCreators.ObjectCreatorServiceSettings, Sandbox.Foundation.ObjectResolution" singleInstance="true">
						<CreateObjectPipelineName>createObject</CreateObjectPipelineName>
					</objectCreatorServiceSettings>
					<objectResolverServiceSettings type="Sandbox.Foundation.ObjectResolution.Models.Resolvers.ObjectResolvers.ObjectResolverServiceSettings, Sandbox.Foundation.ObjectResolution" singleInstance="true">
						<ResolveObjectPipelineName>resolveObject</ResolveObjectPipelineName>
						<UseTypeCache>true</UseTypeCache>
					</objectResolverServiceSettings>
				</objectResolution>
			</foundation>
		</moduleSettings>
</sitecore>
</configuration>

In my next post, I will be using the entire system above for resolving custom Forms Submit Actions from the Sitecore IoC container. Stay tuned for that post.

If you have made it this far, hats off to you. πŸ˜‰

Sorry for throwing so much at you, but that’s what I do. πŸ˜‰

On closing, I would like to mention that the system above could be used for resolving types from the Sitecore IoC container for WFFM but this is something that I will not investigate. If you happen to get this to work on WFFM, please share in a comment below.

Until next time, keep on Sitecoring.

Advertisements

Write Sitecore Experience Forms Log Entries to a Custom SQL Server Database Table

Not long after I wrote the code for my last post, I continued exploring ways of changing service classes in Sitecore Experience Forms.

One thing that popped out when continuing on this quest was Sitecore.ExperienceForms.Diagnostics.ILogger. I immediately thought “I just wrote code for retrieving Forms configuration settings from a SQL Server database table, why not create a new ILogger service class for storing log entries in a custom SQL table?”

Well, that’s what I did, and the code in this post captures how I went about doing that.

You might be asking “Mike, you know you can just use a SQL appender in log4net, right?”

Well, I certainly could have but what fun would that have been?

Anyways, let’s get started.

We first need a class that represents a log entry. I created the following POCO class to serve that purpose:

using System;

namespace Sandbox.Foundation.Forms.Models.Logging
{
	public class LogEntry
	{
		public Exception Exception { get; set; }

		public string LogEntryType { get; set; }

		public string LogMessage { get; set; }

		public string Message { get; set; }

		public object Owner { get; set; }

		public DateTime CreatedDate { get; set; }
	}
}

Since I hate calling the “new” keyword when creating new instances of classes, I chose to create a factory class. The following interface will be for instances of classes that create LogEntry instances:

using System;

using Sandbox.Foundation.Forms.Models.Logging;

namespace Sandbox.Foundation.Forms.Services.Factories.Diagnostics
{
	public interface ILogEntryFactory
	{
		LogEntry CreateLogEntry(string logEntryType, string message, Exception exception, Type ownerType, DateTime createdDate);

		LogEntry CreateLogEntry(string logEntryType, string message, Exception exception, object owner, DateTime createdDate);

		LogEntry CreateLogEntry(string logEntryType, string message, Type ownerType, DateTime createdDate);

		LogEntry CreateLogEntry(string logEntryType, string message, object owner, DateTime createdDate);
	}
}

Well, we can’t do much with just an interface. The following class implements the interface above. It creates an instance of LogEntry with the passed parameters to all methods (assuming the required parameters are passed with the proper values on them):

using System;

using Sandbox.Foundation.Forms.Models.Logging;

namespace Sandbox.Foundation.Forms.Services.Factories.Diagnostics
{
	public class LogEntryFactory : ILogEntryFactory
	{
		public LogEntry CreateLogEntry(string logEntryType, string message, Exception exception, Type ownerType, DateTime createdDate)
		{
			return CreateLogEntry(logEntryType, message, exception, ownerType, createdDate);
		}

		public LogEntry CreateLogEntry(string logEntryType, string message, Exception exception, object owner, DateTime createdDate)
		{
			if (!CanCreateLogEntry(logEntryType, message, owner, createdDate))
			{
				return null;
			}

			return new LogEntry
			{
				LogEntryType = logEntryType,
				Message = message,
				Exception = exception,
				Owner = owner,
				CreatedDate = createdDate
			};
		}

		public LogEntry CreateLogEntry(string logEntryType, string message, Type ownerType, DateTime createdDate)
		{
			return CreateLogEntry(logEntryType, message, ownerType, createdDate);
		}

		public LogEntry CreateLogEntry(string logEntryType, string message, object owner, DateTime createdDate)
		{
			if(!CanCreateLogEntry(logEntryType, message, owner, createdDate))
			{
				return null;
			}

			return new LogEntry
			{
				LogEntryType = logEntryType,
				Message = message,
				Owner = owner,
				CreatedDate = createdDate
			};
		}

		protected virtual bool CanCreateLogEntry(string logEntryType, string message, object owner, DateTime createdDate)
		{
			return !string.IsNullOrWhiteSpace(logEntryType)
				&& !string.IsNullOrWhiteSpace(message)
				&& owner != null
				&& createdDate != DateTime.MinValue
				&& createdDate != DateTime.MaxValue;
		}
	}
}

I didn’t want to send LogEntry instances directly to a repository class instance directly, so I created the following class to represent the entities which will ultimately be stored in the database:

using System;

namespace Sandbox.Foundation.Forms.Models.Logging
{
	public class RepositoryLogEntry
	{
		public string LogEntryType { get; set; }

		public string LogMessage { get; set; }

		public DateTime Created { get; set; }
	}
}

As I had done with LogEntry, I created a factory class for it. The difference here is we will be passing an instance of LogEntry to this new factory so we can create a RepositoryLogEntry instance from it.

The following interface is for factories of RepositoryLogEntry:

using System;

using Sandbox.Foundation.Forms.Models.Logging;

namespace Sandbox.Foundation.Forms.Services.Factories.Diagnostics
{
	public interface IRepositoryLogEntryFactory
	{
		RepositoryLogEntry CreateRepositoryLogEntry(LogEntry entry);

		RepositoryLogEntry CreateRepositoryLogEntry(string logEntryType, string logMessage, DateTime created);
	}
}

Now that we have the interface ready to go, we need an implementation class for it. The following class does the job:

using System;

using Sandbox.Foundation.Forms.Models.Logging;

namespace Sandbox.Foundation.Forms.Services.Factories.Diagnostics
{
	public class RepositoryLogEntryFactory : IRepositoryLogEntryFactory
	{
		public RepositoryLogEntry CreateRepositoryLogEntry(LogEntry entry)
		{
			return CreateRepositoryLogEntry(entry.LogEntryType, entry.LogMessage, entry.CreatedDate);
		}

		public RepositoryLogEntry CreateRepositoryLogEntry(string logEntryType, string logMessage, DateTime created)
		{
			if (!CanCreateRepositoryLogEntry(logEntryType, logMessage, created))
			{
				return null;
			}

			return new RepositoryLogEntry
			{
				LogEntryType = logEntryType,
				LogMessage = logMessage,
				Created = created
			};
		}

		protected virtual bool CanCreateRepositoryLogEntry(string logEntryType, string logMessage, DateTime created)
		{
			return !string.IsNullOrWhiteSpace(logEntryType)
					&& !string.IsNullOrWhiteSpace(logMessage)
					&& created != DateTime.MinValue
					&& created != DateTime.MaxValue;
		}
	}
}

I’m following a similiar structure here as I had done in the LogEntryFactory class above. The CanCreateRepositoryLogEntry() method ensures required parameters are passed to methods on the class. If they are not, then a null reference is returned to the caller.

Since I hate hardcoding things, I decided to create a service class that gets the newline character. The following interface is for classes that do that:

namespace Sandbox.Foundation.Forms.Services.Environment
{
	public interface IEnvironmentService
	{
		string GetNewLine();
	}
}

This next class implements the interface above:

namespace Sandbox.Foundation.Forms.Services.Environment
{
	public class EnvironmentService : IEnvironmentService
	{
		public string GetNewLine()
		{
			return System.Environment.NewLine;
		}
	}
}

In the class above, I’m taking advantage of stuff build into the .NET library for getting the newline character.

I love when I discover things like this, albeit wish I had found something like this when trying to find an html break string for something I was working on the other day, but I digress (if you know of a way, please let me know in a comment below πŸ˜‰ ).

The above interface and class might seem out of place in this post but I am using them when formatting messages for the LogEntry instances further down in another service class. Just keep an eye out for it.

Since I loathe hardcoding strings with a passion, I like to hide these away in Sitecore configuration patch files and hydrate a POCO class instance with the values from the aforementioned configuration. The following class is such a POCO settings object for a service class I will discuss further down in the post:

namespace Sandbox.Foundation.Forms.Models.Logging
{
	public class LogEntryServiceSettings
	{
		public string DebugLogEntryType { get; set; }

		public string ErrorLogEntryType { get; set; }

		public string FatalLogEntryType { get; set; }

		public string InfoLogEntryType { get; set; }

		public string WarnLogEntryType { get; set; }

		public string ExceptionPrefix { get; set; }

		public string MessagePrefix { get; set; }

		public string SourcePrefix { get; set; }

		public string NestedExceptionPrefix { get; set; }

		public string LogEntryTimeFormat { get; set; }
	}
}

Okay, so need we need to know what “type” of LogEntry we are dealing with — is it an error or a warning or what? — before sending to a repository to save in the database. I created the following interface for service classes that return back strings for the different LogEntry types, and also generate a log message from the data on properties on the LogEntry instance — this is the message that will end up in the database for the LogEntry:

using Sandbox.Foundation.Forms.Models.Logging;

namespace Sandbox.Foundation.Forms.Services.Diagnostics
{
	public interface ILogEntryService
	{
		string GetDebugLogEntryType();

		string GetErrorLogEntryType();

		string GetFatalLogEntryType();

		string GetInfoLogEntryType();

		string GetWarnLogEntryType();

		string GenerateLogMessage(LogEntry entry);
	}
}

And here is its implementation class:

using System;
using System.Text;

using Sandbox.Foundation.Forms.Models.Logging;
using Sandbox.Foundation.Forms.Services.Environment;

namespace Sandbox.Foundation.Forms.Services.Diagnostics
{
	public class LogEntryService : ILogEntryService
	{
		private readonly string _newLine;
		private readonly LogEntryServiceSettings _logEntryServiceSettings;

		public LogEntryService(IEnvironmentService environmentService, LogEntryServiceSettings logEntryServiceSettings)
		{
			_newLine = GetNewLine(environmentService);
			_logEntryServiceSettings = logEntryServiceSettings;
		}

		protected virtual string GetNewLine(IEnvironmentService environmentService)
		{
			return environmentService.GetNewLine();
		}

		public string GetDebugLogEntryType()
		{
			return _logEntryServiceSettings.DebugLogEntryType;
		}

		public string GetErrorLogEntryType()
		{
			return _logEntryServiceSettings.ErrorLogEntryType;
		}

		public string GetFatalLogEntryType()
		{
			return _logEntryServiceSettings.FatalLogEntryType;
		}

		public string GetInfoLogEntryType()
		{
			return _logEntryServiceSettings.InfoLogEntryType;
		}

		public string GetWarnLogEntryType()
		{
			return _logEntryServiceSettings.WarnLogEntryType;
		}

		public string GenerateLogMessage(LogEntry entry)
		{
			if(!CanGenerateLogMessage(entry))
			{
				return string.Empty;
			}

			string exceptionMessage = GenerateExceptionMessage(entry.Exception);
			if(string.IsNullOrWhiteSpace(exceptionMessage))
			{
				return $"{entry.Message}";
			}

			return $"{entry.Message} {exceptionMessage}";
		}

		protected virtual bool CanGenerateLogMessage(LogEntry entry)
		{
			return entry != null
					&& !string.IsNullOrWhiteSpace(entry.Message)
					&& entry.Owner != null;
		}

		protected virtual string GenerateExceptionMessage(Exception exception)
		{
			if(exception == null)
			{
				return string.Empty;
			}

			StringBuilder messageBuilder = new StringBuilder();
			messageBuilder.Append(_logEntryServiceSettings.ExceptionPrefix).Append(exception.GetType().FullName); ;
			AppendNewLine(messageBuilder);
			messageBuilder.Append(_logEntryServiceSettings.MessagePrefix).Append(exception.Message);
			AppendNewLine(messageBuilder);

			if (!string.IsNullOrWhiteSpace(exception.Source))
			{
				messageBuilder.Append(_logEntryServiceSettings.SourcePrefix).Append(exception.Source);
				AppendNewLine(messageBuilder);
			}

			if(!string.IsNullOrWhiteSpace(exception.StackTrace))
			{
				messageBuilder.Append(exception.StackTrace);
				AppendNewLine(messageBuilder);
			}

			if (exception.InnerException != null)
			{
				AppendNewLine(messageBuilder);
				messageBuilder.Append(_logEntryServiceSettings.NestedExceptionPrefix);
				AppendNewLine(messageBuilder, 3);
				messageBuilder.Append(GenerateExceptionMessage(exception.InnerException));
				AppendNewLine(messageBuilder);
			}

			return messageBuilder.ToString();
		}

		protected virtual void AppendNewLine(StringBuilder builder, int repeatCount = 1)
		{
			AppendRepeat(builder, _newLine, repeatCount);
		}

		protected virtual void AppendRepeat(StringBuilder builder, string stringToAppend, int repeatCount)
		{
			if (builder == null || string.IsNullOrWhiteSpace(stringToAppend) || repeatCount < 1)
			{
				return;
			}

			for(int i = 0; i < repeatCount; i++)
			{
				builder.Append(stringToAppend);
			}
		}
	}
}

I’m not going to discuss all the code in the above class as it should be self-explanatory.

I do want to point out GenerateLogMessage() will generate one of two strings, depending on whether an Exception was set on the LogEntry instance.

If an Exception was set, we append the Exception details — the GenerateExceptionMessage() method generates a string from the Exception — onto the end of the LogEntry message

If it was not set, we just return the LogEntry message to the caller.

Well, now we need a place to store the log entries. I used the following SQL script to create a new table for storing these:

USE [ExperienceFormsSettings]
GO

CREATE TABLE [dbo].[ExperienceFormsLog](
	[ID] [uniqueidentifier] NOT NULL,
	[LogEntryType] [nvarchar](max) NOT NULL,
	[LogMessage] [nvarchar](max) NOT NULL,
	[Created] [datetime] NOT NULL,
 CONSTRAINT [PK_ExperienceFormsLog] PRIMARY KEY CLUSTERED
(
	[ID] ASC
)WITH (PAD_INDEX = OFF, STATISTICS_NORECOMPUTE = OFF, IGNORE_DUP_KEY = OFF, ALLOW_ROW_LOCKS = ON, ALLOW_PAGE_LOCKS = ON) ON [PRIMARY]
) ON [PRIMARY] TEXTIMAGE_ON [PRIMARY]
GO

ALTER TABLE [dbo].[ExperienceFormsLog] ADD  DEFAULT (newsequentialid()) FOR [ID]
GO

I also sprinkled some magical database dust onto the table:

πŸ˜‰

Wonderful, we now can move on to the fun bit — actually writing some code to store these entries into the database table created from the SQL script above.

I wrote the following POCO class to represent a SQL command — either a query or statement (it really doesn’t matter as it will support both):

namespace Sandbox.Foundation.Forms.Models.Logging
{
	public class SqlCommand
	{
		public string Sql { get; set; }

		public object[] Parameters { get; set; }
	}
}

I’m sure I could have found something in Sitecore.Kernel.dll that does exactly what the class above does but I couldn’t find such a thing (if you know of such a class, please share in a comment below).

Now we need a settings class for the SQL Logger I am writing further down in this post. As I had done for the LogEntryService class above, this data will be coming from Sitecore configuration:

namespace Sandbox.Foundation.Forms.Models.Logging
{
	public class SqlLoggerSettings
	{
		public string LogPrefix { get; set; }

		public string LogDatabaseConnectionStringName { get; set; }

		public string InsertLogEntrySqlFormat { get; set; }

		public string ConnectionStringNameColumnName { get; set; }

		public string FieldsPrefixColumnName { get; set; }

		public string FieldsIndexNameColumnName { get; set; }

		public int NotFoundOrdinal { get; set; }

		public string LogEntryTypeParameterName { get; set; }

		public string LogMessageParameterName { get; set; }

		public string CreatedParameterName { get; set; }
	}
}

Now the fun part — creating an implementation of Sitecore.ExperienceForms.Diagnostics.ILogger:

using System;

using Sitecore.Abstractions;
using Sitecore.Data.DataProviders.Sql;
using Sitecore.ExperienceForms.Diagnostics;

using Sandbox.Foundation.Forms.Services.Factories;
using Sandbox.Foundation.Forms.Models.Logging;
using Sandbox.Foundation.Forms.Services.Factories.Diagnostics;

namespace Sandbox.Foundation.Forms.Services.Diagnostics
{
	public class SqlLogger : ILogger
	{
		private readonly SqlLoggerSettings _sqlLoggerSettings;
		private readonly BaseSettings _settings;
		private readonly BaseFactory _factory;
		private readonly SqlDataApi _sqlDataApi;
		private readonly ILogEntryFactory _logEntryFactory;
		private readonly ILogEntryService _logEntryService;
		private readonly IRepositoryLogEntryFactory _repositoryLogEntryFactory;

		public SqlLogger(SqlLoggerSettings sqlLoggerSettings, BaseSettings settings, BaseFactory factory, ISqlDataApiFactory sqlDataApiFactory, ILogEntryFactory logEntryFactory, IRepositoryLogEntryFactory repositoryLogEntryFactory, ILogEntryService logEntryService)
		{
			_sqlLoggerSettings = sqlLoggerSettings;
			_settings = settings;
			_factory = factory;
			_sqlDataApi = CreateSqlDataApi(sqlDataApiFactory);
			_logEntryFactory = logEntryFactory;
			_logEntryService = logEntryService;
			_repositoryLogEntryFactory = repositoryLogEntryFactory;
		}

		protected virtual SqlDataApi CreateSqlDataApi(ISqlDataApiFactory sqlDataApiFactory)
		{
			return sqlDataApiFactory.CreateSqlDataApi(GetLogDatabaseConnectionString());
		}

		protected virtual string GetLogDatabaseConnectionString()
		{
			return _settings.GetConnectionString(GetLogDatabaseConnectionStringName());
		}

		protected virtual string GetLogDatabaseConnectionStringName()
		{
			return _sqlLoggerSettings.LogDatabaseConnectionStringName;
		}

		public void Debug(string message)
		{
			Debug(message, GetDefaultOwner());
		}

		public void Debug(string message, object owner)
		{
			SaveLogEntry(CreateLogEntry(GetDebugLogEntryType(), message, owner, GetLogEntryDateTime()));
		}

		protected virtual string GetDebugLogEntryType()
		{
			return _logEntryService.GetDebugLogEntryType();
		}

		public void LogError(string message)
		{
			LogError(message, null, GetDefaultOwner());
		}

		public void LogError(string message, object owner)
		{
			LogError(message, null, owner);
		}

		public void LogError(string message, Exception exception, Type ownerType)
		{
			LogError(message, exception, (object)ownerType);
		}

		public void LogError(string message, Exception exception, object owner)
		{
			SaveLogEntry(CreateLogEntry(GetErrorLogEntryType(), message, exception, owner, GetLogEntryDateTime()));
		}

		protected virtual string GetErrorLogEntryType()
		{
			return _logEntryService.GetErrorLogEntryType();
		}

		public void Fatal(string message)
		{
			Fatal(message, null, GetDefaultOwner());
		}

		public void Fatal(string message, object owner)
		{
			Fatal(message, null, owner);
		}

		public void Fatal(string message, Exception exception, Type ownerType)
		{
			Fatal(message, exception, (object)ownerType);
		}

		public void Fatal(string message, Exception exception, object owner)
		{
			SaveLogEntry(CreateLogEntry(GetFatalLogEntryType(), message, exception, owner, GetLogEntryDateTime()));
		}

		protected virtual string GetFatalLogEntryType()
		{
			return _logEntryService.GetFatalLogEntryType();
		}

		public void Info(string message)
		{
			Info(message, GetDefaultOwner());
		}

		public void Info(string message, object owner)
		{
			SaveLogEntry(CreateLogEntry(GetInfoLogEntryType(), message, owner, GetLogEntryDateTime()));
		}

		protected virtual string GetInfoLogEntryType()
		{
			return _logEntryService.GetInfoLogEntryType();
		}

		public void Warn(string message)
		{
			Warn(message, GetDefaultOwner());
		}

		public void Warn(string message, object owner)
		{
			SaveLogEntry(CreateLogEntry(GetWarnLogEntryType(), message, owner, GetLogEntryDateTime()));
		}

		protected virtual string AddPrefixToMessage(string message)
		{
			return string.Concat(_sqlLoggerSettings.LogPrefix, message);
		}

		protected virtual object GetDefaultOwner()
		{
			return this;
		}

		protected virtual LogEntry CreateLogEntry(string logEntryType, string message, Exception exception, Type ownerType, DateTime createdDate)
		{
			return _logEntryFactory.CreateLogEntry(logEntryType, message, exception, ownerType, createdDate);
		}

		protected virtual LogEntry CreateLogEntry(string logEntryType, string message, Exception exception, object owner, DateTime createdDate)
		{
			return _logEntryFactory.CreateLogEntry(logEntryType, message, exception, owner, createdDate);
		}

		protected virtual LogEntry CreateLogEntry(string logEntryType, string message, Type ownerType, DateTime createdDate)
		{
			return _logEntryFactory.CreateLogEntry(logEntryType, message, ownerType, createdDate);
		}

		protected virtual LogEntry CreateLogEntry(string logEntryType, string message, object owner, DateTime createdDate)
		{
			return _logEntryFactory.CreateLogEntry(logEntryType, message, owner, createdDate);
		}

		protected virtual string GetWarnLogEntryType()
		{
			return _logEntryService.GetWarnLogEntryType();
		}

		protected virtual DateTime GetLogEntryDateTime()
		{
			return DateTime.Now.ToUniversalTime();
		}

		protected virtual void SaveLogEntry(LogEntry entry)
		{
			if (entry == null)
			{
				return;
			}

			entry.LogMessage = _logEntryService.GenerateLogMessage(entry);

			RepositoryLogEntry repositoryEntry = CreateRepositoryLogEntry(entry);
			if (repositoryEntry == null)
			{
				return;
			}

			SaveRepositoryLogEntry(repositoryEntry);
		}

		protected virtual string GenerateLogMessage(LogEntry entry)
		{
			return _logEntryService.GenerateLogMessage(entry);
		}

		protected virtual RepositoryLogEntry CreateRepositoryLogEntry(LogEntry entry)
		{
			return _repositoryLogEntryFactory.CreateRepositoryLogEntry(entry);
		}

		protected virtual void SaveRepositoryLogEntry(RepositoryLogEntry entry)
		{
			if(!CanLogEntry(entry))
			{
				return;
			}

			SqlCommand insertCommand = GetinsertCommand(entry);
			if(insertCommand == null)
			{
				return;
			}

			ExecuteNoResult(insertCommand);
		}

		protected virtual bool CanLogEntry(RepositoryLogEntry entry)
		{
			return entry != null
					&& !string.IsNullOrWhiteSpace(entry.LogEntryType)
					&& !string.IsNullOrWhiteSpace(entry.LogMessage)
					&& entry.Created > DateTime.MinValue
					&& entry.Created < DateTime.MaxValue;
		}

		protected virtual SqlCommand GetinsertCommand(RepositoryLogEntry entry)
		{
			return new SqlCommand
			{
				Sql = GetInsertLogEntrySql(),
				Parameters = GetinsertCommandParameters(entry)
			};
		}

		protected virtual object[] GetinsertCommandParameters(RepositoryLogEntry entry)
		{
			return new object[]
			{
				GetLogEntryTypeParameterName(),
				entry.LogEntryType,
				GetLogMessageParameterName(),
				entry.LogMessage,
				GetCreatedParameterName(),
				entry.Created
			};
		}

		protected virtual string GetLogEntryTypeParameterName()
		{
			return _sqlLoggerSettings.LogEntryTypeParameterName;
		}

		protected virtual string GetLogMessageParameterName()
		{
			return _sqlLoggerSettings.LogMessageParameterName;
		}

		protected virtual string GetCreatedParameterName()
		{
			return _sqlLoggerSettings.CreatedParameterName;
		}

		protected virtual string GetInsertLogEntrySql()
		{
			return _sqlLoggerSettings.InsertLogEntrySqlFormat;
		}

		protected virtual void ExecuteNoResult(SqlCommand sqlCommand)
		{
			_factory.GetRetryer().ExecuteNoResult(() => { _sqlDataApi.Execute(sqlCommand.Sql, sqlCommand.Parameters); });
		}
	}
}

Since there is a lot of code in the class above, I’m not going to talk about all of it — it should be clear on what this class is doing for the most part.

I do want to highlight that the SaveRepositoryLogEntry() method takes in a RepositoryLogEntry instance; builds up a SqlCommand instance from it as well as the insert SQL statement and parameters from the SqlLoggerSettings instance (these are coming from Sitecore configuration, and there are hooks on this class to allow for overriding these if needed); and passes the SqlCommand instance to the ExecuteNoResult() method which uses the SqlDataApi instance for saving to the database. Plus, I’m leveraging an “out of the box” “retryer” from the Sitecore.Kernel.dll to ensure it makes its way into the database table.

Moreover, I’m reusing the ISqlDataApiFactory instance above from my previous post. Have a read of it so you can see what this factory class does.

Since Experience Forms was built perfectly — πŸ˜‰ — I couldn’t see any LogEntry instances being saved to my database right away. So went ahead and created some <forms.renderField> pipeline processors to capture some.

The following interface is for a <forms.renderField> pipeline processor to just throw an exception by dividing by zero:

using Sitecore.ExperienceForms.Mvc.Pipelines.RenderField;

namespace Sandbox.Foundation.Forms.Pipelines.RenderField
{
	public interface IThrowExceptionProcessor
	{
		void Process(RenderFieldEventArgs args);
	}
}

Here is its implementation class:

using System;

using Sitecore.ExperienceForms.Diagnostics;
using Sitecore.ExperienceForms.Mvc.Pipelines.RenderField;

namespace Sandbox.Foundation.Forms.Pipelines.RenderField
{
	public class ThrowExceptionProcessor : IThrowExceptionProcessor
	{
		private readonly ILogger _logger;

		public ThrowExceptionProcessor(ILogger logger)
		{
			_logger = logger;
		}

		public void Process(RenderFieldEventArgs args)
		{
			try
			{
				int i = 1 / GetZero();
			}
			catch(Exception ex)
			{
				_logger.LogError(ToString(), ex, this);
			}
		}

		private int GetZero()
		{
			return 0;
		}
	}
}

I’m sure you would never do such a thing, right? πŸ˜‰

I then created the following interface for another <forms.renderField> pipeline processor to log some information on the RenderFieldEventArgs instance sent to the Process() method:

using Sitecore.ExperienceForms.Mvc.Pipelines.RenderField;

namespace Sandbox.Foundation.Forms.Pipelines.RenderField
{
	public interface ILogRenderedFieldInfo
	{
		void Process(RenderFieldEventArgs args);
	}
}

Here is the implementation class for this:

using Sitecore.ExperienceForms.Diagnostics;
using Sitecore.ExperienceForms.Mvc.Pipelines.RenderField;
using Sitecore.Mvc.Pipelines;

namespace Sandbox.Foundation.Forms.Pipelines.RenderField
{
	public class LogRenderedFieldInfo : MvcPipelineProcessor<RenderFieldEventArgs>, ILogRenderedFieldInfo
	{
		private readonly ILogger _logger;

		public LogRenderedFieldInfo(ILogger logger)
		{
			_logger = logger;
		}

		public override void Process(RenderFieldEventArgs args)
		{
			LogInfo($"ViewModel Details:\n\nName: {args.ViewModel.Name}, ItemId: {args.ViewModel.ItemId}, TemplateId: {args.ViewModel.TemplateId}, FieldTypeItemId: {args.ViewModel.FieldTypeItemId}");
			LogInfo($"RenderingSettings Details\n\nFieldTypeName: {args.RenderingSettings.FieldTypeName}, FieldTypeId: {args.RenderingSettings.FieldTypeId}, FieldTypeIcon: {args.RenderingSettings.FieldTypeIcon}, FieldTypeDisplayName: {args.RenderingSettings.FieldTypeDisplayName}, FieldTypeBackgroundColor: {args.RenderingSettings.FieldTypeBackgroundColor}");
			LogInfo($"Item Details: {args.Item.ID}, Name: {args.Item.Name} FullPath: {args.Item.Paths.FullPath}, TemplateID: {args.Item.TemplateID}");
		}

		protected virtual void LogInfo(string message)
		{
			if(string.IsNullOrWhiteSpace(message))
			{
				return;
			}

			_logger.Info(message);
		}
	}
}

I then registered everything in the Sitecore IoC container using the following configurator:

using System;

using Microsoft.Extensions.DependencyInjection;

using Sitecore.Abstractions;
using Sitecore.DependencyInjection;
using Sitecore.ExperienceForms.Diagnostics;

using Sandbox.Foundation.Forms.Services.Factories.Diagnostics;
using Sandbox.Foundation.Forms.Services.Factories;
using Sandbox.Foundation.Forms.Models.Logging;
using Sandbox.Foundation.Forms.Services.Environment;
using Sandbox.Foundation.Forms.Services.Diagnostics;
using Sandbox.Foundation.Forms.Pipelines.RenderField;

namespace Sandbox.Foundation.Forms
{
	public class SqlLoggerConfigurator : IServicesConfigurator
	{
		public void Configure(IServiceCollection serviceCollection)
		{
			ConfigureConfigObjects(serviceCollection);
			ConfigureFactories(serviceCollection);
			ConfigureServices(serviceCollection);
			ConfigurePipelineProcessors(serviceCollection);
		}

		private void ConfigureConfigObjects(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton(provider => GetLogEntryServiceSettings(provider));
			serviceCollection.AddSingleton(provider => GetSqlLoggerSettings(provider));
		}

		private LogEntryServiceSettings GetLogEntryServiceSettings(IServiceProvider provider)
		{
			return CreateConfigObject<LogEntryServiceSettings>(provider, "moduleSettings/foundation/forms/logEntryServiceSettings");
		}

		private SqlLoggerSettings GetSqlLoggerSettings(IServiceProvider provider)
		{
			return CreateConfigObject<SqlLoggerSettings>(provider, "moduleSettings/foundation/forms/sqlLoggerSettings");
		}

		private TConfigObject CreateConfigObject<TConfigObject>(IServiceProvider provider, string path) where TConfigObject : class
		{
			BaseFactory factory = GetService<BaseFactory>(provider);
			return factory.CreateObject(path, true) as TConfigObject;
		}

		private TService GetService<TService>(IServiceProvider provider)
		{
			return provider.GetService<TService>();
		}

		private void ConfigureFactories(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<ILogEntryFactory, LogEntryFactory>();
			serviceCollection.AddSingleton<IRepositoryLogEntryFactory, RepositoryLogEntryFactory>();
			serviceCollection.AddSingleton<ISqlDataApiFactory, SqlDataApiFactory>();
		}

		private void ConfigureServices(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<IEnvironmentService, EnvironmentService>();
			serviceCollection.AddSingleton<ILogEntryService, LogEntryService>();
			serviceCollection.AddSingleton<ILogger, SqlLogger>();
		}

		private void ConfigurePipelineProcessors(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton<ILogRenderedFieldInfo, LogRenderedFieldInfo>();
			serviceCollection.AddSingleton<IThrowExceptionProcessor, ThrowExceptionProcessor>();
		}
	}
}

Note: the GetLogEntryServiceSettings() and the GetSqlLoggerSettings() methods both create settings objects by using the Sitecore Configuration Factory. Ultimately, these settings objects are thrown into the container so they can be injected into the service classes that need them.

I then strung everything together using the following the Sitecore patch configuration file.

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/">
	<sitecore>
		<pipelines>
			<forms.renderField>
				<processor type="Sandbox.Foundation.Forms.Pipelines.RenderField.LogRenderedFieldInfo, Sandbox.Foundation.Forms" resolve="true"/>
				<processor type="Sandbox.Foundation.Forms.Pipelines.RenderField.ThrowExceptionProcessor, Sandbox.Foundation.Forms" resolve="true"/>
			</forms.renderField>
		</pipelines>
		<services>
			<configurator type="Sandbox.Foundation.Forms.SqlLoggerConfigurator, Sandbox.Foundation.Forms" />
			<register serviceType="Sitecore.ExperienceForms.Diagnostics.ILogger, Sitecore.ExperienceForms">
				<patch:delete />
			</register>
		</services>

		<moduleSettings>
			<foundation>
				<forms>
					<logEntryServiceSettings type="Sandbox.Foundation.Forms.Models.Logging.LogEntryServiceSettings, Sandbox.Foundation.Forms" singleInstance="true">
						<DebugLogEntryType>DEBUG</DebugLogEntryType>
						<ErrorLogEntryType>ERROR</ErrorLogEntryType>
						<FatalLogEntryType>FATAL</FatalLogEntryType>
						<InfoLogEntryType>INFO</InfoLogEntryType>
						<WarnLogEntryType>WARN</WarnLogEntryType>
						<ExceptionPrefix>Exception: </ExceptionPrefix>
						<MessagePrefix>Message: </MessagePrefix>
						<SourcePrefix>Source: </SourcePrefix>
						<NestedExceptionPrefix>Nested Exception</NestedExceptionPrefix>
						<LogEntryTimeFormat>HH:mm:ss.ff</LogEntryTimeFormat>
					</logEntryServiceSettings>
					<sqlLoggerSettings type="Sandbox.Foundation.Forms.Models.Logging.SqlLoggerSettings, Sandbox.Foundation.Forms" singleInstance="true">
						<LogPrefix>[Experience Forms]:</LogPrefix>
						<LogDatabaseConnectionStringName>ExperienceFormsSettings</LogDatabaseConnectionStringName>
						<InsertLogEntrySqlFormat>INSERT INTO {0}ExperienceFormsLog{1}({0}LogEntryType{1},{0}LogMessage{1},{0}Created{1})VALUES({2}logEntryType{3},{2}logMessage{3},{2}created{3});</InsertLogEntrySqlFormat>
						<LogEntryTypeParameterName>logEntryType</LogEntryTypeParameterName>
						<LogMessageParameterName>logMessage</LogMessageParameterName>
						<CreatedParameterName>created</CreatedParameterName>
					</sqlLoggerSettings>
				</forms>
			</foundation>
		</moduleSettings>
	</sitecore>
</configuration>

Ok, let’s take this for a spin.

After building and deploying everything above, I spun up my Sitecore instance:

I then navigated to a form I had created in a previous post:

After the page with my form was done loading, I ran a query on my custom log table and saw this:

As you can see, it worked.

If you have any questions or comments, don’t hesitate to drop these in a comment below.

Until next time, have yourself a Sitecoretastic day!

Grab Sitecore Experience Forms Configuration Settings from a Custom SQL Server Database Table

Just the other day, I poking around Sitecore Experience Forms to see what’s customisable and have pretty much concluded virtually everything is.

morpheus

How?

Just have a look at http://[instance]/sitecore/admin/showservicesconfig.aspx of your Sitecore instance and scan for “ExperienceForms”. You will also discover lots of its service class are registered in Sitecore’s IoC container — such makes it easy to swap things out with your own service implementation classes as long as they implement those service types defined in the container.

Since I love to tinkering with all things in Sitecore — most especially when it comes to customising bits of it — I decided to have a crack at replacing IFormsConfigurationSettings — more specifically Sitecore.ExperienceForms.Configuration.IFormsConfigurationSettings in Sitecore.ExperienceForms.dll which represents Sitecore configuration settings for Experience Forms — as it appeared to be something simple enough to do.

The IFormsConfigurationSettings interface represents the following configuration settings:

config-settings-ootb

So, what did I do to customise it?

I wrote a bunch of code — it’s all in this post — which pulls these settings from a custom SQL Server database table.


Why did I do that? Well, I did it because I could. πŸ˜‰

Years ago, long before my Sitecore days, I worked on ASP.NET Web Applications which had their configuration settings stored in SQL Server databases. Whether this was, or still is, a good idea is a discussion for another time though you are welcome to drop a comment below with your thoughts.

However, for the meantime, just roll with it as the point of this post is to show that you can customise virtually everything in Experience Forms, and I’m just showing one example.

I first created the following class which implements IFormsConfigurationSettings:

using Sitecore.ExperienceForms.Configuration;

namespace Sandbox.Foundation.Forms.Models.Configuration
{
	public class SandboxFormsConfigurationSettings : IFormsConfigurationSettings
	{
		public string ConnectionStringName { get; set; }

		public string FieldsPrefix { get; set; }

		public string FieldsIndexName { get; set; }
	}
}

You might be asking “Mike, why did you create an implementation class when Experience Forms already provides one ‘out of the box’?”

Well, all the properties defined in Sitecore.ExperienceForms.Configuration.IFormsConfigurationSettings — these are the same properties that you see in the implementation class above — lack mutators on them in the interface. My implementation class of IFormsConfigurationSettings adds them in — I hate baking method calls in property accessors as it doesn’t seem clean to me. Β―\_(ツ)_/Β―

When I had a look at the “out of the box” implementation class of IFormsConfigurationSettings, I discovered direct calls to the GetSetting() method on the Sitecore.Configuration.Settings static class — this lives in Sitecore.Kernel.dll — but that doesn’t help me with setting those properties, hence the custom IFormsConfigurationSettings class above.

Next, I used the following SQL script to create my custom settings database table:

USE [ExperienceFormsSettings]
GO

CREATE TABLE [dbo].[FormsConfigurationSettings](
	[FieldsPrefix] [nvarchar](max) NULL,
	[FieldsIndexName] [nvarchar](max) NULL,
	[ConnectionStringName] [nvarchar](max) NULL
) ON [PRIMARY] TEXTIMAGE_ON [PRIMARY]
GO

I then inserted the settings from the configuration file snapshot above into my new table (I’ve omitted the SQL insert statement for this):

config-database

Now we need a way to retrieve these settings from the database. The following interface will be for factory classes which create instances of Sitecore.Data.DataProviders.Sql.SqlDataApi — this lives in Sitecore.Kernel.dll — with the passed connection strings:

using Sitecore.Data.DataProviders.Sql;

namespace Sandbox.Foundation.Forms.Services.Factories
{
	public interface ISqlDataApiFactory
	{
		SqlDataApi CreateSqlDataApi(string connectionString);
	}
}

Well, we can’t do much with an interface without having some class implement it. The following class implements the interface above:

using Sitecore.Data.DataProviders.Sql;
using Sitecore.Data.SqlServer;

namespace Sandbox.Foundation.Forms.Services.Factories
{
	public class SqlDataApiFactory : ISqlDataApiFactory
	{
		public SqlDataApi CreateSqlDataApi(string connectionString)
		{
			if(string.IsNullOrWhiteSpace(connectionString))
			{
				return null;
			}

			return new SqlServerDataApi(connectionString);
		}
	}
}

It’s just creating an instance of the SqlServerDataApi class. Nothing special about it at all.

Ironically, I do have to save my own configuration settings in Sitecore Configuration — this would include the the connection string name to the database that contains my new table as well as a few other things.

An instance of the following class will contain these settings — have a look at /sitecore/moduleSettings/foundation/forms/repositorySettings in the Sitecore patch file near the bottom of this post but be sure to come back up here when you are finished πŸ˜‰ — and this instance will be put into the Sitecore IoC container so it can be injected in an instance of a class I’ll talk about further down in this post:

namespace Sandbox.Foundation.Forms.Models.Configuration
{
	public class RepositorySettings
	{
		public string ConnectionStringName { get; set; }

		public string GetSettingsSql { get; set; }

		public string ConnectionStringNameColumnName { get; set; }

		public string FieldsPrefixColumnName { get; set; }

		public string FieldsIndexNameColumnName { get; set; }

		public int NotFoundOrdinal { get; set; }
	}
}

I then defined the following interface for repository classes which retrieve IFormsConfigurationSettings instances:

using Sitecore.ExperienceForms.Configuration;

namespace Sandbox.Foundation.Forms.Repositories.Configuration
{
	public interface ISettingsRepository
	{
		IFormsConfigurationSettings GetFormsConfigurationSettings();
	}
}

Here’s the implementation class for the interface above:

using System;
using System.Data;
using System.Linq;

using Sitecore.Abstractions;
using Sitecore.Data.DataProviders.Sql;
using Sitecore.ExperienceForms.Configuration;
using Sitecore.ExperienceForms.Diagnostics;

using Sandbox.Foundation.Forms.Models.Configuration;
using Sandbox.Foundation.Forms.Services.Factories;

namespace Sandbox.Foundation.Forms.Repositories.Configuration
{
	public class SettingsRepository : ISettingsRepository
	{
		private readonly RepositorySettings _repositorySettings;
		private readonly BaseSettings _settings;
		private readonly int _notFoundOrdinal;
		private readonly ILogger _logger;
		private readonly SqlDataApi _sqlDataApi;

		public SettingsRepository(RepositorySettings repositorySettings, BaseSettings settings, ILogger logger, ISqlDataApiFactory sqlDataApiFactory)
		{
			_repositorySettings = repositorySettings;
			_settings = settings;
			_notFoundOrdinal = GetNotFoundOrdinal();
			_logger = logger;
			_sqlDataApi = GetSqlDataApi(sqlDataApiFactory);
		}

		protected virtual SqlDataApi GetSqlDataApi(ISqlDataApiFactory sqlDataApiFactory)
		{
			return sqlDataApiFactory.CreateSqlDataApi(GetConnectionString());
		}

		protected virtual string GetConnectionString()
		{
			return _settings.GetConnectionString(GetConnectionStringName());
		}

		protected virtual string GetConnectionStringName()
		{
			return _repositorySettings.ConnectionStringName;
		}

		public IFormsConfigurationSettings GetFormsConfigurationSettings()
		{
			try
			{
				return _sqlDataApi.CreateObjectReader(GetSqlQuery(), GetParameters(), GetMaterializer()).FirstOrDefault();
			}
			catch (Exception ex)
			{
				LogError(ex);

			}

			return CreateFormsConfigurationSettingsNullObject();
		}

		protected virtual string GetSqlQuery()
		{
			return _repositorySettings.GetSettingsSql;
		}

		protected virtual object[] GetParameters()
		{
			return Enumerable.Empty<object>().ToArray();
		}

		protected virtual Func<IDataReader, IFormsConfigurationSettings> GetMaterializer()
		{
			return new Func<IDataReader, IFormsConfigurationSettings>(ParseFormsConfigurationSettings);
		}

		protected virtual IFormsConfigurationSettings ParseFormsConfigurationSettings(IDataReader dataReader)
		{
			return new SandboxFormsConfigurationSettings
			{
				ConnectionStringName = GetString(dataReader, GetConnectionStringNameColumnName()),
				FieldsPrefix = GetString(dataReader, GetFieldsPrefixColumnName()),
				FieldsIndexName = GetString(dataReader, GetFieldsIndexNameColumnName())
			};
		}

		protected virtual string GetString(IDataReader dataReader, string columnName)
		{
			if(dataReader == null || string.IsNullOrWhiteSpace(columnName))
			{
				return string.Empty;

			}

			int ordinal = GetOrdinal(dataReader, columnName);
			if(ordinal == _notFoundOrdinal)
			{
				return string.Empty;
			}

			return dataReader.GetString(ordinal);
		}

		protected virtual int GetOrdinal(IDataReader dataReader, string columnName)
		{
			if(dataReader == null || string.IsNullOrWhiteSpace(columnName))
			{
				return _notFoundOrdinal;
			}

			try
			{
				return dataReader.GetOrdinal(columnName);
			}
			catch(IndexOutOfRangeException)
			{
				return _notFoundOrdinal;
			}
		}

		protected virtual int GetNotFoundOrdinal()
		{
			return _repositorySettings.NotFoundOrdinal;
		}

		protected virtual void LogError(Exception exception)
		{
			_logger.LogError(ToString(), exception, this);
		}

		protected virtual string GetConnectionStringNameColumnName()
		{
			return _repositorySettings.ConnectionStringNameColumnName;
		}

		protected virtual string GetFieldsPrefixColumnName()
		{
			return _repositorySettings.FieldsPrefixColumnName;
		}

		protected virtual string GetFieldsIndexNameColumnName()
		{
			return _repositorySettings.FieldsIndexNameColumnName;
		}

		protected virtual IFormsConfigurationSettings CreateFormsConfigurationSettingsNullObject()
		{
			return new SandboxFormsConfigurationSettings
			{
				ConnectionStringName = string.Empty,
				FieldsIndexName = string.Empty,
				FieldsPrefix = string.Empty
			};
		}
	}
}

I’m not going to go into details of all the code above but will talk about some important pieces.

The GetFormsConfigurationSettings() method above creates an instance of the IFormsConfigurationSettings instance using the SqlDataApi instance created from the injected factory service — this was defined above — with the SQL query provided from configuration along with the GetMaterializer() method which just uses the ParseFormsConfigurationSettings() method to create an instance of the IFormsConfigurationSettings by grabbing data from the IDataReader instance.

Phew, I’m out of breath as that was a mouthful. πŸ˜‰

I then registered all of my service classes above in the Sitecore IoC container using the following the configurator — aka a class that implements the IServicesConfigurator interface:

using System;

using Microsoft.Extensions.DependencyInjection;

using Sitecore.Abstractions;
using Sitecore.DependencyInjection;
using Sitecore.ExperienceForms.Configuration;

using Sandbox.Foundation.Forms.Repositories.Configuration;
using Sandbox.Foundation.Forms.Models.Configuration;

using Sandbox.Foundation.Forms.Services.Factories;

namespace Sandbox.Foundation.Forms
{
	public class SettingsConfigurator : IServicesConfigurator
	{
		public void Configure(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton(provider => GetRepositorySettings(provider));
			serviceCollection.AddSingleton<ISqlDataApiFactory, SqlDataApiFactory>();
			serviceCollection.AddSingleton<ISettingsRepository, SettingsRepository>();
			serviceCollection.AddSingleton(provider => GetFormsConfigurationSettings(provider));
		}

		private RepositorySettings GetRepositorySettings(IServiceProvider provider)
		{
			return CreateConfigObject<RepositorySettings>(provider, "moduleSettings/foundation/forms/repositorySettings");
		}

		private TConfigObject CreateConfigObject<TConfigObject>(IServiceProvider provider, string path) where TConfigObject : class
		{
			BaseFactory factory = GetService<BaseFactory>(provider);
			return factory.CreateObject(path, true) as TConfigObject;
		}

		private IFormsConfigurationSettings GetFormsConfigurationSettings(IServiceProvider provider)
		{
			ISettingsRepository repository = GetService<ISettingsRepository>(provider);
			return repository.GetFormsConfigurationSettings();
		}

		private TService GetService<TService>(IServiceProvider provider)
		{
			return provider.GetService<TService>();
		}
	}
}

One thing to note is the GetRepositorySettings() method above uses the Configuration Factory — this is represented by the BaseFactory abstract class which lives in the Sitecore IoC container “out of the box” — to create an instance of the RepositorySettings class, defined further up in this post, using the settings in the following Sitecore patch file:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/">
	<sitecore>
		<services>
			<configurator type="Sandbox.Foundation.Forms.SettingsConfigurator, Sandbox.Foundation.Forms" />
			<register serviceType="Sitecore.ExperienceForms.Configuration.IFormsConfigurationSettings, Sitecore.ExperienceForms">
				<patch:delete />
			</register>
		</services>

		<moduleSettings>
			<foundation>
				<forms>
					<repositorySettings type="Sandbox.Foundation.Forms.Models.Configuration.RepositorySettings, Sandbox.Foundation.Forms" singleInstance="true">
						<ConnectionStringName>ExperienceFormsSettings</ConnectionStringName>
						<GetSettingsSql>SELECT TOP (1) {0}ConnectionStringName{1},{0}FieldsPrefix{1},{0}FieldsIndexName{1} FROM {0}FormsConfigurationSettings{1}</GetSettingsSql>
						<ConnectionStringNameColumnName>ConnectionStringName</ConnectionStringNameColumnName>
						<FieldsPrefixColumnName>FieldsPrefix</FieldsPrefixColumnName>
						<FieldsIndexNameColumnName>FieldsIndexName</FieldsIndexNameColumnName>
						<NotFoundOrdinal>-1</NotFoundOrdinal>
					</repositorySettings>
				</forms>
			</foundation>
		</moduleSettings>
	</sitecore>
</configuration>

I want to point out that I’m deleting the Sitecore.ExperienceForms.Configuration.IFormsConfigurationSettings service from Sitecore’s configuration as I am adding it back in to the Sitecore IoC container with my own via the configurator above.

After deploying everything, I waited for my Sitecore instance to reload.


Once Sitecore was responsive again, I navigated to “Forms” on the Sitecore Launch Pad and made sure everything had still worked as before.

It did.

Trust me, it did. πŸ˜‰

living-in-db

If you have any questions/comments on any of the above, or would just like to drop a line to say “hello”, then please share in a comment below.

Otherwise, until next time, keep on Sitecoring.

Encrypt Sitecore Experience Forms Data in Powerful Ways

Last week, I was honoured to co-present Sitecore Experience Forms alongside my dear friend — and fellow trollster πŸ˜‰ — Sitecore MVP Kamruz Jaman at SUGCON EU 2018. We had a blast showing the ins and outs of Experience Forms, and of course trolled a bit whilst on the main stage.

During our talk, Kamruz had mentioned the possibility of replacing the “Out of the Box” (OOTB) Sitecore.ExperienceForms.Data.IFormDataProvider — this lives in Sitecore.ExperienceForms.dll — whose class implementations serve as Repository objects for storing or retrieving from some datastore (in Experience Forms this is MS SQL Server OOTB) with another to encrypt/decrypt data when saving to or retrieving from the datastore.

Well, I had done something exactly like this for Web Forms for Marketers (WFFM) about five years ago — be sure to have a read my blog post on this before proceeding as it gives context to the rest of this blog post — so thought it would be appropriate for me to have a swing at doing this for Experience Forms.

I first created an interface for classes that will encrypt/decrypt strings — this is virtually the same interface I had used in my older post on encrypting data in WFFM:

namespace Sandbox.Foundation.Forms.Services.Encryption
{
	public interface IEncryptor
	{
		string Encrypt(string key, string input);

		string Decrypt(string key, string input);
	}
}

I then created a class to encrypt/decrypt strings using the RC2 encryption algorithm — I had also poached this from my older post on encrypting data in WFFM (please note, this encryption algorithm is not the most robust so do not use this in any production environment. Please be sure to use something more robust):

using System.Text;
using System.Security.Cryptography;

namespace Sandbox.Foundation.Forms.Services.Encryption
{
	public class RC2Encryptor : IEncryptor
	{
		public string Encrypt(string key, string input)
		{
			byte[] inputArray = UTF8Encoding.UTF8.GetBytes(input);
			RC2CryptoServiceProvider rc2 = new RC2CryptoServiceProvider();
			rc2.Key = UTF8Encoding.UTF8.GetBytes(key);
			rc2.Mode = CipherMode.ECB;
			rc2.Padding = PaddingMode.PKCS7;
			ICryptoTransform cTransform = rc2.CreateEncryptor();
			byte[] resultArray = cTransform.TransformFinalBlock(inputArray, 0, inputArray.Length);
			rc2.Clear();
			return System.Convert.ToBase64String(resultArray, 0, resultArray.Length);
		}

		public string Decrypt(string key, string input)
		{
			byte[] inputArray = System.Convert.FromBase64String(input);
			RC2CryptoServiceProvider rc2 = new RC2CryptoServiceProvider();
			rc2.Key = UTF8Encoding.UTF8.GetBytes(key);
			rc2.Mode = CipherMode.ECB;
			rc2.Padding = PaddingMode.PKCS7;
			ICryptoTransform cTransform = rc2.CreateDecryptor();
			byte[] resultArray = cTransform.TransformFinalBlock(inputArray, 0, inputArray.Length);
			rc2.Clear();
			return UTF8Encoding.UTF8.GetString(resultArray);
		}
	}
}

Next, I created the following class to store settings I need for encrypting and decrypting data using the RC2 algorithm class above:

namespace Sandbox.Foundation.Forms.Models
{
	public class FormEncryptionSettings
	{
		public string EncryptionKey { get; set; }
	}
}

The encryption key above is needed for the RC2 algorithm to encrypt/decrypt data. I set this key in a config object defined in a Sitecore patch configuration file towards the bottom of this post.

I then created an interface for classes that will encrypt/decrypt FormEntry instances (FormEntry objects contain submitted data from form submissions):

using Sitecore.ExperienceForms.Data.Entities;

namespace Sandbox.Foundation.Forms.Services.Encryption
{
	public interface IFormEntryEncryptor
	{
		void EncryptFormEntry(FormEntry entry);

		void DecryptFormEntry(FormEntry entry);
	}
}

The following class implements the interface above:

using System.Linq;

using Sitecore.ExperienceForms.Data.Entities;

using Sandbox.Foundation.Forms.Models;

namespace Sandbox.Foundation.Forms.Services.Encryption
{
	public class FormEntryEncryptor : IFormEntryEncryptor
	{
		private readonly FormEncryptionSettings _formEncryptionSettings;
		private readonly IEncryptor _encryptor;

		public FormEntryEncryptor(FormEncryptionSettings formEncryptionSettings, IEncryptor encryptor)
		{
			_formEncryptionSettings = formEncryptionSettings;
			_encryptor = encryptor;
		}

		public void EncryptFormEntry(FormEntry entry)
		{
			if (!HasFields(entry))
			{
				return;
			}

			foreach (FieldData field in entry.Fields)
			{
				EncryptField(field);
			}
		}

		protected virtual void EncryptField(FieldData field)
		{
			if(field == null)
			{
				return;
			}

			field.FieldName = Encrypt(field.FieldName);
			field.Value = Encrypt(field.Value);
			field.ValueType = Encrypt(field.ValueType);
		}

		protected virtual string Encrypt(string input)
		{
			return _encryptor.Encrypt(_formEncryptionSettings.EncryptionKey, input);
		}

		public void DecryptFormEntry(FormEntry entry)
		{
			if (!HasFields(entry))
			{
				return;
			}

			foreach (FieldData field in entry.Fields)
			{
				DecryptField(field);
			}
		}

		protected virtual bool HasFields(FormEntry entry)
		{
			return entry != null
					&& entry.Fields != null
					&& entry.Fields.Any();
		}

		protected virtual void DecryptField(FieldData field)
		{
			if(field == null)
			{
				return;
			}

			field.FieldName = Decrypt(field.FieldName);
			field.Value = Decrypt(field.Value);
			field.ValueType = Decrypt(field.ValueType);
		}

		protected virtual string Decrypt(string input)
		{
			return _encryptor.Decrypt(_formEncryptionSettings.EncryptionKey, input);
		}
	}
}

The EncryptFormEntry() method above iterates over all FieldData objects contained on the FormEntry instance, and passes them to the EncryptField() mehod which encrypts the FieldName, Value and ValueType properties on them.

Likewise, the DecryptFormEntry() method iterates over all FieldData objects contained on the FormEntry instance, and passes them to the DecryptField() mehod which decrypts the same properties mentioned above.

I then created an interface for classes that will serve as factories for IFormDataProvider instances:

using Sitecore.ExperienceForms.Data;
using Sitecore.ExperienceForms.Data.SqlServer;

namespace Sandbox.Foundation.Forms.Services.Factories
{
	public interface IFormDataProviderFactory
	{
		IFormDataProvider CreateNewSqlFormDataProvider(ISqlDataApiFactory sqlDataApiFactory);
	}
}

The following class implements the interface above:

using Sitecore.ExperienceForms.Data;
using Sitecore.ExperienceForms.Data.SqlServer;

namespace Sandbox.Foundation.Forms.Services.Factories
{
	public class FormDataProviderFactory : IFormDataProviderFactory
	{
		public IFormDataProvider CreateNewSqlFormDataProvider(ISqlDataApiFactory sqlDataApiFactory)
		{
			return new SqlFormDataProvider(sqlDataApiFactory);
		}
	}
}

The CreateNewSqlFormDataProvider() method above does exactly was the method name says. You’ll see it being used in the following class below.

This next class ultimately becomes the new IFormDataProvider instance but decorates the OOTB one which is created from the factory class above:

using System;
using System.Collections.Generic;
using System.Linq;


using Sitecore.ExperienceForms.Data;
using Sitecore.ExperienceForms.Data.Entities;
using Sitecore.ExperienceForms.Data.SqlServer;

using Sandbox.Foundation.Forms.Services.Encryption;
using Sandbox.Foundation.Forms.Services.Factories;

namespace Sandbox.Foundation.Forms.Services.Data
{
	public class FormEncryptionDataProvider : IFormDataProvider
	{
		private readonly IFormDataProvider _innerProvider;
		private readonly IFormEntryEncryptor _formEntryEncryptor;

		public FormEncryptionDataProvider(ISqlDataApiFactory sqlDataApiFactory, IFormDataProviderFactory formDataProviderFactory, IFormEntryEncryptor formEntryEncryptor)
		{
			_innerProvider = CreateInnerProvider(sqlDataApiFactory, formDataProviderFactory);
			_formEntryEncryptor = formEntryEncryptor;
		}

		protected virtual IFormDataProvider CreateInnerProvider(ISqlDataApiFactory sqlDataApiFactory, IFormDataProviderFactory formDataProviderFactory)
		{
			return formDataProviderFactory.CreateNewSqlFormDataProvider(sqlDataApiFactory);
		}

		public void CreateEntry(FormEntry entry)
		{
			EncryptFormEntryField(entry);
			_innerProvider.CreateEntry(entry);
		}

		protected virtual void EncryptFormEntryField(FormEntry entry)
		{
			_formEntryEncryptor.EncryptFormEntry(entry);
		}

		public void DeleteEntries(Guid formId)
		{
			_innerProvider.DeleteEntries(formId);
		}

		public IReadOnlyCollection<FormEntry> GetEntries(Guid formId, DateTime? startDate, DateTime? endDate)
		{
			IReadOnlyCollection<FormEntry>  entries = _innerProvider.GetEntries(formId, startDate, endDate);
			if(entries == null || !entries.Any())
			{
				return entries;
			}

			foreach(FormEntry entry in entries)
			{
				DecryptFormEntryField(entry);
			}

			return entries;
		}

		protected virtual void DecryptFormEntryField(FormEntry entry)
		{
			_formEntryEncryptor.DecryptFormEntry(entry);
		}
	}
}

The class above does delegation to the IFormEntryEncryptor instance to encrypt the FormEntry data and then passes the FormEntry to the inner provider for saving.

For decrypting, it retrieves the data from the inner provider, and then decrypts it via the IFormEntryEncryptor instance before returning to the caller.

Finally, I created an IServicesConfigurator class to wire everything up into the Sitecore container (I hope you are using Sitecore Dependency Injection capabilities as this comes OOTB — there are no excuses for not using this!!!!!!):

using System;

using Microsoft.Extensions.DependencyInjection;

using Sitecore.Abstractions;
using Sitecore.DependencyInjection;
using Sitecore.ExperienceForms.Data;

using Sandbox.Foundation.Forms.Models;
using Sandbox.Foundation.Forms.Services.Encryption;
using Sandbox.Foundation.Forms.Services.Data;
using Sandbox.Foundation.Forms.Services.Factories;

namespace Sandbox.Foundation.Forms
{
	public class FormsServicesConfigurator : IServicesConfigurator
	{
		public void Configure(IServiceCollection serviceCollection)
		{
			serviceCollection.AddSingleton(provider => GetFormEncryptionSettings(provider));
			serviceCollection.AddSingleton<IEncryptor, RC2Encryptor>();
			serviceCollection.AddSingleton<IFormEntryEncryptor, FormEntryEncryptor>();
			serviceCollection.AddSingleton<IFormDataProviderFactory, FormDataProviderFactory>();
			serviceCollection.AddSingleton<IFormDataProvider, FormEncryptionDataProvider>();
		}

		private FormEncryptionSettings GetFormEncryptionSettings(IServiceProvider provider)
		{
			return CreateConfigObject<FormEncryptionSettings>(provider, "moduleSettings/foundation/forms/formEncryptionSettings");
		}

		private TConfigObject CreateConfigObject<TConfigObject>(IServiceProvider provider, string path) where TConfigObject : class
		{
			BaseFactory factory = GetService<BaseFactory>(provider);
			return factory.CreateObject(path, true) as TConfigObject;
		}

		private TService GetService<TService>(IServiceProvider provider)
		{
			return provider.GetService<TService>();
		}
	}
}

Everything above is normal service class registration except for the stuff in the GetFormEncryptionSettings() method. Here, I’m creating an instance of a FormEncryptionSettings class but am instantiating it using the Sitecore Configuration Factory for the configuration object defined in the Sitecore patch configuration file below, and am making that available for being injected into classes that need it (the FormEntryEncryptor above uses it).

I then wired everything together using the following Sitecore patch configuration file:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/">
	<sitecore>
		<services>
			<configurator type="Sandbox.Foundation.Forms.FormsServicesConfigurator, Sandbox.Foundation.Forms" />
			<register serviceType="Sitecore.ExperienceForms.IFormDataProvider, Sitecore.ExperienceForms">
				<patch:delete />
			</register>
		</services>
		<moduleSettings>
			<foundation>
				<forms>
					<formEncryptionSettings type="Sandbox.Foundation.Forms.Models.FormEncryptionSettings, Sandbox.Foundation.Forms" singleInstance="true">
						<!-- I stole this from https://sitecorejunkie.com/2013/06/21/encrypt-web-forms-for-marketers-fields-in-sitecore/ -->
						<EncryptionKey>88bca90e90875a</EncryptionKey>
					</formEncryptionSettings>
				</forms>
			</foundation>
		</moduleSettings>
	</sitecore>
</configuration>

I want to call out that I’m deleting the OOTB IFormDataProvider above using a patch:delete. I’m re-adding it via the IServicesConfigurator above using the decorator class previously shown above.

Let’s take this for a spin.

I first created a new form (this is under “Forms” on the Sitecore Launchepad ):

I then put it on a page with an MVC Layout; published everything; navigated to the test page with the form created above; filled out the form; and then clicked the submit button:

Let’s see if the data was encrypted. I opened up SQL Server Management Studio and ran a query on the FormEntry table in my Experience Forms Database:

As you can see the data was encrypted.

Let’s export the data to make sure it gets decrypted. We can do that by exporting the data as a CSV from Forms in the Sitecore Launchpad:

As you can see the data is decrypted in the CSV:

I do want to mention that Sitecore MVP JoΓ£o Neto had provided two other methods for encrypting data in Experience Forms in a post he wrote last January. I recommend having a read of that.

Until next time, see you on the Sitecore Slack πŸ˜‰

Display How Many Bucketed Items Live Within a Sitecore Item Bucket Using a Custom DataView

Over the past few weeks — if you haven’t noticed — I’ve been having a blast experimenting with Sitecore Item Buckets. It seems new ideas on what to build for it keep flooding my thoughts everyday. πŸ˜€

However, the other day an old idea that I wanted to solve a while back bubbled its way up into the forefront of my consciousness: displaying the count of Bucketed Items which live within each Item Bucket in the Content Tree.

I’m sure someone has built something to do this before though I didn’t really do any research on it as I was up for the challenge.

darth-vader-didnt-read

In all honesty, I enjoy spending my nights after work and on weekends building things in Sitecore — even if someone has built something like it before — as it’s a great way to not only discover new treasures hidden within the Sitecore assemblies, but also improve my programming skills — the saying “you lose it if you don’t use it” applies here.

nerds

You might be asking “Mike, we don’t store that many Sitecore Items in our Item Buckets; I can just go count them all by hand”.

Well, if that’s the case for you then you might want to reconsider why you are using the Item Buckets feature.

However, in theory, thousands if not millions of Items can live within an Item Bucket in Sitecore. If counting by hand is your thing — or even writing some sort of “script” (I’m not referring to PowerShell scripts that you would write using Sitecore PowerShell Extensions (SPE) — I definitely recommend harnessing all of the power this module has to offer — but instead to standalone ASP.NET Web Forms which some people erroneously call “scripts”) to generate some kind of report, then by all means go for it.

counting

That’s just not how I roll.

aint-no-time-for-that

So how are we going to display these counts to the user? We are ultimately going to create a custom Sitecore DataView.

If you aren’t familiar with DataViews in Sitecore, they basically allow you to change how Items are displayed in the Sitecore Content Tree.

I’m not going to go too much into details of how these work. I recommend having a read of the following posts by two fellow Sitecore MVPs for more information and to see other examples:

I do want to warn you: there is a lot of code in this post.

arghhhhh

You might want to go get a snack for this as it might take a while to get through all the code that I am showing here. Don’t worry, I’ll wait for you to get back.

eat-popcorn

Anyways, let’s jump right into it.

partay-meow

For this feature, I want to add a checkbox toggle in the Sitecore Ribbon to give users the ability turn this feature on and off.

bucketed-items-count-view-ribbon

In order to save the state of this checkbox, I defined the following interface:

namespace Sitecore.Sandbox.Web.UI.HtmlControls.Registries
{
    public interface IRegistry
    {
        bool GetBool(string key);

        bool GetBool(string key, bool defaultvalue);

        int GetInt(string key);

        int GetInt(string key, int defaultvalue);

        string GetString(string key);

        string GetString(string key, string defaultvalue);

        string GetValue(string key);

        void SetBool(string key, bool val);

        void SetInt(string key, int val);

        void SetString(string key, string value);

        void SetValue(string key, string value);
    }
}

Classes of the above interface will keep track of settings which need to be stored somewhere.

The following class implements the interface above:

namespace Sitecore.Sandbox.Web.UI.HtmlControls.Registries
{
    public class Registry : IRegistry
    {
        public virtual bool GetBool(string key)
        {
            return Sitecore.Web.UI.HtmlControls.Registry.GetBool(key);
        }

        public virtual bool GetBool(string key, bool defaultvalue)
        {
            return Sitecore.Web.UI.HtmlControls.Registry.GetBool(key, defaultvalue);
        }

        public virtual int GetInt(string key)
        {
            return Sitecore.Web.UI.HtmlControls.Registry.GetInt(key);
        }

        public virtual int GetInt(string key, int defaultvalue)
        {
            return Sitecore.Web.UI.HtmlControls.Registry.GetInt(key, defaultvalue);
        }

        public virtual string GetString(string key)
        {
            return Sitecore.Web.UI.HtmlControls.Registry.GetString(key);
        }

        public virtual string GetString(string key, string defaultvalue)
        {
            return Sitecore.Web.UI.HtmlControls.Registry.GetString(key, defaultvalue);
        }

        public virtual string GetValue(string key)
        {
            return Sitecore.Web.UI.HtmlControls.Registry.GetValue(key);
        }

        public virtual void SetBool(string key, bool val)
        {
            Sitecore.Web.UI.HtmlControls.Registry.SetBool(key, val);
        }

        public virtual void SetInt(string key, int val)
        {
            Sitecore.Web.UI.HtmlControls.Registry.SetInt(key, val);
        }

        public virtual void SetString(string key, string value)
        {
            Sitecore.Web.UI.HtmlControls.Registry.SetString(key, value);
        }

        public virtual void SetValue(string key, string value)
        {
            Sitecore.Web.UI.HtmlControls.Registry.SetValue(key, value);
        }
    }
}

I’m basically wrapping calls to methods on the static Sitecore.Web.UI.HtmlControls.Registry class which is used for saving state on the checkboxes in the Sitecore ribbon — it might be used for keeping track of other things in the Sitecore Content Editor though that is beyond the scope of this post. Nothing magical going on here.

I then defined the following interface for keeping track of Content Editor settings for things related to Item Buckets:

namespace Sitecore.Sandbox.Buckets.Settings
{
    public interface IBucketsContentEditorSettings
    {
        bool ShowBucketedItemsCount { get; set; }

        bool AreItemBucketsEnabled { get; }
    }
}

The ShowBucketedItemsCount boolean property lets the caller know if we are to show the Bucketed Items count, and the AreItemBucketsEnabled boolean property lets the caller know if the Item Buckets feature is enabled in Sitecore.

The following class implements the interface above:

using Sitecore.Diagnostics;

using Sitecore.Sandbox.Determiners.Features;
using Sitecore.Sandbox.Web.UI.HtmlControls.Registries;

namespace Sitecore.Sandbox.Buckets.Settings
{
    public class BucketsContentEditorSettings : IBucketsContentEditorSettings
    {
        protected IFeatureDeterminer ItemBucketsFeatureDeterminer { get; set; }

        protected IRegistry Registry { get; set; }

        protected string ShowBucketedItemsCountRegistryKey { get; set; }

        public bool ShowBucketedItemsCount
        {
            get
            {
                return ShouldShowBucketedItemsCount();
            }
            set
            {
                ToggleShowBucketedItemsCount(value);
            }
        }

        public bool AreItemBucketsEnabled
        {
            get
            {
                return GetAreItemBucketsEnabled();
            }
        }

        protected virtual bool ShouldShowBucketedItemsCount()
        {
            if (!AreItemBucketsEnabled)
            {
                return false;
            }

            EnsureRegistryDependencies();
            return Registry.GetBool(ShowBucketedItemsCountRegistryKey, false);
        }

        protected virtual void ToggleShowBucketedItemsCount(bool turnOn)
        {

            if (!AreItemBucketsEnabled)
            {
                return;
            }

            EnsureRegistryDependencies();
            Registry.SetBool(ShowBucketedItemsCountRegistryKey, turnOn);
        }

        protected virtual void EnsureRegistryDependencies()
        {
            Assert.IsNotNull(Registry, "Registry must be defined in configuration!");
            Assert.IsNotNullOrEmpty(ShowBucketedItemsCountRegistryKey, "ShowBucketedItemsCountRegistryKey must be defined in configuration!");
        }

        protected virtual bool GetAreItemBucketsEnabled()
        {
            Assert.IsNotNull(ItemBucketsFeatureDeterminer, "ItemBucketsFeatureDeterminer must be defined in configuration!");
            return ItemBucketsFeatureDeterminer.IsEnabled();
        }
    }
}

I’m injecting an IFeatureDeterminer instance into the instance of the class above via the Sitecore Configuration Factory — have a look at the patch configuration file further down in this post — specifically the ItemBucketsFeatureDeterminer which is defined in a previous blog post. The IFeatureDeterminer instance determines whether the Item Buckets feature is turned on/off (I’m not going to repost that code here so if you haven’t seen this code, please go have a look now so you have an understanding of what it’s doing).

Its instance is used in the GetAreItemBucketsEnabled() method which just delegates to its IsEnabled() method and returns the value from that call. The GetAreItemBucketsEnabled() method is used in the get accessor of the AreItemBucketsEnabled property.

I’m also injecting an IRegistry instance into the instance of the class above — this is also defined in the patch configuration file further down — which is used for storing/retrieving the value of the ShowBucketedItemsCount property.

It is leveraged in the ShouldShowBucketedItemsCount() and ToggleShowBucketedItemsCount() methods where a boolean value is saved or retrieved, respectively, in the Sitecore Registry under a certain key — this key is also injected into the ShowBucketedItemsCountRegistryKey property via the Sitecore Configuration Factory.

So, we now have a way to keep track of whether we should display the Bucketed Items count. We just need a way to let the user turn this on/off. To do that, I need to create a custom Sitecore.Shell.Framework.Commands.Command.

Since Sitecore Commands are instantiated by the CreateObject() method on the MainUtil class (this lives in the Sitecore namespace in Sitecore.Kernel.dll and isn’t as advanced as the Sitecore.Configuration.Factory class as it won’t instantiate nested objects defined in configuration as does the Sitecore Configuration Factory), I built the following Command which will decorate Commands defined in Sitecore configuration:

using System.Xml;

using Sitecore.Configuration;
using Sitecore.Diagnostics;
using Sitecore.Shell.Framework.Commands;
using Sitecore.Web.UI.HtmlControls;
using Sitecore.Xml;

namespace Sitecore.Sandbox.Shell.Framework.Commands
{
    public class ExtendedConfigCommand : Command
    {
        private Command command;
        protected Command Command
        {
            get
            {
                if(command == null)
                {
                    command = GetCommand();
                    EnsureCommand();
                }

                return command;
            }
        }

        protected virtual Command GetCommand()
        {
            XmlNode currentCommandNode = Factory.GetConfigNode(string.Format("commands/command[@name='{0}']", Name));
            string configPath = XmlUtil.GetAttribute("extendedCommandPath", currentCommandNode);
            Assert.IsNotNullOrEmpty(configPath, string.Format("The extendedCommandPath attribute must be set {0}!", currentCommandNode));
            Command command = Factory.CreateObject(configPath, false) as Command;
            Assert.IsNotNull(command, string.Format("The command defined at '{0}' was either not properly set or is not an instance of Sitecore.Shell.Framework.Commands.Command. Double-check it!", configPath));
            return command;
        }

        protected virtual void EnsureCommand()
        {
            Assert.IsNotNull(Command, "GetCommand() cannot return a null Sitecore.Shell.Framework.Commands.Command instance!");
        }

        public override void Execute(CommandContext context)
        {
            Command.Execute(context);
        }

        public override string GetClick(CommandContext context, string click)
        {
            return Command.GetClick(context, click);
        }

        public override string GetHeader(CommandContext context, string header)
        {
            return Command.GetHeader(context, header);
        }

        public override string GetIcon(CommandContext context, string icon)
        {
            return Command.GetIcon(context, icon);
        }

        public override Control[] GetSubmenuItems(CommandContext context)
        {
            return Command.GetSubmenuItems(context);
        }

        public override string GetToolTip(CommandContext context, string tooltip)
        {
            return Command.GetToolTip(context, tooltip);
        }

        public override string GetValue(CommandContext context, string value)
        {
            return Command.GetValue(context, value);
        }

        public override CommandState QueryState(CommandContext context)
        {
            return Command.QueryState(context);
        }
    }
}

The GetCommand() method reads the XmlNode for the current command, and gets the value set on its extendedCommandPath attribute. This value must to be a config path defined under the <sitecore> element in Sitecore configuration.

If the attribute doesn’t exist or is empty, or a Command instance isn’t properly created, an exception is thrown.

Otherwise, it is set on the Command property on the class.

All methods here delegate to the same methods on the Command stored in the Command property.

I then defined the following Command which will be used by the checkbox we are adding to the Sitecore Ribbon:

using Sitecore.Diagnostics;
using Sitecore.Shell.Framework.Commands;
using Sitecore.Web.UI.Sheer;

using Sitecore.Sandbox.Buckets.Settings;

namespace Sitecore.Sandbox.Buckets.Shell.Framework.Commands
{
    public class ToggleBucketedItemsCountCommand : Command
    {
        protected IBucketsContentEditorSettings BucketsContentEditorSettings { get; set; }

        public override void Execute(CommandContext context)
        {
            if (!AreItemBucketsEnabled())
            {
                return;
            }

            ToggleShowBucketedItemsCount();
            Reload();
        }

        protected virtual void ToggleShowBucketedItemsCount()
        {
            Assert.IsNotNull(BucketsContentEditorSettings, "BucketsContentEditorSettings must be defined in configuration!");
            BucketsContentEditorSettings.ShowBucketedItemsCount = !BucketsContentEditorSettings.ShowBucketedItemsCount;
        }

        protected virtual void Reload()
        {
            SheerResponse.SetLocation(string.Empty);
        }

        public override CommandState QueryState(CommandContext context)
        {
            if(!AreItemBucketsEnabled())
            {
                return CommandState.Hidden;
            }

            if(!ShouldShowBucketedItemsCount())
            {
                return CommandState.Enabled;
            }

            return CommandState.Down;
        }

        protected virtual bool AreItemBucketsEnabled()
        {
            Assert.IsNotNull(BucketsContentEditorSettings, "BucketsContentEditorSettings must be defined in configuration!");
            return BucketsContentEditorSettings.AreItemBucketsEnabled;
        }

        protected virtual bool ShouldShowBucketedItemsCount()
        {
            Assert.IsNotNull(BucketsContentEditorSettings, "BucketsContentEditorSettings must be defined in configuration!");
            return BucketsContentEditorSettings.ShowBucketedItemsCount;
        }
    }
}

The QueryState() method determines whether we should display the checkbox — it will only be displayed if the Item Buckets feature is on — and what the state of the checkbox should be — if we are currently showing Bucketed Items count, the checkbox will be checked (this is represented by CommandState.Down). Otherwise, it will be unchecked (this is represented by CommandState.Enabled).

The Execute() method encapsulates the logic of what we are to do when the user checks/unchecks the checkbox. It’s basically delegating to the ToggleShowBucketedItemsCount() method to toggle the value of whether we are to display the Bucketed Items count, and then reloads the Content Editor to refresh the display in the Content Tree.

I then had to define this checkbox in the Core database:

bucketed-items-count-checkbox-core

I’m not going to go into details of how the above works as I’ve written over a gazillion posts on the subject. I recommend having a read of one of these older posts.

After going back to my Master database, I saw the new checkbox in the Sitecore Ribbon:

buckted-items-count-new-checkbox

Since we could be dealing with thousands — if not millions — of Bucketed Items for each Item Bucket, we need a performant way to grab the count of these Items. In this solution, I am leveraging the Sitecore.ContentSearch API to get these counts though needed to add some custom
Computed Index Field classes:

using Sitecore.Buckets.Managers;
using Sitecore.Configuration;
using Sitecore.ContentSearch;
using Sitecore.ContentSearch.ComputedFields;
using Sitecore.Data.Items;
using Sitecore.Diagnostics;

using Sitecore.Sandbox.Buckets.Util.Methods;

namespace Sitecore.Sandbox.Buckets.ContentSearch.ComputedFields
{
    public class IsBucketed : AbstractComputedIndexField
    {
        protected IItemBucketsFeatureMethods ItemBucketsFeatureMethods { get; private set; }

        public IsBucketed()
        {
            ItemBucketsFeatureMethods = GetItemBucketsFeatureMethods();
            Assert.IsNotNull(ItemBucketsFeatureMethods, "GetItemBucketsFeatureMethods() cannot return null!");
        }

        protected virtual IItemBucketsFeatureMethods GetItemBucketsFeatureMethods()
        {
            IItemBucketsFeatureMethods methods = Factory.CreateObject("buckets/methods/itemBucketsFeatureMethods", false) as IItemBucketsFeatureMethods;
            Assert.IsNotNull(methods, "the IItemBucketsFeatureMethods instance was not defined properly in /sitecore/buckets/methods/itemBucketsFeatureMethods!");
            return methods;
        }

        public override object ComputeFieldValue(IIndexable indexable)
        {
            Item item = indexable as SitecoreIndexableItem;
            if (item == null)
            {
                return null;
            }


            return IsBucketable(item) && IsItemContainedWithinBucket(item);
        }

        protected virtual bool IsBucketable(Item item)
        {
            Assert.ArgumentNotNull(item, "item");
            return BucketManager.IsBucketable(item);
        }

        protected virtual bool IsItemContainedWithinBucket(Item item)
        {
            Assert.ArgumentNotNull(item, "item");
            if(IsItemBucket(item))
            {
                return false;
            }

            return ItemBucketsFeatureMethods.IsItemContainedWithinBucket(item);
        }

        protected virtual bool IsItemBucket(Item item)
        {
            Assert.ArgumentNotNull(item, "item");
            if (!ItemBucketsFeatureMethods.IsItemBucket(item))
            {
                return false;
            }

            return true;
        }
    }
}

An instance of the class above ultimately determines if an Item is bucketed within an Item Bucket, and passes a boolean value to its caller denoting this via its ComputeFieldValue() method.

What determines whether an Item is bucketed? The code above says it’s bucketed only when the Item is bucketable and is contained within an Item Bucket.

The IsBucketable() method above ascertains whether the Item is bucketable by delegating to the IsBucketable() method on the BucketManager class in Sitecore.Buckets.dll.

The IsItemContainedWithinBucket() method determines if the Item is contained within an Item Bucket — you might be laughing as the name on the method is self-documenting — by delegating to the IsItemContainedWithinBucket() method on the IItemBucketsFeatureMethods instance — I’ve defined the code for this in this post so go have a look.

Moreover, the code does not consider Item Buckets to be Bucketed as that just doesn’t make much sense. πŸ˜‰ This would also give us an inaccurate count.

The following Computed Index Field’s ComputeFieldValue() method returns the string representation of the ancestor Item Bucket’s Sitecore.Data.ID for the Item — if it is contained within an Item Bucket:

using Sitecore.Configuration;
using Sitecore.ContentSearch;
using Sitecore.ContentSearch.ComputedFields;
using Sitecore.ContentSearch.Utilities;
using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Diagnostics;

using Sitecore.Sandbox.Buckets.Util.Methods;

namespace Sitecore.Sandbox.Buckets.ContentSearch.ComputedFields
{
    public class ItemBucketAncestorId : AbstractComputedIndexField
    {
        protected IItemBucketsFeatureMethods ItemBucketsFeatureMethods { get; private set; }

        public ItemBucketAncestorId()
        {
            ItemBucketsFeatureMethods = GetItemBucketsFeatureMethods();
            Assert.IsNotNull(ItemBucketsFeatureMethods, "GetItemBucketsFeatureMethods() cannot return null!");
        }

        protected virtual IItemBucketsFeatureMethods GetItemBucketsFeatureMethods()
        {
            IItemBucketsFeatureMethods methods = Factory.CreateObject("buckets/methods/itemBucketsFeatureMethods", false) as IItemBucketsFeatureMethods;
            Assert.IsNotNull(methods, "the IItemBucketsFeatureMethods instance was not defined properly in /sitecore/buckets/methods/itemBucketsFeatureMethods!");
            return methods;
        }

        public override object ComputeFieldValue(IIndexable indexable)
        {
            Item item = indexable as SitecoreIndexableItem;
            if (item == null)
            {
                return null;
            }

            Item itemBucketAncestor = GetItemBucketAncestor(item);
            if(itemBucketAncestor == null)
            {

                return null;
            }

            return NormalizeGuid(itemBucketAncestor.ID);
        }

        protected virtual Item GetItemBucketAncestor(Item item)
        {
            Assert.ArgumentNotNull(item, "item");
            if(IsItemBucket(item))
            {
                return null;
            }

            Item itemBucket = ItemBucketsFeatureMethods.GetItemBucket(item);
            if(!IsItemBucket(itemBucket))
            {
                return null;
            }

            return itemBucket;
        }

        protected virtual bool IsItemBucket(Item item)
        {
            Assert.ArgumentNotNull(item, "item");
            if (!ItemBucketsFeatureMethods.IsItemBucket(item))
            {
                return false;
            }

            return true;
        }

        protected virtual string NormalizeGuid(ID id)
        {
            return IdHelper.NormalizeGuid(id);
        }
    }
}

Not to go too much into details of the class above, it will only return an Item Bucket’s Sitecore.Data.ID as a string if the Item lives within an Item Bucket and is not itself an Item Bucket.

If the Item is not within an Item Bucket or is an Item Bucket, null is returned to the caller via the ComputeFieldValue() method.

I then created the following subclass of Sitecore.ContentSearch.SearchTypes.SearchResultItem — this lives in Sitecore.ContentSearch.dll — in order to use the values in the index that the previous Computed Field Index classes returned for their storage in the search index:

using System.ComponentModel;

using Sitecore.ContentSearch;
using Sitecore.ContentSearch.Converters;
using Sitecore.ContentSearch.SearchTypes;
using Sitecore.Data;

namespace Sitecore.Sandbox.Buckets.ContentSearch.SearchTypes
{
    public class BucketedSearchResultItem : SearchResultItem
    {
        [IndexField("item_bucket_ancestor_id")]
        [TypeConverter(typeof(IndexFieldIDValueConverter))]
        public ID ItemBucketAncestorId { get; set; }

        [IndexField("is_bucketed")]
        public bool IsBucketed { get; set; }
    }
}

Now, we need a class to get the Bucketed Item count for an Item Bucket. I defined the following interface for class implementations that do just that:

using Sitecore.Data.Items;

namespace Sitecore.Sandbox.Buckets.Providers.Items
{
    public interface IBucketedItemsCountProvider
    {
        int GetBucketedItemsCount(Item itemBucket);
    }
}

I then created the following class that implements the interface above:

using System;
using System.Collections.Generic;
using System.Linq;
using System.Linq.Expressions;
using System.Xml;

using Sitecore.Configuration;
using Sitecore.ContentSearch;
using Sitecore.ContentSearch.Linq;
using Sitecore.ContentSearch.Linq.Utilities;
using Sitecore.ContentSearch.SearchTypes;
using Sitecore.ContentSearch.Utilities;
using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Diagnostics;
using Sitecore.Xml;

using Sitecore.Sandbox.Buckets.ContentSearch.SearchTypes;

namespace Sitecore.Sandbox.Buckets.Providers.Items
{
    public class BucketedItemsCountProvider : IBucketedItemsCountProvider
    {
        protected IDictionary<string, ISearchIndex> SearchIndexMap { get; private set; }

        public BucketedItemsCountProvider()
        {
            SearchIndexMap = CreateNewSearchIndexMap();
        }

        protected virtual IDictionary<string, ISearchIndex> CreateNewSearchIndexMap()
        {
            return new Dictionary<string, ISearchIndex>();
        }

        protected virtual void AddSearchIndexMap(XmlNode configNode)
        {
            if(configNode == null)
            {
                return;
            }

            string databaseName = XmlUtil.GetAttribute("database", configNode, null);
            Assert.IsNotNullOrEmpty(databaseName, "The database attribute on the searchIndexMap configuration element cannot be null or the empty string!");
            Assert.ArgumentCondition(!SearchIndexMap.ContainsKey(databaseName), "database", "The searchIndexMap configuration element's database attribute values must be unique!");

            Database database = Factory.GetDatabase(databaseName);
            Assert.IsNotNull(database, string.Format("No database exists with the name of '{0}'! Make sure the database attribute on your searchIndexMap configuration element is set correctly!", databaseName));

            string searchIndexName = XmlUtil.GetAttribute("searchIndex", configNode, null);
            Assert.IsNotNullOrEmpty(searchIndexName, "The searchIndex attribute on the searchIndexMap configuration element cannot be null or the empty string!");

            ISearchIndex searchIndex = GetSearchIndex(searchIndexName);
            Assert.IsNotNull(searchIndex, string.Format("No search index exists with the name of '{0}'! Make sure the searchIndex attribute on your searchIndexMap configuration element is set correctly", searchIndexName));

            SearchIndexMap.Add(databaseName, searchIndex);
        }

        public virtual int GetBucketedItemsCount(Item bucketItem)
        {
            Assert.ArgumentNotNull(bucketItem, "bucketItem");

            ISearchIndex searchIndex = GetSearchIndex();
            using (IProviderSearchContext searchContext = searchIndex.CreateSearchContext())
            {
                var predicate = GetSearchPredicate<BucketedSearchResultItem>(bucketItem.ID);
                IQueryable<SearchResultItem> query = searchContext.GetQueryable<BucketedSearchResultItem>().Filter(predicate);
                SearchResults<SearchResultItem> results = query.GetResults();
                return results.Count();
            }
        }

        protected virtual ISearchIndex GetSearchIndex()
        {
            string databaseName = GetContentDatabaseName();
            Assert.IsNotNullOrEmpty(databaseName, "The GetContentDatabaseName() method cannot return null or the empty string!");
            Assert.ArgumentCondition(SearchIndexMap.ContainsKey(databaseName), "databaseName", string.Format("There is no ISearchIndex instance mapped to the database: '{0}'!", databaseName));
            return SearchIndexMap[databaseName];
        }

        protected virtual string GetContentDatabaseName()
        {
            Database database = Context.ContentDatabase ?? Context.Database;
            Assert.IsNotNull(database, "Argggggh! There's no content database! Houston, we have a problem!");
            return database.Name;
        }

        protected virtual ISearchIndex GetSearchIndex(string searchIndexName)
        {
            Assert.ArgumentNotNullOrEmpty(searchIndexName, "searchIndexName");
            return ContentSearchManager.GetIndex(searchIndexName);
        }

        protected virtual Expression<Func<TSearchResultItem, bool>> GetSearchPredicate<TSearchResultItem>(ID itemBucketId) where TSearchResultItem : BucketedSearchResultItem
        {
            Assert.ArgumentCondition(!ID.IsNullOrEmpty(itemBucketId), "itemBucketId", "itemBucketId cannot be null or empty!");
            var predicate = PredicateBuilder.True<TSearchResultItem>();
            predicate = predicate.And(item => item.ItemBucketAncestorId == itemBucketId);
            predicate = predicate.And(item => item.IsBucketed);
            return predicate;
        }
    }
}

Ok, so what’s going on in the class above? The AddSearchIndexMap() method is called by the Sitecore Configuration Factory to add database-to-search-index mappings — have a look at the patch configuration file further below. The code is looking up the appropriate search index for the content/context database.

The GetBucketedItemsCount() method gets the “predicate” from the GetSearchPredicate() method which basically says “Hey, I want an Item that has an ancestor Item Bucket Sitecore.Data.ID which is the same as the Sitecore.Data.ID passed to the method, and also this Item should be bucketed”.

The GetBucketedItemsCount() method then employs the Sitecore.ContentSearch API to get the result-set of the Items for the query, and returns the count of those Items.

Just as Commands, DataViews in Sitecore are instantiated by the CreateObject() method on MainUtil. I want to utilize the Sitecore Configuration Factory instead so that my nested configuration elements are instantiated and injected into my custom DataView. I built the following interface to make that possible:

using System.Collections;

using Sitecore.Collections;
using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Globalization;

namespace Sitecore.Sandbox.Web.UI.HtmlControls.DataViews
{
    public interface IDataViewBaseExtender
    {
        void FilterItems(ref ArrayList children, string filter);

        void GetChildItems(ItemCollection items, Item item);

        Database GetDatabase();

        Item GetItemFromID(string id, Language language, Version version);

        Item GetParentItem(Item item);

        bool HasChildren(Item item, string filter);

        void Initialize(string parameters);

        bool IsAncestorOf(Item ancestor, Item item);

        void SortItems(ArrayList children, string sortBy, bool sortAscending);
    }
}

All of the methods in the above interface correspond to virtual methods defined on the Sitecore.Web.UI.HtmlControl.DataViewBase class in Sitecore.Kernel.dll.

I then built the following abstract class which inherits from any DataView class that inherits from Sitecore.Web.UI.HtmlControl.DataViewBase:

using System.Collections;

using Sitecore.Collections;
using Sitecore.Configuration;
using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Diagnostics;
using Sitecore.Globalization;
using Sitecore.Web.UI.HtmlControls;

namespace Sitecore.Sandbox.Web.UI.HtmlControls.DataViews
{
    public abstract class ExtendedDataView<TDataView> : DataViewBase where TDataView : DataViewBase
    {
        protected IDataViewBaseExtender DataViewBaseExtender { get; private set; }

        protected ExtendedDataView()
        {
            DataViewBaseExtender = GetDataViewBaseExtender();
            EnsureDataViewBaseExtender();
        }

        protected virtual IDataViewBaseExtender GetDataViewBaseExtender()
        {
            string configPath = GetDataViewBaseExtenderConfigPath();
            Assert.IsNotNullOrEmpty(configPath, "GetDataViewBaseExtenderConfigPath() cannot return null or the empty string!");
            IDataViewBaseExtender dataViewBaseExtender = Factory.CreateObject(configPath, false) as IDataViewBaseExtender;
            Assert.IsNotNull(dataViewBaseExtender, string.Format("the IDataViewBaseExtender instance was not defined properly in '{0}'!", configPath));
            return dataViewBaseExtender;
        }

        protected abstract string GetDataViewBaseExtenderConfigPath();

        protected virtual void EnsureDataViewBaseExtender()
        {
            Assert.IsNotNull(DataViewBaseExtender, "GetDataViewBaseExtender() cannot return a null IDataViewBaseExtender instance!");
        }

        protected override void FilterItems(ref ArrayList children, string filter)
        {
            DataViewBaseExtender.FilterItems(ref children, filter);
        }

        protected override void GetChildItems(ItemCollection items, Item item)
        {
            DataViewBaseExtender.GetChildItems(items, item);
        }

        public override Database GetDatabase()
        {
            return DataViewBaseExtender.GetDatabase();
        }

        protected override Item GetItemFromID(string id, Language language, Version version)
        {
            return DataViewBaseExtender.GetItemFromID(id, language, version);
        }

        protected override Item GetParentItem(Item item)
        {
            return DataViewBaseExtender.GetParentItem(item);
        }

        public override bool HasChildren(Item item, string filter)
        {
            return DataViewBaseExtender.HasChildren(item, filter);
        }

        public override void Initialize(string parameters)
        {
            DataViewBaseExtender.Initialize(parameters);
        }

        public override bool IsAncestorOf(Item ancestor, Item item)
        {
            return DataViewBaseExtender.IsAncestorOf(ancestor, item);
        }

        protected override void SortItems(ArrayList children, string sortBy, bool sortAscending)
        {
            DataViewBaseExtender.SortItems(children, sortBy, sortAscending);
        }
    }
}

The GetDataViewBaseExtender() method gets the config path for the configuration-defined IDataViewBaseExtender — these IDataViewBaseExtender configuration definitions may or may not have nested configuration elements which will also be instantiated by the Sitecore Configuration Factory — from the abstract GetDataViewBaseExtenderConfigPath() method (subclasses must define this method).

The GetDataViewBaseExtender() then employs the Sitecore Configuration Factory to create this IDataViewBaseExtender instance, and return it to the caller (it’s being called in the class’ constructor).

If the instance is null, an exception is thrown.

All other methods in the above class delegate to methods with the same name and parameters on the IDataViewBaseExtender instance.

I then built the following subclass of the abstract class above:

using Sitecore.Web.UI.HtmlControls;

namespace Sitecore.Sandbox.Web.UI.HtmlControls.DataViews
{
    public class ExtendedMasterDataView : ExtendedDataView<MasterDataView>
    {
        protected override string GetDataViewBaseExtenderConfigPath()
        {
            return "extendedDataViews/extendedMasterDataView";
        }
    }
}

The above class is used for extending the MasterDataView in Sitecore.

It’s now time for the “real deal” DataView that does what we want: show the Bucketed Item counts for Item Buckets. The instance of the following class does just that:

using System.Collections;

using Sitecore.Buckets.Forms;
using Sitecore.Collections;
using Sitecore.Data;
using Sitecore.Data.Fields;
using Sitecore.Data.Items;
using Sitecore.Diagnostics;
using Sitecore.Globalization;

using Sitecore.Sandbox.Buckets.Providers.Items;
using Sitecore.Sandbox.Buckets.Settings;
using Sitecore.Sandbox.Buckets.Util.Methods;
using Sitecore.Sandbox.Web.UI.HtmlControls.DataViews;

namespace Sitecore.Sandbox.Buckets.Forms
{
    public class BucketedItemsCountDataView : BucketDataView, IDataViewBaseExtender
    {
        protected IBucketsContentEditorSettings BucketsContentEditorSettings { get; set; }

        protected IItemBucketsFeatureMethods ItemBucketsFeatureMethods { get; set; }

        protected IBucketedItemsCountProvider BucketedItemsCountProvider { get; set; }

        protected string SingularBucketedItemsDisplayNameFormat { get; set; }

        protected string PluralBucketedItemsDisplayNameFormat { get; set; }

        void IDataViewBaseExtender.FilterItems(ref ArrayList children, string filter)
        {
            FilterItems(ref children, filter);
        }

        void IDataViewBaseExtender.GetChildItems(ItemCollection children, Item parent)
        {
            GetChildItems(children, parent);
        }

        protected override void GetChildItems(ItemCollection children, Item parent)
        {

            base.GetChildItems(children, parent);
            if(!ShouldShowBucketedItemsCount())
            {
                return;
            }

            for (int i = children.Count - 1; i >= 0; i--)
            {
                Item child = children[i];
                if (IsItemBucket(child))
                {
                    int count = GetBucketedItemsCount(child);
                    Item alteredItem = GetCountDisplayNameItem(child, count);
                    children.RemoveAt(i);
                    children.Insert(i, alteredItem);
                }
            }
        }

        protected virtual bool ShouldShowBucketedItemsCount()
        {
            Assert.IsNotNull(BucketsContentEditorSettings, "BucketsContentEditorSettings must be defined in configuration!");
            return BucketsContentEditorSettings.ShowBucketedItemsCount;
        }

        protected virtual bool IsItemBucket(Item item)
        {
            Assert.IsNotNull(ItemBucketsFeatureMethods, "ItemBucketsFeatureMethods must be set in configuration!");
            Assert.ArgumentNotNull(item, "item");
            return ItemBucketsFeatureMethods.IsItemBucket(item);
        }

        protected virtual int GetBucketedItemsCount(Item itemBucket)
        {
            Assert.IsNotNull(BucketedItemsCountProvider, "BucketedItemsCountProvider must be set in configuration!");
            Assert.ArgumentNotNull(itemBucket, "itemBucket");
            return BucketedItemsCountProvider.GetBucketedItemsCount(itemBucket);
        }

        protected virtual Item GetCountDisplayNameItem(Item item, int count)
        {
            FieldList fields = new FieldList();
            item.Fields.ReadAll();

            foreach (Field field in item.Fields)
            {
                fields.Add(field.ID, field.Value);
            }

            int bucketedCount = GetBucketedItemsCount(item);
            string displayName = GetItemNameWithBucketedCount(item, bucketedCount);
            ItemDefinition itemDefinition = new ItemDefinition(item.ID, displayName, item.TemplateID, ID.Null);
            return new Item(item.ID, new ItemData(itemDefinition, item.Language, item.Version, fields), item.Database) { RuntimeSettings = { Temporary = true } };
        }

        protected virtual string GetItemNameWithBucketedCount(Item item, int bucketedCount)
        {
            Assert.IsNotNull(SingularBucketedItemsDisplayNameFormat, "SingularBucketedItemsDisplayNameFormat must be set in configuration!");
            Assert.IsNotNull(PluralBucketedItemsDisplayNameFormat, "PluralBucketedItemsDisplayNameFormat must be set in configuration!");

            if (bucketedCount == 1)
            {
                return ReplaceTokens(SingularBucketedItemsDisplayNameFormat, item, bucketedCount);
            }

            return ReplaceTokens(PluralBucketedItemsDisplayNameFormat, item, bucketedCount);
        }

        protected virtual string ReplaceTokens(string format, Item item, int bucketedCount)
        {
            Assert.ArgumentNotNullOrEmpty(format, "format");
            Assert.ArgumentNotNull(item, "item");
            string replaced = format;
            replaced = replaced.Replace("$displayName", item.DisplayName);
            replaced = replaced.Replace("$bucketedCount", bucketedCount.ToString());
            return replaced;
        }

        Database IDataViewBaseExtender.GetDatabase()
        {
            return GetDatabase();
        }

        Item IDataViewBaseExtender.GetItemFromID(string id, Language language, Version version)
        {
            return GetItemFromID(id, language, version);
        }

        Item IDataViewBaseExtender.GetParentItem(Item item)
        {
            return GetParentItem(item);
        }

        bool IDataViewBaseExtender.HasChildren(Item item, string filter)
        {
            return HasChildren(item, filter);
        }

        void IDataViewBaseExtender.Initialize(string parameters)
        {
            Initialize(parameters);
        }

        bool IDataViewBaseExtender.IsAncestorOf(Item ancestor, Item item)
        {
            return IsAncestorOf(ancestor, item);
        }

        void IDataViewBaseExtender.SortItems(ArrayList children, string sortBy, bool sortAscending)
        {
            SortItems(children, sortBy, sortAscending);
        }
    }
}

You might be saying to yourself “Mike, what in the world is going on here?” πŸ˜‰ Let me explain by starting with the GetChildItems() method.

The GetChildItems() method is used to build up the collection of child Items that display in the Content Tree when you expand a parent node. It does this by populating the ItemCollection instance passed to it.

The particular implementation above is delegating to the base class’ implementation to get the list of child Items for display in the Content Tree.

If we should not show the Bucketed Items count — this is determined by the ShouldShowBucketedItemsCount() method which just returns the boolean value set on the ShowBucketedItemsCount property of the injected IBucketsContentEditorSettings instance — the code just exits.

If we are to show the Bucketed Items count, we iterate over the ItemCollection collection and see if any of these child Items are Item Buckets — this is determined by the IsItemBucket() method.

If we find an Item Bucket, we get its count of Bucketed Items via the GetBucketedItemsCount() method which delegates to the GetBucketedItemsCount() method on the injected IBucketedItemsCountProvider instance.

Once we have the count, we call the GetCountDisplayNameItem() method which populates a FieldList collection with all of the fields defined on the Item Bucket; call the GetItemNameWithBucketedCount() method to get the new display name to show in the Content Tree — this method determines which display name format to use depending on whether we should use singular or pluralized messaging, and expands value on tokens via the ReplaceTokens() method — these tokens are defined in the patch configuration file below; creates an ItemDefinition instance so we can set the new display name; and returns a new Sitecore.Data.Items.Item instance to the caller.

No, don’t worry, we aren’t adding a new Item in the content tree but creating a fake “wrapper” of the real one, and replacing this in the ItemCollection.

We also have to fully implement the IDataViewBaseExtender interface. For most methods, I just delegate to the corresponding methods defined on the base class except for the IDataViewBaseExtender.GetChildItems() method which uses the GetChildItems() method defined above.

I then bridged everything above together via the following patch configuration file:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/">
  <sitecore>
    <buckets>
      <extendedCommands>
        <toggleBucketedItemsCountCommand type="Sitecore.Sandbox.Buckets.Shell.Framework.Commands.ToggleBucketedItemsCountCommand, Sitecore.Sandbox" singleInstance="on">
          <BucketsContentEditorSettings ref="buckets/settings/bucketsContentEditorSettings" />
        </toggleBucketedItemsCountCommand>
      </extendedCommands>
      <providers>
        <items>
          <bucketedItemsCountProvider type="Sitecore.Sandbox.Buckets.Providers.Items.BucketedItemsCountProvider, Sitecore.Sandbox" singleInstance="true">
            <searchIndexMaps hint="raw:AddSearchIndexMap">
              <searchIndexMap database="master" searchIndex="sitecore_master_index" />
              <searchIndexMap database="web" searchIndex="sitecore_web_index" />
            </searchIndexMaps>
          </bucketedItemsCountProvider>
        </items>
      </providers>
      <settings>
        <bucketsContentEditorSettings type="Sitecore.Sandbox.Buckets.Settings.BucketsContentEditorSettings, Sitecore.Sandbox" singleInstance="true">
          <ItemBucketsFeatureDeterminer ref="determiners/features/itemBucketsFeatureDeterminer"/>
          <Registry ref="registries/registry" />
          <ShowBucketedItemsCountRegistryKey>/Current_User/UserOptions.View.ShowBucketedItemsCount</ShowBucketedItemsCountRegistryKey>
        </bucketsContentEditorSettings>
      </settings>
    </buckets>
    <commands>
      <command name="contenteditor:togglebucketeditemscount" type="Sitecore.Sandbox.Shell.Framework.Commands.ExtendedConfigCommand, Sitecore.Sandbox" extendedCommandPath="buckets/extendedCommands/toggleBucketedItemsCountCommand" />
    </commands>
    <contentSearch>
      <indexConfigurations>
        <defaultLuceneIndexConfiguration>
          <fieldMap>
            <fieldNames>
              <field fieldName="item_bucket_ancestor_id" storageType="YES" indexType="TOKENIZED" vectorType="NO" boost="1f" type="System.String" settingType="Sitecore.ContentSearch.LuceneProvider.LuceneSearchFieldConfiguration, Sitecore.ContentSearch.LuceneProvider">
                <analyzer type="Sitecore.ContentSearch.LuceneProvider.Analyzers.LowerCaseKeywordAnalyzer, Sitecore.ContentSearch.LuceneProvider" />
              </field>
              <field fieldName="is_bucketed" storageType="YES" indexType="TOKENIZED" vectorType="NO" boost="1f" type="System.Boolean" settingType="Sitecore.ContentSearch.LuceneProvider.LuceneSearchFieldConfiguration, Sitecore.ContentSearch.LuceneProvider" />
            </fieldNames>
          </fieldMap>
          <documentOptions>
            <fields hint="raw:AddComputedIndexField">
              <field fieldName="item_bucket_ancestor_id">Sitecore.Sandbox.Buckets.ContentSearch.ComputedFields.ItemBucketAncestorId, Sitecore.Sandbox</field>
              <field fieldName="is_bucketed">Sitecore.Sandbox.Buckets.ContentSearch.ComputedFields.IsBucketed, Sitecore.Sandbox</field>
            </fields>
          </documentOptions>
        </defaultLuceneIndexConfiguration>
      </indexConfigurations>
    </contentSearch>
    <dataviews>
      <dataview name="Master">
        <patch:attribute name="assembly">Sitecore.Sandbox</patch:attribute>
        <patch:attribute name="type">Sitecore.Sandbox.Web.UI.HtmlControls.DataViews.ExtendedMasterDataView</patch:attribute>
      </dataview>
    </dataviews>
    <extendedDataViews>
      <extendedMasterDataView type="Sitecore.Sandbox.Buckets.Forms.BucketedItemsCountDataView, Sitecore.Sandbox" singleInstance="true">
        <BucketsContentEditorSettings ref="buckets/settings/bucketsContentEditorSettings" />
        <ItemBucketsFeatureMethods ref="buckets/methods/itemBucketsFeatureMethods" />
        <BucketedItemsCountProvider ref="buckets/providers/items/bucketedItemsCountProvider" />
        <SingularBucketedItemsDisplayNameFormat>$displayName &lt;span style="font-style: italic; color: blue;"&gt;($bucketedCount bucketed item)&lt;span&gt;</SingularBucketedItemsDisplayNameFormat>
        <PluralBucketedItemsDisplayNameFormat>$displayName &lt;span style="font-style: italic; color: blue;"&gt;($bucketedCount bucketed items)&lt;span&gt;</PluralBucketedItemsDisplayNameFormat>
      </extendedMasterDataView>
    </extendedDataViews>
    <registries>
      <registry type="Sitecore.Sandbox.Web.UI.HtmlControls.Registries.Registry, Sitecore.Sandbox" singleInstance="true" />
    </registries>
  </sitecore>
</configuration>

bridge-collapse

Let’s see this in action:

bucketed-items-count-testing

As you can see, it is working as intended.

partay-hard

Magical, right?

magic

Well, not really — it just appears that way. πŸ˜‰

magic-not-really

If you have any thoughts on this, please drop a comment.

A Sitecore Item Buckets GutterRenderer to Convey Which Algorithm Was Used for Creating Bucket Folders

In my previous post, I gave a solution which I leverages the Sitecore Rules Engine to create a custom Item Buckets folder structure for storing bucketable Items.

Last night, I had a thought: what if you needed to know which “algorithm” created a given bucket folder structure for an Item Bucket? How could we go about conveying this type of information?

Immediately, the Sitecore Gutter came to mind — it’s a great way to communicate this type of information visually.

mind-outta-gutter

Before I move forward on the solution I started last night and completed today, let me explain what the Sitecore Gutter is, just in case you are unfamiliar with this feature.

The Sitecore Gutter lives here in the Content Editor:

smart-bucket-gutter-sitecore-gutter

If you right-click in this area, you get a context menu to turn on/off Gutter indicators:

smart-gutter-sitecore-gutter-context-menu

I turned on the Item Buckets Gutter indicator, and now can see which Items are Buckets:

smart-gutter-turn-on-buckets-gutter

There is a huge body of blog posts out on the interwebs which give examples on adding to the Sitecore Gutter. Here are a few posts from some fellow Sitecore MVPs which I highly recommend reading (in order of publish date):

I also wrote a post on how to add to the Sitecore Gutter using the Sitecore PowerShell Extensions module. I recommend having a look at that as well. πŸ˜‰

Now that we are well-versed — or “wicked smaht” as we Bostonians would alternatively say — on what the Sitecore Gutter is, let’s move on to the solution I came up with.

three-stooges-ejoomicated

Just a “heads up”: there is a lot of code in this solution so don’t freak out and/or get too overwhelmed. Stay the course. πŸ˜‰

curly-bug-out

I first explored Sitecore.Buckets.Gutters.BucketGutter in Sitecore.Buckets.dll to see if I should take note of anything special I need to know about when creating custom Sitecore.Shell.Applications.ContentEditor.Gutters.GutterRenderer — this lives in Sitecore.Kernel.dll and needs to be subclassed when adding to the Sitecore Gutter — subclasses for Item Buckets.

I noticed there is code in there which ascertains whether the Item Buckets feature is turned on/off, and obviously returns a null instance of Sitecore.Shell.Applications.ContentEditor.Gutters.GutterIconDescriptor — this lives in Sitecore.Kernel.dll — via its GetIconDescriptor() method.

I decided I needed to a way to also ascertain this. I came up with the following interface for classes that determined whether a feature is enabled or not:

namespace Sitecore.Sandbox.Determiners.Features
{
    public interface IFeatureDeterminer
    {
        bool IsEnabled();
    }
}

I then implemented the above interface with the following class:

using Sitecore.ContentSearch;
using Sitecore.ContentSearch.Utilities;

using Sitecore.Sandbox.Determiners.Features;

namespace Sitecore.Sandbox.Buckets.Determiners.Features
{
    public class ItemBucketsFeatureDeterminer : IFeatureDeterminer
    {
        public virtual bool IsEnabled()
        {
            return ContentSearchManager.Locator.GetInstance<IContentSearchConfigurationSettings>().ItemBucketsEnabled();
        }
    }
}

The code in the IsEnabled() method basically returns a boolean indicating whether the Item Buckets feature is turned on/off.

We now need classes whose instances can ascertain whether a bucketed Item’s path matches the paths generated by the bucketing algorithms they represent. I created the following class whose instances would serve as a parameters object to these objects:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;

namespace Sitecore.Sandbox.Buckets.Ascertainers
{
    public class BucketFolderPathAscertainerParameters
    {
        public Item BucketItem { get; set; }

        public Item BucketedItem { get; set; }

        public DateTime CreationDateOfNewItem { get; set; }
    }
}

We’re just going to pass the Item Bucket, the bucketed Item and the creation date of the bucketed Item.

Next, we need those objects that ascertain whether a given Item Bucket uses a particular bucketing algorithm for its folder structure. I created the following interface for classes whose instances do just that:


namespace Sitecore.Sandbox.Buckets.Ascertainers
{
    public interface IBucketFolderPathAscertainer
    {
        string GetIcon();

        string GetToolTip();

        bool IsFolderPathMatch(BucketFolderPathAscertainerParameters parameters);
    }
}

After implementing two classes which implemented the interface above, I noticed some code similarities between them, and decided to employ Martin Fowler‘s refactoring technique Pull Up Method to move up these code similarities into a base class — I highly recommend reading his book Refactoring: Improving the Design of Existing Code which discusses this refactoring technique as well as a host of others — to make it easier for creating future subclasses and to hopefully abate the chances of code duplication. That exercise gave birth to the following abstract class:

using System;

using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Diagnostics;

namespace Sitecore.Sandbox.Buckets.Ascertainers
{
    public abstract class BucketFolderPathAscertainer : IBucketFolderPathAscertainer
    {
        private string icon;
        protected string Icon
        {
            get
            {
                Assert.IsNotNullOrEmpty(icon, "Icon must be set in configuration!");
                return icon;
            }
            set
            {
                Assert.IsNotNullOrEmpty(value, "Icon must be set in configuration!");
                icon = value;
            }
        }

        private string toolTip;
        protected string ToolTip
        {
            get
            {
                Assert.IsNotNullOrEmpty(toolTip, "ToolTip must be set in configuration!");
                return toolTip;
            }
            set
            {
                Assert.IsNotNullOrEmpty(value, "ToolTip must be set in configuration!");
                toolTip = value;
            }
        }

        public virtual string GetIcon()
        {
            return Icon;
        }

        public virtual string GetToolTip()
        {
            return ToolTip;
        }

        public bool IsFolderPathMatch(BucketFolderPathAscertainerParameters parameters)
        {
            EnsureParameters(parameters);
            ID settingsItemID = GetSettingsItemID();
            Assert.IsTrue(!ID.IsNullOrEmpty(settingsItemID), "GetSettingsItemID() cannot return null or empty!");
            Item settingsItem = parameters.BucketItem.Database.GetItem(settingsItemID);
            Assert.IsNotNull(settingsItem, string.Format("Setting Item does not exist! Make sure it exists! Item ID: {0}", settingsItemID.ToString()));

            string resolvedPath = GetResolvedPath(parameters, settingsItem);
            if (string.IsNullOrWhiteSpace(resolvedPath))
            {
                return false;
            }

            return IsPathMatch(parameters, resolvedPath);
        }

        protected virtual void EnsureParameters(BucketFolderPathAscertainerParameters parameters)
        {
            Assert.ArgumentNotNull(parameters, "parameters");
            Assert.ArgumentNotNull(parameters.BucketItem, "parameters.BucketItem");
            Assert.ArgumentNotNull(parameters.BucketedItem, "parameters.BucketedItem");
            Assert.ArgumentCondition(parameters.BucketItem.Database == parameters.BucketedItem.Database, "parameters.BucketItem.Database", "parameters.BucketItem.Database and parameters.BucketedItem.Database must be the same database");
            Assert.ArgumentCondition(parameters.BucketItem.Axes.IsAncestorOf(parameters.BucketedItem), "parameters.BucketItem", string.Format("parameters.BucketItem", "Bucket Item: {0} must be an ancestor of Bucketed Item: {1}", parameters.BucketItem.ID.ToString(), parameters.BucketedItem.ID.ToString()));
            Assert.ArgumentNotNull(parameters.BucketedItem, "parameters.BucketedItem");
        }

        protected virtual ID GetSettingsItemID()
        {
            return Sitecore.Buckets.Util.Constants.SettingsItemId;
        }

        protected abstract string GetResolvedPath(BucketFolderPathAscertainerParameters parameters, Item settingsItem);

        protected virtual bool IsPathMatch(BucketFolderPathAscertainerParameters parameters, string resolvedPath)
        {
            if (string.IsNullOrWhiteSpace(resolvedPath))
            {
                return false;
            }

            string bucketedFolderPath = parameters.BucketedItem.Paths.ParentPath.Replace(parameters.BucketItem.Paths.FullPath, string.Empty);
            if(bucketedFolderPath.StartsWith("/"))
            {
                bucketedFolderPath = bucketedFolderPath.Substring(1);
            }

            return string.Equals(bucketedFolderPath, resolvedPath, StringComparison.OrdinalIgnoreCase);
        }
    }
}

The Icon and ToolTip property values in the above class live in the patch configuration file further down in this post. The Sitecore Configuration Factory will inject those values into these properties, and the GetIcon() and GetToolTip() will return the values housed in the Icon and ToolTip properties, respectively.

The IsFolderPathMatch() gets the settingsItem Item instance — this Item lives in /sitecore/system/Settings/Buckets/Item Buckets Settings in Sitecore — which is needed by the GetResolvedPath() method — this method is declared abstract and must be implemented by subclasses — whose job it is to get the bucketed Item’s folder path via the algorithm which the subclass implementation represents.

When the algorithm path is return, it is then passed to the IsPathMatch() method which determines if there is a match. If there is a match, true is returned to the caller of the IsFolderPathMatch() method; false is returned otherwise.

The class above combined with its subclasses would be an example of the Template method design pattern in action.

Now, we need a subclass of the above to determine if a bucketed Item’s path was generated by the Sitecore Rules Engine. Since we don’t want the Rules Engine to evaluate the rules defined on /sitecore/system/Settings/Buckets/Item Buckets Settings for the bucketed Item given the Item Bucket’s current state — its “when” Condition will most likely evaluate to false — we need a way to trick the Rules Engine. I came up with the following Condition class that always evaluates to true:

using Sitecore.Rules;
using Sitecore.Rules.Conditions;

namespace Sitecore.Sandbox.Rules
{
    public class AlwaysTrueWhenCondition<TRuleContext> : WhenCondition<TRuleContext> where TRuleContext : RuleContext
    {
        protected override bool Execute(TRuleContext ruleContext)
        {
            return true;
        }
    }
}

There isn’t much going on in the above class. Its Execute() method always returns true.

The following subclass of the BucketFolderPathAscertainer class determines if a bucketed Item’s path was generated by the Sitecore Rules Engine:

using System;
using System.Collections.Generic;

using Sitecore.Data.Items;
using Sitecore.Diagnostics;
using Sitecore.Buckets.Rules.Bucketing;
using Sitecore.Rules;
using Sitecore.Sandbox.Rules;

namespace Sitecore.Sandbox.Buckets.Ascertainers
{
    public class RulesDefinedBucketFolderPathAscertainer : BucketFolderPathAscertainer
    {
        protected override string GetResolvedPath(BucketFolderPathAscertainerParameters parameters, Item settingsItem)
        {
            string bucketRulesFieldId = GetBucketRulesFieldId();
            Assert.IsNotNullOrEmpty(bucketRulesFieldId, "GetBucketRulesFieldId() cannot return null or empty!");
            BucketingRuleContext ruleContext = CreateNewBucketingRuleContext(parameters);
            RuleList<BucketingRuleContext> rules = GetRuleList<BucketingRuleContext>(settingsItem, bucketRulesFieldId);
            SetAlwaysTrueWhenConditions(rules.Rules);
            if (rules == null)
            {
                return string.Empty;
            }

            try
            {
                rules.Run(ruleContext);
            }
            catch (Exception ex)
            {
                Log.Error(ToString(), ex, this);
            }

            return ruleContext.ResolvedPath;
        }

        protected virtual string GetBucketRulesFieldId()
        {
            return Sitecore.Buckets.Util.Constants.BucketRulesFieldId;
        }

        protected virtual BucketingRuleContext CreateNewBucketingRuleContext(BucketFolderPathAscertainerParameters parameters)
        {
            return new BucketingRuleContext(parameters.BucketedItem.Database, parameters.BucketItem.ID, parameters.BucketedItem.ID, parameters.BucketedItem.Name,
                            parameters.BucketedItem.TemplateID, parameters.CreationDateOfNewItem)
            {
                NewItemId = parameters.BucketedItem.ID,
                CreationDate = parameters.CreationDateOfNewItem
            };
        }

        protected virtual RuleList<T> GetRuleList<T>(Item settingsItem, string bucketRulesFieldId) where T : BucketingRuleContext
        {
            Assert.ArgumentNotNull(settingsItem, "settingsItem");
            Assert.ArgumentNotNullOrEmpty(bucketRulesFieldId, "bucketRulesFieldId");
            return RuleFactory.GetRules<T>(new[] { settingsItem }, bucketRulesFieldId);
        }

        protected virtual void SetAlwaysTrueWhenConditions<TRuleContext>(IEnumerable<Rule<TRuleContext>> rules) where TRuleContext : RuleContext
        {
            foreach(Rule<TRuleContext> rule in rules)
            {
                rule.Condition = CreateNewAlwaysTrueWhenCondition<TRuleContext>();
            }
        }

        protected virtual AlwaysTrueWhenCondition<TRuleContext> CreateNewAlwaysTrueWhenCondition<TRuleContext>() where TRuleContext : RuleContext
        {
            return new AlwaysTrueWhenCondition<TRuleContext>();
    }
    }
}

I’m not going to go too much into all the methods of this class given that most of the magic happens in the GetResolvedPath() method. It basically replaces all Conditions in the rules Sitecore.Rules.RulesList instance with an instance of the Condition class above; calls the Rules Engine API to evaluate the rules defined on the settingsItem instance though with the Conditions always returning true; and returns the resolved path to the caller.

The following class which also subclasses the BucketFolderPathAscertainer class — if I only had a dollar for every instance of the word “class” or “subclass” in this post — basically wraps an Sitecore.Buckets.Util.IDynamicBucketFolderPath instance — ahem, I mean employs the Adapter design pattern — where its GetResolvedPath() method delegates a call to the IDynamicBucketFolderPath instances GetFolderPath() method:

using Sitecore.Buckets.Util;
using Sitecore.Data.Items;
using Sitecore.Diagnostics;

namespace Sitecore.Sandbox.Buckets.Ascertainers
{
    public class DynamicBucketFolderPathPathAscertainer : BucketFolderPathAscertainer
    {
        private IDynamicBucketFolderPath PathResolver { get; set; }

        protected override string GetResolvedPath(BucketFolderPathAscertainerParameters parameters, Item settingsItem)
        {
            Assert.IsNotNull(PathResolver, "The IDynamicBucketFolderPath instance named PathResolver must be set in configuration!");
            return PathResolver.GetFolderPath(parameters.BucketItem.Database, parameters.BucketedItem.Name, parameters.BucketedItem.TemplateID,
                                                                parameters.BucketedItem.ID, parameters.BucketItem.ID, parameters.CreationDateOfNewItem);
        }
    }
}

You might be asking “what are we using the above class for?” Well, we are going to inject an instance of Sitecore.Buckets.Util.DateBasedFolderPath into the PathResolver property via the Sitecore Configuration Factory (please see the patch configuration file further down in this post).

I thought it might be cumbersome for a class to make calls to every single IBucketFolderPathAscertainer instance — sure, we only have two above but just think about how messy things will quickly progress if more are added. I decided I would utilize the Composite design pattern via the following class:

using System.Collections.Generic;
using System.Linq;
using System.Xml;

using Sitecore.Configuration;
using Sitecore.Diagnostics;

namespace Sitecore.Sandbox.Buckets.Ascertainers
{

    public class CompositeBucketFolderPathAscertainer : IBucketFolderPathAscertainer
    {
        private string Icon { get; set; }

        private string ToolTip { get; set; }

        private List<IBucketFolderPathAscertainer> FolderPathAscertainers { get; set; }

        public CompositeBucketFolderPathAscertainer()
        {
            FolderPathAscertainers = new List<IBucketFolderPathAscertainer>();
        }

        public string GetIcon()
        {
            return Icon;
        }

        protected virtual void SetIcon(string icon)
        {
            Assert.ArgumentNotNullOrEmpty(icon, "icon");
            Icon = icon;
        }

        public string GetToolTip()
        {
            return ToolTip;
        }

        protected virtual void SetToolTip(string toolTip)
        {
            Assert.ArgumentNotNullOrEmpty(toolTip, "toolTip");
            ToolTip = toolTip;
        }

        public bool IsFolderPathMatch(BucketFolderPathAscertainerParameters parameters)
        {
            if(FolderPathAscertainers == null || !FolderPathAscertainers.Any())
            {
                return false;
            }

            foreach(IBucketFolderPathAscertainer ascertainer in FolderPathAscertainers)
            {
                if(ascertainer.IsFolderPathMatch(parameters))
                {
                    SetIcon(ascertainer.GetIcon());
                    SetToolTip(ascertainer.GetToolTip());
                    return true;
                }
            }

            return false;
        }

        protected virtual void AddFolderPathAscertainer(XmlNode configNode)
        {
            if(configNode == null)
            {
                return;
            }

            IBucketFolderPathAscertainer ascertainer = Factory.CreateObject(configNode, false) as IBucketFolderPathAscertainer;
            Assert.IsNotNull(ascertainer, "An IBucketFolderPathAscertainer was not defined correctly in configuration!");
            FolderPathAscertainers.Add(ascertainer);
        }
    }
}

All configuration-defined IBucketFolderPathAscertainer instances will be added to the FolderPathAscertainers List property via the AddFolderPathAscertainer() method (have a look at the configuration file below to see the AddFolderPathAscertainer() method being there for the Sitecore Configuration Factory to use).

The IsFolderPathMatch() method will then iterate over all IBucketFolderPathAscertainer instances and try to find a match. If a match is found, the instance of the class above will grab and save local copies of that IBucketFolderPathAscertainer instance’s Icon and Tooltip values, and then return true. If no match was found, it returns false.

Now, we need a way to grab one bucketed Item for an Item Bucket. I defined the following interface for a class whose instance will return one Item given another Item:

using Sitecore.Data.Items;

namespace Sitecore.Sandbox.Providers.Items
{
    public interface IItemProvider
    {
        Item GetItem(Item item);
    }
}

The following class implements the interface above:

using System;
using System.Linq;
using System.Linq.Expressions;

using Sitecore.ContentSearch;
using Sitecore.ContentSearch.Linq;
using Sitecore.ContentSearch.Linq.Utilities;
using Sitecore.ContentSearch.SearchTypes;
using Sitecore.ContentSearch.Utilities;
using Sitecore.Data;
using Sitecore.Data.Items;
using Sitecore.Diagnostics;

using Sitecore.Sandbox.Providers.Items;

namespace Sitecore.Sandbox.Buckets.Providers.Items
{
    public class BucketedItemProvider : IItemProvider
    {
        private string BucketFolderTemplateId { get; set; }

        private string SearchIndexName { get; set; }

        private ISearchIndex searchIndex;
        private ISearchIndex SearchIndex
        {
            get
            {
                if (searchIndex == null && !string.IsNullOrWhiteSpace(SearchIndexName))
                {
                    searchIndex = GetSearchIndex(SearchIndexName);
                }

                return searchIndex;
            }
        }

        public virtual Item GetItem(Item bucketItem)
        {
            ID bucketFolderTemplateId;
            Assert.ArgumentCondition(ID.TryParse(BucketFolderTemplateId, out bucketFolderTemplateId), "BucketFolderTemplateId", "BucketFolderTemplateId cannot be empty and must be a Sitecore.Data.ID! Check its configuration setting!");
            Assert.ArgumentNotNull(bucketItem, "bucketItem");
            Assert.IsNotNullOrEmpty(SearchIndexName, "SearchIndexName is empty. Double-check its configuration setting!");
            Assert.IsNotNull(SearchIndex, "SearchIndex is null. Double-check the SearchIndexName configuration setting!");

            using (IProviderSearchContext searchContext = SearchIndex.CreateSearchContext())
            {
                var predicate = GetSearchPredicate<SearchResultItem>(bucketItem.ID, bucketFolderTemplateId);
                IQueryable<SearchResultItem> query = searchContext.GetQueryable<SearchResultItem>().Filter(predicate);
                SearchResults<SearchResultItem> results = query.GetResults();
                if (results.Count() < 1)
                {
                    return null;
                }

                SearchHit<SearchResultItem> hit = results.Hits.First();
                return hit.Document.GetItem();
            }
        }

        protected virtual ISearchIndex GetSearchIndex(string searchIndexName)
        {
            Assert.ArgumentNotNullOrEmpty(searchIndexName, "searchIndexName");
            return ContentSearchManager.GetIndex(searchIndexName);
        }

        protected virtual Expression<Func<T, bool>> GetSearchPredicate<T>(ID bucketItemId, ID bucketFolderTemplateId) where T : SearchResultItem
        {
            var predicate = PredicateBuilder.True<T>();
            predicate = predicate.And(item => item.Paths.Contains(bucketItemId));
            predicate = predicate.And(item => item.TemplateId != bucketFolderTemplateId);
            predicate = predicate.And(item => item.Parent != bucketItemId);
            predicate = predicate.And(item => item.ItemId != bucketItemId);
            return predicate;
        }
    }
}

The class above is leveraging the Sitecore.ContentSearch API to get this bucketed Item.

Why am I using the Sitecore.ContentSearch API? Well, imagine if there are thousands if not tens of thousands of bucketed Items under the Item Bucket. A Sitecore query would be slow as molasses, and we need keep performance on our minds at all times for all of our solutions. Don’t lose sight of that on anything you build.

The GetSearchPredicate() method builds up and returns an Expression<Func> instance — let’s call this instance the “predicate”. The predicate basically says we want an Item who is a descendant of the Item Bucket; isn’t a Bucket Folder Item; lives under a Bucket Folder; and isn’t the Item Bucket Item.

The GetItem() method then uses that predicate and the Sitecore.ContentSearch API to gather those SearchResultItem instances, and then returns the Item instance on the first one in the result set if any were returned. If none were found, it returns null.

Since we have a lot of moving parts in this solution — just look at all of the classes you’ve just gone through — I need a way to piece all of this together for a GutterRenderer.

Unfortunately, we can’t magically inject instances into a GutterRenderer via the Sitecore Configuration Factory — well, you can call it but imagine all the calls I would need for this — so I decided to define the following interface whose classes would be used by a GutterRenderer, and these classes would be defined in Sitecore configuration:

using Sitecore.Data.Items;
using Sitecore.Shell.Applications.ContentEditor.Gutters;

namespace Sitecore.Sandbox.Shell.Applications.ContentEditor.Gutters
{
    public interface IGutter
    {
        GutterIconDescriptor GetIconDescriptor(Item item);

        bool IsVisible();
    }
}

The following class implements the interface above:

using System;

using Sitecore.Buckets.Extensions;
using Sitecore.Data.Fields;
using Sitecore.Data.Items;
using Sitecore.Diagnostics;
using Sitecore.Globalization;
using Sitecore.Shell.Applications.ContentEditor.Gutters;

using Sitecore.Sandbox.Buckets.Ascertainers;
using Sitecore.Sandbox.Determiners.Features;
using Sitecore.Sandbox.Providers.Items;
using Sitecore.Sandbox.Shell.Applications.ContentEditor.Gutters;

namespace Sitecore.Sandbox.Buckets.Gutters
{
    public class FolderPathBucketGutter : IGutter
    {
        private string DefaultIcon { get; set; }

        private string DefaultToolTip { get; set; }

        private string CreatedDatetimeFieldName { get; set; }

        private IFeatureDeterminer ItemBucketsFeatureDeterminer { get; set; }

        private IItemProvider BucketedItemProvider { get; set; }

        private IBucketFolderPathAscertainer FolderPathAscertainer { get; set; }

        public virtual GutterIconDescriptor GetIconDescriptor(Item item)
        {
            EnsureRequiredProperties();
            Assert.ArgumentNotNull(item, "item");

            if(!AreItemBucketsEnabled() || !item.IsABucket())
            {
                return null;
            }

            Item bucketedItem = GetBucketedItem(item);
            if(bucketedItem == null)
            {
                return CreateNewGutterIconDescriptor(DefaultIcon, DefaultToolTip);
            }

            BucketFolderPathAscertainerParameters parameters = new BucketFolderPathAscertainerParameters
            {
                BucketItem = item,
                BucketedItem = bucketedItem,
                CreationDateOfNewItem = GetItemCreatedDateTime(bucketedItem)
            };

            if(!FolderPathAscertainer.IsFolderPathMatch(parameters))
            {
                return CreateNewGutterIconDescriptor(DefaultIcon, DefaultToolTip);
            }

            return CreateNewGutterIconDescriptor(FolderPathAscertainer.GetIcon(), FolderPathAscertainer.GetToolTip());
        }

        protected virtual void EnsureRequiredProperties()
        {
            Assert.IsNotNull(FolderPathAscertainer, "FolderPathAscertainer must be defined in configuration!");
            Assert.IsNotNullOrEmpty(DefaultIcon, "DefaultIcon must be defined in configuration!");
            Assert.IsNotNullOrEmpty(DefaultToolTip, "DefaultToolTip must be defined in configuration!");
            Assert.IsNotNullOrEmpty(CreatedDatetimeFieldName, "CreatedDatetimeFieldName must be defined in configuration!");
        }

        public virtual bool IsVisible()
        {
            return AreItemBucketsEnabled();
        }

        protected virtual bool AreItemBucketsEnabled()
        {
            Assert.IsNotNull(ItemBucketsFeatureDeterminer, "ItemBucketsFeatureDeterminer must be set in configuration!");
            return ItemBucketsFeatureDeterminer.IsEnabled();
        }

        protected virtual Item GetBucketedItem(Item bucketItem)
        {
            Assert.IsNotNull(BucketedItemProvider, "BucketedItemProvider must be set in configuration!");
            return BucketedItemProvider.GetItem(bucketItem);
        }

        protected virtual GutterIconDescriptor CreateNewGutterIconDescriptor(string icon, string toolTip)
        {
            Assert.ArgumentNotNullOrEmpty(icon, "icon");
            Assert.ArgumentNotNullOrEmpty(toolTip, "toolTip");
            return new GutterIconDescriptor
            {
                Icon = icon,
                Tooltip = TranslateText(toolTip)
            };
        }

        protected virtual string TranslateText(string text)
        {
            Assert.ArgumentNotNullOrEmpty(text, "text");
            return Translate.Text(text);
        }

        protected virtual DateTime GetItemCreatedDateTime(Item item)
        {
            Assert.IsNotNullOrEmpty(CreatedDatetimeFieldName, "CreatedDatetimeFieldName must be defined in configuration!");
            Assert.ArgumentNotNull(item, "item");
            DateField created = item.Fields[CreatedDatetimeFieldName];
            if(created == null)
            {
                return DateTime.MinValue;
            }

            return created.DateTime;
        }
    }
}

The AreItemBucketsEnabled() method in the above classes determines if the Item Bucket feature is enabled via the injected IBucketFolderPathAscertainer instance. This method is then used by the IsVisible() method which represents the method by the same name on GutterRenderer instances, and is also called by the GetIconDescriptor() method.

If the Item Buckets feature is not enabled, the GetIconDescriptor() method will return null as well as when the passed Item is not an Item Bucket.

If the passed Item is an Item Bucket, the GetIconDescriptor() gets one bucketed Item via the GetBucketedItem() method — this method just delegates to the IItemProvider instance injected into the class instance — and puts this bucketed Item as well as the Item Bucket into a BucketFolderPathAscertainerParameters parameters object instance. The creation date of the bucketed is also set on this parameters object since it is required when ascertaining whether the folder structure was constructed based on its creation date.

The BucketFolderPathAscertainerParameters instance is then passed to the IsFolderPathMatch() method on the injected IBucketFolderPathAscertainer property which determines if there is a folder path match.

If there is a match, a new GutterIconDescriptor instance is returned which contains the appropriate Icon and Tooltip.

If there is no match, then a new GutterIconDescriptor is returned with default values for the Icon and Tooltip.

This next class subclasses the GutterRenderer class:

using System;

using Sitecore.Configuration;
using Sitecore.Data.Items;
using Sitecore.Diagnostics;
using Sitecore.Shell.Applications.ContentEditor.Gutters;

namespace Sitecore.Sandbox.Shell.Applications.ContentEditor.Gutters
{
    public class ConfigDefinedGutterRenderer : GutterRenderer
    {
        private IGutter gutter;
        private IGutter Gutter
        {
            get
            {
                if (gutter == null)
                {
                    gutter = GetInnerGutterRenderer();
                }

                return gutter;
            }
        }

        protected override GutterIconDescriptor GetIconDescriptor(Item item)
        {
            Assert.IsNotNull(Gutter, "Gutter wasn't set properly. Double-check it!");
            return Gutter.GetIconDescriptor(item);
        }

        public override bool IsVisible()
        {
            Assert.IsNotNull(Gutter, "Gutter wasn't set properly. Double-check it!");
            return Gutter.IsVisible();
        }

        protected virtual IGutter GetInnerGutterRenderer()
        {
            string configPath = GetConfigPath();
            if (string.IsNullOrWhiteSpace(configPath))
            {
                Log.Error("ConfigDefinedGutterRenderer: configPath must be set as a parameter!", this);
                return null;
            }

            try
            {
                IGutter gutter = Factory.CreateObject(configPath, false) as IGutter;
                if (gutter == null)
                {
                    Log.Error(string.Format("ConfigDefinedGutterRenderer: the IGutter defined in {0} isn't correctly defined. Double-check it!", configPath), this);
                    return null;
                }

                return gutter;

            }
            catch (Exception ex)
            {
                Log.Error(ToString(), ex, this);
            }

            return null;
        }

        protected virtual string GetConfigPath()
        {
            string key = "configPath";
            if (Parameters.ContainsKey(key))
            {
                return Parameters[key];
            }

            return string.Empty;
        }
    }
}

The GetInnerGutterRenderer() method above calls the Sitecore Configuration Factory to grab an IGutter instance from a configuration path which is set on the Parameters field of the definition Item for this GutterRenderer in the Core database — see the screenshot further down in this post — when the Gutter property is called for the first time, and sets this instance on a private member on the class instance.

Both the GetIconDescriptor() and IsVisible() methods delegate to the methods on the IGutter instance with the same names (quiz time: what design pattern is this class using? πŸ˜‰ ).

I then duct-taped everything together via the following patch configuration file:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/">
  <sitecore>
    <gutters>
      <folderPathBucketGutter type="Sitecore.Sandbox.Buckets.Gutters.FolderPathBucketGutter, Sitecore.Sandbox" singleInstance="true">
        <DefaultIcon>business/32x32/chest_add.png</DefaultIcon>
        <DefaultToolTip>This item is a bucket. You can use this as a content repository.</DefaultToolTip>
        <CreatedDatetimeFieldName>__Created</CreatedDatetimeFieldName>
        <ItemBucketsFeatureDeterminer ref="determiners/features/itemBucketsFeatureDeterminer" />
        <BucketedItemProvider ref="providers/items/bucketedItemProvider" />
        <FolderPathAscertainer ref="ascertainers/buckets/compositeBucketFolderPathAscertainer" />
      </folderPathBucketGutter>
    </gutters>
    <ascertainers>
      <buckets>
        <compositeBucketFolderPathAscertainer type="Sitecore.Sandbox.Buckets.Ascertainers.CompositeBucketFolderPathAscertainer, Sitecore.Sandbox" singleInstance="true">
          <ascertainers hint="raw:AddFolderPathAscertainer">
            <ascertainer ref="ascertainers/buckets/rulesDefinedBucketFolderPathAscertainer" />
            <ascertainer ref="ascertainers/buckets/dateBasedFolderPathAscertainer" />
          </ascertainers>
        </compositeBucketFolderPathAscertainer>
        <dateBasedFolderPathAscertainer type="Sitecore.Sandbox.Buckets.Ascertainers.DynamicBucketFolderPathPathAscertainer, Sitecore.Sandbox" singleInstance="true">
          <Icon>Business/32x32/calendar_down.png</Icon>
          <ToolTip>This item is a bucket. Its bucket folders were generated based on the creation date of the bucketed items. You can use this as a content repository.</ToolTip>
          <PathResolver type="Sitecore.Buckets.Util.DateBasedFolderPath, Sitecore.Buckets" />
        </dateBasedFolderPathAscertainer>
        <rulesDefinedBucketFolderPathAscertainer type="Sitecore.Sandbox.Buckets.Ascertainers.RulesDefinedBucketFolderPathAscertainer, Sitecore.Sandbox"
        singleInstance="true">
          <Icon>Business/32x32/briefcase_add.png</Icon>
          <ToolTip>This item is a bucket. Its bucket folders were generated by the rules engine. You can use this as a content repository.</ToolTip>
        </rulesDefinedBucketFolderPathAscertainer>
      </buckets>
    </ascertainers>
    <determiners>
      <features>
        <itemBucketsFeatureDeterminer type="Sitecore.Sandbox.Buckets.Determiners.Features.ItemBucketsFeatureDeterminer" singleInstance="true" />
      </features>
    </determiners>
    <providers>
      <items>
        <bucketedItemProvider type="Sitecore.Sandbox.Buckets.Providers.Items.BucketedItemProvider" singleInstance="true">
          <BucketFolderTemplateId>{ADB6CA4F-03EF-4F47-B9AC-9CE2BA53FF97}</BucketFolderTemplateId>
          <SearchIndexName>sitecore_master_index</SearchIndexName>
        </bucketedItemProvider>
      </items>
    </providers>
  </sitecore>
</configuration>

We need to let Sitecore know about the new Gutter addition. I did this in the Core database:

smart-bucket-gutter-core-db

One thing to keep in mind is that the Sitecore Rules Engine folder path match will only work when we have an algorithm that will return the same path consistently for a bucketed Item. This unfortunately means I could not use the same Action from my previous post given that it generates random folder paths.

To over come this hurdle, I built the following Action which just reverses the bucketed Item’s ID (oh no, more code πŸ˜‰ ):

using System.Collections.Generic;
using System.Linq;

using Sitecore.Buckets.Rules.Bucketing;
using Sitecore.Buckets.Rules.Bucketing.Actions;
using Sitecore.Diagnostics;

namespace Sitecore.Sandbox.Buckets.Rules.Actions
{
    public class CreateReversedIDBasedPath<TContext> : CreateIDBasedPath<TContext> where TContext : BucketingRuleContext
    {
        public override void Apply(TContext ruleContext)
        {
            Assert.ArgumentNotNull(ruleContext, "ruleContext");
            base.Apply(ruleContext);
            if (string.IsNullOrWhiteSpace(ruleContext.ResolvedPath))
            {
                return;
            }

            ruleContext.ResolvedPath = ReversePath(ruleContext.ResolvedPath);
        }

        protected virtual string ReversePath(string path)
        {
            if(string.IsNullOrWhiteSpace(path))
            {
                return string.Empty;
            }

            List<string> pieces = path.Split('/').ToList();
            pieces.Reverse();
            return string.Join("/", pieces);
        }
    }
}

I’m not going to go into details of how I set this in the rules on /sitecore/system/Settings/Buckets/Item Buckets Settings — you can see an example of how this is done from my previous post.

Now that everything is set, we can see that the new Gutter option is available:

smart-bucket-gutter-right-click-lets-turn-on

I then turned it on:

smart-gutter-new-gutter-turned-on

As you can see, we have different Gutter icons for different folder structures.

If you have any thoughts on this, please share in a comment.

Oh, by the way, if you made it all the way to the end of this post, then you deserve a treat. Go get yourself a cookie. You deserve it. πŸ˜‰

cookie

Until next time, keep up the good fight, one piece of code at time. πŸ˜€

Download Images and Save to the Media Library Via a Custom Content Editor Image Field in Sitecore

Yesterday evening — a Friday evening by the way (what, you don’t code on Friday evenings? πŸ˜‰ ) — I wanted to have a bit of fun by building some sort of customization in Sitecore but was struggling on what to build.

After about an hour of pondering, it dawned on me: I was determined to build a custom Content Editor Image field that gives content authors the ability to download images from a supplied URL; save the image to disk; upload the image into the Media Libary; and then set it on a custom Image field of an Item.

I’m sure someone has built something like this in the past and may have even uploaded a module that does this to the Sitecore Marketplace — I didn’t really look into whether this had already been done before since I wanted to have some fun by taking on the challenge. What follows is the fruit of that endeavor.

Before I move forward, I would like to caution you on using the code that follows — I have not rigorously tested this code at all so use at your own risk.

Before I began coding, I thought about how I wanted to approach this challenge. I decided I would build a custom Sitecore pipeline to handle this code. Why? Well, quite frankly, it gives you flexibility on customization, and also native Sitecore code is hugely composed of pipelines — why deviate from the framework?

First, I needed a class whose instances would serve as the custom pipeline’s arguments object. The following class was built for that:

using Sitecore.Data;
using Sitecore.Pipelines;

namespace Sitecore.Sandbox.Pipelines.DownloadImageToMediaLibrary
{
    public class DownloadImageToMediaLibraryArgs : PipelineArgs
    {
        public Database Database { get; set; }

        public string ImageFileName { get; set; }

        public string ImageFilePath { get; set; }

        public string ImageItemName { get; set; }

        public string ImageUrl { get; set; }

        public string MediaId { get; set; }

        public string MediaLibaryFolderPath { get; set; }

        public string MediaPath { get; set; }

        public bool FileBased { get; set; }

        public bool IncludeExtensionInItemName { get; set; }

        public bool OverwriteExisting { get; set; }

        public bool Versioned { get; set; }
    }
}

I didn’t just start off with all of the properties you see on this class — it was an iterative process where I had to go back, add more and even remove some that were no longer needed. You will see why I have these on it from the code below.

I decided to employ the Template method pattern in this code, and defined the following abstract base class which all processors of my custom pipeline will sub-class:

using Sitecore.Diagnostics;

namespace Sitecore.Sandbox.Pipelines.DownloadImageToMediaLibrary
{
    public abstract class DownloadImageToMediaLibraryProcessor
    {
        public void Process(DownloadImageToMediaLibraryArgs args)
        {
            Assert.ArgumentNotNull(args, "args");
            if(!CanProcess(args))
            {
                AbortPipeline(args);
                return;
            }

            Execute(args);
        }

        protected abstract bool CanProcess(DownloadImageToMediaLibraryArgs args);

        protected virtual void AbortPipeline(DownloadImageToMediaLibraryArgs args)
        {
            args.AbortPipeline();
        }

        protected abstract void Execute(DownloadImageToMediaLibraryArgs args);
    }
}

All processors of the custom pipeline will have to implement the CanProcess and Execute methods above, and also have the ability to redefine the AbortPipeline method if needed.

The main magic for all processors happen in the Process method above — if the processor can process the data supplied via the arguments object, then it will do so using the Execute method. Otherwise, the pipeline will be aborted via the AbortPipeline method.

The following class serves as the first processor of the custom pipeline.

using Sitecore.Data.Items;
using Sitecore.Diagnostics;
using Sitecore.IO;

namespace Sitecore.Sandbox.Pipelines.DownloadImageToMediaLibrary
{
    public class SetProperties : DownloadImageToMediaLibraryProcessor
    {
        private string UploadDirectory { get; set; }

        protected override bool CanProcess(DownloadImageToMediaLibraryArgs args)
        {
            Assert.IsNotNullOrEmpty(UploadDirectory, "UploadDirectory must be set in configuration!");
            Assert.IsNotNull(args.Database, "args.Database must be supplied!");
            return !string.IsNullOrWhiteSpace(args.ImageUrl)
                && !string.IsNullOrWhiteSpace(args.MediaLibaryFolderPath);
        }

        protected override void Execute(DownloadImageToMediaLibraryArgs args)
        {
            args.ImageFileName = GetFileName(args.ImageUrl);
            args.ImageItemName = GetImageItemName(args.ImageUrl);
            args.ImageFilePath = GetFilePath(args.ImageFileName);
        }

        protected virtual string GetFileName(string url)
        {
            Assert.ArgumentNotNullOrEmpty(url, "url");
            return FileUtil.GetFileName(url);
        }

        protected virtual string GetImageItemName(string url)
        {
            Assert.ArgumentNotNullOrEmpty(url, "url");
            string fileNameNoExtension = GetFileNameNoExtension(url);
            if(string.IsNullOrWhiteSpace(fileNameNoExtension))
            {
                return string.Empty;
            }

            return ItemUtil.ProposeValidItemName(fileNameNoExtension);
        }

        protected virtual string GetFileNameNoExtension(string url)
        {
            Assert.ArgumentNotNullOrEmpty(url, "url");
            return FileUtil.GetFileNameWithoutExtension(url);
        }

        protected virtual string GetFilePath(string fileName)
        {
            Assert.ArgumentNotNullOrEmpty(fileName, "fileName");
            return string.Format("{0}/{1}", FileUtil.MapPath(UploadDirectory), fileName);
        }
    }
}

Instances of the above class will only run if an upload directory is supplied via configuration (see the patch include configuration file down below); a Sitecore Database is supplied (we have to upload this image somewhere); an image URL is supplied (can’t download an image without this); and a Media Library folder is supplied (where are we storing this image?).

The Execute method then sets additional properties on the arguments object that the next processors will need in order to complete their tasks.

The following class serves as the second processor of the custom pipeline. This processor will download the image from the supplied URL:

using System.Net;

namespace Sitecore.Sandbox.Pipelines.DownloadImageToMediaLibrary
{
    public class DownloadImage : DownloadImageToMediaLibraryProcessor
    {
        protected override bool CanProcess(DownloadImageToMediaLibraryArgs args)
        {
            return !string.IsNullOrWhiteSpace(args.ImageUrl)
                && !string.IsNullOrWhiteSpace(args.ImageFilePath);
        }

        protected override void Execute(DownloadImageToMediaLibraryArgs args)
        {
            using (WebClient client = new WebClient())
            {
                client.DownloadFile(args.ImageUrl, args.ImageFilePath);
            }
        }
    }
}

The processor instance of the above class will only execute when an image URL is supplied and a location on the file system is given — this is the location on the file system where the image will live before being uploaded into the Media Library.

If all checks out, the image is downloaded from the given URL into the specified location on the file system.

The next class serves as the third processor of the custom pipeline. This processor will upload the image on disk to the Media Library:

using System.IO;

using Sitecore.Data.Items;
using Sitecore.Diagnostics;
using Sitecore.Resources.Media;
using Sitecore.Sites;

namespace Sitecore.Sandbox.Pipelines.DownloadImageToMediaLibrary
{
    public class UploadImageToMediaLibrary : DownloadImageToMediaLibraryProcessor
    {
        private string Site { get; set; }

        protected override bool CanProcess(DownloadImageToMediaLibraryArgs args)
        {
            Assert.IsNotNullOrEmpty(Site, "Site must be set in configuration!");
            return !string.IsNullOrWhiteSpace(args.MediaLibaryFolderPath)
                && !string.IsNullOrWhiteSpace(args.ImageItemName)
                && !string.IsNullOrWhiteSpace(args.ImageFilePath)
                && args.Database != null;
        }

        protected override void Execute(DownloadImageToMediaLibraryArgs args)
        {
            MediaCreatorOptions options = new MediaCreatorOptions
            {
                Destination = GetMediaLibraryDestinationPath(args),
                FileBased = args.FileBased,
                IncludeExtensionInItemName = args.IncludeExtensionInItemName,
                OverwriteExisting = args.OverwriteExisting,
                Versioned = args.Versioned,
                Database = args.Database
            };

            MediaCreator creator = new MediaCreator();
            MediaItem mediaItem;
            using (SiteContextSwitcher switcher = new SiteContextSwitcher(GetSiteContext()))
            {
                using (FileStream fileStream = File.OpenRead(args.ImageFilePath))
                {
                    mediaItem = creator.CreateFromStream(fileStream, args.ImageFilePath, options);
                }
            }

            if (mediaItem == null)
            {
                AbortPipeline(args);
                return;
            }

            args.MediaId = mediaItem.ID.ToString();
            args.MediaPath = mediaItem.MediaPath;
        }

        protected virtual SiteContext GetSiteContext()
        {
            SiteContext siteContext = SiteContextFactory.GetSiteContext(Site);
            Assert.IsNotNull(siteContext, string.Format("The site: {0} does not exist!", Site));
            return siteContext;
        }

        protected virtual string GetMediaLibraryDestinationPath(DownloadImageToMediaLibraryArgs args)
        {
            return string.Format("{0}/{1}", args.MediaLibaryFolderPath, args.ImageItemName);
        }
    }
}

The processor instance of the class above will only run when we have a Media Library folder location; an Item name for the image; a file system path for the image; and a Database to upload the image to. I also ensure a “site” is supplied via configuration so that I can switch the site context — when using the default of “shell”, I was being brought to the image Item in the Media Library after it was uploaded which was causing the image not to be set on the custom Image field on the Item.

If everything checks out, we upload the image to the Media Library in the specified location.

The next class serves as the last processor of the custom pipeline. This processor just deletes the image from the file system (why keep it around since we are done with it?):

using Sitecore.IO;

namespace Sitecore.Sandbox.Pipelines.DownloadImageToMediaLibrary
{
    public class DeleteImageFromFileSystem : DownloadImageToMediaLibraryProcessor
    {
        protected override bool CanProcess(DownloadImageToMediaLibraryArgs args)
        {
            return !string.IsNullOrWhiteSpace(args.ImageFilePath)
                && FileUtil.FileExists(args.ImageFilePath);
        }

        protected override void Execute(DownloadImageToMediaLibraryArgs args)
        {
            FileUtil.Delete(args.ImageFilePath);
        }
    }
}

The processor instance of the class above can only delete the image if its path is supplied and the file exists.

If all checks out, the image is deleted.

The next class is the class that serves as the custom Image field:

using System;
using System.Net;

using Sitecore.Data.Items;
using Sitecore.Diagnostics;
using Sitecore.Pipelines;
using Sitecore.Shell.Framework;
using Sitecore.Web.UI.Sheer;

using Sitecore.Sandbox.Pipelines.DownloadImageToMediaLibrary;

namespace Sitecore.Sandbox.Shell.Applications.ContentEditor
{
    public class Image : Sitecore.Shell.Applications.ContentEditor.Image
    {
        public Image()
            : base()
        {
        }

        public override void HandleMessage(Message message)
        {
            Assert.ArgumentNotNull(message, "message");
            if (string.Equals(message.Name, "contentimage:download", StringComparison.CurrentCultureIgnoreCase))
            {
                GetInputFromUser();
                return;
            }

            base.HandleMessage(message);
        }

        protected void GetInputFromUser()
        {
            RunProcessor("GetImageUrl", new ClientPipelineArgs());
        }

        protected virtual void GetImageUrl(ClientPipelineArgs args)
        {
            if (!args.IsPostBack)
            {
                SheerResponse.Input("Enter the url of the image to download:", string.Empty);
                args.WaitForPostBack();
            }
            else if (args.HasResult && IsValidUrl(args.Result))
            {
                args.Parameters["imageUrl"] = args.Result;
                args.IsPostBack = false;
                RunProcessor("ChooseMediaLibraryFolder", args);
            }
            else
            {
                CancelOperation(args);
            }
        }

        protected virtual bool IsValidUrl(string url)
        {
            if (string.IsNullOrWhiteSpace(url))
            {
                return false;
            }

            try
            {
                HttpWebRequest request = (HttpWebRequest)HttpWebRequest.Create(url);
                request.Method = "HEAD";
                request.GetResponse();
            }
            catch (Exception ex)
            {
                SheerResponse.Alert("The specified url is not valid. Please try again.");
                return false;
            }

            return true;
        }

        protected virtual void RunProcessor(string processor, ClientPipelineArgs args)
        {
            Assert.ArgumentNotNullOrEmpty(processor, "processor");
            Sitecore.Context.ClientPage.Start(this, processor, args);
        }

        public void ChooseMediaLibraryFolder(ClientPipelineArgs args)
        {
            if (!args.IsPostBack)
            {
                Dialogs.BrowseItem
                (
                    "Select A Media Library Folder",
                    "Please select a media library folder to store this image.",
                    "Applications/32x32/folder_into.png",
                    "OK",
                    "/sitecore/media library",
                    string.Empty
                );

                args.WaitForPostBack();
            }
            else if (args.HasResult)
            {
                Item folder = Client.ContentDatabase.Items[args.Result];
                args.Parameters["mediaLibaryFolderPath"] = folder.Paths.FullPath;
                RunProcessor("DownloadImage", args);
            }
            else
            {
                CancelOperation(args);
            }
        }

        protected virtual void DownloadImage(ClientPipelineArgs args)
        {
            DownloadImageToMediaLibraryArgs downloadArgs = new DownloadImageToMediaLibraryArgs
            {
                Database = Client.ContentDatabase,
                ImageUrl = args.Parameters["imageUrl"],
                MediaLibaryFolderPath = args.Parameters["mediaLibaryFolderPath"]
            };

            CorePipeline.Run("downloadImageToMediaLibrary", downloadArgs);
            SetMediaItemInField(downloadArgs);
        }

        protected virtual void SetMediaItemInField(DownloadImageToMediaLibraryArgs args)
        {
            Assert.ArgumentNotNull(args, "args");
            if(string.IsNullOrWhiteSpace(args.MediaId) || string.IsNullOrWhiteSpace(args.MediaPath))
            {
                return;
            }

            XmlValue.SetAttribute("mediaid", args.MediaId);
            Value = args.MediaPath;
            Update();
            SetModified();
        }

        protected virtual void CancelOperation(ClientPipelineArgs args)
        {
            Assert.ArgumentNotNull(args, "args");
            args.AbortPipeline();
        }
    }
}

The class above subclasses the Sitecore.Shell.Applications.ContentEditor.Image class — this lives in Sitecore.Kernel.dll — which is the “out of the box” Content Editor Image field. The Sitecore.Shell.Applications.ContentEditor.Image class provides hooks that we can override in order to augment functionality which I am doing above.

The magic of this class starts in the HandleMessage method — I intercept the message for a Menu item option that I define below for downloading an image from a URL.

If we are to download an image from a URL, we first prompt the user for a URL via the GetImageUrl method using a Sheer UI api call (note: I am running these methods as one-off client pipeline processors as this is the only way you can get Sheer UI to run properly).

If we have a valid URL, we then prompt the user for a Media Library location via another Sheer UI dialog (this is seen in the ChooseMediaLibraryFolder method).

If the user chooses a location in the Media Library, we then call the DownloadImage method as a client pipeline processor — I had to do this since I was seeing some weird behavior on when the image was being saved into the Media Library — which invokes the custom pipeline for downloading the image to the file system; uploading it into the Media Library; and then removing it from disk.

I then duct-taped everything together using the following patch include configuration file:

<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/">
  <sitecore>
    <controlSources>
      <source mode="on" namespace="Sitecore.Sandbox.Shell.Applications.ContentEditor" assembly="Sitecore.Sandbox" prefix="sandbox-content"/>
    </controlSources>
    <overrideDialogs>
      <override dialogUrl="/sitecore/shell/Applications/Item%20browser.aspx" with="/sitecore/client/applications/dialogs/InsertSitecoreItemViaTreeDialog">
        <patch:delete/>
      </override>
    </overrideDialogs>
    <pipelines>
      <downloadImageToMediaLibrary>
        <processor type="Sitecore.Sandbox.Pipelines.DownloadImageToMediaLibrary.SetProperties, Sitecore.Sandbox">
          <UploadDirectory>/upload</UploadDirectory>
        </processor>
        <processor type="Sitecore.Sandbox.Pipelines.DownloadImageToMediaLibrary.DownloadImage, Sitecore.Sandbox" />
        <processor type="Sitecore.Sandbox.Pipelines.DownloadImageToMediaLibrary.UploadImageToMediaLibrary, Sitecore.Sandbox">
          <Site>website</Site>
        </processor>
        <processor type="Sitecore.Sandbox.Pipelines.DownloadImageToMediaLibrary.DeleteImageFromFileSystem, Sitecore.Sandbox" />
      </downloadImageToMediaLibrary>
    </pipelines>
  </sitecore>
</configuration>

One thing to note in the above file: I’ve disabled the SPEAK dialog for the Item Browser — you can see this in the <overrideDialogs> xml element — as I wasn’t able to set messaging text on it but could do so using the older Sheer UI dialog.

Now that all code is in place, we need to tell Sitecore that we have a new Image field. I do so by defining it in the Core database:

external-image-core-1

We also need a new Menu item for the “Download Image” link:

external-image-core-2

Let’s take this for a spin!

I added a new field using the custom Image field type to my Sample item template:

template-new-field-external-image

As you can see, we have this new Image field on my “out of the box” home item. Let’s click the “Download Image” link:

home-external-image-1

I was then prompted with a dialog to supply an image URL. I pasted one I found on the internet:

home-external-image-2

After clicking “OK”, I was prompted with another dialog to choose a Media Library location for storing the image. I chose some random folder:

home-external-image-3

After clicking “OK” on that dialog, the image was magically downloaded from the internet; uploaded into the Media Library; and set in the custom Image field on my home item:

home-external-image-4

If you have any comments, thoughts or suggestions on this, please drop a comment.

Addendum:
It’s not a good idea to use the /upload directory for temporarily storing download images — see this post for more details.

If you decide to use this solution — by the way, use this solution at your own risk πŸ˜‰ — you will have to change the /upload directory in the patch include configuration file above.
